Luxaire ACCLIMATE AL21B2421S Quick start guide

TECHNICAL GUIDE
ACCLIMATETM SERIES
SPLIT SYSTEM
AIR CONDITIONERS
20 SEER – R-410A – 1 PHASE
2 THRU 5 NOMINAL TONS
MODELS: AL21B24 THRU 60
Due to continuous product improvement, specifications
are subject to change without notice.
Visit us on the web at
www.upgnet.com and www.luxaire.com
Additional rating information can be found at
www.ahridirectory.org
WARRANTY SUMMARY*
Extended 10-Years limited parts warranty.
Extended Lifetime limited compressor warranty.
Extended parts and compressor warranties require online
registration within 90 days of purchase for replacement or
closing for new home construction.
*Does not apply to 3-Phase models, or Internet sales.
See Limited Warranty certificate in User's Information Manual for details.
FOR INSTALLATION IN ALL US REGIONS AND CANADA
Installation Allowed

5443703-LTG-B-0418
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
DESCRIPTION
The Acclimate™ Series AL21 variable capacity air conditioners
are the outdoor section of a high efficiency communicating cool-
ing system. They are designed as part of a matched system
using an AVV air handler or variable speed communicating fur-
nace with a CM coil. Both the matched CM coil and AVV air
handler have factory mounted EEVs. The CM coils with factory
mounted EEVs can also be matched with the variable speed
MVC modular air handlers.
FEATURES
•Superior Coil Protection – An easily removable two-piece
steel extruded louver coil guard protects the tube-in-fin coil
from debris and physical damage while making access for
coil cleaning quick and simple.
•Environmentally Friendly Refrigerant – The next genera-
tion refrigerant R-410A delivers environmentally friendly per-
formance with zero ozone depletion.
•Durable Finish – A high quality powder paint finish rated at
1000 hrs. salt spray provides the ultimate protection from
corrosion and harmful UV rays, ensuring a long-lasting, high
quality appearance.
•Charge Smart™ – A built-in touch screen instantly displays
the system overall condition, including the system pressures
and refrigerant charge without the need to attach additional
gauges or sensors.
•SilentDrive™ System – Features a combination of engi-
neered, sound-neutralizing attributes such as a swept-wing
fan blade, composite base pan, multi-density compressor
cloak and variable capacity operation to reduce sound levels
to that of a mere conversation.
•ECM Fan Motor – Dynamically adjusts speed in sync with
the compressor demand to keep heat exchange in balance
while minimizing power consumption and sound.
•Swept Wing Fan – A design adapted from aerospace engi-
neering provides whisper-quiet operation by allowing air to
flow smoothly and efficiently across the fan surface and
edges.
•Composite Base Pan – The strong and durable composite
base pan is corrosion resistant while adding strength,
absorbing sound, and reducing vibration.
•High-Efficiency Outdoor Coil – An aluminum fin and cop-
per tube outdoor coil provide easy cleaning, low restriction to
airflow and efficient heat exchange.
•Factory Installed Filter-Drier – A corrosion resistant copper
solid core liquid line filter-drier removes debris and moisture
which can be harmful to the system.
•Climate Sync™ – provides pre-configured operating profiles
the installing contractor can select during set-up to fine tune
the system's operation for either Humid, Dry, or Normal cli-
mates. Additional fine-tune adjustments are always available
to provide a custom comfort solution.
•Easy Service Access – A large electrical box cover, inde-
pendent Charge Smart access, and a swing open electrical
box provide superior full corner access to the inside of the
unit for maintenance or service.
•System Protection – Each system contains high and low
pressure transducers which constantly monitor system per-
formance and can alert the consumer or contractor system
concerns or alerts.
•EEV Controls – All indoor coils, whether in the cased CM
coil or in the AVV air handler, have factory installed EEVs
(Electronic Expansion Valves).

5443703-LTG-B-0418
2 Johnson Controls Unitary Products
•Communications Capable – Requiring only 3 thermostat
wires between the outdoor and indoor units, the communi-
cating system provides self-commissioning on start-up as
well as the ability to check system status at the outdoor unit,
thermostat, or remotely using the designated App.
•Advanced System Control – The proprietary Wi-Fi Hx™
thermostat interface is an integral part of this innovative sys-
tem design. Using the Consumer App, consumers can moni-
tor and adjust their system from anywhere in the world using
a smart device. Contractors can use the Service App (with
homeowner permission), to monitor the system remotely and
make adjustments as needed. The system can be configured
to provide alerts for emerging issues as well as items that
require immediate attention.
•Variable Capacity Inverter Controlled Scroll Compressor
–Constantly monitors and dynamically adjusts system
capacity in precise increments as necessary to closely meet
the comfort demands of the conditioned space.
•Premium System Warranty –Limited lifetime compressor
warranty when registered online within 90 days of installa-
tion.
•Agency Listed – Safety certified by CSA to UL 1995 / CSA
22.2. Performance certified to ANSI/AHRI Standard 210/240
in accordance with the Unitary Small Equipment certification
program.
LIST OF SECTIONS
DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
LIST OF SECTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
NOMENCLATURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
PHYSICAL AND ELECTRICAL DATA . . . . . . . . . . . . . . . . . . . . . . .3
DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
SYSTEM CHARGE FOR VARIOUS MATCHED SYSTEMS . . . . . . .4
LIMITATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
SYSTEM CAPACITY - Single Piece and Modular Air Handlers . . .6
COOLING CAPACITY - With High Efficiency Motor Furnaces . . .7
APPLICATION & ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . .11
SOUND POWER RATINGS - COOLING . . . . . . . . . . . . . . . . . . . . .11
UNIT OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
MECHANICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . .12
TYPICAL INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
TYPICAL FIELD WIRING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
ALTERNATIVE INSTALLATION CLEARANCES . . . . . . . . . . . . . .14
PERFORMANCE DATA - 2 TON . . . . . . . . . . . . . . . . . . . . . . . . . . .15
PERFORMANCE DATA - 3 TON . . . . . . . . . . . . . . . . . . . . . . . . . . .16
PERFORMANCE DATA - 4 TON . . . . . . . . . . . . . . . . . . . . . . . . . . .17
PERFORMANCE DATA - 5 TON . . . . . . . . . . . . . . . . . . . . . . . . . . .18
NOMENCLATURE
PRODUCT TYPE AA= Premium Air Conditioner
BRAND LL= Luxaire
NOMINAL
SERIES EFFICIENCY
AND STAGING 21 21 = 20 SEER / Modulating
REFRIGERANT BB= R-410A
NOMINAL UNIT
CAPACITY (MBH) 36 24 = 2 Ton 48 = 4 Ton
36 = 3 Ton 60 = 5 Ton
VOLTAGE
(Voltage-Phase-Hertz) 22= 208/230-1-60
GENERATION
(MAJOR REVISION) 11= 1st Gen
2= 2nd Gen
etc
FACTORY OPTION SS= Standard (No Options)
H= Hard Start Kit
STYLE LETTER
(MINOR REVISION)
NOT USED
FOR ORDERING
AA= Style A
B= Style B
etc

5443703-LTG-B-0418
Johnson Controls Unitary Products 3
All dimensions are in inches and are subject to change without notice.
Overall height is from bottom of base pan to top of fan guard.
Overall length and width include screw heads.
PHYSICAL AND ELECTRICAL DATA
MODEL AL21B2421S AL21B3621S AL21B4821S AL21B6021S
Unit Supply Voltage 208-230V, 1 60Hz
Normal Voltage Range 1187 to 252
Minimum Circuit Ampacity 17.4 25.7 28.6 33.9
Max. Overcurrent Device Amps 230 40 45 50
Compressor Type Scroll Scroll Scroll Scroll Rated Load 12.8 19.2 20.8 25.0
Locked Rotor 23.0 35.0 35.0 50.0
Crankcase Heater (Stator Heat) Yes Yes Yes Yes
HS Kit Required with TXV N/A N/A N/A N/A
Fan Diameter Inches 24 24 26 26
Fan Motor
Rated HP 1/8 1/4 1/3 1/3
Rated Load Amps 1.4 1.7 2.6 2.6
Nominal RPM 1025 1025 975 1050
Nominal CFM 3500 3900 4800 5300
Coil Face Area Sq. Ft. 23.82 23.82 28.80 31.2 Rows Deep 1 1 2 2
Fins / Inch 22 22 18 18
Liquid Line Set OD (Field Installed) 3/8 3/8 3/8 3/8
Vapor Line Set OD (Field Installed)33/4 3/4 7/8 7/8
Unit Charge (Lbs. - Oz.) 47 - 8 7 - 6 14 - 9 15 - 1
Charge Per Foot, Oz. 0.62 0.62 0.67 0.67
Operating Weight Lbs. 194 205 264 270
1. Rated in accordance with AHRI Standard 110-2012, utilization range “A”.
2. Dual element fuses or HACR circuit breaker. Maximum allowable overcurrent protection.
3. For applications with non-standard vapor line sizes, see the “Applications & Accessories” section of this Technical Guide.
4. The Unit Charge is correct for the outdoor unit, smallest matched indoor unit, and 15 feet of refrigerant tubing. For tubing lengths other than 15 feet, add or sub-
tract the amount of refrigerant, using the difference in actual lineset length (not the equivalent length) multiplied by the per foot value.
&
%
$
$
DIMENSIONS
Unit
Model
Dimensions
(Inches) Refrigerant Connection Service Valve Size
A B C Liquid Vapor
AL21B2421S 40-1/4 35-1/2 32
3/8 3/4
AL21B3621S 40-1/4 35-1/2 32
AL21B4821S 43-1/4 38-1/4 34-1/2 7/8
AL21B6021S 46-1/2 38-1/4 34-1/2

5443703-LTG-B-0418
4 Johnson Controls Unitary Products
CHARGING PROCEDURES:
1. Determine outdoor unit factory charge from Tabular Data Sheet.
2. Determine indoor coil adjustment (if any) from Tabular Data Sheet.
3. Calculate the additional charge for refrigerant piping using this Tabular Data Sheet if line length is greater than 15 feet (4.6 m).
4. Total system charge = item 1 + item 2 + item 3.
5. The manifold gauge set is already installed on the unit for evacuation and charging. Use these gauges to initially charge the system using system pressures and
subcooling. Before charging put the equipment into “Service Mode” at the outdoor control. You will find the charging information printed on the bottom of the unit
data tag. More charging information is available in the “Service Data Application Guide”, available online. For subsequent annual maintenance visits the charge
verification display can be used to quickly check overall system condition and the system charge without attaching a separate manifold gauge set or temperature
sensors.
6. Permanently mark the unit data plate with the total amount of refrigerant in the system.
SYSTEM CHARGE FOR VARIOUS MATCHED SYSTEMS
Outdoor Unit AL21B2421S AL21B3621S AL21B4821S AL21B6021S
Indoor Unit 1 Additional Charge, oz
AVV25BE121 0 – – –
AVV37BE221 – 0 – –
AVV37CE221 – 0 – –
AVV49CE321 – – 0 –
AVV49DE321 – – 0 –
AVV61CE421 – – – 0
AVV61DE421 – – – 0
CM25BE1A1 0 – – –
CM37BE2A1 – 0 – –
CM37CE2A1 – 0 – –
CM49CE3A1 – – 0 –
CM49DE3A1 – – 0 –
CM61CE4A1 – – – 0
CM61DE4A1 – – – 0
All of the combinations shown in the above System Charge table require Advanced Main Air Circulating Fan indoor product. “Coil Only” matches
are not available for these systems.
FOOTNOTES:
1. Charge adders shown above do not indicate that coils are rated for every application. Refer to Performance Data Tables for actual performance for specified
system matches. Obtain certified system ratings from www.ahridirectory.org.
IMPORTANT
It is recommended before starting the system to connect the thermostat to Wi-Fi using a local network or portable hot-spot so the
thermostat and system receive the latest software updates to optimize system performance.

5443703-LTG-B-0418
Johnson Controls Unitary Products 5
LIMITATIONS
The unit should be installed in accordance with all National, State and
Local Safety Codes and the limitations listed below:
1. Limitations for the indoor unit, coil, and appropriate accessories
must also be observed.
2. The outdoor unit must not be installed with any duct work in the air
stream. The outdoor fan is the propeller type and is not designed to
operate against any additional external static pressure.
3. The maximum and minimum conditions for operation must be
observed to ensure a system will give maximum performance with
minimal service.
4. The maximum allowable equivalent line length for this product is 80
feet.
Standard Lineset Applications
Maximum allowable lineset varies depending on the vertical separation
between the evaporator and condenser. See Table below for allowable
line set lengths and sizing.
Unit Reduced Capacity Conditions
Minimum / Maximum Operating Limit Conditions
AIR TEMPERATURE AT
OUTDOOR COIL, ° F (° C) AIR TEMPERATURE AT INDOOR COIL, ° F (° C)
Min. Max. Min. Max.
DB Cool DB Cool WB Cool WB Cool
35(2)* 125(52)* 57(14) 72(22)
*Reference the NOTICE under the “Unit Reduced Capacity Conditions”
section.
Allowable Vertical Linesets
Model Liquid
Line Suction Line
Max Line
Length -
Units on
Equal Level
Max Suction
Line Riser - If
OD Unit is
Above ID Unit
Max Liquid
Line Riser - If
OD Unit is
Below ID Unit
24
3/8” 3/4” 80 feet 25 feet 25 feet
36
48 7/8”
60
NOTICE
Inverter Temperature Protection:
If excessive inverter temperatures are sensed, the compressor speed
/ capacity is reduced until an acceptable condition is reached.
When the inverter temperature returns to an acceptable level, the
system returns to normal operation.
Over / Under Current Protection: If a low or high Current Condition
is sensed, the compressor speed / capacity is reduced until an
acceptable current level is reached.
When the system reaches an acceptable current level, the compres-
sor and fan return to normal operating conditions.
Over / Under Voltage Protection: If a low or high supply Voltage
Condition is experienced (below 187 VAC or above 265 VAC), the
compressor speed / capacity is automatically reduced until an accept-
able voltage level is sensed.
When an acceptable voltage level is sensed, the system automati-
cally returns to a normal state of operation.
High Altitude Protection: If the unit is installed in Altitudes of 6,500
ft / 2,000 m above sea level or higher, the compressor and outdoor
fan reduce speeds to protect the system. It is not recommended
these units be installed at altitudes greater than 6,500 ft / 2,000 m
above sea level.
Low Ambient Protection:
Cooling Mode: The unit automatically adjusts to maintain cooling
operation in outdoor ambient conditions down to 35° F (2° C). The
unit reduces capacity and Low Ambient Protection (cooling mode) or
cycles off if asked to provide cooling when the outdoor temperature is
at or below these conditions.

5443703-LTG-B-0418
6 Johnson Controls Unitary Products
— = Not applicable.
SYSTEM CAPACITY - Single Piece and Modular Air Handlers
UNIT
MODEL
AIR HANDLER COIL
MODEL1
1. CM coils available with a factory installed horizontal drain pan. See price pages for specific model number.
Stage RATED
CFM
COOLING
MODEL WIDTH NET MBH SEER EER
TOTAL SENS.
AL21B2421S AVV25BE121 17.5 – High 850 23.40 17.70 21.00 14.50 Med 550 14.10 11.20 – 18.50
Low 425 10.00 7.90 – 34.30
AL21B2421S MVC12BN21 17.5 CM25BE1A1 High 850 23.40 18.30 20.50 14.50 Med 425 14.00 10.50 – 18.85
Low 375 10.00 8.30 – 36.85
AL21B3621S AVV37BE221 17.5 – High 1250 34.80 26.60 18.50 13.00 Med 700 18.80 15.30 – 17.90
Low 450 11.20 9.70 – 33.20
AL21B3621S AVV37CE221 21.0 – High 1175 35.00 26.00 20.00 13.50 Med 725 19.00 14.60 – 19.20
Low 450 11.20 8.90 – 35.35
AL21B3621S MVC12BN21 17.5 CM37BE2A1 High 1175 34.80 25.80 18.50 12.75 Med 700 18.90 15.40 – 17.90
Low 450 11.20 9.70 – 33.20
AL21B3621S MVC16CN21 21.0 CM37CE2A1 High 1175 34.80 26.00 19.25 13.00 Med 675 18.90 15.30 – 18.30
Low 475 11.30 10.00 – 33.90
AL21B4821S AVV49CE321 21.0 – High 1450 45.50 32.80 20.00 13.00 Med 825 25.20 19.80 – 19.05
Low 475 14.20 11.30 – 35.70
AL21B4821S AVV49DE321 24.5 – High 1550 45.50 34.40 20.00 13.00 Med 800 25.20 18.50 – 19.10
Low 525 14.90 11.50 – 36.20
AL21B4821S MVC16CN21 21.0 CM49CE3A1 High 1450 45.50 32.80 20.00 13.00 Med 825 25.20 19.80 – 19.05
Low 475 14.20 11.30 – 35.70
AL21B4821S MVC20DN21 24.5 CM49DE3A1 High 1475 45.50 32.80 20.00 13.00 Med 850 25.40 20.00 – 19.20
Low 450 14.10 11.10 – 35.65
AL21B6021S AVV61CE421 21.0 – High 1725 52.50 38.00 20.25 12.50 Med 1050 30.40 24.40 – 19.40
Low 800 20.60 17.30 – 37.25
AL21B6021S AVV61DE421 24.5 – High 1650 52.50 38.50 20.50 13.00 Med 1025 30.40 23.40 – 19.10
Low 775 20.80 16.60 – 36.25
AL21B6021S MVC20DN21 24.5 CM61DE4A1 High 1750 52.50 38.00 20.50 13.00 Med 1075 30.40 24.80 – 19.60
Low 800 20.80 17.50 – 38.30
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ANSI/AHRI Standard 210/240.
Cooling MBH based on 80°F entering air temperature, 50% RH (Relative Humidity), and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTUs at 95°F outdoor ambient divided by the total electric power in watt-hours at those
conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTUs during a normal annual usage period for cooling divided by the total
electric power input in watt-hours during the same period.

5443703-LTG-B-0418
Johnson Controls Unitary Products 7
COOLING CAPACITY - With High Efficiency Motor Furnaces1
UNIT
MODEL
FURNACE COIL
MODEL2STAGE COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.
AL21B2421S TM8V080B12MP12C 17.5 CM25BE1A1 High 825 23.4 18.3 20.75 14.50
Med 500 14.0 11.5 – 19.35
Low 375 9.9 8.2 – 37.20
AL21B2421S TM9V060B12MP12C 17.5 CM25BE1A1 High 775 23.0 17.4 20.50 14.25
Med 475 13.8 10.8 – 19.05
Low 325 9.7 7.7 – 36.35
AL21B2421S TM9V080B12MP12C 17.5 CM25BE1A1 High 825 23.4 18.3 20.75 14.50
Med 500 14.0 11.4 – 19.30
Low 375 9.9 8.2 – 37.05
AL21B2421S TMLV080B12MP12C 17.5 CM25BE1A1 High 825 23.4 18.3 20.75 14.50
Med 500 14.0 11.5 – 19.35
Low 375 9.9 8.2 – 37.20
AL21B2421S TP9C060B12MP13C 17.5 CM25BE1A1 High 775 23.0 17.4 20.50 14.25
Med 475 13.8 10.8 – 19.05
Low 325 9.7 7.7 – 36.35
AL21B2421S TP9C080B12MP13C 17.5 CM25BE1A1 High 825 23.4 18.3 20.75 14.50
Med 500 14.0 11.4 – 19.30
Low 375 9.9 8.2 – 37.05
AL21B2421S TPLC080B12MP13C 17.5 CM25BE1A1 High 825 23.4 18.3 20.75 14.50
Med 500 14.0 11.5 – 19.35
Low 375 9.9 8.2 – 37.20
AL21B2421S LP9C060B12MP13C 17.5 CM25BE1A1 High 775 23.0 17.4 20.50 14.25
Med 475 13.8 10.8 – 19.05
Low 325 9.7 7.7 – 36.35
AL21B2421S LP9C080B12MP13C 17.5 CM25BE1A1 High 825 23.4 18.3 20.75 14.50
Med 500 14.0 11.4 – 19.30
Low 375 9.9 8.2 – 37.05
AL21B2421S LPLC080B12MP13C 17.5 CM25BE1A1 High 825 23.4 18.3 20.75 14.50
Med 500 14.0 11.5 – 19.35
Low 375 9.9 8.2 – 37.20
AL21B3621S TM8V080B12MP12C 17.5 CM37BE2A1 High 1275 34.6 26.6 19.00 12.20
Med 725 18.9 15.4 – 18.25
Low 475 11.1 9.6 – 33.70
AL21B3621S TM8V080C16MP12C 21.0 CM37CE2A1 High 1200 34.8 26.2 19.25 13.00
Med 700 18.9 15.6 – 18.60
Low 550 10.8 8.6 – 31.60
AL21B3621S TM8V100C16MP12C 21.0 CM37CE2A1 High 1200 34.8 26.2 19.25 13.00
Med 700 18.9 15.6 – 18.60
Low 550 10.8 8.6 – 31.60
AL21B3621S TM9V080B12MP12C 17.5 CM37BE2A1 High 1250 34.6 26.4 19.00 12.20
Med 725 18.9 15.4 – 18.15
Low 475 11.0 9.6 – 33.05
AL21B3621S TM9V080C16MP12C 21.0 CM37CE2A1 High 1125 34.8 25.6 19.25 13.00
Med 650 18.6 14.8 – 18.40
Low 575 10.8 8.6 – 31.25
AL21B3621S TM9V100C16MP12C 21.0 CM37CE2A1 High 1300 34.8 27.0 19.00 12.75
Med 750 18.9 16.0 – 18.45
Low 650 10.6 8.4 – 30.45
AL21B3621S TMLV080B12MP12C 17.5 CM37BE2A1 High 1275 34.6 26.6 19.00 12.20
Med 725 18.9 15.4 – 18.25
Low 475 11.1 9.6 – 33.70

5443703-LTG-B-0418
8 Johnson Controls Unitary Products
AL21B3621S TMLV080C16MP12C 21.0 CM37CE2A1 High 1200 34.8 26.2 19.25 13.00
Med 700 18.9 15.6 – 18.60
Low 550 10.8 8.6 – 31.60
AL21B3621S TMLV100C16MP12C 21.0 CM37CE2A1 High 1200 34.8 26.2 19.25 13.00
Med 700 18.9 15.6 – 18.60
Low 550 10.8 8.6 – 31.60
AL21B3621S TP9C080B12MP13C 17.5 CM37BE2A1 High 1250 34.6 26.4 19.00 12.20
Med 725 18.9 15.4 – 18.15
Low 475 11.0 9.6 – 33.05
AL21B3621S TP9C080C16MP13C 21.0 CM37CE2A1 High 1125 34.8 25.6 19.25 13.00
Med 650 18.6 14.8 – 18.40
Low 575 10.8 8.6 – 31.25
AL21B3621S TP9C100C16MP13C 21.0 CM37CE2A1 High 1300 34.8 27.0 19.00 12.75
Med 750 18.9 16.0 – 18.45
Low 650 10.6 8.4 – 30.45
AL21B3621S TPLC080B12MP13C 17.5 CM37BE2A1 High 1275 34.6 26.6 19.00 12.20
Med 725 18.9 15.4 – 18.25
Low 475 11.1 9.6 – 33.70
AL21B3621S TPLC080C16MP13C 21.0 CM37CE2A1 High 1200 34.8 26.2 19.25 13.00
Med 700 18.9 15.6 – 18.60
Low 550 10.8 8.6 – 31.60
AL21B3621S TPLC100C16MP13C 21.0 CM37CE2A1 High 1200 34.8 26.2 19.25 13.00
Med 700 18.9 15.6 – 18.60
Low 550 10.8 8.6 – 31.60
AL21B3621S LP9C080B12MP13C 17.5 CM37BE2A1 High 1250 34.6 26.4 19.00 12.20
Med 725 18.9 15.4 – 18.15
Low 475 11.0 9.6 – 33.05
AL21B3621S LP9C080C16MP13C 21.0 CM37CE2A1 High 1125 34.8 25.6 19.25 13.00
Med 650 18.6 14.8 – 18.40
Low 575 10.8 8.6 – 31.25
AL21B3621S LP9C100C16MP13C 21.0 CM37CE2A1 High 1300 34.8 27.0 19.00 12.75
Med 750 18.9 16.0 – 18.45
Low 650 10.6 8.4 – 30.45
AL21B3621S LPLC080B12MP13C 17.5 CM37BE2A1 High 1275 34.6 26.6 19.00 12.20
Med 725 18.9 15.4 – 18.25
Low 475 11.1 9.6 – 33.70
AL21B3621S LPLC080C16MP13C 21.0 CM37CE2A1 High 1200 34.8 26.2 19.25 13.00
Med 700 18.9 15.6 – 18.60
Low 550 10.8 8.6 – 31.60
AL21B3621S LPLC100C16MP13C 21.0 CM37CE2A1 High 1200 34.8 26.2 19.25 13.00
Med 700 18.9 15.6 – 18.60
Low 550 10.8 8.6 – 31.60
AL21B4821S TM8V080C16MP12C 21.0 CM49CE3A1 High 1475 45.5 32.8 19.50 12.50
Med 850 25.0 19.8 – 18.70
Low 625 14.6 13.1 – 34.85
AL21B4821S TM8V100C16MP12C 21.0 CM49CE3A1 High 1475 45.5 32.8 19.50 12.50
Med 850 25.0 19.8 – 18.70
Low 625 14.6 13.1 – 34.85
AL21B4821S TM8V100C20MP12C 21.0 CM49CE3A1 High 1525 45.5 33.2 19.50 12.50
Med 875 25.0 20.0 – 18.65
Low 675 14.4 11.1 – 34.05
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2STAGE COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5443703-LTG-B-0418
Johnson Controls Unitary Products 9
AL21B4821S TM8V120C20MP12C 21.0 CM49CE3A1 High 1525 45.5 33.2 19.50 12.50
Med 875 25.0 20.0 – 18.65
Low 675 14.4 11.1 – 34.05
AL21B4821S TM9V080C16MP12C 21.0 CM49CE3A1 High 1500 45.5 32.8 19.50 12.25
Med 775 25.0 19.1 – 18.80
Low 600 14.6 12.8 – 34.95
AL21B4821S TM9V100C16MP12C 21.0 CM49CE3A1 High 1450 45.5 33.0 19.25 12.50
Med 875 24.8 19.8 – 18.35
Low 675 14.5 11.2 – 33.70
AL21B4821S TM9V100C20MP12C 21.0 CM49CE3A1 High 1625 45.5 33.8 19.00 12.20
Med 925 24.8 20.2 – 18.05
Low 575 14.7 12.7 – 36.15
AL21B4821S TM9V120D20MP12C 24.5 CM49DE3A1 High 1475 45.5 32.8 19.25 12.50
Med 825 25.0 19.7 – 18.70
Low 600 14.6 12.8 – 32.85
AL21B4821S TMLV080C16MP12C 21.0 CM49CE3A1 High 1475 45.5 32.8 19.50 12.50
Med 850 25.0 19.8 – 18.70
Low 625 14.6 13.1 – 34.85
AL21B4821S TMLV100C16MP12C 21.0 CM49CE3A1 High 1475 45.5 32.8 19.50 12.50
Med 850 25.0 19.8 – 18.70
Low 625 14.6 13.1 – 34.85
AL21B4821S TMLV100C20MP12C 21.0 CM49CE3A1 High 1525 45.5 33.2 19.50 12.50
Med 875 25.0 20.0 – 18.65
Low 675 14.4 11.1 – 34.05
AL21B4821S TMLV120C20MP12C 21.0 CM49CE3A1 High 1525 45.5 33.2 19.50 12.50
Med 875 25.0 20.0 – 18.65
Low 675 14.4 11.1 – 34.05
AL21B4821S TP9C080C16MP13C 21.0 CM49CE3A1 High 1500 45.5 32.8 19.50 12.25
Med 775 25.0 19.1 – 18.80
Low 600 14.6 12.8 – 34.95
AL21B4821S TP9C100C16MP13C 21.0 CM49CE3A1 High 1450 45.5 33.0 19.25 12.50
Med 875 24.8 19.8 – 18.35
Low 675 14.5 11.2 – 33.70
AL21B4821S TP9C100C20MP13C 21.0 CM49CE3A1 High 1625 45.5 33.8 19.00 12.20
Med 925 24.8 20.2 – 18.05
Low 575 14.7 12.7 – 36.15
AL21B4821S TP9C120D20MP13C 24.5 CM49DE3A1 High 1475 45.5 32.8 19.25 12.50
Med 825 25.0 19.7 – 18.70
Low 600 14.6 12.8 – 32.85
AL21B4821S TPLC080C16MP13C 21.0 CM49CE3A1 High 1475 45.5 32.8 19.50 12.50
Med 850 25.0 19.8 – 18.70
Low 625 14.6 13.1 – 34.85
AL21B4821S TPLC100C16MP13C 21.0 CM49CE3A1 High 1475 45.5 32.8 19.50 12.50
Med 850 25.0 19.8 – 18.70
Low 625 14.6 13.1 – 34.85
AL21B4821S TPLC100C20MP13C 21.0 CM49CE3A1 High 1525 45.5 33.2 19.50 12.50
Med 875 25.0 20.0 – 18.65
Low 675 14.4 11.1 – 34.05
AL21B4821S TPLC120C20MP13C 21.0 CM49CE3A1 High 1525 45.5 33.2 19.50 12.50
Med 875 25.0 20.0 – 18.65
Low 675 14.4 11.1 – 34.05
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2STAGE COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5443703-LTG-B-0418
10 Johnson Controls Unitary Products
AL21B4821S LP9C080C16MP13C 21.0 CM49CE3A1 High 1500 45.5 32.8 19.50 12.25
Med 775 25.0 19.1 – 18.80
Low 600 14.6 12.8 – 34.95
AL21B4821S LP9C100C16MP13C 21.0 CM49CE3A1 High 1450 45.5 33.0 19.25 12.50
Med 875 24.8 19.8 – 18.35
Low 675 14.5 11.2 – 33.70
AL21B4821S LP9C100C20MP13C 21.0 CM49CE3A1 High 1625 45.5 33.8 19.00 12.20
Med 925 24.8 20.2 – 18.05
Low 575 14.7 12.7 – 36.15
AL21B4821S LP9C120D20MP13C 24.5 CM49DE3A1 High 1475 45.5 32.8 19.25 12.50
Med 825 25.0 19.7 – 18.70
Low 600 14.6 12.8 – 32.85
AL21B4821S LPLC080C16MP13C 21.0 CM49CE3A1 High 1475 45.5 32.8 19.50 12.50
Med 850 25.0 19.8 – 18.70
Low 625 14.6 13.1 – 34.85
AL21B4821S LPLC100C16MP13C 21.0 CM49CE3A1 High 1475 45.5 32.8 19.50 12.50
Med 850 25.0 19.8 – 18.70
Low 625 14.6 13.1 – 34.85
AL21B4821S LPLC100C20MP13C 21.0 CM49CE3A1 High 1525 45.5 33.2 19.50 12.50
Med 875 25.0 20.0 – 18.65
Low 675 14.4 11.1 – 34.05
AL21B4821S LPLC120C20MP13C 21.0 CM49CE3A1 High 1525 45.5 33.2 19.50 12.50
Med 875 25.0 20.0 – 18.65
Low 675 14.4 11.1 – 34.05
AL21B6021S TM8V100C20MP12C 21.0 CM61CE4A1 High 1675 52.5 37.6 19.75 12.50
Med 1100 30.2 24.6 – 18.95
Low 825 20.6 17.8 – 35.95
AL21B6021S TM8V120C20MP12C 21.0 CM61CE4A1 High 1675 52.5 37.6 19.75 12.50
Med 1100 30.2 24.6 – 18.95
Low 825 20.6 17.8 – 35.95
AL21B6021S TM9V100C20MP12C 21.0 CM61CE4A1 High 1750 52.0 37.8 19.75 12.20
Med 1050 30.4 24.4 – 19.10
Low 700 20.4 16.3 – 37.05
AL21B6021S TM9V120D20MP12C 24.5 CM61DE4A1 High 1650 52.5 37.2 20.00 12.50
Med 1025 30.4 24.4 – 19.15
Low 775 20.8 17.4 – 36.65
AL21B6021S TMLV100C20MP12C 21.0 CM61CE4A1 High 1675 52.5 37.6 19.75 12.50
Med 1100 30.2 24.6 – 18.95
Low 825 20.6 17.8 – 35.95
AL21B6021S TMLV120C20MP12C 21.0 CM61CE4A1 High 1675 52.5 37.6 19.75 12.50
Med 1100 30.2 24.6 – 18.95
Low 825 20.6 17.8 – 35.95
AL21B6021S TP9C100C20MP13C 21.0 CM61CE4A1 High 1750 52.0 37.8 19.75 12.20
Med 1050 30.4 24.4 – 19.10
Low 700 20.4 16.3 – 37.05
AL21B6021S TP9C120D20MP13C 24.5 CM61DE4A1 High 1650 52.5 37.2 20.00 12.50
Med 1025 30.4 24.4 – 19.15
Low 775 20.8 17.4 – 36.65
AL21B6021S TPLC100C20MP13C 21.0 CM61CE4A1 High 1675 52.5 37.6 19.75 12.50
Med 1100 30.2 24.6 – 18.95
Low 825 20.6 17.8 – 35.95
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2STAGE COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.

5443703-LTG-B-0418
Johnson Controls Unitary Products 11
APPLICATION & ACCESSORIES
Refer to Price Manual for specific model numbers.
Support Feet S1-HPRKIT-**: Kit of 5 support feet to raise unit
above snow or landscaping. Available in heights of 3", 6" or 12".
Anchor Bracket Kit S1-1HK0401: Firmly anchors unit to pad
or support structure. When properly installed, approved for
ground-mounted or roof-mounted applications.
Wall Mount Kit (S1-ACB-**): Includes two brackets to allow
outdoor unit to be securely mounted to a vertical wall. Mounting
hardware is field sourced according to the specific application.
Winter Cover Kit S1-CCVRE***: Custom fit winter cover pro-
tects AC condensing unit from debris during the off-season.
Must be removed prior to unit operation. See Price Pages or
Source1 SmartSearch for the correct cover for each application
Touch-up Paint S1-5130153****: Color matched aerosol paint
for touching up unit chassis and panels. See Price Pages or
Source1 SmartSearch for the correct color for each application.
Thermostat: These advanced, communicating, variable capac-
ity designs require the Luxaire Hx™ Touchscreen Thermostat
available through Source1. For more information, see the ther-
mostat section of the Product Equipment Catalog.
Rated in accordance with ARI Standard 270.
AL21B6021S TPLC120C20MP13C 21.0 CM61CE4A1 High 1675 52.5 37.6 19.75 12.50
Med 1100 30.2 24.6 – 18.95
Low 825 20.6 17.8 – 35.95
AL21B6021S LP9C100C20MP13C 21.0 CM61CE4A1 High 1750 52.0 37.8 19.75 12.20
Med 1050 30.4 24.4 – 19.10
Low 700 20.4 16.3 – 37.05
AL21B6021S LP9C120D20MP13C 24.5 CM61DE4A1 High 1650 52.5 37.2 20.00 12.50
Med 1025 30.4 24.4 – 19.15
Low 775 20.8 17.4 – 36.65
AL21B6021S LPLC100C20MP13C 21.0 CM61CE4A1 High 1675 52.5 37.6 19.75 12.50
Med 1100 30.2 24.6 – 18.95
Low 825 20.6 17.8 – 35.95
AL21B6021S LPLC120C20MP13C 21.0 CM61CE4A1 High 1675 52.5 37.6 19.75 12.50
Med 1100 30.2 24.6 – 18.95
Low 825 20.6 17.8 – 35.95
For rated condition information, see the footnotes below the System Capacity - Single Piece and Modular Air Handlers table.
1. High Efficiency Motor Furnaces have B.O.D (Blower Off Delay) standard.
2. CM coils available with a factory installed horizontal drain pan. See price pages for specific model number.
COOLING CAPACITY - With High Efficiency Motor Furnaces1(Continued)
UNIT
MODEL
FURNACE COIL
MODEL2STAGE COOLING
MODEL WIDTH RATED
CFM NET MBH SEER EER
TOTAL SENS.
SOUND POWER RATINGS - COOLING
High Stage Cooling Octave Band Sound Power Level (db re. 1-pW)
Model Numbers 63 125 250 500 1000 2000 4000 8000 dBA SQI
AL21B2421S 67 69 65 68 63 59 57 53 69 19.1
AL21B3621S 71 75 69 71 69 65 59 53 73 19.1
AL21B4821S 72 73 71 71 69 64 59 54 73 19.2
AL21B6021S 75 76 73 72 70 65 61 55 74 19.0
Low Stage Cooling Octave Band Sound Power Level (db re. 1-pW)
Model Numbers 63 125 250 500 1000 2000 4000 8000 dBA SQI
AL21B2421S 63 64 52 49 46 42 33 36 53 19.0
AL21B3621S 63 64 55 59 55 50 42 37 60 19.1
AL21B4821S 64 64 72 53 50 42 36 35 64 19.1
AL21B6021S 64 65 59 56 54 49 42 38 59 19.1

5443703-LTG-B-0418
12 Johnson Controls Unitary Products
UNIT OPERATION
COOLING OPERATION
During cooling operation, the main outdoor control will receive a
communicated demand signal along with the current space
temperature and setpoint. The control algorithm will then utilize
these signals to communicate the proper compressor speed,
OD fan speed, and ID blower CFM to match system output for
the required space load.
MECHANICAL SPECIFICATIONS
MANUFACTURE AND CERTIFICATIONS
• Units shall be manufactured in an ISO 9001 certified facility.
• Units shall be certified by CSA to UL 1995 / CSA 22.2 and
performance certified to ANSI/AHRI Standard 210/240.
• Units shall be sound tested according to ANSI/AHRI Stan-
dard 270.
• Certified matched system ratings will be available for down-
load from the AHRI online directory at www.ahridirectory.org.
• Unit packaging shall be marked, “Assembled in the USA”.
• Unit shall be labeled with the ENERGY STAR logo.
• Unit shall be recognized as ENERGY STAR Most Efficient.
(May apply only to select models in each series).
UNIT APPLICATION
• Units shall be approved for cooling operation between 35ºF
and 125ºF without modification.
• Units shall be approved for linesets up to 80 feet equivalent
length without modification.
• Units shall be approved for installation within 6 inches of a
flat vertical wall without modification, according to the
instructions in the technical literature.
• Units shall be certified to the 5th Edition (2014) of the Florida
Building Code for both Ground Mounted and Rooftop
Mounted applications up to 200 feet above grade with
approved mounting kit.
UNIT ACCESS
• Units shall have a removable fan guard that can be removed
independently of the top for interior access through the top of
the unit without damaging the coil.
• Units shall have two removable stamped steel coil guards for
exterior coil access.
• Units shall have a separate compartment for electrical con-
trols that can be accessed without disturbing the unit airflow.
• Units shall have a blockoff panel that can be removed to pro-
vide interior unit access through the side of the unit.
• Units shall have a removable blockoff panel and a swing
away removable electrical panel that provides sufficient inte-
rior unit access for removing the compressor through the
side of the unit.
UNIT CONSTRUCTION
• Units shall be shipped completely wired, piped and assem-
bled. Wiring pigtails shall be provided for field control wiring
connections. Service valves shall be provided for field refrig-
erant line connections.
• Units shall be factory leak checked, run tested, and shipped
with a holding charge of R-410A refrigerant.
• Unit cabinet components shall be G90 equivalent steel fin-
ished with powder-coat paint rated at a minimum of 1,000
hours under ASTM B117 testing.
• Unit shall be constructed with a composite base pan to pre-
vent corrosion and minimize noise and vibration.
• Units shall have a single corner post opposite the electrical
control box and two independently removable steel coil
guard panels to optimize cabinet strength and serviceability.
• Units shall have L-shaped stamped sheet metal coil guards
with extruded louvers for maximum panel durability and sys-
tem protection.
• Units shall have a factory installed filter-drier for faster instal-
lation and improved system reliability.
• Unit base valves shall be mounted diagonally on the unit
base pan with service ports that provide sufficient clearance
for low-loss hose fittings.
• Units shall be constructed with a high pressure switch and a
low pressure for system protection.
• Units shall be constructed with all badging and labels applied
at the factory.
UNIT COMPONENTS
• Compressor shall be hermetic with internal electrical over-
load protection and internal overpressure protection.
• Compressor shall be mounted on rubber vibration isolators
that do not require the removal of transportation clips or
brackets.
• Units shall be constructed using a scroll compressor paired
with an inverter drive.
• Condenser fan shall be direct drive with vertical air discharge
for low sound levels.
• Condenser fan blades shall be swept-wing to minimize
sound.
• Condenser fan motor shall be ECM construction with perma-
nently lubricated ball bearing motors approved for vertical
shaft applications.
• Condenser coil shall be air cooled and constructed of
enhanced aluminum fins mechanically bonded to internally
enhanced Ø 7mm copper tubing.
UNIT WARRANTIES
• Unit manufacturer shall provide a Limited Lifetime compres-
sor warranty with unit registration.
• Unit manufacturer shall provide a limited 5-Year parts war-
ranty extended to 10 years with registration.

5443703-LTG-B-0418
Johnson Controls Unitary Products 13
TYPICAL INSTALLATION
127(
(QVXUHDPLQLPXPRI
´FOHDUDQFHEHWZHHQ
DQ\WZRXQLWV
´&/($5$1&(
$5281'3(5,0(7(5
´FOHDUDQFH
SHUPLVVLEOHRQRQH
VLGHRQO\VHH
$OWHUQDWLYH
,QVWDOODWLRQ
&OHDUDQFHV
´29(5+($'&/($5$1&(
0,1,080´6(59,&($&&(66&/($5$1&(
0DLQWDLQPLQLPXPFOHDUDQFHRQRQHVLGHRIDFFHVVSDQHO
:($7+(53522)
',6&211(&7
6:,7&+
1(&&/$66:,5,1*
7+(50267$7
1(&&/$66:,5,1*
72)851$&(25
$,5+$1'/(5
7(50,1$/%/2&.
1(&&/$66:,5,1*
&21752/$&&(66
3$1(/:,7+6:,1*
$:$<'225
6($/23(1,1*6
8VHSHUPDJXPRUHTXLYDOHQW
127(
$OORXWGRRUZLULQJ
PXVWEHZHDWKHUSURRI
612:3803836
8VHLQGHHSVQRZDUHDV
ZLWK¿IWKSXPSXSXQGHU
FHQWHURIFRPSUHVVRU
$
%5$&(6
8VHIRUZDOOPRXQWZLWK
FHQWHUEUDFHXQGHU
FHQWHURIFRPSUHVVRU
127(
(QVXUHDGHTXDWH
ZDOOVXSSRUW
&$87,216SHFLDOFDUHPXVWEHWDNHQWRDYRLGUHFLUFXODWLRQRIGLVFKDUJHDLUWKURXJKRXWGRRUFRLO
CAUTION
Care must be taken to prevent ice from damaging the unit. Damage may occur from ice falling onto unit from a sloped roof or from a vertical drip
line due to a partial overhang.
!
$
5HIHUWR&$87,21DERYH

,167$//$7,21$&&(37$%/( ,167$//$7,21$&&(37$%/( ,167$//$7,211275(&200(1'('
1229(5+$1*&29(5,1*81,7 29(5+$1*&203/(7(/<
&29(5,1*81,7
´0,1,080
29(5+($'
&/($5$1&(
127(
7KHXQLWPXVWEHLQVWDOOHGRQDVROLGEDVHDERYHWKHJUDGH
7KHEDVHPXVWQRWEHDEOHWRVHWWOHRUVKLIWFDXVLQJVWUDLQRQ
UHIULJHUDQWOLQHVDQGSRVVLEOHOHDNV
127(
,QVWDOOXQLWRQÀDWVXUIDFH,ILQVWDOODWLRQVXUIDFHLVVORSHGHQVXUH
WKDWXQLWVORSHVDZD\IURPKRXVHVWUXFWXUHDW´SHUIRRW
5HIHUWR&$87,21DERYH

&$87,216SHFLDOFDUHPXVWEHWDNHQWRDYRLGUHFLUFXODWLRQRIGLVFKDUJHDLUWKURXJKRXWGRRUFRLO
29(5+$1*3$57,$//<
&29(5,1*81,7

5443703-LTG-B-0418
14 Johnson Controls Unitary Products
TYPICAL FIELD WIRING
ALTERNATIVE INSTALLATION CLEARANCES
32:(5:,5,1*
&21752/:,5,1*
)$&725<:,5,1*
% 5 $
&
$
$//),(/':,5,1*72%(,1$&&25'$1&(:,7+(/(&75,&&2'(1(&$1'25/2&$/
7(50,1$/
%/2&.
&21752/
%2$5'
*1'
/8*
)851$&(25$,5+$1'/(57(50,1$/%/2&.
70
+[ 7+(50267$7
287'22581,7
$//287'225:,5,1*0867%(:($7+(53522)86(&233(5&21'8&725621/<
32:(5:,5,1*
92/7&21752/:,5,1*
0,1,080*$:,5(
1(&&/$66
&
$
%
% 5 $&
'2127FRQQHFWWKH³5´WHUPLQDOIURPWKHWKHUPRVWDW
WRWKHXQLWFRQWUROERDUG
:+7
*51
%/.
0,1,080&/($5$1&(%(7:((181,76
127(
&OHDUDQFHEHWZHHQWZRXQLWVPD\EH
UHGXFHGWR´PLQLPXPSURYLGHG
WKHVHUYLFHDFFHVVFOHDUDQFHLV
LQFUHDVHGWR´PLQLPXPDQGWKH
FOHDUDQFHRQHDFKUHPDLQLQJVLGH
LVPDLQWDLQHGDW´PLQLPXP
127(
&OHDUDQFHWRRQHVLGHRIWKH
XQLWPD\EHUHGXFHGWR´SURYLGHG
WKHFOHDUDQFHWRHDFKUHPDLQLQJVLGH
LVLQFUHDVHGWR´PLQLPXPWKH
VHUYLFHDFFHVVLVLQFUHDVHGWR´
PLQLPXPDQGWKHFOHDUDQFHVEHWZHHQ
DQ\WZRXQLWVLVPDLQWDLQHGDW´
PLQLPXP
0,1,080&/($5$1&()520:$//
´ ´
´
6(59,&(
$1'81,7
7281,7
´
6(59,&(
´
´
´
:$//
)(1&(
´
6(59,&(
´
6(59,&( ´
6(59,&(
´
81,7
7281,7
´
81,7
7281,7
´
´ ´ ´
´
:$//
)(1&(
&$87,21
6SHFLDOFDUHPXVWEHWDNHQWRDYRLGUHFLUFXODWLRQRIGLVFKDUJHDLUWKURXJKRXWGRRUFRLO $

5443703-LTG-B-0418
Johnson Controls Unitary Products 15
PERFORMANCE DATA - 2 TON
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 °F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
NOTICE
Outdoor units must be applied with Johnson Controls Unitary Products indoor coils, so Condenser Only data is not provided.
COOLING PERFORMANCE DATA- HIGH
AIR CONDITIONER MODEL NO. AL21B2421S
AIR TEMP.
ENTERING
OUTDOOR UNIT (°F)
IDCFM 680 780 880
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
55 T.C. 19.3 20.0 21.1 22.9 25.7 19.3 20.2 21.15 23.5 26.75 19.3 20.4 21.2 24.1 27.8 S.C. 13.4 14.1 14.3 15.7 17.7 13.45 14.25 14.4 16.05 18.15 13.5 14.4 14.5 16.4 18.6
KW 1.08 1.07 1.03 1.00 0.94 1.04 1.11 1.06 1.03 0.98 1.00 1.14 1.09 1.06 1.01
65 T.C. 19.5 20.4 21.2 23.4 26.4 19.6 20.7 21.6 24.0 27.2 19.8 21.1 22.1 24.6 28.1 S.C. 13.5 14.3 14.4 15.9 17.9 13.7 14.5 14.7 16.3 18.3 13.9 14.7 14.9 16.6 18.7
KW 1.21 1.20 1.18 1.16 1.11 1.20 1.24 1.21 1.18 1.14 1.20 1.27 1.25 1.21 1.17
75 T.C. 19.7 20.7 21.3 23.8 27.0 20.0 21.3 22.1 24.4 27.7 20.2 21.8 22.9 25.0 28.4 S.C. 13.6 14.4 14.5 16.1 18.0 13.9 14.7 14.9 16.5 18.4 14.2 15.0 15.3 16.8 18.8
KW 1.35 1.34 1.34 1.31 1.27 1.37 1.36 1.37 1.34 1.30 1.40 1.39 1.40 1.37 1.33
85 T.C. 19.9 21.1 21.4 24.3 27.1 20.4 21.8 22.3 24.9 28.0 20.9 22.5 23.2 25.5 29.0 S.C. 13.7 14.6 14.6 16.3 18.1 14.1 14.9 15.0 16.7 18.6 14.6 15.3 15.5 17.0 19.1
KW 1.62 1.61 1.61 1.60 1.57 1.65 1.64 1.65 1.63 1.60 1.68 1.68 1.68 1.66 1.63
95 T.C. 20.0 21.5 21.5 24.7 27.1 20.8 22.4 22.5 25.3 28.3 21.6 23.2 23.4 25.9 29.5 S.C. 13.8 14.7 14.7 16.5 18.1 14.4 15.2 15.2 16.9 18.7 14.9 15.6 15.6 17.2 19.3
KW 1.89 1.89 1.89 1.88 1.86 1.93 1.92 1.92 1.91 1.89 1.96 1.96 1.96 1.94 1.93
105 T.C. 20.2 21.9 21.6 25.2 27.2 21.2 22.9 22.6 25.8 28.6 22.3 23.9 23.7 26.4 30.1 S.C. 13.9 14.9 14.8 16.7 18.2 14.6 15.4 15.3 17.1 18.9 15.3 15.9 15.8 17.4 19.6
KW 2.39 2.39 2.39 2.38 2.37 2.43 2.42 2.42 2.41 2.41 2.47 2.46 2.45 2.45 2.44
115 T.C. 20.3 22.3 21.7 25.6 27.2 21.7 23.5 22.8 26.2 28.9 23.0 24.6 23.9 26.8 30.6 S.C. 14.0 15.0 14.9 16.9 18.2 14.8 15.6 15.4 17.3 19.0 15.6 16.2 15.9 17.6 19.8
KW 2.88 2.87 2.87 2.86 2.86 2.92 2.91 2.90 2.90 2.90 2.96 2.94 2.93 2.94 2.94
125 T.C. 20.5 22.7 21.8 26.1 27.3 22.1 24.0 23.0 26.7 29.2 23.7 25.3 24.2 27.3 31.2 S.C. 14.1 15.2 15.0 17.1 18.3 15.0 15.8 15.5 17.5 19.2 16.0 16.5 16.1 17.8 20.1
KW 3.36 3.35 3.35 3.35 3.36 3.41 3.39 3.38 3.39 3.40 3.45 3.43 3.42 3.43 3.44
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Green shaded cells are ACCA (TVA) conditions.
Blue shaded cells are AHRI conditions.
COIL MULTIPLIERS - 2 TON
Air Handler Coil T.C. S.C. KW
AVV25BE121 – 1.00 1.00 1.00
MVC12BN21 CM25BE1A1 1.00 1.04 1.00
FURNACE MULTIPLIERS - 2 TON
Furnaces Coil T.C. S.C. KW
TM8V080B12MP12C CM25BE1A1 1.00 1.03 1.00
TM9V060B12MP12C CM25BE1A1 0.98 0.99 1.00
TM9V080B12MP12C CM25BE1A1 1.00 1.03 1.00
TMLV080B12MP12C CM25BE1A1 1.00 1.03 1.00
TP9C060B12MP13C CM25BE1A1 0.98 0.99 1.00
TP9C080B12MP13C CM25BE1A1 1.00 1.03 1.00
TPLC080B12MP13C CM25BE1A1 1.00 1.03 1.00
LP9C060B12MP13C CM25BE1A1 0.98 0.99 1.00
LP9C080B12MP13C CM25BE1A1 1.00 1.03 1.00
LPLC080B12MP13C CM25BE1A1 1.00 1.03 1.00

5443703-LTG-B-0418
16 Johnson Controls Unitary Products
PERFORMANCE DATA - 3 TON
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 °F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
NOTICE
Outdoor units must be applied with Johnson Controls Unitary Products indoor coils, so Condenser Only data is not provided.
COOLING PERFORMANCE DATA - HIGH
AIR CONDITIONER MODEL NO. AL21B3621S
AIR TEMP.
ENTERING
OUTDOOR UNIT (°F)
IDCFM 1020 1200 1320
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
55 T.C. 29.6 30.1 32.1 34.9 36.4 29.4 30.9 33.2 35.4 37.0 29.1 31.6 34.2 35.9 37.5 S.C. 20.0 20.7 21.4 23.3 24.0 20.1 21.0 21.95 23.5 24.2 20.2 21.3 22.5 23.7 24.4
KW 1.42 1.40 1.40 1.38 1.38 1.46 1.45 1.45 1.43 1.44 1.49 1.49 1.50 1.49 1.49
65 T.C. 29.7 30.5 32.2 35.3 38.1 29.8 31.3 33.4 36.2 38.8 30.0 32.2 34.5 37.2 39.5 S.C. 20.1 20.9 21.5 23.5 25.1 20.4 21.2 22.0 23.9 25.4 20.7 21.6 22.6 24.3 25.7
KW 1.72 1.71 1.71 1.69 1.66 1.76 1.76 1.76 1.74 1.71 1.81 1.81 1.81 1.79 1.76
75 T.C. 29.8 30.9 32.3 35.6 39.8 30.3 31.8 33.6 37.1 40.6 30.8 32.7 34.8 38.5 41.4 S.C. 20.2 21.0 21.5 23.6 26.1 20.7 21.5 22.1 24.3 26.5 21.1 21.9 22.6 24.9 26.9
KW 2.02 2.02 2.02 2.00 1.93 2.07 2.07 2.07 2.05 1.98 2.12 2.12 2.12 2.10 2.04
85 T.C. 29.9 31.3 32.4 35.7 40.0 30.8 32.3 33.8 37.7 41.7 31.7 33.3 35.1 39.8 43.4 S.C. 20.3 21.2 21.6 23.8 26.3 20.9 21.7 22.1 24.6 27.2 21.6 22.2 22.6 25.5 28.2
KW 2.42 2.43 2.43 2.43 2.40 2.48 2.48 2.49 2.45 2.42 2.53 2.53 2.54 2.48 2.45
95 T.C. 30.0 31.7 32.5 35.7 40.2 31.3 32.8 34.0 38.4 42.8 32.5 33.8 35.4 41.1 45.3
S.C. 20.4 21.3 21.6 23.9 26.4 21.2 21.9 22.1 25.0 27.9 22.0 22.5 22.6 26.1 29.4
KW 2.82 2.84 2.84 2.85 2.86 2.88 2.89 2.90 2.85 2.87 2.94 2.95 2.96 2.86 2.87
105 T.C. 30.1 31.8 32.6 35.8 40.4 31.4 32.9 34.2 39.1 43.8 32.7 33.9 35.7 42.4 47.3 S.C. 20.5 21.4 21.7 24.0 26.6 21.3 22.0 22.2 25.4 28.6 22.1 22.6 22.7 26.7 30.7
KW 3.54 3.56 3.56 3.59 3.62 3.61 3.62 3.62 3.61 3.64 3.67 3.68 3.68 3.64 3.67
115 T.C. 30.2 32.0 32.7 36.0 40.5 31.5 33.0 34.4 39.8 44.9 32.8 34.0 36.0 43.7 49.2 S.C. 20.6 21.5 21.8 24.1 26.7 21.4 22.1 22.3 25.7 29.3 22.3 22.7 22.9 27.3 31.9
KW 4.24 4.26 4.26 4.30 4.35 4.31 4.32 4.32 4.35 4.40 4.38 4.38 4.39 4.40 4.44
125 T.C. 30.3 32.1 32.8 36.1 40.7 31.7 33.1 34.6 40.6 45.9 33.0 34.1 36.3 45.0 51.2 S.C. 20.7 21.6 21.9 24.2 26.9 21.6 22.2 22.5 26.1 30.0 22.4 22.8 23.0 27.9 33.2
KW 4.93 4.95 4.96 5.01 5.08 5.01 5.02 5.03 5.08 5.15 5.09 5.09 5.09 5.16 5.22
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Green shaded cells are ACCA (TVA) conditions.
Blue shaded cells are AHRI conditions.
COIL MULTIPLIERS - 3 TON
Air Handler Coil T.C. S.C. KW
AVV37BE221 – 0.99 1.03 1.03
AVV37CE221 – 1.00 1.00 1.00
MVC12BN21 CM37BE2A1 0.99 1.00 1.05
MVC16CN21 CM37CE2A1 0.99 1.00 1.03
FURNACE MULTIPLIERS - 3 TON
Furnaces Coil T.C. S.C. KW
TM8V080B12MP12C CM37BE2A1 0.99 1.03 1.09
TM8V080C16MP12C CM37CE2A1 0.99 1.01 1.03
TM8V100C16MP12C CM37CE2A1 0.99 1.01 1.03
TM9V080B12MP12C CM37BE2A1 0.99 1.02 1.09
TM9V080C16MP12C CM37CE2A1 0.99 0.99 1.03
TM9V100C16MP12C CM37CE2A1 0.99 1.04 1.05
TMLV080B12MP12C CM37BE2A1 0.99 1.03 1.09
TMLV080C16MP12C CM37CE2A1 0.99 1.01 1.03
TMLV100C16MP12C CM37CE2A1 0.99 1.01 1.03
TP9C080B12MP13C CM37BE2A1 0.99 1.02 1.09
TP9C080C16MP13C CM37CE2A1 0.99 0.99 1.03
TP9C100C16MP13C CM37CE2A1 0.99 1.04 1.05
TPLC080B12MP13C CM37BE2A1 0.99 1.03 1.09
TPLC080C16MP13C CM37CE2A1 0.99 1.01 1.03
TPLC100C16MP13C CM37CE2A1 0.99 1.01 1.03
LP9C080B12MP13C CM37BE2A1 0.99 1.02 1.09
LP9C080C16MP13C CM37CE2A1 0.99 0.99 1.03
LP9C100C16MP13C CM37CE2A1 0.99 1.04 1.05
LPLC080B12MP13C CM37BE2A1 0.99 1.03 1.09
LPLC080C16MP13C CM37CE2A1 0.99 1.01 1.03
LPLC100C16MP13C CM37CE2A1 0.99 1.01 1.03
FURNACE MULTIPLIERS - 3 TON (Continued)
Furnaces Coil T.C. S.C. KW

5443703-LTG-B-0418
Johnson Controls Unitary Products 17
PERFORMANCE DATA - 4 TON
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 °F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
NOTICE
Outdoor units must be applied with Johnson Controls Unitary Products indoor coils, so Condenser Only data is not provided.
COOLING PERFORMANCE DATA - HIGH
AIR CONDITIONER MODEL NO. AL21B4821S
AIR TEMP.
ENTERING
OUTDOOR UNIT (°F)
IDCFM 1360 1560 1760
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
55 T.C. 40.4 42 42.1 45 45.5 42.4 42.9 43.0 45.0 45.4 44.4 43.8 43.9 44.9 45.3 S.C. 27.2 28.1 28.0 30.0 30.3 29.0 28.8 28.7 30.0 30.2 30.8 29.4 29.3 30.0 30.1
KW 2.10 1.85 1.85 1.82 1.81 2.16 1.91 1.92 1.89 1.89 2.22 1.97 1.98 1.96 1.96
65 T.C. 40.8 42.3 42.5 46.1 49.1 42.7 43.3 43.3 46.5 49.2 44.6 44.2 44.2 46.9 49.3 S.C. 27.5 28.4 28.4 30.8 32.7 29.2 29.1 29.0 31.1 32.7 30.9 29.8 29.6 31.4 32.8
KW 2.40 2.27 2.27 2.25 2.23 2.46 2.34 2.34 2.32 2.31 2.53 2.40 2.41 2.39 2.38
75 T.C. 41.1 42.6 42.8 47.2 52.6 43.0 43.6 43.6 48.0 53.0 44.8 44.6 44.4 48.8 53.3 S.C. 27.8 28.7 28.7 31.6 35.0 29.4 29.4 29.3 32.2 35.3 31.0 30.1 29.8 32.7 35.5
KW 2.70 2.69 2.69 2.68 2.65 2.76 2.76 2.77 2.75 2.73 2.83 2.83 2.84 2.82 2.80
85 T.C. 41.5 42.9 43.2 47.7 52.9 43.2 43.9 44.0 48.5 53.6 45.0 45.0 44.8 49.3 54.2 S.C. 28.1 29.0 29.1 32.0 35.4 29.6 29.7 29.6 32.6 35.8 31.1 30.4 30.1 33.2 36.3
KW 3.28 3.29 3.29 3.29 3.30 3.35 3.36 3.36 3.37 3.37 3.43 3.43 3.44 3.44 3.45
95 T.C. 41.8 43.2 43.5 48.1 53.2 43.5 44.3 44.3 48.9 54.2 45.1 45.3 45.1 49.7 55.1 S.C. 28.4 29.3 29.4 32.4 35.8 29.8 30.0 29.9 33.0 36.4 31.2 30.7 30.4 33.6 37.0
KW 3.86 3.88 3.88 3.91 3.94 3.94 3.96 3.96 3.99 4.02 4.03 4.04 4.04 4.07 4.10
105 T.C. 41.5 43.2 43.5 47.5 55.8 43.1 43.9 44.3 48.3 54.7 44.6 44.6 45.0 49.0 53.5 S.C. 28.3 29.3 29.4 32.3 38.3 29.4 29.9 29.9 32.9 37.6 30.5 30.4 30.3 33.4 36.9
KW 4.58 4.60 4.60 4.65 4.72 4.67 4.68 4.68 4.73 4.79 4.76 4.77 4.76 4.82 4.85
115 T.C. 41.3 43.0 42.7 46.9 52.4 42.7 43.5 43.8 47.6 52.2 44.1 43.9 44.9 48.3 51.9 S.C. 28.2 29.3 29.4 32.2 36.6 29.0 29.7 29.8 32.7 36.7 29.8 30.1 30.2 33.2 36.8
KW 5.62 5.64 5.64 5.72 5.81 5.72 5.74 5.74 5.82 5.89 5.83 5.83 5.83 5.92 5.98
125 T.C. 37.3 38.0 38.1 41.2 45.8 38.6 38.9 38.8 41.9 46.5 39.8 39.8 39.5 42.5 47.2 S.C. 25.9 26.4 26.3 28.4 31.5 26.7 27.1 26.8 28.9 32.0 27.4 27.8 27.3 29.4 32.5
KW 5.78 5.69 5.68 6.80 6.89 5.77 5.79 5.76 6.91 7.00 5.76 5.90 5.84 7.02 7.11
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Green shaded cells are ACCA (TVA) conditions.
Blue shaded cells are AHRI conditions.
COIL MULTIPLIERS - 4 TON
Air Handler Coil T.C. S.C. KW
AVV49CE321 – 1.00 0.95 1.00
AVV49DE321 – 1.00 1.00 1.00
MVC16CN21 CM49CE3A1 1.00 0.95 1.00
MVC20DN21 CM49DE3A1 1.00 0.96 1.00
FURNACE MULTIPLIERS - 4 TON
Furnaces Coil T.C. S.C. KW
TM8V080C16MP12C CM49CE3A1 1.00 0.96 1.04
TM8V100C16MP12C CM49CE3A1 1.00 0.96 1.04
TM8V100C20MP12C CM49CE3A1 1.00 0.96 1.04
TM8V120C20MP12C CM49CE3A1 1.00 0.96 1.04
TM9V080C16MP12C CM49CE3A1 1.00 0.96 1.06
TM9V100C16MP12C CM49CE3A1 1.00 0.96 1.04
TM9V100C20MP12C CM49CE3A1 1.00 0.98 1.07
TM9V120D20MP12C CM49DE3A1 1.00 0.95 1.04
TMLV080C16MP12C CM49CE3A1 1.00 0.96 1.04
TMLV100C16MP12C CM49CE3A1 1.00 0.96 1.04
TMLV100C20MP12C CM49CE3A1 1.00 0.96 1.04
TMLV120C20MP12C CM49CE3A1 1.00 0.96 1.04
TP9C080C16MP13C CM49CE3A1 1.00 0.96 1.06
TP9C100C16MP13C CM49CE3A1 1.00 0.96 1.04
TP9C100C20MP13C CM49CE3A1 1.00 0.98 1.07
TP9C120D20MP13C CM49DE3A1 1.00 0.95 1.04
TPLC080C16MP13C CM49CE3A1 1.00 0.96 1.04
TPLC100C16MP13C CM49CE3A1 1.00 0.96 1.04
TPLC100C20MP13C CM49CE3A1 1.00 0.96 1.04
TPLC120C20MP13C CM49CE3A1 1.00 0.96 1.04
LP9C080C16MP13C CM49CE3A1 1.00 0.96 1.06
LP9C100C16MP13C CM49CE3A1 1.00 0.96 1.04
LP9C100C20MP13C CM49CE3A1 1.00 0.98 1.07
LP9C120D20MP13C CM49DE3A1 1.00 0.95 1.04
LPLC080C16MP13C CM49CE3A1 1.00 0.96 1.04
LPLC100C16MP13C CM49CE3A1 1.00 0.96 1.04
LPLC100C20MP13C CM49CE3A1 1.00 0.96 1.04
LPLC120C20MP13C CM49CE3A1 1.00 0.96 1.04
FURNACE MULTIPLIERS - 4 TON (Continued)
Furnaces Coil T.C. S.C. KW

Subject to change without notice. Published in U.S.A. 5443703-LTG-B-0418
Copyright © 2018 by Johnson Controls, Inc. All rights reserved. Supersedes: 5443703-LTG-A-1017
York International Corp.
5005 York Drive
Norman, OK 73069
PERFORMANCE DATA - 5 TON
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 °F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the listed
temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
NOTICE
Outdoor units must be applied with Johnson Controls Unitary Products indoor coils, so Condenser Only data is not provided.
COOLING PERFORMANCE DATA - HIGH
AIR CONDITIONER MODEL NO. AL21B6021S
AIR TEMP.
ENTERING
OUTDOOR UNIT (°F)
IDCFM 1530 1800 1980
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
55 T.C. 51.3 53.7 54.6 58.4 59.8 52.9 55.0 55.6 58.6 59.6 54.4 56.3 56.5 58.7 59.4 S.C. 34.7 35.5 35.7 39.4 40.2 36.0 36.8 36.9 39.6 40.1 37.3 38.0 38.0 39.7 40.0
KW 2.60 2.58 2.58 2.56 2.54 2.67 2.66 2.66 2.63 2.62 2.74 2.73 2.73 2.71 2.70
65 T.C. 51.3 53.8 54.6 58.9 62.7 53.0 55.1 55.6 59.5 62.9 54.7 56.4 56.6 60.2 63.1 S.C. 34.7 36.1 36.3 40.1 42.4 36.1 37.2 37.3 40.5 42.6 37.5 38.2 38.3 41.0 42.8
KW 3.13 3.13 3.13 3.13 3.13 3.21 3.22 3.22 3.21 3.22 3.30 3.30 3.30 3.29 3.31
75 T.C. 51.3 53.8 54.6 59.3 65.5 53.1 55.1 55.6 60.5 66.2 54.9 56.4 56.6 61.7 66.8 S.C. 34.7 36.7 36.8 40.8 44.6 36.2 37.6 37.7 41.5 45.1 37.6 38.4 38.5 42.2 45.5
KW 3.65 3.69 3.68 3.70 3.72 3.76 3.78 3.78 3.79 3.82 3.86 3.87 3.87 3.88 3.91
85 T.C. 51.3 53.9 54.7 59.8 65.5 53.2 55.2 55.7 60.8 66.5 55.1 56.5 56.7 61.8 67.5 S.C. 35.3 37.3 37.4 41.3 45.3 36.6 38.2 38.2 42.0 45.9 37.9 39.0 39.0 42.8 46.6
KW 4.49 4.52 4.52 4.56 4.60 4.59 4.62 4.62 4.65 4.69 4.69 4.71 4.71 4.75 4.79
95 T.C. 51.3 53.9 54.8 60.2 65.5 53.3 55.3 55.8 61.1 66.9 55.3 56.6 56.7 61.9 68.2 S.C. 35.9 37.9 37.9 41.7 45.9 37.1 38.8 38.7 42.5 46.8 38.2 39.6 39.4 43.3 47.7
KW 5.33 5.36 5.36 5.42 5.47 5.42 5.46 5.46 5.51 5.57 5.52 5.55 5.55 5.61 5.67
105 T.C. 47.6 49.8 50.1 55.5 61.3 49.5 51.0 51.1 56.6 62.7 51.4 52.2 52.1 57.6 64.0 S.C. 34.1 35.6 35.8 39.5 43.3 35.5 36.5 36.5 40.2 44.2 36.8 37.3 37.2 40.8 45.1
KW 5.90 5.94 5.94 6.00 6.08 6.01 6.04 6.03 6.10 6.17 6.12 6.14 6.13 6.20 6.27
115 T.C. 44.2 45.8 46.0 52.1 56.5 45.8 47.1 46.9 53.3 57.7 47.3 48.3 47.7 54.4 58.8 S.C. 31.3 32.8 32.9 36.7 40.4 32.7 33.8 33.6 37.5 41.2 34.0 34.8 34.3 38.3 41.9
KW 6.50 6.52 6.52 6.59 6.68 6.59 6.60 6.61 6.68 6.77 6.68 6.69 6.70 6.77 6.87
125 T.C. 39.5 41.8 41.4 46.7 52.2 41.1 42.9 42.5 47.5 53.1 42.6 44.0 43.6 48.2 53.9 S.C. 28.4 30.1 30.4 33.7 37.4 29.7 31.0 31.0 34.3 38.0 30.9 31.9 31.6 34.8 38.6
KW 7.15 7.21 7.19 7.27 7.34 7.24 7.29 7.28 7.36 7.43 7.34 7.37 7.36 7.45 7.52
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT. KW VALUES ARE FOR THE SYSTEM (OUTDOOR + INDOOR).
Green shaded cells are ACCA (TVA) conditions.
Blue shaded cells are AHRI conditions.
COIL MULTIPLIERS - 5 TON
Air Handler Coil T.C. S.C. KW
AVV61CE421 – 1.00 0.98 1.04
AVV61DE421 – 1.00 1.00 1.00
MVC20DN21 CM61DE4A1 1.00 0.99 1.00
FURNACE MULTIPLIERS - 5 TON
Furnaces Coil T.C. S.C. KW
TM8V100C20MP12C CM61CE4A1 1.00 0.97 1.04
TM8V120C20MP12C CM61CE4A1 1.00 0.97 1.04
TM9V100C20MP12C CM61CE4A1 0.99 0.98 1.06
TM9V120D20MP12C CM61DE4A1 1.00 0.96 1.04
TMLV100C20MP12C CM61CE4A1 1.00 0.97 1.04
TMLV120C20MP12C CM61CE4A1 1.00 0.97 1.04
TP9C100C20MP13C CM61CE4A1 0.99 0.98 1.06
TP9C120D20MP13C CM61DE4A1 1.00 0.96 1.04
TPLC100C20MP13C CM61CE4A1 1.00 0.97 1.04
TPLC120C20MP13C CM61CE4A1 1.00 0.97 1.04
LP9C100C20MP13C CM61CE4A1 0.99 0.98 1.06
LP9C120D20MP13C CM61DE4A1 1.00 0.96 1.04
LPLC100C20MP13C CM61CE4A1 1.00 0.97 1.04
LPLC120C20MP13C CM61CE4A1 1.00 0.97 1.04
FURNACE MULTIPLIERS - 5 TON (Continued)
Furnaces Coil T.C. S.C. KW
