Lutz-Jesco MEMDOS SMART LD User manual

Dosing
Conveying
Control
Liquids
Gases
Systems
Original operating instructions
© Lutz-Jesco GmbH 2015
BA-10102-02-V02
Stepper motor-driven diaphragm dosing pump
MEMDOS SMART LD
Operating Instructions
Read the operating instructions!
The user is responsible for installation and operation related mistakes!

Table of Contents 3
© Lutz-Jesco GmbH 2015
Subject to technical changes.
150302
BA-10102-02-V02
Stepper motor-driven diaphragm dosing pump MEMDOS SMART LD Operating Instructions
Table of Contents
1 Notes to the Reader............................................................4
1.1 General non-discrimination......................................................4
1.2 Explanation of the signal words ................................................4
1.3 Explanation of the warning signs ..............................................4
1.4 Identification of warnings.........................................................4
1.5 Identification of instructions for action ......................................4
2 Safety .................................................................................5
2.1 General warnings.....................................................................5
2.2 Hazards due to non-compliance with the safety instructions .....6
2.3 Working in a safety-conscious manner .....................................6
2.4 Personal protective equipment.................................................6
2.5 Personnel qualification.............................................................6
3 Appropriate and Intended Use........................................... 7
3.1 Notes on Product warranty .......................................................7
3.2 Intended purpose.....................................................................7
3.3 Device revision ........................................................................7
3.4 Principles ................................................................................7
3.5 Prohibited dosing media...........................................................7
3.6 Foreseeable misuse.................................................................7
4 Product description ...........................................................9
4.1 Properties................................................................................9
4.2 Scope of delivery .....................................................................9
4.3 Structure of the dosing pump ...................................................9
4.4 Function description ..............................................................10
4.5 Rating plate (type label)..........................................................10
4.6 Conveying characteristics ......................................................11
5 Technical specifications ..................................................12
5.1 Delivery capacity data............................................................12
5.2 Operating conditions and limits ..............................................12
5.3 Electrical data........................................................................13
5.4 Other data .............................................................................13
6 Dimensions ......................................................................14
6.1 MEMDOS SMART LD 2, 5, 10..................................................14
6.2 MEMDOS SMART LD 15, 20....................................................15
7 Installing the Dosing Pump.............................................. 16
7.1 Set up information .................................................................16
7.2 Installation examples .............................................................16
8 Hydraulic installations..................................................... 17
8.1 Design of the system..............................................................17
8.2 System piping........................................................................18
8.3 Aligning the dosing head ........................................................18
8.4 Hydraulic connections............................................................18
8.5 Connecting a leakage drain....................................................20
8.6 Connecting the dosing head venting facility ............................20
8.7 Hydraulic accessories ............................................................21
9 Electrical installation.......................................................28
9.1 Principles ..............................................................................28
9.2 Description of connection sockets ..........................................29
10 Control..............................................................................31
10.1 Operator controls of the control unit......................................31
10.2 Explanation of the menu icons..............................................31
10.3 Password protection ............................................................31
11 Operation..........................................................................33
11.1 Commissioning the dosing pump..........................................33
11.2 Operating modes .................................................................34
11.3 External On / Off via Release input ........................................37
11.4 Decommissioning the dosing pump......................................37
11.5 Shutting down in an emergency ...........................................37
11.6 Storage ...............................................................................37
11.7 Transportation......................................................................37
11.8 Disposal of old equipment....................................................37
12 Maintenance ....................................................................38
12.1 Maintenance intervals..........................................................38
12.2 Tighten up dosing head bolts................................................39
12.3 Change the diaphragm.........................................................39
12.4 Clean suction and discharge valves ......................................39
13 Troubleshooting ...............................................................40
13.1 Type of fault .........................................................................40
14 Spare parts.......................................................................43
14.1 Diaphragm spare parts kits ..................................................43
14.2 Dosing head spare parts kits including valves.......................43
15 Delivery characteristic curves.........................................44
16 EC declaration of conformity ...........................................45
17 Declaration of no objection..............................................46
18 Warranty claim.................................................................48
Notes ......................................................................................49
Index ......................................................................................50

Notes to the Reader
General non-discrimination
4© Lutz-Jesco GmbH 2015
BA-10102-02-V02
Stepper motor-driven diaphragm dosing pump MEMDOS SMART LD Operating Instructions
1 Notes to the Reader
These Operating instructions contain information and behaviour rules for
safe and designated operation of the dosing pump MEMDOS SMART LD.
Observe the following principles:
nread the entire operating manual prior to starting-up the device.
nEnsure that everyone who works with or on the dosing pump has read
the operating instructions and follows them.
nKeep the operating instructions for the entire service life of the dosing
pump.
nPass on the operating instructions to any subsequent owner of the
dosing pump.
1.1 General non-discrimination
In these operating instructions, only the male gender is used where
grammar allows gender allocation. The purpose of this is to make the text
easy to read. Men and women are always referred to equally. We would
like to ask female readers for understanding of this text simplification.
1.2 Explanation of the signal words
Different signal words in combination with warning signs are used in
these operating instructions. Signal words illustrate the gravity of
possible injuries if the risk is ignored:
Signal word Meaning
DANGER! Refers to imminent danger. Ignoring this sign may
lead to death or the most serious injuries.
WARNING Refers to a potentially hazardous situation.
Failure to follow this instruction may lead to death
or severe injuries.
CAUTION Refers to a potentially hazardous situation.
Failure to follow this instruction may lead to
minor injury or damage to property.
Note Refers to a danger which, if ignored, may lead to
risk to the machine and its function.
Table 1: Explanation of the signal words
1.3 Explanation of the warning signs
Warning signs represent the type and source of a danger:
Warning sign Type of danger
General danger zone
Danger of electric shock
Danger of caustic or other burns
Danger of explosions
Danger of automatic start up
Danger of damage to machine or functional
influences
Table 2: Explanation of the warning signs
1.4 Identification of warnings
Warnings are intended to help you recognise risks and avoid negative
consequences.
This is how warnings are identified:
Warning sign SIGNAL WORD
Description of danger.
Consequences if ignored.
ðThe arrow signals a safety precaution to be taken to eliminate
the danger.
1.5 Identification of instructions for action
This is how pre-conditions for action are identified:
üPre-condition for action which must be met before taking action.
This is how instructions for action are identified:
èSeparate step with no follow-up action.
1. First step in a series of steps.
2. Second step in a series of steps.
4Result of the above action.
üAction completed, aim achieved.

Safety
General warnings 5
© Lutz-Jesco GmbH 2015
Subject to technical changes.
150302
BA-10102-02-V02
Stepper motor-driven diaphragm dosing pump MEMDOS SMART LD Operating Instructions
2 Safety
2.1 General warnings
The following warnings are intended to help you to eliminate the dangers
that can arise while handling the dosing pump. Risk prevention measures
always apply regardless of any specific action.
Safety instructions warning against risks arising from specific activities
or situations can be found in the respective sub-chapters.
DANGER!
Mortal danger from electric shock!
Wrongly connected or located cables or damaged ones can injure you.
ðConnect the device only to a socket outlet with earthing contact
protected by a ground fault circuit interrupter (GFCI).
ðReplace damaged cables without delay.
ðDo not use extension cables.
ðDo not bury cables.
ðSecure cables to avoid being damaged by other equipment.
DANGER!
Danger to life through explosions!
When using dosing pumps without ATEX certification in a potentially
explosive area, explosions can occur that result in fatal injuries.
ðNever use the dosing pump MEMDOS SMART LD in potentially
explosive areas.
WARNING
Caustic burns or other burns through dosing media!
After connecting the mains supply, residual dosing media in the
dosing head can spray out.
ðBefore connecting the mains supply, connect the dosing lines.
ðCheck that all the screw connections have been tightened
correctly and are leak-proof.
WARNING
Caustic burns or other burns through dosing media!
While working on the dosing head, valves and connections, you may
come into contact with dosing media.
ðUse sufficient personal protective equipment.
ðRinse the dosing pump with a liquid (e.g. water) which does not
pose any risk. Ensure that the liquid is compatible with the dosing
medium.
ðRelease pressure in hydraulic parts.
ðNever look into open ends of plugged pipelines and valves.
WARNING
Caustic burns or other burns through dosing media!
The materials of the dosing pump and hydraulic parts of the system
must be suitable for the dosing medium that is used. Should this not
be the case, the dosing media may leak.
ðMake sure that the materials you are using are suitable for the
dosing medium.
ðMake sure that the lubricants, adhesives, sealants, etc. that you
use are suitable for the dosing medium.
CAUTION
Increased risk of accidents due to insufficient qualifica-
tion of personnel!
Dosing pumps and their accessories may only be installed, operated
and maintained by personnel with sufficient qualifications. Insufficient
qualification will increase the risk of accidents.
ðEnsure that all action is taken only by personnel with sufficient and
corresponding qualifications.
ðPrevent access to the system for unauthorised persons.
CAUTION
Danger of personal injury and material damage!
Changing dosing media can lead to unpredictable reactions.
ðThoroughly clean the dosing pump and appropriate sections of the
plant avoid chemical reactions.

Safety
Hazards due to non-compliance with the safety instructions
6© Lutz-Jesco GmbH 2015
BA-10102-02-V02
Stepper motor-driven diaphragm dosing pump MEMDOS SMART LD Operating Instructions
2.2 Hazards due to non-compliance with the safety
instructions
Failure to follow the safety instructions may endanger not only persons,
but also the environment and the device.
The specific consequences can be:
nfailure of vital functions of the dosing pump and the system,
nfailure of required maintenance and repair methods,
ndanger for individuals through dangerous dosing media,
ndanger to the environment caused by substances leaking from the
system.
2.3 Working in a safety-conscious manner
Besides the safety instructions specified in these operating instructions,
further safety rules apply and must be followed:
naccident prevention regulations
nsafety and operating provisions,
nsafety provisions for handling dangerous substances (mostly the
safety data sheets to dosing media),
nenvironmental protection provisions,
napplicable standards and legislation.
2.4 Personal protective equipment
Based on the degree of risk posed by the dosing medium and the type of
work you are carrying out, you must use corresponding protective
equipment. Read the Accident Prevention Regulations and the Safety
Data Sheets to the dosing media find out what protective equipment you
need.
As a minimum, the following protective equipment is recommended:
Protective clothing Protective gloves Goggles
Corresponding protective equipment must be used during these tasks:
ncommissioning,
nworking on the dosing pump while running,
nshutdown,
nmaintenance work,
ndisposal.
2.5 Personnel qualification
Any personnel who work on the dosing pump must have appropriate
special knowledge and skills.
Anybody who works on the dosing pump must meet the conditions below:
nattendance at all the training courses offered by the owner,
npersonal suitability for the respective activity,
nsufficient qualification for the respective activity,
nTraining in handling of the dosing pump,
nknowledge of safety equipment and the way this equipment functions,
nknowledge of this operating manual, particularly of safety instructions
and sections relevant for the activity,
nknowledge of fundamental regulations regarding health and safety
and accident prevention.
All persons must generally have the following minimum qualification:
nTraining as specialists to carry out work on the dosing pump
unsupervised,
nSufficient training that they can work on the dosing pump under the
supervision and guidance of a trained specialist.
These operating instructions differentiate between these user groups:
2.5.1 Specialist staff
Specialist staff are able, thanks to their professional training, knowledge
and experience as well as knowledge of the respective provisions, to do
the job allocated to them and recognise and/or eliminate any possible
dangers by themselves.
2.5.2 Trained persons
Trained persons have received training from the operator about the tasks
they are to perform and about the dangers stemming from improper
behaviour.
In the table below you can check what qualifications are the pre-condi-
tion for the respective tasks. Only people with appropriate qualifications
are allowed to perform these tasks!
Qualification Activities
Specialist staff nAssembly
nHydraulic installations
nElectrical installation
nMaintenance
nRepairs
nCommissioning
nTaking out of operation
nDisposal
nFault rectification
Trained persons nStorage
nTransportation
nControl
nFault rectification
Table 3: Personnel qualification

Appropriate and Intended Use
Notes on Product warranty 7
© Lutz-Jesco GmbH 2015
Subject to technical changes.
150302
BA-10102-02-V02
Stepper motor-driven diaphragm dosing pump MEMDOS SMART LD Operating Instructions
3 Appropriate and Intended Use
3.1 Notes on Product warranty
Any non-designated use of the product can compromise its function or
intended protection. This leads to invalidation of any warranty claims!
Please note that liability is on the side of the user in the following cases:
nThe dosing pump is operated in a manner which is not consistent with
these operating instructions, particularly the safety and handling
instructions and the chapter 3 „Bestimmungsgemäße Verwendung“
auf Seite 7.
nIf people operate the product who are not adequately qualified to carry
out their respective activities,
nno original spare parts or accessories of Lutz-Jesco GmbH are used.
nUnauthorised changes are made to the device by the user,
nThe user uses different dosing media than those indicated in the
order,
nThe user does not use dosing media under the conditions agreed with
the manufacturer such as modified concentration, density, tempera-
ture, contamination, etc.
3.2 Intended purpose
The dosing pump MEMDOS SMART LD is intended for the following
purpose: the conveying and dosing of liquids.
3.3 Device revision
This operating instructions apply to the following devices:
Device Month / year of
manufacture
Firmware
MEMDOS SMART LD 03/2015 onwards From 01:49
Table 4: Device revision
3.4 Principles
nBefore delivery, the manufacturer inspected the dosing pump and
operated it under specific conditions (with a specific dosing medium
with a specific density and temperature, with specific pipe dimen-
sions, etc.) Since these conditions differ at every location of usage,
the delivery capacity of the dosing pump should be measured by
gauging it at the operating company's installation. For details on the
approximate values and the capacity of the dosing pump, refer to the
chapter 15 „Förderkennlinien“ auf Seite 44.
nComply with the information regarding the operating and environmen-
tal conditions (see chapter 5 „Technische Daten“ auf Seite 12).
nAny restrictions regarding the viscosity, temperature and density of
dosing media must be followed. You must only use dosing media at
temperatures above freezing point or below the boiling point of the
respective medium.
nThe materials of the dosing pump and hydraulic parts of the system
must be suitable for the dosing medium that is used. In this connec-
tion, note that the resistance of these components can change in
dependence on the temperature of the media and the operating
pressure.
i
Information on the suitability of materials combined with
different dosing media can be found in the Compatibility Chart
of Lutz-Jesco GmbH.
The information in this resistance list is based on information
from the material manufacturers and on expertise obtained by
Lutz-Jesco from handling the materials.
As the durability of the materials depends on many factors,
this list only constitutes initial guidance on selecting material.
In all cases, test the equipment with the chemicals you use
under operating conditions.
nThe dosing pump is not intended for outdoor use unless appropriate
protective measures have been taken.
nAvoid leaks of liquids and dust into the casing and avoid direct
exposure to sunlight.
nYou must never operate dosing pumps in a potentially explosive
atmosphere if they do not have corresponding nameplates or an
appropriate EC Declaration of Conformity for potentially explosive
atmospheres.
3.5 Prohibited dosing media
The dosing pump must not be used for these media and substances:
nGaseous media,
nradioactive media,
nsolid substances,
ncombustible media,
nall other media that are not suitable for delivery using this dosing
pump.
3.6 Foreseeable misuse
Below, there is information about the applications of the dosing pump or
associated equipment that are not considered to be intended use. This
chapter is intended to allow you to detect possible misuse in advance and
to avoid it.
Foreseeable misuse is assigned to the individual stages of the product
lifetime:
3.6.1 Incorrect assembly
nUnstable or unsuitable bracket
nDosing pump bolted wrongly or loosely

Appropriate and Intended Use
Foreseeable misuse
8© Lutz-Jesco GmbH 2015
BA-10102-02-V02
Stepper motor-driven diaphragm dosing pump MEMDOS SMART LD Operating Instructions
3.6.2 Incorrect hydraulic installation
nSuction and pressure lines dimensioned incorrectly
nUnsuitable connection of the pipes due to wrong material or
unsuitable connections.
nSuction and pressure lines mixed-up
nDamage to threads due to them being tightened too much
nBending of pipelines
nNo free return flow of the pressure relief valve
nExcessive demand due to the pressure differences between the
suction and discharge valves
nThrough-suction at installation without back-pressure valves
nDamage due to undamped acceleration mass forces
nExceeding the admissible pressure on the suction and discharge sides
nUsing damaged parts
3.6.3 Incorrect electrical installation
nConnecting the mains voltage without a protective earth
nUnsecured mains or one that does not conform to standards
nNot possible to immediately or easily disconnect the power supply
nWrong connecting cables for mains voltage
nDosing pump accessories connected to wrong sockets
nDiaphragm monitoring not connected or defective
nProtective earth removed
3.6.4 Incorrect commissioning
nCommissioning with damaged plant
nShut-off valves closed at commissioning
nClosed suction or pressure line, e.g. due to blockages
nPersonnel was not informed before commissioning
nSystem was recommissioned after maintenance without all the
protective equipment and fixtures, etc. being reconnected.
nInadequate protective clothing or none at all
3.6.5 Incorrect operation
nProtective equipment not functioning correctly or dismantled
nModification of the dosing pump without authority
nIgnoring operational disturbances
nElimination of operational disturbances by personnel without
adequate qualifications
nDeposits in the dosing head due to inadequate purging, particularly
with suspensions
nBridging the external fuse
nOperation made more difficult due to inadequate lighting or machines
that are difficult to access
nOperation not possible due to dirty or illegible display of the dosing
pump
nDelivery of dosing media for which the system is not designed
nDelivery of particulate or contaminated dosing media
nInadequate protective clothing or none at all
3.6.6 Incorrect maintenance
nCarrying out maintenance during ongoing operation
nCarrying out work that is not described in the operating instructions
nNo adequate or regular inspection of correct functioning
nNo replacement of damaged parts or cables with inadequate
insulation
nNo securing against reactivation during maintenance work
nUsing cleaning materials that can cause reactions with the dosing
media
nInadequate cleaning of the system
nUnsuitable purging medium
nUnsuitable cleaning materials
nCleaning materials left in system sections
nUsing unsuitable cleaning equipment
nUsing the wrong spares or lubricants
nContaminating the dosing medium with lubricant
nInstalling spares without following the instructions in the operating
manual
nBlocking venting orifices
nPulling off sections of the plant
nContamination at installation without a dirt trap
nMixing up the valves
nMixing up the sensor lines
nNot reconnecting all the lines
nDamaging or not installing all the seals
nNot renewing seals
nNot paying attention to safety data sheets
nInadequate protective clothing or none at all
3.6.7 Incorrect decommissioning
nNot completely removing the dosing medium
nDismantling lines while the dosing pump is running
nDevice not disconnected from the power supply
nUsing the wrong dismantling tools
nInadequate protective clothing or none at all
3.6.8 Incorrect disposal
nIncorrect disposal of dosing media, operating resources and other
materials
nNo labelling of hazardous substances

Product description
Properties 9
© Lutz-Jesco GmbH 2015
Subject to technical changes.
150302
BA-10102-02-V02
Stepper motor-driven diaphragm dosing pump MEMDOS SMART LD Operating Instructions
4 Product description
4.1 Properties
The MEMDOS SMART LD is a stepper motor-driven diaphragm dosing
pump that is used when precise dosing results are required.
They are characterized by the following properties:
nOutput range from 2 – 20 l/h, up to 15 bar
nPower supply 110—240 V, 50/60 Hz, IP65, 25 W
nMicroprocessor-controlled drive
nIntegrated dosing head ventilation (only MEMDOS SMART LD 5 and LD
10 with plastic dosing head)
nSuitable for wall and floor mounting
nMaterial finishes PVC, PP, PVDF and stainless steel
nStroke frequency can be precisely adjusted via the keyboard
nGraphic display
nPulse input (increase and reduction)
nLevel input with early warning and main alarm
nRelease input for external start/stop
nCalculation wizard for pulse operation available online
4.2 Scope of delivery
Please compare the delivery note with the scope of delivery.The
following items are part of the scope of delivery:
nDosing pump MEMDOS SMART LD,
nOne set each of hose clamping connections for the suction and
discharge sides for hoses with diameters of 4/6 mm, 6/9 mm and
6/12 mm (made of PVC, PP and PVDF),
n3 covering caps for electrical connections (mounted on the dosing
pump),
n2 conductive rubber bands for electrical contacts (installed in
connection sockets 1 and 3)
nMains cable,
nOperating instructions,
nInspection report and test certificate (optional),
nAccessory kit (optional).
4.3 Structure of the dosing pump
4.3.1 General Overview
a
b
c
Fig. 1: Dosing pump overview MEMDOS SMART LD
No. Description
aDosing head
bDrive unit
cControl
4.3.2 Dosing head
a
c
d
b
Fig. 2: Dosing head
No. Description
aValve and connection on the discharge side
bintegrated dosing head venting facility (plastic version only)
cArrow indicating the direction of throughflow of the dosing
medium (plastic version only)
dValve and connection on the suction side

Product description
Function description
10 © Lutz-Jesco GmbH 2015
BA-10102-02-V02
Stepper motor-driven diaphragm dosing pump MEMDOS SMART LD Operating Instructions
4.3.3 Control elements
a
b
d
c
Fig. 3: Controller of dosing pump MEMDOS SMART LD
No. Description
aGraphic display
bMultifunction keys on the contol unit for operator inputs
cConnection sockets for external operation or connecting
accessories
dMains cable for power supply
Table 5: Designation of components
4.4 Function description
Dosing pumps are positive displacement pumps. They are used if
precisely defined delivery of a medium is necessary.A constant volume
per stroke or time is delivered.
The system delivers or meters the dosing medium by means of a
repeated sequence of suction strokes followed by pressure strokes. This
results in a pulsing flow.
If the dosing pump is in the suction stroke phase, the diaphragm is pulled
into the rear final position. Due to the resulting vacuum in the dosing
head, the discharge valve closes, the suction valve opens and dosing
medium flows from the suction line into the dosing head.
If the dosing pump is in the pressure stroke phase, the diaphragm is
moved into the front final position. Due to the pressure in the dosing head,
the suction valve closes and the dosing medium flows through the
discharge valve from the dosing head into the pressurised pipe.
4.5 Rating plate (type label)
There is information on the equipment about safety or the product's way
of functioning. The information must stay legible for the duration of the
service life of the product.
Fig. 4:
Material:
Max. XXX l/h bei X bar
Max. XXX l/h bei X bar
IP XX, XXX V, XXXX Hz, XX W
Lutz-Jesco GmbH
30900 Wedemark Germany
XX/XXXX
S/N: XXXXXXXXXXP/N:
Made in Germany
*102A12345678*
*12345678012345*
MEMDOS SMART LD
a
b
c
d
e
Rating plate MEMDOS SMART LD
No. Description
aProduct, type, nominal size
bPart number
cType of material of dosing head/ type of material of seals
dMaximum delivery capacity at average pressure
eMaximum delivery capacity at maximum pressure
fProtection classification
gVoltage supply
hFrequency
iPower consumption
jWEEE label
kLabel showing conformity with applicable European directives
lMonth / year of manufacture
mSerial number
Table 6: Rating plate
f g h i
j
k
l
m

Product description
Conveying characteristics 11
© Lutz-Jesco GmbH 2015
Subject to technical changes.
150302
BA-10102-02-V02
Stepper motor-driven diaphragm dosing pump MEMDOS SMART LD Operating Instructions
4.6 Conveying characteristics
The design of the dosing pump MEMDOS SMART LD enables it to perform the pressure and suction stroke at different speeds. For low supply rates, for
example, the dosing pump performs the suction stroke at the maximum speed and adjusts the speed of the pressure stroke to match the desired supply
rate. This produces a constant supply stream, which gives you a low-pulsation, smooth dosing.
Settings
100 % delivery rate Time
50 % delivery rate Time
10 % delivery rate Time
Pressure stroke
Suction stroke
Fig. 5: Selection of available dosing programs

Technical specifications
Delivery capacity data
12 © Lutz-Jesco GmbH 2015
BA-10102-02-V02
Stepper motor-driven diaphragm dosing pump MEMDOS SMART LD Operating Instructions
5 Technical specifications
5.1 Delivery capacity data
Please note that some of this data only represents guide values. The actual capacity of a dosing pump depends on various factors. For approximate
values of the delivery capacity at different pressures, refer to chapter 15 „Delivery characteristic curves“ (see page 46).
Information Value
MEMDOS SMART LD Size
2 5 10 15 20
Delivery capacity at max. back pressure
l/h 2,4 5.3 10.8 14.2 19.2
ml/stroke 0,22**** 0.59 1.20 1.58 2.13
Max. back pressure bar 20 15 9 5 4
Delivery capacity at average back pressure
l/h 2,6 6 11.3 14.7 19.7
ml/stroke 0,28 0.67 1.26 1.63 2.19
Average back pressure bar 10 8 5 3 2
Max. stroke frequency RPM 150
Suction height for non-gassing media mWS 3
Table 7: Output data
5.2 Operating conditions and limits
Information Value
MEMDOS SMART LD Size
2 – 20
Approved ambient temperature °C 5 – 45 (with PVC components 5 – 40)*
Relative humidity %Max. 90
Max. sound pressure level dB(A) 51 – 56
Max. supply pressure mbar 800
Viscosity limits mPa s 300** / 1000***
Adjustable dosing range %0 – 100
Table 8: Operating conditions and limits
* Use of the dosing pump at ambient temperatures below 5 °C must be checked individually. In such cases, please contact the manufacturer.
** With a viscosity of ~300 mPa s and above, you must use spring-loaded valves.
*** If the viscosity is above 1000 mPa s, this must be checked individually.
**** Only for LK 2 with PVDF or stainless steel dosing head, otherwise max. 16 bar counterpressure.

Technical specifications
Electrical data 13
© Lutz-Jesco GmbH 2015
Subject to technical changes.
150302
BA-10102-02-V02
Stepper motor-driven diaphragm dosing pump MEMDOS SMART LD Operating Instructions
5.2.1 Permitted media temperatures
Information Value MEMDOS SMART LD (all sizes)
Dosing head made of PVC °C 0 – 35
Dosing head made of PP °C 0 – 60
Dosing head made of PVDF °C 0 – 80
Dosing head made of stainless steel (1.4571) °C 0 – 80
Table 9: Approved media temperature
5.3 Electrical data
Information Value MEMDOS SMART LD (all sizes)
Voltage supply 110 – 240 V AC, -10% / +5%, 50/60 Hz
Power consumption W 25
Table 10: Electrical specifications
5.4 Other data
Information Value
MEMDOS SMART LD Size
2 5 10 15 20
Weight (with dosing head made of PVC, PP or PVDF) kg ~ 2.2
Weight (with dosing head made of stainless steel (1.4571)) kg ~ 3.3
Diameter of diaphragm mm 33 39 54
Electrical cable m1.8 m (with mains plug)
Protection class IP65 (with covering caps on the connections)
Insulation class F
Valve connection G 5/8 male
Valve size DN3 DN4
Table 11: Other data

Dimensions
MEMDOS SMART LD 2, 5, 10
14 © Lutz-Jesco GmbH 2015
BA-10102-02-V02
Stepper motor-driven diaphragm dosing pump MEMDOS SMART LD Operating Instructions
6 Dimensions
6.1 MEMDOS SMART LD 2, 5, 10
76~43~
~ 59
~ 180
120 L
L
~ 260
205~
100 116
80
Ø
70
6,5 Ø
Fig. 6: Dimensioned drawing of MEMDOS SMART LD 2, 5, 10 with dosing head made of PVC, PP or PVDF (all dimensions in mm)
237~
202~
~ 81
~ 17
LL~ 120
176~
~ 56
70
6,5 Ø
100
116
80
Ø
Fig. 7: Dimensioned drawing of MEMDOS SMART LD 2, 5, 10 with dosing head made of stainless steel (1.4571) (all dimensions in mm)
Hose clip Material Size Nominal diameter L
LD 2
PVC / PP / PVDF 4/6 mm DN3 31
Stainless steel 4/6 mm DN3 54
LD 5, 10, 15, 20
PVC / PP / PVDF
4/6 mm DN4 31
1/4x3/8” 1/4" 34
6/9 mm DN6 34
6/12 mm DN6 15
Stainless steel (1.4571) / PVDF
4/6 mm DN4 50
6/9 mm DN6 54

Dimensions
MEMDOS SMART LD 15, 20 15
© Lutz-Jesco GmbH 2015
Subject to technical changes.
150302
BA-10102-02-V02
Stepper motor-driven diaphragm dosing pump MEMDOS SMART LD Operating Instructions
6.2 MEMDOS SMART LD 15, 20
8 4~17, 5~
LL
5 3~
1 8 1~
70
6,5 Ø
84
Ø
100
116
2 3 7~
2 0 2~
Fig. 8: Dimensioned drawing of MEMDOS SMART LD with dosing head made of PVC, PP, PVDF or stainless steel (1.4571) (all dimensions in mm)
Connection Material Scale Nominal width L
Hose clip
PVC / PP / PVDF
4/6 mm DN4 31
1/4x3/8" 1/4" 34
6/9 mm DN6 34
6/12 mm DN6 15
Stainless steel (1.4571) /
PVDF
4/6 mm DN4 50
6/9 mm DN6 54
~ 130 (plastic) ~ 132 (stainless steel)

Installing the Dosing Pump
Set up information
16 © Lutz-Jesco GmbH 2015
BA-10102-02-V02
Stepper motor-driven diaphragm dosing pump MEMDOS SMART LD Operating Instructions
7 Installing the Dosing Pump
DANGER!
Mortal danger from electric shock!
Electrically conductive liquid can enter pump housings, cable screw
connections and mains connectors.
ðMake sure that all protective measures comply at least with the
requirements of protection class IP 55.
ðAlways set up the dosing pump such that water cannot enter the
housing.
CAUTION
Danger of personal injury and material damage!
A dosing pump that is difficult to access represents a danger due to
incorrect operation and faulty maintenance.
ðInstall the dosing pump such that it is accessible at all times.
7.1 Set up information
When installing, follow the basic principles below:
nThe valves must be vertical: Discharge valve at top, suction valve at
bottom. in this connection, pay attention to the arrow on the dosing
head. The dosing head must be aligned such that the arrow points
vertically upwards.
nYou should install the dosing pump at a convenient height for
operation.
nIt must not be installed under the ceiling.
nThe frame of foundation for fixing the dosing pump must not be
subjected to jolts. The pump must be vibration-free and stable.
nThere must be enough free space in the area of the dosing head and
the suction and discharge valves for these parts to be easily
dismantled if required. The entire space requirement for installation
and maintenance is approximately 1 m².
nThe distance from the sides of the dosing pump to the wall or other
dosing pumps or equipment must be at least 3 cm. There must be a
guaranteed flow of circulating air.
nThe maximum ambient temperature must be complied with, see
chapter 5.2 „Betriebsbedingungen und Grenzen“ auf Seite 12. If
necessary, radiated heat from surrounding equipment must be
screened.
nAvoid exposure to direct sunlight.
nThe dosing pump is not intended for use out of doors unless
appropriate protective measures have been taken to prevent dust and
water from entering the housing.
nFor the dimensions of the fastening holes, refer to chapter 6
„Abmessungen“ auf Seite 14.
nThe tightening torque for the fastening bolts is 1.5 – 2 Nm.
7.2 Installation examples
7.2.1 Installation on a wall console
Fig. 9: Installation on a wall console
To reduce the structure-borne noise, the dosing pump is bolted to the
wall bracket using rubber elements. The materials necessary for this are
included with the wall bracket.
7.2.2 Installation on the wall
Fig. 10: Installation on the wall
The dosing pump can be mounted to the floor or directly to the wall
without the need for additional elements. Turn the dosing head appropri-
ately to ensure the flow direction of the medium through the dosing head.

Hydraulic installations
Design of the system 17
© Lutz-Jesco GmbH 2015
Subject to technical changes.
150302
BA-10102-02-V02
Stepper motor-driven diaphragm dosing pump MEMDOS SMART LD Operating Instructions
8 Hydraulic installations
In this chapter, you will find information about the hydraulic parts of a
system that you should install or that can install additionally. In many
cases, you must install hydraulic accessories to be able to use all the
functions that the dosing pump MEMDOS SMART LD offers, to guarantee
functional safety or to achieve a high level of dosing precision.
WARNING
Caustic burns or other burns through dosing media!
The materials of the dosing pump and hydraulic parts of the system
must be suitable for the dosing medium that is used. Should this not
be the case, the dosing media may leak. Depending on the type and
hazardousness of the dosing medium, this can result in injury.
ðMake sure that the materials you are using are suitable for the
dosing medium.
ðMake sure that the lubricants, adhesives, sealants, etc. that you
use are suitable for the dosing medium.
WARNING
Caustic burns or other burns through dosing media!
If there is a diaphragm rupture, the dosing medium can escape in an
uncontrolled way. Depending on the type and hazardousness of the
dosing medium, this can result in injury.
ðInstall a leakage drain.
WARNING
Caustic burns or other burns through dosing media!
The dosing pump can generate a pressure that is many times the
rated one. A blocked pressure line can lead to dosing medium
escaping. Depending on the type and hazardousness of the dosing
medium, this can result in injury.
ðInstall pressure relief valves.
CAUTION
Danger of personal injury and material damage!
High peak pressures can lead to piping vibrating and cause them to
snap. This can result in injury due to uncontrollable piping or escaping
dosing media.
ðInstall pulsation dampeners.
NOTICE
Damage to drives due to overloading
The pressure conditions between the suction and discharge sides
must be balanced; otherwise, overloading can result. This can lead to
uncontrolled dosing processes, damage to the plant pipework and to
the dosing pump.
ðEnsure that the pressure on the discharge side is at least 1 bar
than on the suction side.
NOTICE
Locking of threads
Stainless steel and plastic parts (particularly those made of PVC) that
are bolted together in a detachable connection (e.g. the dosing head
and the valves) can lock. This makes them difficult to release.
ðBefore bolting, grease the corresponding parts with a lubricant
(e.g. PTFE spray). Ensure that the lubricant is compatible with the
dosing medium.
8.1 Design of the system
nThe dosing pumps technical data (see chapter 5 „Technische Daten“
auf Seite 12) must be taken into account and the plant s layout
must be set up appropriately (e.g. pressure loss when rating the lines
with regard to their nominal diameter and length).
nThe entire system and its integrated dosing pump must be designed
in such a way that an escaping dosing medium (due to the failure of
wearing parts such as the diaphragm, or burst hoses) does not lead to
permanent damage to system parts or the premises.
nThe leakage opening of the dosing head must be visible so that you
can detect a diaphragm rupture. It must be possible for the outflow
from the leakage drain to be on a free downwards gradient.
nIf you use hazardous dosing media, the installation must be designed
such that no disproportionately high consequential damages arise
due to dosing media escaping.
nTo avoid dosing errors after the end of the process, the dosing pump
must be locked hydraulically.
nTo allow you to easily inspect the pressure conditions in the system,
you should provide connections for pressure gauges close to the
suction and discharge valves.

Hydraulic installations
System piping
18 © Lutz-Jesco GmbH 2015
BA-10102-02-V02
Stepper motor-driven diaphragm dosing pump MEMDOS SMART LD Operating Instructions
8.2 System piping
nThe system piping must not exert any force on the connections and
valves of the dosing pump.
nThis means that steel piping should be connected to the dosing pump
by means of flexible pipe sections.
nThe nominal diameters of the pipework and the installed fittings
should be rated the same as or greater than the nominal diameters of
the dosing pump's suction and discharge valves.
nThe suction line should be kept as short as possible.
nYou should avoid intertwined hoses.
nAvoid loops, since air bubbles can collect.
8.3 Aligning the dosing head
a
b
c
Fig. 11: Aligning the dosing head
When connecting the dosing lines to the dosing pump, you must observe
the direction of through-flow (see arrow b). The dosing head must be
aligned vertically. The alignment can be changed in 90° intervals.
The suction valve cmust always point downwards. Accordingly, arrow
band pressure valve aalways point upwards. This is irrespective of
the positioning of the dosing head to the drive.
8.4 Hydraulic connections
8.4.1 Connecting hose clips
Choose the hose connection according to the condition of the hose
(material, inner diameter, wall thickness) in order to ensure maximum
pressure resistance.
8.4.1.1 Size 4.6 and 6.9
a
b
c
d
e
a
b
c
d
e
4/6 6/9
Fig. 12: Hose clips 4/6 and 6/9 (internal and external diameters in mm)
Perform the following working steps:
1. Cut the hose ato length neatly and at an exact right angle.
2. Place a gasket that is suitable for the dosing medium between the
connection eand the valve.
3. Screw the connecting piece eto the dosing pump's valve using the
b.
4. Thread the union nut cand the clamping ring donto the hose.
5. Plug the hose aall the way in to the grommet of connection piece
e.
6. Push the clamping ring donto the grommet of connection piece e
and screw it to the union nut .
7. Carry out the same procedure with the connection to the dosing
pump's other valve.
üHose clip connected.

Hydraulic installations
Hydraulic connections 19
© Lutz-Jesco GmbH 2015
Subject to technical changes.
150302
BA-10102-02-V02
Stepper motor-driven diaphragm dosing pump MEMDOS SMART LD Operating Instructions
8.4.1.2 Size 6/12
a
b
c
d
Fig. 13: Hose clip 6/12 (internal and external diameter in mm)
Size 6/12 hose clips only have a union nut. It clamps the hose onto the
grommet of the connection piece and at the same time fastens on the
dosing pump's valve.
Perform the following working steps:
1. Cut the hose ato length neatly and at an exact right angle.
2. Place a gasket that is suitable for the dosing medium between the
connection dand the valve.
3. Push the union nut band the cutting ring cover the hose a.
4. Press the end of the hose aonto the grommet of connection piece
d. You can do this more easily by moistening the end of the hose on
the inside or applying some lubricant to the grommet in the cone
area. You should push at least two thirds of the hose onto the
grommet of the connection piece.
5. Push the cutting ring cover the hose ainto the cone area on the
grommet of connection piece d.
6. Screw the union nut bonto the valve of the dosing pump.
üHose clip connected.
8.4.2 Making the bonded connection
a
b
Fig. 14: Glue-in connection
Perform the following working steps:
1. Cut the PVC tube to length.
2. Push the union nut onto the tube.
3. Stick the bonded coupling sleeve bto the tube (follow the
instructions of the adhesive manufacturer).
4. Screw the union nut onto the valve of the dosing pump. Use a gasket
that is suitable for the dosing medium.
üBonded connection made.
8.4.3 Making the cemented connection
a
b
Fig. 15: Cemented connection
Perform the following working steps:
1. Cut the tube to length.
2. Cut the thread bonto the end of the tube.
3. Push the union nut aonto the tube.
4. Seal the thread b.When choosing your sealing material, take into
account its resistance to material, temperature and pressure.
5. Screw the union nut onto the valve of the dosing pump. Use a gasket
that is suitable for the dosing medium.
üCemented connection made.
i
Under normal conditions, you only need to screw the hydraulic
connections finger-tight. However, due to the material settling,
the pre-tension of the screw connection can slacken. This
means that you must re-tighten the screw connection before
carrying out commissioning.

Hydraulic installations
Connecting a leakage drain
20 © Lutz-Jesco GmbH 2015
BA-10102-02-V02
Stepper motor-driven diaphragm dosing pump MEMDOS SMART LD Operating Instructions
8.5 Connecting a leakage drain
Lutz-Jesco GmbH dosing pumps are produced to the highest of quality
standards with a long service life. However, some parts are subject to
operational wear. This is the case particularly with the diaphragms that
are continuously subjected to forces during the suction and discharge
strokes and to the effects of the dosing medium.
If a diaphragm ruptures, the dosing medium starts to leak.This leakage is
drained via the leakage opening. On the flange of the dosing head, there
are three openings for this purpose. Depending on the alignment of the
dosing pump, the leakage is drained via the downward opening.
Fig. 16: Openings of the leakage drain
NOTICE
Damage to drives due to effervescent media
If a hose is connected to the leakage drain and it is routed back into
the dosing tank, effervescent media can enter the drive and damage
it.
ðCollect the the leakage in a collecting pan.
ðAs an alternative, you can route the leakage back to to the dosing
tank using a funnel. You should install the funnel at an adequate
distance from the leakage opening.
8.6 Connecting the dosing head venting facility
The dosing heads of the MEMDOS SMART LD 5 and LD 10 have an
integrated dosing head venting unit (except for dosing heads made of
stainless steel).
For the procedure when venting, refer to chapter 11.1.1 „Venting the
dosing pump“ on page 34.
Fig. 17: Dosing head venting facility with hose connection
Perform the following working steps:
6. Connect a 4/6 hose to the dosing head venting facility.
7. Route the other end of the hose into the dosing tank or a collecting
tank.
üDosing head venting facility connected.
