Lutron Electronics DW-6063 User manual

99.99 W x 0.01 W, 520.0 W x 0.1 W
Power factor, ACV, ACA
WATT METER
Model : DW-6063
Y
our purchase of this
WATT METER marks a
step forward for you
into the field o
f
precision measurement.
A
lthough this METER is
a complex and delicate
instrument, its durable
structure will allow
many years of use i
f
proper operating
techniques are
developed. Please read
the following
instructions carefully
and always keep this
manual within easy
reach.
OPERATION MANUAL

Caution Symbol
Caution :
* Risk of electric shock !
Caution :
* Do not apply the overload
voltage, current to the input
terminal !
* Remove test leads before open
the battery cover !
* Cleaning - Only use the dry
cloth to clean the plastic case !
Environment Conditions
* Installation Categories III-260V.
* Pollution Degree 2.
* Altitude up to 2000 meters.
* Indoor use.
* Relative humidity 80% max.

TABLE OF CONTENTS
1. FEATURES..................................................................1
2. SPECIFICATIONS........................................................1
2-1 General specifications............................................1
2-2 Electrical specifications..........................................3
3. FRONT PANEL DESCRIPTION......................................
.
4
3-1 Display................................................................. 4
3-2 POWER/Backlight button.......................................
.
4
3-3 FUNCTION button................................................. 4
3-4 HOLD button........................................................
.
4
3-5 RECORD button ( MAX. / MIN. ).............................4
3-6 LOAD terminal......................................................
.
4
3-7 POWER SOURCE terminal......................................
.
4
3-8 RS-232 output terminal.........................................
.
4
3-9 DC 9V Power Adapter input socket......................... 4
3-10 Battery Cover / Compartment..............................
.
4
3-11 Stand.................................................................
.
4
4. MEASUREING PROCEDURES........................................5
4-1 Power ON/OFF......................................................5
4-2 ACV measurement procedure.................................5
4-3 ACA measurement procedure.................................5
4-4 Watt measurement procedure................................6
4-5 Data Hold............................................................. 6
4-6 Data Record ( Max., Min. reading ).........................6
4-7 Backlight ON/OFF.................................................7
4-8 Auto power management......................................
.
7
5. MAINTENANCE...........................................................8
6. RS232 PC SERIAL INTERFACE.....................................
.
8
7. BATTERY REPLACEMENT.............................................10
8.THE ADDRESS OF AFTER SERVICE CENTER..................
.
10

1. FEATURES
* 0.01 W resolution, precision Watt meter is special for
low power measurement.
* Designed for the high resolution low power measurement.
* LSI - circuit provides high reliability and durability.
* Directly operation.
*Measurement:
WATT ( AC ) : 99.99 W x 0.01 W, 520 W x 0.1 W
ACV : 260V x 0.1 V.
ACA : 2 A x 1 mA / 1 A x 0.1 mA.
PF : 1.00 x 0.01
* True Power and Wide range 0 W to 520 Watt.
* True RMS measurement of ACV / ACA.
* Super large LCD , Dual display at same time.
* Full function Auto range.
* Memory Record ( Max. , Min. ) , Data Hold.
* RS232 / USB Computer interface.
* Built-in low battery indicator.
* Built - in backlight easy to readout.
* Power : DC 9V ( 006P ) or AC to DC 9V adapter in.
2. SPECIFICATIONS
2-1 General Specifications
Circuit Custom one-chip of microprocessor LSI
circuit.
Display Large LCD display max. reading 9999.
Digit size : 21.8 x 8.5 mm.
Dual value display with backlight
Measurement ACV 0.1 to 260.0 V
Unit ACA 0.1 mA to 2000 mA.
WATT 0.01 W to 520.0 W
PF 0.01 to 1.00
1

Over input " ---- " mark indication .
Zero Automatic adjustment
Sampling Time Approx. 1 second .
Data Hold Freeze the display reading .
Memory Recall Maximum & Minimum value .
Data output RS232 / USB PC Computer interface.
* Connect the optional RS232 cable
UPCB - 02 will get the RS232 plug.
* Connect the optional USB cable
USB - 01 will get the USB plug.
Operation 0 to 50 ( 32 to 122 ).℃℃℉ ℉
Temperature
Operation Less than 80% RH
Humidity
Power Supply Alkaline or Heavy duty type DC 9V battery
006P , MN1604 (PP3) or equivalent.
Power Approx. DC 10 mA
Consumption
Weight 398 g/0.88 LB
Dimension 190 x 88 x 40 mm ( 7.5 x 3.5 x 1.6 inch ).
Accessories Instruction manual....................1 PC
Included Test lead (Red & Black).............1 Pair
Optional AC to DC 9V adapter
Accessories USB cable , USB - 01
RS232 cable , UPCB - 02
Data Acquisition software, SW-U801-WIN
Excel Data Acquisition software, SW-E802
2

2-2 Electrical Specifications (23±5 )℃
WATT ( TRUE POWER )
Range Resolution Accuracy
520 W 0.1 W ± ( 1% + 0.5 W )
0 to 99.99 W 0.01 W
* Auto range.
* Measuring Signal come from the front LOAD plug terminals.
* Accuracy is test under input signal is sine wave , 50 / 60 Hz.
* ACV ACA frequency response is from 40 to 400 Hz.
* Max. input value, AC voltage : 260V, AC current : 2 A.
* Accuracy @ 23 ± 5 .℃℃
V/A ( TRUE RMS )
Range Resolution Accuracy
ACV 260 V 0.1 V ± ( 0.3 % + 0.3 V )
ACA 1 A 0.1 mA ± ( 0.3 % + 0.3 mA )
ACA 2 A 1 mA ± ( 0.3 % + 3 mA )
* Auto range.
* ACV, ACA accuracy is test under input signal is sine wave,
50/ 60 Hz.
* ACV ACA frequency response is from 40 to 400 Hz.
* Max. input value, AC voltage : 260V, AC current : 2 A.
* Accuracy @ 23 ± 5 .℃℃
PF ( Power factor )
Range Resolution Accuracy
1.00 0.01 ± ( 1 %+ 2d )
* ACV, ACA accuracy is test under input signal is sine wave,
50/ 60 Hz
* ACV ACA frequency response is from 40 to 400 Hz.
* Max. input value, AC voltage : 260V, AC current : 2 A.
* Accuracy is available when the measuring power > 1 W.
* Accuracy @ 23 ± 5 .℃℃
@
Above specification tests under the environment RF Field Stren
g
t
h
less than 3 V/M & frequency less than 30 MHz only.
3

3. FRONT PANEL DESCRIPTION
Fig. 1
3-1 Display
3-2 POWER / Backlight button
3-3 FUNCTION button
3-4 HOLD button
3-5 RECORD button ( MAX. / MIN. )
3-6 LOAD terminal
3-7 POWER SOURCE terminal
3-8 RS-232 output terminal
3-9 DC 9V Power Adapter input socket
3-10 Battery Cover / Compartment
3-11 STAND
4

4. MEASURING PROCEDURE
4-1 Power ON/OFF
1)Press the POWER button ( 3-2, Fig. 1 ) more than 1.5
sec to Turn ON the meter.
2)Press the POWER button ( 3-2, Fig. 1 ) more than 1.5
sec to Turn OFF themeter.
4-2 ACV measurement procedure
1)Press the POWER button ( 3-2, Fig.1 ) more than 1.5
sec to Turn ON the meter.
2)Push the FUNCTION button ( 3-3, Fig. 1 ) once then
change function for measuring ACV.
3)Connect Red test lead to the " V " input terminal and
Black test lead to " COM " input terminal .
4)Then use the test lead measurement unknown AC voltage.
5)Read the up display . The value indicated corresponds
to the position selected. If the Display shows " ---- "
it indicates an Out-of-range measurement.
4-3 ACA measurement procedure
1)Press the POWER button ( 3-2, Fig.1 ) more than 1.5
sec to Turn ON the meter.
2)Push the FUNCTION button ( 3-3, Fig. 1 ) once then
change function for measuring ACA
3)Connect red test lead to the " 2 A " input terminal and
black test lead to "COM" input terminal .
4)Then use the test lead measurement unknown AC current.
5)Read the down display . The value indicated
corresponds to the position selected. If the display
shows "---- " it indicates an Out-of-range measurement.
5

4-4 Watt measurement procedure
1)Press the POWER button ( 3-2, Fig. 1 ) more than 1.5
sec to Turn ON the meter.
2)Make sure your equipment work voltage, such as 110 V
or 220 V.
3)Turn off the POWER SOURCE.
4)Plug in the LOAD ( equipment ) to V terminal and COM
terminal.
5)Plug in the power source to WATT terminal and 2 A
terminal.
6)Push the FUNCTION ( 3-3, Fig. 1 ) button once then
change function for measuring ACV / ACA
7)Turn on the POWER SOURCE,
then you can read out the WORK VOLTAGE from the
top of the LCD display value.
8)Turn on the equipment power switch. Let it work,
then you can read out the POWER CONSUMPTION
from the bottom of the LCD display value
9)At the same time. Push the FUNCTION button ( 3-3, Fig.
1 ) once then change function for measuring WATT / PF
10) Now you can take the Active Power value and Power
Factor value from the LCD display .
4-5 Data Hold
During the measurement, press the " Hold Button " ( 3-4,
Fig. 1 ) once will hold the measured value & the LCD will
display a " HOLD " symbol.
Press the " Hold Button " once again will release the data
hold function.
4-6 Data Record ( Max., Min. reading )
1)The data record function records the maximum and
minimum readings. Press the " REC Button " ( 3-5, Fig.
1 ) once to start the Data Record function and there
will be a " REC. " symbol on the display.
6

2)With the " REC. " symbol on the display :
a)Press the " REC Button " ( 3-5, Fig. 1 ) once, the "
REC. MAX. " symbol along with the maximum value
will appear on the display.
If intend to delete the maximum value, just press
the " Hold Button " ( 3-4, Fig. 1 ) once, then the
display will show the " REC. " symbol only & execute
the memory function continuously.
b)Press the " REC Button " ( 3-5, Fig. 1 ) again, the
" REC. MIN. " symbol along with the minimum value
will appear on the display.
If intend to delete the minimum value, just press
the " Hold Button " ( 3-4, Fig. 1 ) once, then
the display will show the " REC. " symbol only &
execute the memory function continuously.
c)To exit the memory record function, just press the
" REC " button for 2 seconds at least. The display will
revert to the current reading.
4-7 Backlight ON/OFF
1)When use the instrument in a dark place or under the SUN .
You can turn ON the Backlight for easy readout.
2)If the instrument is working. Press the POWER button
( 3-2, Fig. 1 ) once, can turn ON the Backlight.
3)Press the button again will turn OFF the Backlight .
4-8 Auto power management
1)The instrument has built-in "Auto Power Shut-off"
in order to prolong battery life. The meter will switch
off automatically if none of the buttons are pressed
within 10 min.
2)To de-activate this feature, Select the memory record
function during measurement, by pressing the
" Record button " ( 3-5, Fig. 1 ).
7

5. MAINTENANCE
1)This WATT METER is intended for measuring the TURE
RMS POWER CONSUMPTION. At the same , It can let
you know .how many effect from your equipment.
2)When measuring POWER CONSUMPTION. Equipment
working voltage must be recheck again, before turn on
the equipment power switch.
3)Instruments used in dusty environments should be
stripped and cleaned periodically.
4)Do not leave the instrument exposed to direct heat from
the sun for long periods.
5)Before removing the battery compartment cover, ensure
that the instrument is disconnect from any circuit and
the power switch is on the OFF position.
6. RS232 PC SERIAL INTERFACE
The instrument has RS232 PC serial interface via a 3.5
mm terminal ( 3-8, Fig. 1 ).
The data output is a 16 digit stream which can be
utilized for user's specific application.
A RS232 lead with the following connection will be
required to link the instrument with the PC serial port.
8

Meter PC
(9W 'D" Connector)
Center Pin.........................
.
Pin 4
(3.5 mm jack plug)
Ground/shield......................
.
Pin 2 2.2 K
resistor
Pin 5
The 16 digits data stream will be displayed in the
following format :
D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0
Each digit indicates the following status :
D0 End Word
D1 & D8 Display reading, D1 = LSD, D8 = MSD
For example :
If the display reading is 1234, then D8 to
D1 is : 00001234
D9 Decimal Point(DP), position from right to the
left
0 = No DP, 1= 1 DP, 2 = 2 DP, 3 = 3 DP
D10 Polarity
0 = Positive 1 = Negative
D11 & D12 Annunciator for Display
ACV = 50 W = 47 mA = 53
PF = 54
D13 When send the upper display data = 1
When send the lower display data = 2
D14 4
D15 Start Word
9

RS232 FORMAT : 9600, N, 8, 1
Baud rate 9600
Parity No parity
Data bit no. 8 Data bits
Stop bit 1 Stop bit
7. BATTERY REPLACEMENT
1)When the Top of left corner on LCD display show " " ,
it is necessary to replace the battery , However in -spec.
measurement may still be made for several hours after
LOW BATTERY INDICATOR appears before the
instrument become inaccurate.
2)Open the screw of " Battery Cover " by screwdriver,
then move the battery.
3)Replace with 9V battery and reinstate the cover.
8. THE ADDRES OF AFTER CENTER
10 1111-DW6063
