Luxaire Climasure pac030 Quick start guide

FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE

246836-LTG-E-0107

TECHNICAL GUIDE Description

These Luxaire®Climasure™ packaged cooling/heating air

conditioners are designed for outdoor installation. Only utility

and duct connections are required at the point of installation.

Field-installed electric heater accessories are available to

provide electric heat, if required. (Single phase only)

CLIMASURE™ SERIES

R-22, 13 SEER

60 Hertz

Tested in accordance with:

ISO 9001

Certified Quality

Management System

246836-LTG-E-0107

2Unitary Products Group

Table of Contents

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Component Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Nomenclature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Features and Benefits. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Guide Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Physical Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Capacity Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Airflow Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Sound Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Weights and Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Component Location

Cooling Unit and Heat Pump

'LUHFW'ULYH

&RQGHQVHU)DQ0RWRU

'HFRUDWLYH3URWHFWLYH

&RLO*XDUG

+HDY\*DXJH

%DVH5DLOV

&RQWURO%R[6HUYLFH

$FFHVV3DQHO

5HIULJHUDQW

&RQQHFWLRQV

;'LUHFW'ULYH

%ORZHU0RWRU

%ORZHU6HUYLFH

$FFHVV3DQHO

+LJK(IILFLHQF\(QKDQFHG

&RSSHU7XEH$OXPLQXP)LQ

2XWGRRU&RLO

+LJK(IILFLHQF\(QKDQFHG

&RSSHU7XEH$OXPLQXP)LQ

InGRRU&RLO

+LJK(IILFLHQF\

&RPSUHVVRU5LJLGO\

0RXQWHG

246836-LTG-E-0107

Unitary Products Group 3

Nomenclature

Cooling Unit

Heat Pump

Features and Benefits

Standard Features

•Operating Efficiency - All cooling units provide a SEER

of 13.0.

All heat pump units provide operating efficiency of 13.0

SEER and 7.7 HSPF. All efficiencies meet legislated

minimum levels.

•Lower Installation Cost - Installation time and costs are

reduced by easy power and control wiring connections.

The small base dimension means less space is required

on the ground or roof, plus, the installer can fit this unit

between the wheel wells of full size pick-up truck. All

models are well under 400 pounds.

All units are completely wired, charged with R-22 and

tested prior to shipment. Unique test stations using a new

state of the art computerized process system are used to

insure product quality. Refrigerant charge and component

part numbers are verified via computers at assembly. Vital

run test statistics such as system pressure, motor

currents, air velocity and temperature, unit vibration, and

gas system safeties are monitored and recorded by the

system to insure unit performance.

Equal size, side supply and return duct connections

allows easy hook-up of ducts to match low crawl spaces

without transition pieces.

•Utility Connections Made Easy - Electric utility

knockouts are provided through the side of the unit. Utility

connections can be made quickly and with a minimum

amount of field labor. A field supplied and field installed

electrical disconnect switch must be installed.

•Condensate Pan - A non-corrosive, long-lasting, water-

tight pan is positioned below the evaporator coil to collect

PAC 036 2 1 AH 13

Cabinet Layout

H = Horizontal

Product Category

PAC = Air Conditioner, Single Package, R-22

Unit Efficiency

13 = 13 SEER

024 = 2.0 Ton

030 = 2.5 Ton

036 = 3.0 Ton

Voltage Code

2 = 208/230-1-60

3 = 208/230-3-60

4 = 460-3-60

8 = 380/415-3-50

Product Style

A = Style A

Product Generation

1 = First Generation

2 = Second Generation

042 = 3.5 Ton

048 = 4.0 Ton

060 = 5.0 Ton

Nominal Cooling Capacity (MBH)

3+3    $+ 

&DELQHW/D\RXW

+ +RUL]RQWDO

3URGXFW&DWHJRU\

3+3 +HDW3XPS6LQJOH3DFNDJH5

8QLW(IILFLHQF\

 6((5

 7RQ

 7RQ

 7RQ

9ROWDJH&RGH

 

 

 

 

3URGXFW6W\OH

$ 6W\OH$

3URGXFW*HQHUDWLRQ

 )LUVW*HQHUDWLRQ

 6HFRQG*HQHUDWLRQ

 7RQ

 7RQ

 7RQ

1RPLQDO&RROLQJ&DSDFLW\0%+

246836-LTG-E-0107

4Unitary Products Group

and drain all condensate. Less collection of stagnate

condensate will build-up. The condensate pan conforms

to ASHRAE 62-89 standards (Ventilation for Acceptable

Indoor Air Quality).

•Condensate Drain - The heavy duty, 3/4 inch NPTI

copper connection is more durable over time. The

connection is rigidly mounted to assure proper fit and leak

tight seal.

•Durable Finish - With a heavy duty cabinet made of pre-

painted, galvanized steel the neutral color blends into

surrounding areas. The pre-paint provides a better paint

to steel bond, which resists corrosion and rust creep,

insures less fading when exposed to sunlight and offers a

more attractive on site appearance.

•Full Perimeter Base Rails - The base rails provide a

solid foundation for the entire unit and protects the unit

during shipment. The rails provide fork lift access from all

sides. On applications where the unit is placed on a pad,

the base will keep the unit off the pad to deter corrosion.

•More Attractive Appearance - A single piece Water

Shed top cover containing a top discharge condenser fan

arrangement requires less square footage on installation

and provides a wider variety of installations. The one

piece design adds greater water integrity.

•Top Discharge - The top discharge condenser fan does

not disrupt neighboring areas or dry-out vegetation

surrounding the unit. The warm air from the top mounted

fan is blown up away from the structure and any

landscaping. This allows compact location on multi-unit

applications.

•Condenser Coil Guard - A multi-piece totally enclosed,

rigidly mounted condenser coil guard provides protection

from objects after installation and provides protection

during transit.

•Low Operating Sound Level - The upward air flow

carries the normal operating noise up and away from the

living area. The rigid top panel effectively isolates any

motor sound. Isolator mounted compressor and the

rippled fins of the condenser coil muffle the normal fan

motor and compressor operating sounds.

•Fan System - All models operate over a wide range of

design conditions with a constant torque fan motor. These

units have 5 speed taps to provide greater on site flexibility

to match comfort requirements.

•Protected Compressor - The compressor is internally

protected against high pressure and temperature. This is

accomplished by the simultaneous operation of high

pressure relief valve and a temperature sensor which protect

the compressor if undesirable operating conditions occur.

•Pressure Switches - High pressure switches standard in

all heat pump units. When abnormal conditions are

sensed through the pressure switches, the unit will lock

out after 3 tries preventing any further operation until reset

or problem is corrected.

•Exclusive Coil Design - Grooved copper tubes and

enhanced aluminum fin construction improves heat

transfer for maximum efficiency and durability.

•Low Maintenance - Long life, permanently lubricated

condenser and evaporator fan motor bearings need no

annual maintenance adding greater reliability to the unit.

•Secured Service Access Ports - Protected, externally

mounted, re-usable service access ports are provided on

both the high and low lines for ease of evacuating and

charging the system. No final field mounting required.

•Easy Service Access - A large, single panel covers the

electrical controls makes servicing easy. The blower

compartment has a large panel which when removed will

allow the blower fan assembly to slide-out for ease of

maintenance and trouble shooting.

•Replacement Parts - The installer requires no special

training to replace any of the components of these units

and does not need to maintain an inventory of unique

parts.

Field Installed Accessories

•Wall Thermostat - The units are designed to operate with

24-volt electronic and electro-mechanical thermostats.

•Electric Heat Kit - Available in 3 different kW capacities

(5, 10 and 15 kW). (Single phase only)

•Start Assist Kits - Available for all models.

•Outdoor Thermostat - Available for all heat pump models.

Guide Specifications

GENERAL

Units shall be factory-assembled, single packaged, Electric

Cooling units, designed for outdoor mounted installation. Units

shall have minimum SEER ratings of 13.0. Heat pump 7.7 HSPF.

The units shall be factory wired, piped, charged with R-22

refrigerant and factory tested prior to shipment. All unit wiring

shall be color coded.

All units shall be manufactured in a facility certified to ISO 9001

standards, and the cooling performance shall be rated in

accordance with DOE and ARI test procedures. Units shall be

certified to UL 1995/CAN/CSA C22.2 No. 236 standards.

UNIT CABINET

1. Unit cabinet shall be constructed of G90, pre-paint textured

steel, certified at 500 hours salt spray test per ASTMB117

standards.

2. The unit top shall be a single piece "Water Shed" design.

3. Unit shall have a rigidly mounted condenser coil guard to

provide protection from objects and personnel after

installation.

4. Indoor blower section shall be insulated with up to 3/4"

thick insulation.

5. Cabinet panels shall be "large" size, easily removable for

servicing and maintenance.

246836-LTG-E-0107

Unitary Products Group 5

6. Unit shall be built on a formed, "Super-Structure" design

base pan, with embossments at critical points to add

strength, rigidity and aid in minimizing sound.

7. Full perimeter base rails shall be provided to assure

reliable transit of equipment.

8. Condensate pan shall be internally sloped and conform to

ASHARE 62-89 self-draining standards, with 3/4" NPTI

copper, ridged mount connection.

INDOOR (EVAPORATOR) FAN ASSEMBLY

1. Fan shall be direct drive, constant torque design with 5

available speed selections.

2. Fan wheel shall be double-inlet type with forward-curved

blades, dynamically balanced to operate smoothly

throughout the entire range of operation. Airflow design

shall be constant air volume.

3. Bearings shall be sealed and permanently lubricated for

longer life and no maintenance.

4. Fan assembly shall be accessible via removable inlet ring.

OUTDOOR (CONDENSER) FAN ASSEMBLY

1. The outdoor fan shall be of the direct-driven propeller type,

discharge air vertically, have aluminum blades riveted to

corrosion resistant steel spider bracket and shall be

statically balanced for smooth operation.

2. The outdoor fan motor shall be totally enclosed with

permanently lubricated bearings and internally protected

against overload conditions.

REFRIGERANT COMPONENTS

Compressors:

a. Shall be fully hermetic reciprocating, rotary or scroll type,

direct drive, internally protected with internal high-

pressure relief and over temperature protection. The

hermetic motor shall be suction gas cooled and have a

voltage range of + or - 10% of the unit nameplate

voltage.

b. Shall have internal isolation and sound muffling to

minimize vibration and noise, and be externally isolated

on a dedicated, independent mounting.

Coils:

a. Evaporator and condenser coils shall have aluminum

plate fins mechanically bonded to seamless internally-

enhanced copper tubes with all joints brazed.

b. Evaporator and Condenser coils shall be of the direct

expansion, draw-thru design.

Refrigerant Circuit and Refrigerant Safety Components shall

include:

a. Independent fixed-orifice or TXV expansion devices.

b. Filter/strainer to eliminate any foreign matter.

c. Accessible service gage connections on both suction

and discharge lines to charge, evacuate, and measure

refrigerant pressure during any necessary servicing or

troubleshooting, without losing charge and without

disrupting condenser or evaporator air flow.

Unit Controls:

a. Controls shall be mounted in a large control box, allowing

easy access for trouble shooting and maintenance

without affecting the normal system operation pressures.

b. Unit shall have large, easily removable panels, covering

electrical controls and compressor, allowing easy access

for any necessary maintenance or servicing.

ELECTRIC HEATING SECTION

1. An electric heating section, with nickel chromium elements,

shall be provided in a range of 5 thru 15 KW, single phase

only.

2. The heating section shall have a primary limit control(s)

and automatic reset, to prevent the heating element

system from operating at an excessive temperature.

3. The heating section assembly shall slide out of the unit for

easy maintenance and service.

UNIT OPERATING CHARACTERISITCS

1. Unit shall be capable of starting and running at 125° F

outdoor temperature, exceeding maximum load criteria of

ARI Standard 210/240.

2. The compressor, with standard controls, shall be capable

of cooling operation down to 45° F outdoor temperature.

Accessory low ambient kit shall be available for operation

to 0° F.

ELECTRICAL REQUIREMENTS

All unit power wiring shall enter unit cabinet at a single factory

provided location.

Separate openings shall be provided for the control wiring.

246836-LTG-E-0107

6Unitary Products Group

Physical Data

PAC024-060 Physical Data

Component Models

PAC024 PAC030 PAC036 PAC042 PAC048 PAC060

Nominal Tonnage 2.0 2.5 3.0 3.5 4.0 5.0

ARI COOLING PERFORMANCE

Gross Capacity @ ARI A point (Btu) 22900 28800 36100 42100 47100 58000

ARI net capacity (Btu) 22500 28000 35100 41000 46200 56400

EER 11.5 11.4 11.3 11.4 11.65 11.4

SEER 13 13 13 13 13 13

Nominal CFM 800 1000 1100 1200 1400 1650

System power (KW) 1.96 2.6 3.10 3.60 3.97 4.94

Refrigerant type R-22 R-22 R-22 R-22 R-22 R-22

Refrigerant charge (lb-oz)

System 1 5-5 6-6 7-0 7-12 8-0 10-8

DIMENSIONS (inches)

Length 45-1/4 45-1/4 47-1/4 47-1/4 57-9/16 57-9/16

Width 30-13/16 30-13/16 32-13/16 32-13/16 32-13/16 32-13/16

Height 26-11/16 26-11/16 30-11/16 30-11/16 34-11/16 34-11/16

OPERATING WT. (lbs.) 259 270 345 349 375 385

COMPRESSORS

Type Recip Rotary Recip Recip Recip Scroll

Quantity 111111

CONDENSER COIL DATA

Face area (Sq. Ft.) 9.2 9.2 11.3 11.3 16.0 16.0

Rows 222222

Fins per inch 15 15 15 15 15 15

Tube diameter (in.) 3/8 3/8 3/8 3/8 3/8 3/8

Circuitry Type Intertwined Intertwined Intertwined Intertwined Intertwined Intertwined

EVAPORATOR COIL DATA

Face area (Sq. Ft.) 3.61 3.61 4.67 4.67 5.44 5.44

Rows 334434

Fins per inch 13 13 13 13 13 13

Tube diameter 3/8 3/8 3/8 3/8 3/8 3/8

Circuitry Type Intertwined Intertwined Intertwined Intertwined Intertwined Intertwined

Refrigerant control Orifice Orifice Orifice Orifice Orifice Orifice

CONDENSER FAN DATA

Quantity 111111

Fan diameter (Inch) 18 18 20 20 22 22

Type Prop Prop Prop Prop Prop Prop

Drive type Direct Direct Direct Direct Direct Direct

No. speeds 1 1 1 1 1 1

Number of motors 1 1 1 1 1 1

Motor HP each 1/4 1/4 1/4 1/4 1/3 1/3

RPM 850 850 1100 1100 1100 1100

Nominal total CFM 2200 2200 2800 2800 3200 3200

DIRECT DRIVE EVAP FAN DATA

Quantity 111111

Fan Size (Inch) 10 x 7 10 x 7 10 x 7 10 x 7 11 x 10 11 x 10

Type Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal

Motor HP each 1/2 1/2 1/2 1/2 1 1

RPM 1100 1100 1100 1100 1100 1100

Frame size 48 48 48 48 48 48

FILTERS

Quantity-Size ------

246836-LTG-E-0107

Unitary Products Group 7

PHP024-060 Physical Data

Component Models

PHP024 PHP030 PHP036 PHP042 PHP048 PHP060

Nominal Tonnage 2.0 2.5 3.0 3.5 4.0 5.0

ARI COOLING PERFORMANCE

Gross Capacity @ ARI A point (Btu) 25160 29700 37000 45800 50600 55700

ARI net capacity (Btu) 24660 29000 36000 44700 49300 53600

EER 11.95 11.5 11.3 11.9 12.2 11.15

SEER 13 13 13 13 13 13

Nominal CFM 900 1000 1150 1400 1500 1750

System power (KW) 2060 2500 3200 3740 4030 4820

Refrigerant type R-22 R-22 R-22 R-22 R-22 R-22

Refrigerant charge (lb-oz)

System 1 10-4 10-8 10-8 11-8 11-8 11-8

ARI HEATING PERFORMANCE

47°F Capacity Rating (MBH) 22400 25900 32100 39600 43900 50000

System Power KW/COP 1760/3.70 2100/3.60 2780/3.40 3420/3.40 3750/3.45 4580/3.25

17°F Capacity Rating (MBH) 10500 12900 17300 19900 23600 29000

System Power KW/COP 1490/2.10 1770/2.15 2410/2.10 2835/2.05 3400/2.05 3980/2.10

HSPF BTU/Watts-hr 7.7 7.7 7.7 7.7 7.7 7.7

DIMENSIONS (inches)

Length 47-1/4 47-1/4 47-1/4 57-9/16 57-9/16 57-9/16

Width 32-13/16 32-13/16 32-13/16 32-13/16 32-13/16 32-13/16

Height 30-11/16 30-11/16 30-11/16 34-11/16 34-11/16 34-11/16

OPERATING WT. (lbs.) 342 347 350 372 382 390

COMPRESSORS

Type Recip Recip Recip Recip Scroll Scroll

Quantity 111111

CONDENSER COIL DATA

Face area (Sq. Ft.) 11.28 11.28 11.28 16 16 16

Rows 222222

Fins per inch 15 15 15 15 15 15

Tube diameter (in.) 3/8 3/8 3/8 3/8 3/8 3/8

Circuitry Type Intertwined Intertwined Intertwined Intertwined Intertwined Intertwined

Refrigerant Control TXV TXV TXV TXV TXV TXV

EVAPORATOR COIL DATA

Face area (Sq. Ft.) 4.67 4.67 4.67 5.44 5.44 5.44

Rows 444444

Fins per inch 13 13 13 13 13 13

Tube diameter 3/8 3/8 3/8 3/8 3/8 3/8

Circuitry Type Intertwined Intertwined Intertwined Intertwined Intertwined Intertwined

Refrigerant control Orifice Orifice Orifice Orifice Orifice Orifice

CONDENSER FAN DATA

Quantity 111111

Fan diameter (Inch) 20 20 20 22 22 22

Type Prop Prop Prop Prop Prop Prop

Drive type Direct Direct Direct Direct Direct Direct

No. speeds 111111

Numberofmotors 111111

Motor HP each 1/4 1/4 1/4 1/3 1/3 1/3

RPM 850 850 1100 1100 1100 1100

Nominal total CFM 2500 2500 2850 3200 3200 3200

DIRECT DRIVE EVAP FAN DATA

Quantity 111111

Fan diameter (Inch) 10 x 7 10 x 7 10 x 7 11 x 10 11 x 10 11 x 10

Type Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal

Drive type Direct Direct Direct Direct Direct Direct

No. speeds 555555

Numberofmotors 111111

Motor HP each 1/2 1/2 1/2 1 1 1

RPM 1100 1100 1100 1100 1100 1100

Frame size 48 48 48 48 48 48

246836-LTG-E-0107

8Unitary Products Group

PAC and PHP Unit Limitations

Size

(Tons) Model Unit Voltage Unit Limitations

Applied Voltage Outdoor DB Temp

Min Max Max (°F)

024

(2.0) PAC

PHP 208/230-1-60 187 252 125

030

(2.5) PAC

PHP 208/230-1-60 187 252 125

036

(3.0) PAC

PHP 208/230-1-60 187 252 125

208/230-3-60 187 252 125

042

(3.5) PAC

PHP 208/230-1-60 187 252 125

048

(4.0) PAC

PHP

208/230-1-60 187 252 125

208/230-3-60 187 252 125

460-3-60 432 504 125

060

(5.0) PAC

PHP

208/230-1-60 187 252 125

208/230-3-60 187 252 125

460-3-60 432 504 125

246836-LTG-E-0107

Unitary Products Group 9

Capacity Performance

PAC024-060 Cooling Capacities

PAC024 (2.0 Ton)

Air on

Evaporator Coil Temperature of Air on Condenser Coil

Total

Capacity1

(MBh)

1. These capacities are gross ratings. For net capacity, deduct air blower motor, MBh = 3.415 x kW. Refer to the appropriate Blower Performance Table for the

kW of the supply air blower motor.

Total

Input

(kW)2

2. These ratings include the condensate fan motors (total .25 kW) and the compressor motors but not the supply air blower motor.

Sensible Capacity (MBh) Total

Capacity1

(MBh)

Total

Input

(kW)2

Sensible Capacity (MBh)

CFM WB

(°F) Return Dry Bulb (°F) Return Dry Bulb (°F)

86 83 80 77 74 71 68 86 83 80 77 74 71 68

75°F 85°F

600

72 28.6 1.4 16.5 14.8 13.1 11.4 9.7 - - 26.6 1.6 15.9 14.2 12.5 10.8 9.1 - -

67 26.4 1.5 20.0 18.3 16.5 14.8 13.1 11.4 9.7 24.5 1.7 19.3 17.6 15.9 14.2 12.5 10.7 9.0

62 24.5 1.6 24.3 22.2 20.5 18.8 17.1 15.4 13.7 22.8 1.7 22.7 21.0 19.3 17.6 15.9 14.2 12.5

57 24.5 1.6 24.3 22.2 20.5 18.8 17.1 15.4 13.7 22.8 1.7 22.7 21.0 19.3 17.6 15.9 14.2 12.5

700

72 29.4 1.4 18.2 16.2 14.1 12.1 10.1 - - 27.3 1.6 17.6 15.5 13.5 11.5 9.5 - -

67 27.2 1.5 21.9 19.9 17.9 15.9 13.8 11.8 9.8 25.2 1.6 21.2 19.2 17.2 15.1 13.1 11.1 9.1

62 25.2 1.6 25.1 24.0 22.2 20.1 18.1 16.1 14.1 23.4 1.7 23.4 22.5 20.9 18.9 16.8 14.8 12.8

57 25.2 1.6 25.1 24.0 22.2 20.1 18.1 16.1 14.1 23.4 1.7 23.4 22.5 20.9 18.9 16.8 14.8 12.8

800

72 30.2 1.4 19.9 17.5 15.2 12.9 10.5 - - 28.0 1.5 19.2 16.9 14.5 12.2 9.9 - -

67 27.9 1.5 23.9 21.5 19.2 16.9 14.5 12.2 9.9 25.8 1.6 23.1 20.8 18.5 16.1 13.8 11.5 9.1

62 25.8 1.6 25.8 25.8 23.8 21.5 19.1 16.8 14.5 24.0 1.7 24.0 24.0 22.5 20.1 17.8 15.5 13.1

57 25.8 1.6 25.8 25.8 23.8 21.5 19.1 16.8 14.5 24.0 1.7 24.0 24.0 22.5 20.1 17.8 15.5 13.1

900

72 30.8 1.3 21.5 18.9 16.2 13.6 10.9 - - 28.5 1.5 20.8 18.2 15.5 12.9 10.2 - -

67 28.4 1.5 26.4 23.1 20.5 17.8 15.2 12.5 9.9 26.3 1.6 24.9 22.4 19.7 17.1 14.4 11.7 9.1

62 26.3 1.5 26.3 26.3 25.3 22.6 20.0 17.3 14.7 24.5 1.7 24.5 24.5 23.7 21.0 18.4 15.7 13.0

57 26.3 1.5 26.3 26.3 25.3 22.6 20.0 17.3 14.7 24.5 1.7 24.5 24.5 23.7 21.0 18.4 15.7 13.0

1000

72 31.3 1.3 23.2 20.2 17.2 14.2 11.3 - - 29.0 1.5 22.5 19.5 16.5 13.5 10.5 - -

67 28.9 1.4 28.9 24.7 21.8 18.8 15.8 12.8 9.8 26.7 1.6 26.7 23.9 21.0 18.0 15.0 12.0 9.0

62 26.8 1.5 26.8 26.8 26.8 23.8 20.8 17.8 14.8 24.9 1.6 24.9 24.9 24.9 21.9 18.9 15.9 13.0

57 26.8 1.5 26.8 26.8 26.8 23.8 20.8 17.8 14.8 24.9 1.6 24.9 24.9 24.9 21.9 18.9 15.9 13.0

95°F 105°F

600

72 24.6 1.7 15.3 13.6 11.9 10.2 8.5 - - 21.1 1.9 14.5 12.7 11.0 9.3 7.6 - -

67 22.5 1.8 18.6 16.9 15.2 13.5 11.8 10.1 8.4 19.3 1.9 17.4 15.9 14.2 12.5 10.8 9.1 7.3

62 21.1 1.8 21.1 19.8 18.1 16.4 14.7 13.0 11.3 18.2 1.9 18.2 17.6 16.5 14.8 13.1 11.4 9.7

57 21.1 1.8 21.1 19.8 18.1 16.4 14.7 13.0 11.3 18.2 1.9 18.2 17.6 16.5 14.8 13.1 11.4 9.7

700

72 25.2 1.7 16.9 14.9 12.9 10.9 8.8 - - 21.7 1.9 16.0 14.0 12.0 10.0 7.9 - -

67 23.1 1.8 20.5 18.5 16.5 14.4 12.4 10.4 8.4 19.8 1.9 18.5 17.2 15.4 13.4 11.4 9.3 7.3

62 21.7 1.8 21.7 21.0 19.6 17.6 15.6 13.5 11.5 18.7 1.9 18.7 18.4 18.0 15.9 13.9 11.9 9.9

57 21.7 1.8 21.7 21.0 19.6 17.6 15.6 13.5 11.5 18.7 1.9 18.7 18.4 18.0 15.9 13.9 11.9 9.9

800

72 25.8 1.7 18.5 16.2 13.9 11.5 9.2 - - 22.3 1.9 17.6 15.3 12.9 10.6 8.3 - -

67 23.7 1.8 22.4 20.0 17.7 15.4 13.0 10.7 8.4 20.4 1.9 19.7 18.5 16.6 14.3 12.0 9.6 7.3

62 22.2 1.8 22.2 22.2 21.1 18.8 16.4 14.1 11.8 19.2 1.9 19.2 19.2 19.4 17.0 14.7 12.4 10.1

57 22.2 1.8 22.2 22.2 21.1 18.8 16.4 14.1 11.8 19.2 1.9 19.2 19.2 19.4 17.0 14.7 12.4 10.0

900

72 26.3 1.7 20.1 17.5 14.8 12.2 9.5 - - 22.7 1.9 19.1 16.5 13.8 11.2 8.5 - -

67 24.1 1.8 23.5 21.6 18.9 16.3 13.6 11.0 8.3 20.7 1.9 20.4 19.4 17.8 15.1 12.5 9.8 7.2

62 22.6 1.8 22.6 22.6 22.1 19.4 16.7 14.1 11.4 19.5 1.9 19.5 19.5 19.6 17.0 14.3 11.7 9.0

57 22.6 1.8 22.6 22.6 22.1 19.4 16.7 14.1 11.4 19.5 1.9 19.5 19.5 19.6 17.0 14.3 11.7 9.0

1000

72 26.8 1.7 21.8 18.8 15.8 12.8 9.8 - - 23.0 1.9 20.5 17.7 14.8 11.8 8.8 - -

67 24.6 1.7 24.6 23.2 20.2 17.2 14.2 11.2 8.3 21.1 1.9 21.1 20.4 19.0 16.0 13.0 10.0 7.0

62 23.0 1.8 23.0 23.0 23.0 20.0 17.0 14.1 11.1 19.9 1.9 19.9 19.9 19.9 16.9 13.9 10.9 7.9

57 23.0 1.8 23.0 23.0 23.0 20.0 17.0 14.1 11.1 19.9 1.9 19.9 19.9 19.9 16.9 13.9 10.9 7.9

115°F 125°F

600

72 17.7 2.1 13.6 11.9 10.2 8.5 6.7 - - 14.2 2.2 12.7 11.0 9.3 7.6 5.9 - -

67 16.1 2.1 16.1 14.9 13.2 11.5 9.7 8.0 6.3 12.9 2.2 12.9 12.9 12.1 10.4 8.7 7.0 5.3

62 15.3 2.0 15.3 15.3 15.0 13.2 11.5 9.8 8.1 12.4 2.2 12.4 12.4 12.4 11.7 9.9 8.2 6.5

57 15.3 2.0 15.3 15.3 15.0 13.2 11.5 9.8 8.1 12.4 2.2 12.4 12.4 12.4 11.7 9.9 8.2 6.5

700

72 18.2 2.1 15.1 13.1 11.1 9.1 7.0 - - 14.7 2.2 14.2 12.2 10.2 8.2 6.1 - -

67 16.5 2.1 16.5 15.9 14.4 12.3 10.3 8.3 6.3 13.3 2.2 13.3 13.3 13.3 11.3 9.3 7.2 5.2

62 15.7 2.1 15.7 15.7 16.3 14.3 12.3 10.2 8.2 12.8 2.2 12.8 12.8 12.8 12.6 10.6 8.6 6.6

57 15.7 2.1 15.7 15.7 16.3 14.3 12.3 10.2 8.2 12.8 2.2 12.8 12.8 12.8 12.6 10.6 8.6 6.6

800

72 18.7 2.1 16.7 14.3 12.0 9.7 7.3 - - 15.1 2.2 15.1 13.4 11.1 8.7 6.4 - -

67 17.0 2.1 17.0 17.0 15.5 13.2 10.9 8.5 6.2 13.6 2.2 13.6 13.6 13.6 12.1 9.8 7.5 5.1

62 16.2 2.1 16.2 16.2 17.7 15.3 13.0 10.7 8.3 13.2 2.2 13.2 13.2 13.2 13.2 11.3 8.9 6.6

57 16.2 2.1 16.2 16.2 17.7 15.3 13.0 10.7 8.3 13.2 2.2 13.2 13.2 13.2 13.2 11.3 8.9 6.6

900

72 19.0 2.1 18.0 15.5 12.9 10.2 7.5 - - 15.4 2.3 15.4 14.5 11.9 9.2 6.6 - -

67 17.3 2.1 17.3 17.3 16.6 14.0 11.3 8.7 6.0 13.9 2.2 13.9 13.9 13.9 12.8 10.2 7.5 4.9

62 16.5 2.1 16.5 16.5 17.2 14.5 11.9 9.2 6.6 13.4 2.2 13.4 13.4 13.4 12.1 9.5 6.8 4.1

57 16.5 2.1 16.5 16.5 17.2 14.5 11.9 9.2 6.6 13.4 2.2 13.4 13.4 13.4 12.1 9.5 6.8 4.1

1000

72 19.3 2.1 19.3 16.7 13.7 10.7 7.8 - - 15.6 2.3 15.6 15.6 12.7 9.7 6.7 - -

67 17.6 2.1 17.6 17.6 17.8 14.8 11.8 8.8 5.8 14.1 2.2 14.1 14.1 14.1 13.6 10.6 7.6 4.6

62 16.7 2.1 16.7 16.7 16.7 13.8 10.8 7.8 4.8 13.6 2.2 13.6 13.6 13.6 10.6 7.6 4.7 1.7

57 16.7 2.1 16.7 16.7 16.7 13.8 10.8 7.8 4.8 13.6 2.2 13.6 13.6 13.6 10.6 7.6 4.7 1.7

246836-LTG-E-0107

10 Unitary Products Group

PAC030 (2.5 Ton)

Air on

Evaporator Coil Temperature of Air on Condenser Coil

Total

Capacity1

(MBh)

1. These capacities are gross ratings. For net capacity, deduct air blower motor, MBh = 3.415 x kW. Refer to the appropriate Blower Performance Table for the

kW of the supply air blower motor.

Total

Input

(kW)2

2. These ratings include the condensate fan motors (total .25 kW) and the compressor motors but not the supply air blower motor.

Sensible Capacity (MBh) Total

Capacity1

(MBh)

Total

Input

(kW)2

Sensible Capacity (MBh)

CFM WB

(°F) Return Dry Bulb (°F) Return Dry Bulb (°F)

86 83 80 77 74 71 68 86 83 80 77 74 71 68

75°F 85°F

750

72 30.6 2.1 20.5 18.4 16.2 14.1 12.0 - - 29.8 2.1 19.6 17.4 15.3 13.2 11.0 - -

67 28.0 2.1 24.7 22.5 20.4 18.3 16.1 14.0 11.9 27.3 2.1 23.7 21.5 19.4 17.2 15.1 13.0 10.8

62 25.7 2.0 25.7 26.6 24.9 22.8 20.6 18.5 16.4 25.4 2.1 25.4 25.4 23.5 21.3 19.2 17.0 14.9

57 25.7 2.0 25.7 26.6 24.9 22.8 20.6 18.5 16.4 25.4 2.1 25.4 25.4 23.5 21.3 19.2 17.0 14.9

875

72 31.5 2.0 22.6 20.1 17.5 15.0 12.5 - - 30.7 2.1 21.6 19.1 16.5 14.0 11.5 - -

67 28.8 2.0 27.1 24.6 22.0 19.5 17.0 14.4 11.9 28.1 2.1 26.0 23.5 21.0 18.4 15.9 13.4 10.9

62 26.4 2.0 26.4 26.9 26.9 24.4 21.8 19.3 16.8 26.1 2.1 26.1 26.1 25.4 22.9 20.3 17.8 15.3

57 26.4 2.0 26.4 26.9 26.9 24.4 21.8 19.3 16.8 26.1 2.1 26.1 26.1 25.4 22.9 20.3 17.8 15.3

1000

72 32.3 1.9 24.6 21.7 18.8 15.9 13.0 - - 31.5 2.1 23.6 20.7 17.8 14.9 12.0 - -

67 29.5 1.9 29.5 26.6 23.6 20.7 17.8 14.9 12.0 28.9 2.1 28.4 25.5 22.6 19.7 16.7 13.8 10.9

62 27.1 1.9 27.1 27.1 28.9 25.9 23.0 20.1 17.2 26.8 2.1 26.8 26.8 27.3 24.4 21.5 18.6 15.6

57 27.1 1.9 27.1 27.1 28.9 25.9 23.0 20.1 17.2 26.8 2.1 26.8 26.8 27.3 24.4 21.5 18.6 15.6

1125

72 33.0 2.0 26.6 23.3 20.0 16.7 13.4 - - 32.1 2.1 25.6 22.3 19.0 15.7 12.3 - -

67 30.2 2.0 30.2 28.5 25.1 21.8 18.5 15.2 11.9 29.4 2.1 29.2 27.4 24.1 20.7 17.4 14.1 10.8

62 27.7 2.0 27.7 27.7 28.6 25.3 22.0 18.6 15.3 27.3 2.1 27.3 27.3 27.6 24.2 20.9 17.6 14.3

57 27.7 2.0 27.7 27.7 28.6 25.3 22.0 18.6 15.3 27.3 2.1 27.3 27.3 27.5 24.2 20.9 17.6 14.3

1250

72 33.7 2.1 28.7 24.9 21.2 17.5 13.8 - - 32.7 2.1 27.6 23.9 20.1 16.4 12.7 - -

67 30.8 2.1 30.8 30.4 26.6 22.9 19.2 15.5 11.7 29.9 2.1 29.9 29.3 25.5 21.8 18.1 14.4 10.6

62 28.3 2.1 28.3 28.3 28.3 24.6 20.9 17.2 13.4 27.8 2.1 27.8 27.8 27.8 24.1 20.3 16.6 12.9

57 28.3 2.1 28.3 28.3 28.3 24.6 20.9 17.2 13.4 27.8 2.1 27.8 27.8 27.8 24.1 20.3 16.6 12.9

95°F 105°F

750

72 29.0 2.2 18.6 16.5 14.3 12.2 10.1 - - 25.7 2.5 17.6 15.4 13.3 11.2 9.0 - -

67 26.6 2.1 22.6 20.5 18.4 16.2 14.1 11.9 9.8 23.6 2.4 21.4 19.3 17.2 15.0 12.9 10.7 8.6

62 25.0 2.1 25.0 24.1 22.0 19.9 17.7 15.6 13.4 22.4 2.4 22.4 22.0 20.1 18.0 15.8 13.7 11.5

57 25.0 2.1 25.0 24.1 22.0 19.9 17.7 15.6 13.4 22.4 2.4 22.4 22.0 20.1 18.0 15.8 13.7 11.5

875

72 29.8 2.3 20.6 18.1 15.6 13.0 10.5 - - 26.4 2.5 19.5 17.0 14.4 11.9 9.4 - -

67 27.4 2.2 25.0 22.5 19.9 17.4 14.9 12.3 9.8 24.3 2.5 23.0 21.1 18.6 16.1 13.6 11.0 8.5

62 25.7 2.2 25.7 25.3 23.9 21.4 18.8 16.3 13.8 23.0 2.5 23.0 22.8 21.8 19.3 16.8 14.2 11.7

57 25.7 2.2 25.7 25.3 23.9 21.4 18.8 16.3 13.8 23.0 2.5 23.0 22.8 21.8 19.3 16.8 14.2 11.7

1000

72 30.7 2.3 22.6 19.7 16.8 13.9 11.0 - - 27.1 2.6 21.4 18.5 15.6 12.7 9.7 - -

67 28.2 2.3 27.3 24.4 21.5 18.6 15.7 12.7 9.8 24.9 2.5 24.5 23.0 20.1 17.2 14.2 11.3 8.4

62 26.5 2.3 26.5 26.5 25.8 22.8 19.9 17.0 14.1 23.6 2.5 23.6 23.6 23.5 20.6 17.7 14.8 11.9

57 26.5 2.3 26.5 26.5 25.8 22.8 19.9 17.0 14.1 23.6 2.5 23.6 23.6 23.5 20.6 17.7 14.8 11.9

1125

72 31.2 2.3 24.6 21.3 17.9 14.6 11.3 - - 27.5 2.6 23.3 20.0 16.7 13.3 10.0 - -

67 28.6 2.2 28.2 26.3 23.0 19.6 16.3 13.0 9.7 25.3 2.5 25.1 24.1 21.5 18.2 14.8 11.5 8.2

62 26.9 2.2 26.9 26.9 26.5 23.2 19.9 16.5 13.2 24.0 2.5 24.0 24.0 23.9 20.6 17.3 14.0 10.7

57 26.9 2.2 26.9 26.9 26.5 23.2 19.9 16.5 13.2 24.0 2.5 24.0 24.0 23.9 20.6 17.3 14.0 10.7

1250

72 31.6 2.2 26.5 22.8 19.1 15.4 11.6 - - 27.9 2.5 25.2 21.5 17.8 14.0 10.3 - -

67 29.0 2.2 29.0 28.2 24.4 20.7 17.0 13.3 9.5 25.7 2.5 25.7 25.2 22.9 19.2 15.4 11.7 8.0

62 27.3 2.1 27.3 27.3 27.3 23.5 19.8 16.1 12.3 24.4 2.5 24.4 24.4 24.4 20.6 16.9 13.2 9.5

57 27.3 2.1 27.3 27.3 27.3 23.5 19.8 16.1 12.3 24.4 2.5 24.4 24.4 24.4 20.6 16.9 13.2 9.5

115°F 125°F

750

72 22.4 2.8 16.6 14.4 12.3 10.1 8.0 - - 19.2 3.1 15.5 13.4 11.3 9.1 7.0 - -

67 20.7 2.7 20.2 18.1 15.9 13.8 11.7 9.5 7.4 17.7 3.0 17.7 16.9 14.7 12.6 10.5 8.3 6.2

62 19.9 2.7 19.9 19.9 18.2 16.1 13.9 11.8 9.6 17.3 3.0 17.3 17.3 16.3 14.2 12.0 9.9 7.7

57 19.9 2.7 19.9 19.9 18.2 16.1 13.9 11.8 9.6 17.3 3.0 17.3 17.3 16.3 14.2 12.0 9.9 7.7

875

72 23.0 2.8 18.4 15.9 13.3 10.8 8.3 - - 19.5 3.1 17.3 14.7 12.2 9.7 7.2 - -

67 21.1 2.8 20.9 19.8 17.3 14.8 12.3 9.7 7.2 18.0 3.0 18.0 18.0 16.0 13.5 10.9 8.4 5.9

62 20.3 2.7 20.3 20.3 19.7 17.2 14.7 12.2 9.6 17.7 3.0 17.7 17.7 17.7 15.2 12.6 10.1 7.6

57 20.3 2.7 20.3 20.3 19.7 17.2 14.7 12.2 9.6 17.7 3.0 17.7 17.7 17.7 15.2 12.6 10.1 7.6

1000

72 23.5 2.8 20.2 17.3 14.4 11.5 8.5 - - 19.9 3.1 19.0 16.1 13.2 10.2 7.3 - -

67 21.6 2.8 21.6 21.6 18.7 15.7 12.8 9.9 7.0 18.4 3.0 18.4 18.4 17.2 14.3 11.4 8.5 5.6

62 20.8 2.7 20.8 20.8 21.3 18.4 15.5 12.5 9.6 18.0 3.0 18.0 18.0 18.0 16.2 13.2 10.3 7.4

57 20.8 2.7 20.8 20.8 21.3 18.4 15.5 12.5 9.6 18.0 3.0 18.0 18.0 18.0 16.2 13.2 10.3 7.4

1125

72 23.9 2.8 22.0 18.7 15.4 12.1 8.8 - - 20.2 3.1 20.2 17.5 14.1 10.8 7.5 - -

67 22.0 2.8 22.0 21.9 20.0 16.7 13.4 10.0 6.7 18.7 3.0 18.7 18.7 18.5 15.2 11.9 8.6 5.2

62 21.2 2.8 21.2 21.2 21.4 18.1 14.7 11.4 8.1 18.3 3.0 18.3 18.3 18.3 15.5 12.2 8.9 5.5

57 21.2 2.8 21.2 21.2 21.4 18.1 14.7 11.4 8.1 18.3 3.0 18.3 18.3 18.3 15.5 12.2 8.9 5.5

1250

72 24.2 2.8 23.9 20.2 16.4 12.7 9.0 - - 20.6 3.2 20.6 18.8 15.1 11.4 7.6 - -

67 22.3 2.8 22.3 22.3 21.3 17.6 13.9 10.2 6.4 19.0 3.1 19.0 19.0 19.0 16.1 12.3 8.6 4.9

62 21.5 2.8 21.5 21.5 21.5 17.8 14.0 10.3 6.6 18.6 3.1 18.6 18.6 18.6 14.9 11.1 7.4 3.7

57 21.5 2.8 21.5 21.5 21.5 17.8 14.0 10.3 6.6 18.6 3.1 18.6 18.6 18.6 14.9 11.1 7.4 3.7

246836-LTG-E-0107

Unitary Products Group 11

PAC036 (3.0 Ton)

Air on

Evaporator Coil Temperature of Air on Condenser Coil

Total

Capacity1

(MBh)

1. These capacities are gross ratings. For net capacity, deduct air blower motor, MBh = 3.415 x kW. Refer to the appropriate Blower Performance Table for the

kW of the supply air blower motor.

Total

Input

(kW)2

2. These ratings include the condensate fan motors (total .25 kW) and the compressor motors but not the supply air blower motor.

Sensible Capacity (MBh) Total

Capacity1

(MBh)

Total

Input

(kW)2

Sensible Capacity (MBh)

CFM WB

(°F) Return Dry Bulb (°F) Return Dry Bulb (°F)

86 83 80 77 74 71 68 86 83 80 77 74 71 68

75°F 85°F

900

72 43.4 2.6 25.6 23.1 20.5 17.9 15.4 - - 40.6 2.7 24.0 21.5 18.9 16.3 13.8 - -

67 39.9 2.6 31.1 28.5 26.0 23.4 20.8 18.3 15.7 37.3 2.7 29.3 26.8 24.2 21.6 19.1 16.5 13.9

62 36.6 2.6 37.1 34.6 32.0 29.4 26.9 24.3 21.7 34.7 2.6 34.7 32.1 29.6 27.0 24.4 21.9 19.3

57 37.0 2.6 37.5 35.2 32.7 30.1 27.5 25.0 22.4 34.9 2.6 34.9 32.5 29.9 27.3 24.8 22.2 19.6

1050

72 44.7 2.7 28.2 25.2 22.1 19.1 16.1 - - 41.7 2.7 26.5 23.5 20.4 17.4 14.4 - -

67 41.1 2.6 34.1 31.1 28.0 25.0 22.0 18.9 15.9 38.4 2.7 32.3 29.2 26.2 23.2 20.1 17.1 14.1

62 37.7 2.6 37.9 36.7 34.6 31.5 28.5 25.5 22.4 35.7 2.6 35.7 34.4 32.0 29.0 25.9 22.9 19.9

57 38.1 2.6 38.4 37.2 35.3 32.3 29.2 26.2 23.2 35.9 2.6 35.9 34.7 32.3 29.3 26.3 23.3 20.2

1200

72 46.0 2.7 30.8 27.3 23.8 20.3 16.8 - - 42.9 2.7 29.0 25.5 22.0 18.5 15.0 - -

67 42.3 2.6 37.1 33.6 30.1 26.6 23.1 19.6 16.1 39.5 2.7 35.2 31.7 28.2 24.7 21.2 17.7 14.2

62 38.8 2.6 38.8 38.8 37.1 33.6 30.1 26.6 23.1 36.7 2.7 36.7 36.7 34.4 30.9 27.4 23.9 20.4

57 39.3 2.6 39.3 39.3 37.9 34.4 30.9 27.4 23.9 36.9 2.7 36.9 36.9 34.8 31.3 27.8 24.3 20.8

1350

72 46.9 2.7 33.3 29.3 25.4 21.4 17.4 - - 43.7 2.7 31.4 27.4 23.4 19.5 15.5 - -

67 43.1 2.7 40.4 36.1 32.1 28.1 24.2 20.2 16.2 40.2 2.7 38.0 34.0 30.0 26.0 22.1 18.1 14.1

62 39.5 2.6 39.5 39.5 38.7 34.7 30.7 26.7 22.7 37.3 2.7 37.3 37.3 36.2 32.2 28.2 24.2 20.3

57 40.0 2.6 40.0 40.0 39.3 35.3 31.4 27.4 23.4 37.6 2.7 37.6 37.6 36.5 32.5 28.6 24.6 20.6

1500

72 47.8 2.7 35.9 31.4 27.0 22.5 18.0 - - 44.5 2.8 33.8 29.4 24.9 20.4 16.0 - -

67 43.9 2.7 43.8 38.6 34.2 29.7 25.2 20.7 16.3 40.9 2.7 40.8 36.4 31.9 27.4 23.0 18.5 14.0

62 40.3 2.6 40.3 40.3 40.3 35.8 31.3 26.8 22.4 38.0 2.7 38.0 38.0 38.0 33.5 29.0 24.6 20.1

57 40.8 2.6 40.8 40.8 40.8 36.3 31.8 27.4 22.9 38.3 2.7 38.3 38.3 38.3 33.8 29.3 24.8 20.4

95°F 105°F

900

72 37.7 2.8 22.4 19.9 17.3 14.7 12.2 - - 33.9 3.1 21.5 19.0 16.4 13.8 11.3 - -

67 34.7 2.7 27.6 25.0 22.5 19.9 17.3 14.8 12.2 31.1 3.0 26.4 23.9 21.3 18.7 16.2 13.6 11.0

62 32.8 2.7 32.3 29.7 27.1 24.6 22.0 19.4 16.9 29.7 3.0 29.4 27.9 25.3 22.7 20.2 17.6 15.0

57 32.8 2.7 32.3 29.7 27.1 24.6 22.0 19.4 16.9 29.7 3.0 29.4 27.9 25.3 22.7 20.2 17.6 15.0

1050

72 38.8 2.8 24.8 21.8 18.8 15.7 12.7 - - 34.7 3.1 23.9 20.8 17.8 14.8 11.7 - -

67 35.7 2.7 30.4 27.4 24.3 21.3 18.3 15.3 12.2 31.9 3.0 28.7 26.1 23.1 20.1 17.0 14.0 11.0

62 33.7 2.7 33.4 32.1 29.4 26.4 23.3 20.3 17.3 30.4 3.0 30.3 29.5 27.4 24.4 21.4 18.3 15.3

57 33.7 2.7 33.4 32.1 29.4 26.4 23.3 20.3 17.3 30.4 3.0 30.3 29.5 27.4 24.4 21.4 18.3 15.3

1200

72 39.8 2.8 27.2 23.7 20.2 16.7 13.2 - - 35.6 3.1 26.2 22.7 19.2 15.7 12.2 - -

67 36.6 2.8 33.2 29.7 26.2 22.7 19.2 15.7 12.2 32.7 3.0 31.0 28.4 24.9 21.4 17.9 14.4 10.9

62 34.6 2.7 34.6 34.6 31.7 28.2 24.7 21.2 17.7 31.1 3.0 31.1 31.1 29.6 26.1 22.6 19.1 15.6

57 34.6 2.7 34.6 34.6 31.7 28.2 24.7 21.2 17.7 31.1 3.0 31.1 31.1 29.6 26.1 22.6 19.1 15.6

1350

72 40.5 2.8 29.5 25.5 21.5 17.6 13.6 - - 36.2 3.1 28.5 24.5 20.5 16.5 12.5 - -

67 37.3 2.8 35.6 31.9 27.9 24.0 20.0 16.0 12.0 33.2 3.1 32.4 30.2 26.6 22.6 18.7 14.7 10.7

62 35.1 2.7 35.1 35.1 33.7 29.7 25.7 21.8 17.8 31.7 3.0 31.7 31.7 30.9 26.9 22.9 18.9 14.9

57 35.1 2.7 35.1 35.1 33.7 29.7 25.7 21.8 17.8 31.7 3.0 31.7 31.7 30.9 26.9 22.9 18.9 14.9

1500

72 41.2 2.8 31.8 27.3 22.9 18.4 13.9 - - 36.8 3.1 30.8 26.3 21.8 17.4 12.9 - -

67 37.9 2.8 37.9 34.1 29.6 25.2 20.7 16.2 11.8 33.8 3.1 33.8 31.9 28.3 23.9 19.4 14.9 10.5

62 35.7 2.7 35.7 35.7 35.7 31.3 26.8 22.3 17.8 32.2 3.0 32.2 32.2 32.2 27.7 23.3 18.8 14.3

57 35.7 2.7 35.7 35.7 35.7 31.3 26.8 22.3 17.8 32.2 3.0 32.2 32.2 32.2 27.7 23.3 18.8 14.3

115°F 125°F

900

72 30.0 3.4 20.6 18.1 15.5 12.9 10.4 - - 26.2 3.7 19.7 17.2 14.6 12.0 9.5 - -

67 27.5 3.3 25.3 22.7 20.2 17.6 15.0 12.5 9.9 23.9 3.6 23.9 21.6 19.0 16.4 13.9 11.3 8.8

62 26.6 3.2 26.6 26.0 23.5 20.9 18.4 15.8 13.2 23.5 3.5 23.5 23.5 21.7 19.1 16.5 14.0 11.4

57 26.6 3.2 26.6 26.0 23.5 20.9 18.4 15.8 13.2 23.5 3.5 23.5 23.5 21.7 19.1 16.5 14.0 11.4

1050

72 30.7 3.4 22.9 19.9 16.8 13.8 10.8 - - 26.6 3.7 21.9 18.9 15.9 12.8 9.8 - -

67 28.1 3.3 27.0 24.9 21.9 18.8 15.8 12.8 9.7 24.3 3.6 24.3 23.7 20.6 17.6 14.6 11.5 8.5

62 27.1 3.3 27.1 26.9 25.5 22.4 19.4 16.4 13.3 23.9 3.6 23.9 23.9 23.5 20.5 17.4 14.4 11.4

57 27.1 3.3 27.1 26.9 25.5 22.4 19.4 16.4 13.3 23.9 3.6 23.9 23.9 23.5 20.5 17.4 14.4 11.4

1200

72 31.3 3.4 25.1 21.6 18.1 14.6 11.1 - - 27.1 3.7 24.1 20.6 17.1 13.6 10.1 - -

67 28.7 3.3 28.7 27.1 23.6 20.1 16.6 13.1 9.6 24.8 3.6 24.8 24.8 22.3 18.8 15.3 11.8 8.3

62 27.7 3.3 27.7 27.7 27.5 24.0 20.5 17.0 13.5 24.3 3.6 24.3 24.3 24.3 21.9 18.4 14.9 11.4

57 27.7 3.3 27.7 27.7 27.5 24.0 20.5 17.0 13.5 24.3 3.6 24.3 24.3 24.3 21.9 18.4 14.9 11.4

1350

72 31.9 3.4 27.4 23.5 19.5 15.5 11.5 - - 27.5 3.8 26.4 22.4 18.4 14.5 10.5 - -

67 29.2 3.4 29.2 28.4 25.3 21.3 17.3 13.4 9.4 25.2 3.7 25.2 25.2 24.0 20.0 16.0 12.0 8.1

62 28.2 3.3 28.2 28.2 28.1 24.1 20.1 16.1 12.1 24.7 3.6 24.7 24.7 24.7 21.3 17.3 13.3 9.3

57 28.2 3.3 28.2 28.2 28.1 24.1 20.1 16.1 12.1 24.7 3.6 24.7 24.7 24.7 21.3 17.3 13.3 9.3

1500

72 32.4 3.5 29.7 25.3 20.8 16.3 11.9 - - 28.0 3.8 28.0 24.3 19.8 15.3 10.8 - -

67 29.7 3.4 29.7 29.7 27.0 22.6 18.1 13.6 9.2 25.6 3.7 25.6 25.6 25.6 21.3 16.8 12.3 7.9

62 28.7 3.3 28.7 28.7 28.7 24.2 19.7 15.2 10.8 25.1 3.6 25.1 25.1 25.1 20.7 16.2 11.7 7.2

57 28.7 3.3 28.7 28.7 28.7 24.2 19.7 15.2 10.8 25.1 3.6 25.1 25.1 25.1 20.7 16.2 11.7 7.2

246836-LTG-E-0107

12 Unitary Products Group

PAC042 (3.5 Ton)

Air on

Evaporator Coil Temperature of Air on Condenser Coil

Total

Capacity1

(MBh)

1. These capacities are gross ratings. For net capacity, deduct air blower motor, MBh = 3.415 x kW. Refer to the appropriate Blower Performance Table for the

kW of the supply air blower motor.

Total

Input

(kW)2

2. These ratings include the condensate fan motors (total .25 kW) and the compressor motors but not the supply air blower motor.

Sensible Capacity (MBh) Total

Capacity1

(MBh)

Total

Input

(kW)2

Sensible Capacity (MBh)

CFM WB

(°F) Return Dry Bulb (°F) Return Dry Bulb (°F)

86 83 80 77 74 71 68 86 83 80 77 74 71 68

75°F 85°F

1050

72 47.9 2.7 27.3 24.3 21.3 18.3 15.3 - - 45.5 2.9 26.7 23.8 20.8 17.8 14.8 - -

67 44.2 2.6 33.2 30.2 27.2 24.2 21.2 18.2 15.2 42.0 2.9 32.7 29.7 26.7 23.7 20.7 17.7 14.8

62 40.8 2.5 39.8 36.8 33.8 30.8 27.8 24.8 21.8 39.2 2.8 38.7 35.7 32.7 29.7 26.7 23.7 20.7

57 40.8 2.5 39.8 36.8 33.8 30.8 27.8 24.8 21.8 39.2 2.8 38.7 35.7 32.7 29.7 26.7 23.7 20.7

1225

72 49.2 2.7 30.0 26.5 22.9 19.4 15.9 - - 46.8 3.0 29.5 26.0 22.4 18.9 15.3 - -

67 45.5 2.6 36.4 32.8 29.3 25.8 22.2 18.7 15.1 43.2 2.9 35.9 32.4 28.9 25.3 21.8 18.3 14.7

62 42.0 2.6 41.5 40.0 36.5 32.9 29.4 25.8 22.3 40.3 2.8 40.0 38.5 35.3 31.7 28.2 24.7 21.1

57 42.0 2.6 41.5 40.0 36.5 32.9 29.4 25.8 22.3 40.3 2.8 40.0 38.5 35.3 31.7 28.2 24.7 21.1

1400

72 50.6 2.7 32.8 28.7 24.6 20.5 16.4 - - 48.0 3.0 32.2 28.2 24.1 20.0 15.9 - -

67 46.7 2.7 39.6 35.5 31.4 27.3 23.3 19.2 15.1 44.4 2.9 39.2 35.1 31.0 26.9 22.8 18.8 14.7

62 43.2 2.6 43.2 43.2 39.1 35.0 30.9 26.9 22.8 41.4 2.8 41.4 41.4 37.9 33.8 29.7 25.6 21.6

57 43.2 2.6 43.2 43.2 39.1 35.0 30.9 26.9 22.8 41.4 2.8 41.4 41.4 37.9 33.8 29.7 25.6 21.6

1575

72 51.4 2.7 35.4 30.8 26.1 21.5 16.8 - - 48.8 3.0 34.9 30.3 25.6 21.0 16.3 - -

67 47.5 2.7 43.6 38.0 33.4 28.7 24.1 19.4 14.8 45.0 2.9 42.3 37.6 33.0 28.4 23.7 19.1 14.4

62 43.9 2.6 43.9 43.9 41.8 37.2 32.5 27.9 23.2 42.0 2.9 42.0 42.0 40.3 35.6 31.0 26.3 21.7

57 43.9 2.6 43.9 43.9 41.8 37.2 32.5 27.9 23.2 42.0 2.9 42.0 42.0 40.3 35.6 31.0 26.3 21.7

1750

72 52.3 2.8 38.1 32.8 27.6 22.4 17.2 - - 49.5 3.0 37.6 32.4 27.2 22.0 16.7 - -

67 48.2 2.7 47.6 40.5 35.3 30.1 24.9 19.6 14.4 45.7 2.9 45.4 40.2 35.0 29.8 24.6 19.3 14.1

62 44.6 2.6 44.6 44.6 44.6 39.4 34.2 28.9 23.7 42.7 2.9 42.7 42.7 42.7 37.5 32.2 27.0 21.8

57 44.6 2.6 44.6 44.6 44.6 39.4 34.2 28.9 23.7 42.7 2.9 42.7 42.7 42.7 37.5 32.2 27.0 21.8

95°F 105°F

1050

72 43.2 3.2 26.2 23.2 20.2 17.3 14.3 - - 38.8 3.4 24.6 21.6 18.6 15.6 12.6 - -

67 39.9 3.1 32.3 29.3 26.3 23.3 20.3 17.3 14.3 35.8 3.3 30.3 27.3 24.3 21.3 18.3 15.3 12.4

62 37.6 3.0 37.5 34.5 31.5 28.5 25.5 22.5 19.5 34.1 3.3 34.0 31.6 28.6 25.6 22.6 19.6 16.6

57 37.6 3.0 37.5 34.5 31.5 28.5 25.5 22.5 19.5 34.1 3.3 34.0 31.6 28.6 25.6 22.6 19.6 16.6

1225

72 44.3 3.2 29.0 25.4 21.9 18.4 14.8 - - 39.7 3.5 27.3 23.7 20.2 16.7 13.1 - -

67 40.9 3.1 35.5 32.0 28.4 24.9 21.4 17.8 14.3 36.7 3.4 33.1 29.9 26.4 22.8 19.3 15.8 12.2

62 38.6 3.1 38.5 37.0 34.1 30.6 27.0 23.5 20.0 34.9 3.3 34.9 33.7 31.0 27.5 24.0 20.4 16.9

57 38.6 3.1 38.5 37.0 34.1 30.6 27.0 23.5 20.0 34.9 3.3 34.9 33.7 31.0 27.5 24.0 20.4 16.9

1400

72 45.4 3.2 31.7 27.6 23.6 19.5 15.4 - - 40.7 3.5 29.9 25.9 21.8 17.7 13.6 - -

67 42.0 3.2 38.8 34.7 30.6 26.5 22.4 18.3 14.3 37.6 3.4 36.0 32.5 28.4 24.4 20.3 16.2 12.1

62 39.5 3.1 39.5 39.5 36.7 32.6 28.5 24.4 20.4 35.8 3.3 35.8 35.8 33.5 29.4 25.3 21.2 17.1

57 39.5 3.1 39.5 39.5 36.7 32.6 28.5 24.4 20.4 35.8 3.3 35.8 35.8 33.5 29.4 25.3 21.2 17.1

1575

72 46.1 3.3 34.4 29.8 25.1 20.5 15.8 - - 41.3 3.5 32.6 28.0 23.3 18.7 14.0 - -

67 42.6 3.2 41.0 37.3 32.6 28.0 23.4 18.7 14.1 38.2 3.4 37.4 34.8 30.4 25.8 21.1 16.5 11.8

62 40.1 3.1 40.1 40.1 38.7 34.1 29.4 24.8 20.1 36.3 3.4 36.3 36.3 35.2 30.5 25.9 21.2 16.6

57 40.1 3.1 40.1 40.1 38.7 34.1 29.4 24.8 20.1 36.3 3.4 36.3 36.3 35.2 30.5 25.9 21.2 16.6

1750

72 46.8 3.3 37.2 31.9 26.7 21.5 16.3 - - 42.0 3.5 35.3 30.0 24.8 19.6 14.4 - -

67 43.2 3.2 43.2 39.9 34.7 29.5 24.3 19.1 13.8 38.7 3.4 38.7 37.1 32.4 27.2 22.0 16.8 11.5

62 40.7 3.1 40.7 40.7 40.7 35.5 30.3 25.1 19.9 36.9 3.4 36.9 36.9 36.9 31.7 26.4 21.2 16.0

57 40.7 3.1 40.7 40.7 40.7 35.5 30.3 25.1 19.9 36.9 3.4 36.9 36.9 36.9 31.7 26.4 21.2 16.0

115°F 125°F

1050

72 34.3 3.7 23.0 20.0 17.0 14.0 11.0 - - 29.9 3.9 21.4 18.4 15.4 12.4 9.4 - -

67 31.7 3.6 28.3 25.4 22.4 19.4 16.4 13.4 10.4 27.5 3.8 26.4 23.4 20.4 17.4 14.4 11.4 8.4

62 30.5 3.5 30.5 28.7 25.7 22.7 19.7 16.7 13.7 27.0 3.8 27.0 25.8 22.8 19.8 16.8 13.8 10.8

57 30.5 3.5 30.5 28.7 25.7 22.7 19.7 16.7 13.7 27.0 3.8 27.0 25.8 22.8 19.8 16.8 13.8 10.8

1225

72 35.1 3.7 25.6 22.1 18.5 15.0 11.4 - - 30.5 4.0 23.9 20.4 16.8 13.3 9.7 - -

67 32.4 3.6 30.8 27.9 24.3 20.8 17.2 13.7 10.2 28.2 3.8 28.2 25.8 22.3 18.7 15.2 11.6 8.1

62 31.3 3.6 31.3 30.4 28.0 24.4 20.9 17.4 13.8 27.6 3.8 27.6 27.0 24.9 21.4 17.8 14.3 10.7

57 31.3 3.6 31.3 30.4 28.0 24.4 20.9 17.4 13.8 27.6 3.8 27.6 27.0 24.9 21.4 17.8 14.3 10.7

1400

72 35.9 3.7 28.2 24.1 20.0 15.9 11.8 - - 31.2 4.0 26.4 22.3 18.2 14.1 10.1 - -

67 33.2 3.6 33.2 30.4 26.3 22.2 18.1 14.0 9.9 28.8 3.9 28.8 28.2 24.1 20.0 16.0 11.9 7.8

62 32.0 3.6 32.0 32.0 30.2 26.1 22.1 18.0 13.9 28.2 3.8 28.2 28.2 27.0 22.9 18.8 14.7 10.7

57 32.0 3.6 32.0 32.0 30.2 26.1 22.1 18.0 13.9 28.2 3.8 28.2 28.2 27.0 22.9 18.8 14.7 10.7

1575

72 36.5 3.8 30.8 26.1 21.5 16.8 12.2 - - 31.7 4.0 28.9 24.3 19.6 15.0 10.3 - -

67 33.7 3.7 33.7 32.3 28.2 23.5 18.9 14.2 9.6 29.3 3.9 29.3 29.3 26.0 21.3 16.7 12.0 7.4

62 32.5 3.6 32.5 32.5 31.6 27.0 22.3 17.7 13.0 28.7 3.9 28.7 28.7 28.1 23.4 18.8 14.1 9.5

57 32.5 3.6 32.5 32.5 31.6 27.0 22.3 17.7 13.0 28.7 3.9 28.7 28.7 28.1 23.4 18.8 14.1 9.5

1750

72 37.1 3.8 33.4 28.1 22.9 17.7 12.5 - - 32.2 4.0 31.5 26.2 21.0 15.8 10.6 - -

67 34.2 3.7 34.2 34.2 30.1 24.9 19.7 14.5 9.3 29.7 3.9 29.7 29.7 27.8 22.6 17.4 12.2 7.0

62 33.0 3.6 33.0 33.0 33.0 27.8 22.6 17.4 12.1 29.2 3.9 29.2 29.2 29.2 23.9 18.7 13.5 8.3

57 33.0 3.6 33.0 33.0 33.0 27.8 22.6 17.4 12.1 29.2 3.9 29.2 29.2 29.2 23.9 18.7 13.5 8.3

246836-LTG-E-0107

Unitary Products Group 13

PAC048 (4.0 Ton)

Air on

Evaporator Coil Temperature of Air on Condenser Coil

Total

Capacity1

(MBh)

1. These capacities are gross ratings. For net capacity, deduct air blower motor, MBh = 3.415 x kW. Refer to the appropriate Blower Performance Table for the

kW of the supply air blower motor.

Total

Input

(kW)2

2. These ratings include the condensate fan motors (total .25 kW) and the compressor motors but not the supply air blower motor.

Sensible Capacity (MBh) Total

Capacity1

(MBh)

Total

Input

(kW)2

Sensible Capacity (MBh)

CFM WB

(°F) Return Dry Bulb (°F) Return Dry Bulb (°F)

86 83 80 77 74 71 68 86 83 80 77 74 71 68

75°F 85°F

1200

72 55.9 3.0 31.8 28.4 24.9 21.5 18.1 - - 52.3 3.3 30.2 26.8 23.3 19.9 16.5 - -

67 51.7 2.9 38.7 35.2 31.8 28.4 25.0 21.5 18.1 48.4 3.2 37.0 33.5 30.1 26.7 23.3 19.8 16.4

62 48.7 2.8 46.7 43.3 39.9 36.4 33.0 29.6 26.2 45.9 3.1 43.8 40.4 37.0 33.6 30.1 26.7 23.3

57 48.7 2.8 46.7 43.3 39.9 36.4 33.0 29.6 26.2 45.9 3.1 43.8 40.4 37.0 33.6 30.1 26.7 23.3

1400

72 57.3 3.0 34.8 30.7 26.7 22.6 18.6 - - 53.6 3.3 33.2 29.2 25.1 21.1 17.0 - -

67 52.9 2.9 42.1 38.1 34.0 30.0 25.9 21.9 17.8 49.6 3.2 40.5 36.4 32.4 28.4 24.3 20.3 16.2

62 49.9 2.8 48.9 46.7 42.7 38.6 34.6 30.5 26.5 47.0 3.1 46.0 43.8 39.8 35.7 31.7 27.7 23.6

57 49.9 2.8 48.9 46.7 42.6 38.6 34.6 30.5 26.5 47.0 3.1 46.0 43.8 39.8 35.7 31.7 27.7 23.6

1600

72 58.6 3.0 37.7 33.1 28.4 23.7 19.1 - - 54.8 3.3 36.2 31.6 26.9 22.2 17.6 - -

67 54.1 2.9 45.6 40.9 36.2 31.6 26.9 22.2 17.6 50.7 3.2 44.0 39.4 34.7 30.0 25.4 20.7 16.0

62 51.1 2.9 51.1 50.1 45.4 40.8 36.1 31.4 26.8 48.1 3.1 48.1 47.3 42.6 37.9 33.3 28.6 23.9

57 51.1 2.9 51.1 50.1 45.4 40.8 36.1 31.4 26.8 48.1 3.1 48.1 47.3 42.6 37.9 33.3 28.6 23.9

1800

72 59.6 3.0 40.8 35.5 30.2 24.9 19.6 - - 55.7 3.3 39.2 33.9 28.6 23.3 18.0 - -

67 55.1 2.9 49.4 43.8 38.5 33.2 27.9 22.6 17.3 51.6 3.2 47.5 42.2 36.9 31.6 26.3 20.9 15.6

62 51.9 2.9 51.9 51.4 48.3 43.0 37.7 32.4 27.0 48.9 3.2 48.9 48.5 45.3 40.0 34.7 29.4 24.0

57 51.9 2.9 51.9 51.4 48.3 43.0 37.7 32.4 27.0 48.9 3.2 48.9 48.5 45.3 40.0 34.7 29.4 24.0

2000

72 60.6 3.0 43.9 38.0 32.0 26.0 20.1 - - 56.6 3.4 42.2 36.2 30.3 24.3 18.4 - -

67 56.0 3.0 53.2 46.8 40.8 34.8 28.9 22.9 17.0 52.4 3.3 51.0 45.0 39.1 33.1 27.2 21.2 15.2

62 52.8 2.9 52.8 52.8 51.2 45.2 39.2 33.3 27.3 49.7 3.2 49.7 49.7 48.0 42.0 36.1 30.1 24.1

57 52.8 2.9 52.8 52.8 51.2 45.2 39.2 33.3 27.3 49.7 3.2 49.7 49.7 48.0 42.0 36.1 30.1 24.1

95°F 105°F

1200

72 48.7 3.6 28.6 25.2 21.7 18.3 14.9 - - 44.2 3.8 27.3 23.8 20.4 17.0 13.6 - -

67 45.1 3.4 35.3 31.8 28.4 25.0 21.6 18.1 14.7 41.0 3.7 33.7 30.3 26.9 23.5 20.0 16.6 13.2

62 43.1 3.4 40.9 37.5 34.1 30.7 27.2 23.8 20.4 39.5 3.7 38.3 34.9 31.5 28.0 24.6 21.2 17.8

57 43.1 3.4 40.9 37.5 34.1 30.7 27.2 23.8 20.4 39.5 3.7 38.4 35.0 31.6 28.2 24.8 21.4 17.9

1400

72 49.9 3.6 31.6 27.6 23.5 19.5 15.5 - - 45.2 3.9 30.2 26.2 22.1 18.1 14.0 - -

67 46.2 3.5 38.9 34.8 30.8 26.7 22.7 18.7 14.6 42.0 3.7 37.1 33.2 29.1 25.1 21.1 17.0 13.0

62 44.1 3.4 43.0 41.0 36.9 32.9 28.8 24.8 20.8 40.4 3.7 39.8 37.9 34.1 30.1 26.0 22.0 17.9

57 44.1 3.4 43.0 41.0 36.9 32.9 28.8 24.8 20.7 40.4 3.7 39.8 38.0 34.3 30.2 26.2 22.2 18.1

1600

72 51.0 3.6 34.7 30.0 25.4 20.7 16.0 - - 46.2 3.9 33.2 28.5 23.8 19.2 14.5 - -

67 47.3 3.5 42.5 37.8 33.1 28.5 23.8 19.2 14.5 42.9 3.8 40.5 36.1 31.4 26.7 22.1 17.4 12.7

62 45.1 3.4 45.1 44.4 39.8 35.1 30.4 25.8 21.1 41.3 3.7 41.3 40.9 36.8 32.1 27.4 22.8 18.1

57 45.1 3.4 45.1 44.4 39.8 35.1 30.4 25.8 21.1 41.3 3.7 41.3 40.9 36.9 32.3 27.6 22.9 18.3

1800

72 51.9 3.6 37.6 32.3 27.0 21.7 16.3 - - 47.0 3.9 36.1 30.8 25.4 20.1 14.8 - -

67 48.0 3.5 45.6 40.6 35.3 29.9 24.6 19.3 14.0 43.6 3.8 42.4 38.8 33.5 28.2 22.9 17.6 12.2

62 45.9 3.5 45.9 45.5 42.3 37.0 31.7 26.3 21.0 41.9 3.8 41.9 41.7 39.2 33.9 28.6 23.3 17.9

57 45.9 3.5 45.9 45.5 42.3 37.0 31.7 26.3 21.0 41.9 3.8 41.9 41.7 39.3 34.0 28.7 23.4 18.1

2000

72 52.7 3.7 40.5 34.5 28.6 22.6 16.7 - - 47.7 4.0 39.0 33.0 27.0 21.1 15.1 - -

67 48.8 3.5 48.8 43.3 37.4 31.4 25.4 19.5 13.5 44.2 3.8 44.2 41.5 35.6 29.6 23.7 17.7 11.7

62 46.6 3.5 46.6 46.6 44.8 38.8 32.9 26.9 21.0 42.6 3.8 42.6 42.6 41.7 35.7 29.7 23.8 17.8

57 46.6 3.5 46.6 46.6 44.8 38.8 32.9 26.9 21.0 42.6 3.8 42.6 42.6 41.7 35.7 29.8 23.8 17.8

115°F 125°F

1200

72 39.7 4.1 25.9 22.5 19.1 15.7 12.2 - - 35.1 4.4 24.6 21.2 17.8 14.3 10.9 - -

67 36.9 4.0 32.2 28.8 25.3 21.9 18.5 15.1 11.7 32.7 4.2 30.6 27.2 23.8 20.4 17.0 13.5 10.1

62 35.8 3.9 35.7 32.3 28.8 25.4 22.0 18.6 15.1 32.2 4.2 32.2 29.6 26.2 22.8 19.4 15.9 12.5

57 35.8 3.9 35.8 32.6 29.2 25.7 22.3 18.9 15.5 32.2 4.2 32.2 30.1 26.7 23.3 19.9 16.4 13.0

1400

72 40.6 4.2 28.8 24.8 20.7 16.7 12.6 - - 35.9 4.5 27.4 23.3 19.3 15.2 11.2 - -

67 37.7 4.0 35.3 31.5 27.5 23.5 19.4 15.4 11.3 33.4 4.3 33.4 29.9 25.9 21.8 17.8 13.7 9.7

62 36.6 4.0 36.6 34.8 31.3 27.2 23.2 19.2 15.1 32.9 4.3 32.9 31.8 28.5 24.4 20.4 16.3 12.3

57 36.6 4.0 36.6 35.0 31.6 27.6 23.6 19.5 15.5 32.9 4.3 32.9 32.0 29.0 25.0 20.9 16.9 12.8

1600

72 41.4 4.2 31.7 27.0 22.3 17.7 13.0 - - 36.6 4.5 30.1 25.5 20.8 16.2 11.5 - -

67 38.5 4.1 38.5 34.3 29.6 25.0 20.3 15.7 11.0 34.1 4.3 34.1 32.6 27.9 23.2 18.6 13.9 9.2

62 37.4 4.0 37.4 37.4 33.7 29.1 24.4 19.7 15.1 33.6 4.3 33.6 33.6 30.7 26.1 21.4 16.7 12.1

57 37.4 4.0 37.4 37.4 34.1 29.5 24.8 20.1 15.5 33.6 4.3 33.6 33.6 31.3 26.6 22.0 17.3 12.6

1800

72 42.1 4.2 34.5 29.2 23.9 18.6 13.3 - - 37.2 4.5 33.0 27.7 22.4 17.1 11.8 - -

67 39.1 4.1 39.1 37.0 31.7 26.4 21.1 15.8 10.5 34.6 4.4 34.6 34.6 30.0 24.7 19.4 14.0 8.7

62 38.0 4.0 38.0 38.0 36.1 30.8 25.5 20.2 14.9 34.1 4.3 34.1 34.1 33.0 27.7 22.4 17.1 11.8

57 38.0 4.0 38.0 38.0 36.3 31.0 25.7 20.4 15.1 34.1 4.3 34.1 34.1 33.4 28.1 22.7 17.4 12.1

2000

72 42.7 4.3 37.4 31.4 25.5 19.5 13.6 - - 37.7 4.6 35.9 29.9 23.9 18.0 12.0 - -

67 39.7 4.1 39.7 39.7 33.8 27.9 21.9 15.9 10.0 35.1 4.4 35.1 35.1 32.1 26.1 20.1 14.2 8.2

62 38.6 4.1 38.6 38.6 38.5 32.5 26.6 20.6 14.7 34.5 4.4 34.5 34.5 34.5 29.4 23.4 17.5 11.5

57 38.6 4.1 38.6 38.6 38.6 32.6 26.6 20.7 14.7 34.5 4.4 34.5 34.5 34.5 29.5 23.5 17.5 11.6

246836-LTG-E-0107

14 Unitary Products Group

PAC060 (5.0 Ton)

Air on

Evaporator Coil Temperature of Air on Condenser Coil

Total

Capacity1

(MBh)

1. These capacities are gross ratings. For net capacity, deduct air blower motor, MBh = 3.415 x kW. Refer to the appropriate Blower Performance Table for the

kW of the supply air blower motor.

Total

Input

(kW)2

2. These ratings include the condensate fan motors (total .25 kW) and the compressor motors but not the supply air blower motor.

Sensible Capacity (MBh) Total

Capacity1

(MBh)

Total

Input

(kW)2

Sensible Capacity (MBh)

CFM WB

(°F) Return Dry Bulb (°F) Return Dry Bulb (°F)

86 83 80 77 74 71 68 86 83 80 77 74 71 68

75°F 85°F

1500

72 64.6 3.2 37.8 33.6 29.3 25.0 20.7 - - 63.1 3.7 36.0 31.7 27.4 23.2 18.9 - -

67 58.5 3.1 50.6 46.3 42.0 37.7 33.5 29.2 24.9 58.9 3.6 44.6 40.4 36.1 31.8 27.5 23.2 19.0

62 46.8 2.9 75.7 71.4 67.1 62.8 58.6 54.3 50.0 56.4 3.6 51.7 47.5 43.2 38.9 34.6 30.3 26.1

57 53.4 3.0 64.8 60.5 56.2 51.9 47.7 43.4 39.1 56.4 3.6 51.7 47.5 43.2 38.9 34.6 30.3 26.1

1750

72 67.4 3.2 39.1 34.1 29.0 24.0 18.9 - - 64.6 3.7 39.8 34.8 29.7 24.7 19.6 - -

67 61.2 3.1 52.4 47.4 42.3 37.3 32.2 27.2 22.1 60.3 3.6 49.2 44.1 39.1 34.0 29.0 23.9 18.9

62 49.3 2.9 77.7 75.7 70.7 65.6 60.6 55.5 50.5 57.7 3.6 55.4 51.8 46.8 41.7 36.7 31.6 26.6

57 55.9 3.0 64.8 62.8 57.7 52.7 47.6 42.6 37.5 57.7 3.6 55.4 51.8 46.8 41.7 36.7 31.6 26.6

2000

72 70.2 3.3 40.4 34.6 28.8 22.9 17.1 - - 66.1 3.7 43.7 37.9 32.0 26.2 20.4 - -

67 63.8 3.2 54.3 48.5 42.7 36.8 31.0 25.2 19.3 61.7 3.7 53.8 47.9 42.1 36.3 30.4 24.6 18.8

62 51.8 3.0 79.8 80.1 74.3 68.4 62.6 56.8 50.9 59.0 3.6 59.0 56.2 50.4 44.6 38.7 32.9 27.1

57 58.4 3.1 64.7 65.1 59.2 53.4 47.6 41.7 35.9 59.0 3.6 59.0 56.2 50.4 44.6 38.7 32.9 27.1

2250

72 70.0 3.3 47.2 40.5 33.9 27.2 20.6 - - 67.0 3.8 47.6 40.9 34.3 27.6 21.0 - -

67 63.5 3.2 62.6 56.0 49.3 42.7 36.0 29.4 22.8 62.5 3.7 58.3 51.7 45.1 38.4 31.8 25.1 18.5

62 51.2 2.9 80.3 84.2 81.8 75.2 68.5 61.9 55.3 59.8 3.6 59.8 58.4 53.9 47.3 40.6 34.0 27.4

57 58.1 3.1 65.5 69.4 67.1 60.4 53.8 47.1 40.5 59.8 3.6 59.8 58.4 53.9 47.3 40.6 34.0 27.4

2500

72 69.8 3.3 53.9 46.5 39.0 31.6 24.1 - - 67.9 3.8 51.4 44.0 36.5 29.1 21.6 - -

67 63.2 3.1 70.9 63.4 56.0 48.5 41.1 33.6 26.2 63.4 3.7 62.9 55.5 48.0 40.6 33.1 25.7 18.2

62 50.6 2.9 80.8 88.2 89.4 81.9 74.5 67.0 59.6 60.6 3.6 60.6 60.6 57.5 50.0 42.6 35.1 27.7

57 57.7 3.1 66.3 73.8 74.9 67.4 60.0 52.5 45.1 60.6 3.6 60.6 60.6 57.5 50.0 42.6 35.1 27.7

95°F 105°F

1500

72 61.6 4.2 34.2 29.9 25.6 21.3 17.0 - - 57.1 4.6 33.6 29.3 25.1 20.8 16.5 - -

67 59.3 4.1 38.7 34.4 30.1 25.9 21.6 17.3 13.0 54.3 4.5 40.0 35.8 31.5 27.2 22.9 18.7 14.4

62 65.9 4.3 27.8 23.5 19.2 15.0 10.7 6.4 2.1 57.0 4.6 36.9 32.6 28.3 24.0 19.8 15.5 11.2

57 59.3 4.1 38.7 34.4 30.1 25.9 21.6 17.3 13.0 53.7 4.5 42.3 38.0 33.8 29.5 25.2 20.9 16.7

1750

72 61.8 4.2 40.6 35.5 30.4 25.4 20.3 - - 57.7 4.6 38.6 33.6 28.5 23.5 18.4 - -

67 59.4 4.1 46.0 40.9 35.9 30.8 25.7 20.7 15.6 54.8 4.6 45.8 40.8 35.7 30.7 25.6 20.6 15.5

62 66.1 4.3 33.0 27.9 22.9 17.8 12.8 7.7 2.7 57.5 4.6 40.5 36.8 31.7 26.7 21.6 16.6 11.5

57 59.4 4.1 46.0 40.9 35.9 30.8 25.7 20.7 15.6 54.2 4.5 46.9 43.3 38.2 33.1 28.1 23.0 18.0

2000

72 61.9 4.2 47.0 41.1 35.3 29.5 23.6 - - 58.3 4.6 43.7 37.8 32.0 26.2 20.3 - -

67 59.5 4.1 53.2 47.4 41.6 35.7 29.9 24.1 18.2 55.3 4.6 51.6 45.8 40.0 34.2 28.3 22.5 16.7

62 66.2 4.3 38.2 32.4 26.5 20.7 14.9 9.0 3.2 58.1 4.6 44.1 41.0 35.1 29.3 23.5 17.6 11.8

57 59.5 4.1 53.2 47.4 41.6 35.7 29.9 24.1 18.2 54.7 4.6 51.6 48.5 42.6 36.8 31.0 25.1 19.3

2250

72 64.0 4.2 47.9 41.3 34.7 28.0 21.4 - - 59.7 4.7 46.0 39.4 32.7 26.1 19.4 - -

67 61.5 4.2 54.1 47.4 40.8 34.2 27.5 20.9 14.2 56.7 4.6 52.7 47.6 41.0 34.4 27.7 21.1 14.4

62 68.4 4.3 39.3 32.7 26.0 19.4 12.8 6.1 -0.5 59.5 4.7 45.0 41.6 36.5 29.8 23.2 16.6 9.9

57 61.5 4.2 54.1 47.4 40.8 34.2 27.5 20.9 14.2 56.1 4.6 52.4 48.9 43.8 37.2 30.6 23.9 17.3

2500

72 66.0 4.3 48.9 41.5 34.0 26.6 19.1 - - 61.1 4.7 48.3 40.9 33.4 26.0 18.5 - -

67 63.5 4.2 55.0 47.5 40.1 32.6 25.1 17.7 10.2 58.1 4.6 53.8 49.5 42.0 34.6 27.1 19.7 12.2

62 70.6 4.4 40.5 33.0 25.6 18.1 10.7 3.2 -4.2 61.0 4.7 45.9 42.2 37.8 30.4 22.9 15.5 8.0

57 63.5 4.2 55.0 47.5 40.1 32.6 25.1 17.7 10.2 57.4 4.6 53.2 49.4 45.1 37.6 30.2 22.7 15.2

115°F 125°F

1500

72 52.6 5.0 33.1 28.8 24.5 20.3 16.0 - - 48.1 5.5 32.6 28.3 24.0 19.7 15.5 - -

67 49.2 4.9 41.4 37.1 32.8 28.6 24.3 20.0 15.7 44.2 5.3 42.7 38.5 34.2 29.9 25.6 21.4 17.1

62 48.1 4.9 46.0 41.7 37.4 33.1 28.9 24.6 20.3 39.1 5.2 39.1 39.1 39.1 39.1 37.9 33.7 29.4

57 48.1 4.9 45.9 41.7 37.4 33.1 28.8 24.6 20.3 42.4 5.3 42.4 42.4 41.0 36.7 32.5 28.2 23.9

1750

72 53.7 5.1 36.7 31.7 26.6 21.6 16.5 - - 49.6 5.5 34.8 29.8 24.7 19.7 14.6 - -

67 50.2 5.0 45.7 40.7 35.6 30.6 25.5 20.5 15.4 45.6 5.4 45.6 40.6 35.5 30.5 25.4 20.3 15.3

62 49.0 4.9 47.9 45.6 40.6 35.5 30.5 25.4 20.4 40.5 5.3 40.5 40.5 40.5 40.5 39.3 34.3 29.2

57 49.0 4.9 47.9 45.6 40.6 35.5 30.4 25.4 20.3 43.8 5.3 43.8 43.8 42.9 37.9 32.8 27.7 22.7

2000

72 54.7 5.1 40.4 34.5 28.7 22.9 17.0 - - 51.1 5.5 37.1 31.2 25.4 19.6 13.7 - -

67 51.1 5.0 50.1 44.2 38.4 32.6 26.7 20.9 15.1 46.9 5.4 46.9 42.7 36.8 31.0 25.2 19.3 13.5

62 49.9 5.0 49.9 49.6 43.7 37.9 32.1 26.2 20.4 41.8 5.3 41.8 41.8 41.8 41.8 40.7 34.9 29.0

57 49.9 5.0 49.9 49.6 43.7 37.9 32.1 26.2 20.4 45.1 5.4 45.1 45.1 44.8 39.0 33.1 27.3 21.5

2250

72 55.5 5.1 44.1 37.4 30.8 24.1 17.5 - - 51.2 5.5 42.1 35.5 28.8 22.2 15.6 - -

67 51.9 5.0 51.3 47.8 41.2 34.5 27.9 21.3 14.6 47.0 5.4 47.0 47.0 41.4 34.7 28.1 21.5 14.8

62 50.6 5.0 50.6 50.5 46.9 40.3 33.6 27.0 20.3 41.7 5.3 41.7 41.7 41.7 41.7 41.7 37.4 30.8

57 50.6 5.0 50.6 50.4 46.9 40.2 33.6 27.0 20.3 45.2 5.4 45.2 45.2 45.2 43.3 36.6 30.0 23.4

2500

72 56.2 5.1 47.8 40.3 32.9 25.4 18.0 - - 51.3 5.5 47.2 39.7 32.3 24.8 17.4 - -

67 52.6 5.0 52.6 51.4 44.0 36.5 29.1 21.6 14.2 47.1 5.4 47.1 47.1 45.9 38.5 31.0 23.6 16.1

62 51.3 5.0 51.3 51.3 50.1 42.6 35.2 27.7 20.3 41.7 5.3 41.7 41.7 41.7 41.7 41.7 40.0 32.5

57 51.3 5.0 51.3 51.3 50.1 42.6 35.2 27.7 20.3 45.3 5.4 45.3 45.3 45.3 45.3 40.2 32.7 25.3

246836-LTG-E-0107

Unitary Products Group 15

PHP024-060 Cooling Capacities

PHP024 (2.0 Ton)

Air on

Evaporator Coil Temperature of Air on Condenser Coil

Total

Capacity1

(MBh)

1. These capacities are gross ratings. For net capacity, deduct air blower motor, MBh = 3.415 x kW. Refer to the appropriate Blower Performance Table for the

kW of the supply air blower motor.

Total

Input

(kW)2

2. These ratings include the condensate fan motors (total .25 kW) and the compressor motors but not the supply air blower motor.

Sensible Capacity (MBh) Total

Capacity1

(MBh)

Total

Input

(kW)2

Sensible Capacity (MBh)

CFM WB

(°F) Return Dry Bulb (°F) Return Dry Bulb (°F)

86 83 80 77 74 71 68 86 83 80 77 74 71 68

75°F 85°F

600

72 31.9 1.6 18.4 16.7 15.0 13.3 11.6 - - 28.6 1.7 17.2 15.5 13.8 12.1 10.4 - -

67 28.2 1.6 22.0 20.2 18.5 16.8 15.1 13.4 11.7 25.9 1.7 20.9 19.2 17.5 15.8 14.1 12.4 10.7

62 27.9 1.6 27.9 25.7 23.9 22.2 20.5 18.8 17.1 25.2 1.7 25.2 23.6 21.8 20.1 18.4 16.7 15.0

57 28.0 1.6 28.0 25.7 24.0 22.3 20.6 18.9 17.2 25.3 1.7 25.3 23.6 21.9 20.2 18.5 16.7 15.0

700

72 31.9 1.6 20.0 17.9 15.9 13.9 11.9 - - 29.0 1.8 18.9 16.9 14.8 12.8 10.8 - -

67 28.2 1.6 23.7 21.7 19.7 17.6 15.6 13.6 11.6 26.3 1.7 22.8 20.8 18.8 16.8 14.7 12.7 10.7

62 28.0 1.6 28.0 26.8 25.4 23.4 21.4 19.4 17.3 25.6 1.7 25.6 24.8 23.5 21.4 19.4 17.4 15.4

57 28.0 1.6 28.0 26.9 25.5 23.5 21.4 19.4 17.4 25.7 1.7 25.7 24.8 23.5 21.5 19.4 17.4 15.4

800

72 32.0 1.6 21.5 19.2 16.8 14.5 12.2 - - 29.4 1.8 20.5 18.2 15.8 13.5 11.2 - -

67 28.3 1.5 25.4 23.1 20.8 18.5 16.1 13.8 11.5 26.7 1.7 24.7 22.4 20.1 17.7 15.4 13.1 10.8

62 28.0 1.6 28.0 28.0 26.9 24.6 22.2 19.9 17.6 26.0 1.7 26.0 26.0 25.1 22.7 20.4 18.1 15.7

57 28.1 1.6 28.1 28.1 27.0 24.6 22.3 20.0 17.6 26.0 1.7 26.0 26.0 25.1 22.8 20.4 18.1 15.8

900

72 33.8 1.6 23.7 21.0 18.4 15.7 13.1 - - 30.6 1.8 22.5 19.8 17.2 14.5 11.8 - -

67 29.9 1.6 28.4 25.4 22.7 20.1 17.4 14.8 12.1 27.8 1.7 26.8 24.4 21.7 19.1 16.4 13.8 11.1

62 29.6 1.6 29.6 29.6 29.0 26.3 23.7 21.0 18.4 27.0 1.7 27.0 27.0 26.6 23.9 21.3 18.6 15.9

57 29.6 1.6 29.6 29.6 29.1 26.4 23.8 21.1 18.4 27.1 1.7 27.1 27.1 26.6 23.9 21.3 18.6 16.0

1000

72 35.5 1.6 25.9 22.9 20.0 17.0 14.0 - - 31.8 1.8 24.4 21.5 18.5 15.5 12.5 - -

67 31.4 1.6 31.4 27.6 24.7 21.7 18.7 15.7 12.7 28.9 1.8 28.9 26.4 23.4 20.4 17.4 14.5 11.5

62 31.1 1.6 31.1 31.1 31.1 28.1 25.1 22.2 19.2 28.1 1.7 28.1 28.1 28.1 25.1 22.1 19.1 16.1

57 31.2 1.6 31.2 31.2 31.2 28.2 25.2 22.2 19.3 28.1 1.7 28.1 28.1 28.1 25.1 22.1 19.2 16.2

95°F 105°F

600

72 25.3 1.9 16.0 14.3 12.6 10.9 9.2 - - 22.8 2.1 15.4 13.7 12.0 10.3 8.6 - -

67 23.7 1.9 19.9 18.2 16.5 14.7 13.0 11.3 9.6 21.0 2.0 19.0 17.3 15.6 13.8 12.1 10.4 8.7

62 22.6 1.9 22.6 21.5 19.8 18.0 16.3 14.6 12.9 20.2 2.0 20.2 19.7 18.2 16.5 14.8 13.1 11.4

57 22.6 1.9 22.6 21.5 19.7 18.0 16.3 14.6 12.9 20.2 2.0 20.2 19.7 18.2 16.5 14.8 13.1 11.4

700

72 26.1 1.9 17.8 15.8 13.7 11.7 9.7 - - 23.5 2.1 17.1 15.1 13.1 11.1 9.0 - -

67 24.5 1.9 22.0 19.9 17.9 15.9 13.9 11.9 9.8 21.6 2.0 20.3 18.9 17.0 15.0 12.9 10.9 8.9

62 23.3 1.9 23.3 22.7 21.5 19.5 17.5 15.4 13.4 20.9 2.0 20.9 20.6 19.9 17.9 15.8 13.8 11.8

57 23.3 1.9 23.3 22.7 21.5 19.5 17.5 15.4 13.4 20.9 2.0 20.9 20.6 19.9 17.9 15.8 13.8 11.8

800

72 26.9 1.9 19.5 17.2 14.9 12.5 10.2 - - 24.2 2.1 18.8 16.5 14.2 11.8 9.5 - -

67 25.2 1.9 24.0 21.7 19.4 17.0 14.7 12.4 10.0 22.3 2.1 21.7 20.5 18.4 16.1 13.7 11.4 9.1

62 24.0 1.9 24.0 24.0 23.3 20.9 18.6 16.3 13.9 21.5 2.0 21.5 21.5 21.5 19.2 16.9 14.5 12.2

57 24.0 1.9 24.0 24.0 23.3 20.9 18.6 16.3 13.9 21.5 2.0 21.5 21.5 21.5 19.2 16.9 14.5 12.2

900

72 27.5 1.9 21.2 18.6 15.9 13.3 10.6 - - 24.7 2.1 20.5 17.8 15.2 12.5 9.9 - -

67 25.7 1.9 25.2 23.4 20.8 18.1 15.4 12.8 10.1 22.7 2.1 22.5 21.6 19.7 17.0 14.4 11.7 9.1

62 24.5 1.9 24.5 24.5 24.1 21.5 18.8 16.2 13.5 21.9 2.1 21.9 21.9 21.9 19.3 16.6 14.0 11.3

57 24.5 1.9 24.5 24.5 24.1 21.5 18.8 16.2 13.5 21.9 2.1 21.9 21.9 21.9 19.3 16.6 14.0 11.3

1000

72 28.0 2.0 23.0 20.0 17.0 14.0 11.0 - - 25.2 2.1 22.1 19.2 16.2 13.2 10.2 - -

67 26.3 1.9 26.3 25.1 22.1 19.2 16.2 13.2 10.2 23.2 2.1 23.2 22.6 21.0 18.0 15.0 12.1 9.1

62 25.0 1.9 25.0 25.0 25.0 22.0 19.1 16.1 13.1 22.4 2.1 22.4 22.4 22.4 19.4 16.4 13.4 10.4

57 25.0 1.9 25.0 25.0 25.0 22.0 19.1 16.1 13.1 22.4 2.1 22.4 22.4 22.4 19.4 16.4 13.4 10.4

115°F 125°F

600

72 20.3 2.3 14.8 13.1 11.4 9.6 7.9 - - 17.8 2.4 14.1 12.4 10.7 9.0 7.3 - -

67 18.3 2.2 18.1 16.4 14.7 12.9 11.2 9.5 7.8 15.6 2.3 15.6 15.5 13.8 12.0 10.3 8.6 6.9

62 17.9 2.2 17.9 17.9 16.7 15.0 13.3 11.5 9.8 15.6 2.3 15.6 15.6 15.1 13.4 11.7 10.0 8.3

57 17.9 2.2 17.9 17.9 16.7 15.0 13.3 11.5 9.8 15.6 2.3 15.6 15.6 15.1 13.4 11.7 10.0 8.3

700

72 20.9 2.3 16.5 14.4 12.4 10.4 8.4 - - 18.2 2.5 15.8 13.8 11.8 9.7 7.7 - -

67 18.8 2.2 18.7 17.9 16.0 14.0 12.0 10.0 7.9 16.0 2.4 16.0 16.0 15.1 13.1 11.0 9.0 7.0

62 18.4 2.2 18.4 18.4 18.2 16.2 14.2 12.2 10.2 16.0 2.3 16.0 16.0 16.0 14.6 12.6 10.6 8.5

57 18.4 2.2 18.4 18.4 18.2 16.2 14.2 12.2 10.2 16.0 2.3 16.0 16.0 16.0 14.6 12.6 10.6 8.5

800

72 21.4 2.3 18.2 15.8 13.5 11.2 8.8 - - 18.7 2.5 17.5 15.1 12.8 10.5 8.1 - -

67 19.4 2.2 19.4 19.4 17.4 15.1 12.7 10.4 8.1 16.5 2.4 16.5 16.5 16.4 14.1 11.8 9.4 7.1

62 18.9 2.2 18.9 18.9 19.8 17.5 15.2 12.8 10.5 16.4 2.4 16.4 16.4 16.4 15.8 13.4 11.1 8.8

57 18.9 2.2 18.9 18.9 19.8 17.5 15.2 12.8 10.5 16.4 2.4 16.4 16.4 16.4 15.8 13.4 11.1 8.8

900

72 21.9 2.3 19.7 17.1 14.4 11.8 9.1 - - 19.1 2.5 19.0 16.3 13.7 11.0 8.4 - -

67 19.8 2.2 19.8 19.8 18.6 16.0 13.3 10.7 8.0 16.8 2.4 16.8 16.8 16.8 14.9 12.3 9.6 6.9

62 19.3 2.2 19.3 19.3 19.8 17.1 14.4 11.8 9.1 16.7 2.4 16.7 16.7 16.7 14.9 12.3 9.6 6.9

57 19.3 2.2 19.3 19.3 19.8 17.1 14.4 11.8 9.1 16.7 2.4 16.7 16.7 16.7 14.9 12.2 9.6 6.9

1000

72 22.3 2.3 21.3 18.4 15.4 12.4 9.4 - - 19.4 2.5 19.4 17.6 14.6 11.6 8.6 - -

67 20.1 2.3 20.1 20.1 19.9 16.9 13.9 10.9 7.9 17.1 2.4 17.1 17.1 17.1 15.7 12.7 9.8 6.8

62 19.7 2.2 19.7 19.7 19.7 16.7 13.7 10.7 7.8 17.0 2.4 17.0 17.0 17.0 14.0 11.1 8.1 5.1

57 19.7 2.2 19.7 19.7 19.7 16.7 13.7 10.7 7.8 17.0 2.4 17.0 17.0 17.0 14.0 11.1 8.1 5.1

246836-LTG-E-0107

16 Unitary Products Group

PHP030 (2.5 Ton)

Air on

Evaporator Coil Temperature of Air on Condenser Coil

Total

Capacity1

(MBh)

1. These capacities are gross ratings. For net capacity, deduct air blower motor, MBh = 3.415 x kW. Refer to the appropriate Blower Performance Table for the

kW of the supply air blower motor.

Total

Input

(kW)2

2. These ratings include the condensate fan motors (total .25 kW) and the compressor motors but not the supply air blower motor.

Sensible Capacity (MBh) Total

Capacity1

(MBh)

Total

Input

(kW)2

Sensible Capacity (MBh)

CFM WB

(°F) Return Dry Bulb (°F) Return Dry Bulb (°F)

86 83 80 77 74 71 68 86 83 80 77 74 71 68

75°F 85°F

750

72 34.8 2.0 22.8 20.7 18.6 16.4 14.3 - - 31.5 2.1 19.8 17.6 15.5 13.3 11.2 - -

67 32.8 2.0 28.4 26.2 24.1 22.0 19.8 17.7 15.5 28.8 2.0 24.2 22.1 19.9 17.8 15.7 13.5 11.4

62 30.6 2.0 32.3 31.2 29.0 26.9 24.8 22.6 20.5 28.0 2.0 28.0 26.3 24.2 22.1 19.9 17.8 15.6

57 30.6 2.0 32.3 31.2 29.0 26.9 24.8 22.6 20.5 28.0 2.0 28.0 26.3 24.2 22.0 19.9 17.8 15.6

875

72 37.4 2.1 25.7 23.2 20.7 18.2 15.6 - - 33.2 2.1 22.2 19.6 17.1 14.6 12.0 - -

67 35.2 2.1 31.9 29.4 26.9 24.3 21.8 19.3 16.8 30.3 2.1 27.1 24.5 22.0 19.5 17.0 14.4 11.9

62 32.9 2.0 33.7 33.7 32.4 29.9 27.3 24.8 22.3 29.5 2.1 29.5 28.6 26.7 24.2 21.7 19.1 16.6

57 32.9 2.0 33.7 33.7 32.4 29.8 27.3 24.8 22.3 29.5 2.1 29.5 28.6 26.7 24.2 21.7 19.1 16.6

1000

72 39.9 2.1 28.7 25.7 22.8 19.9 17.0 - - 34.9 2.1 24.6 21.6 18.7 15.8 12.9 - -

67 37.6 2.1 35.5 32.5 29.6 26.7 23.8 20.9 18.0 31.8 2.1 29.9 27.0 24.1 21.2 18.3 15.4 12.4

62 35.2 2.1 35.2 36.2 35.7 32.8 29.9 27.0 24.1 30.9 2.1 30.9 30.9 29.3 26.3 23.4 20.5 17.6

57 35.1 2.1 35.1 36.2 35.7 32.8 29.9 27.0 24.1 30.9 2.1 30.9 30.9 29.3 26.3 23.4 20.5 17.6

1125

72 39.9 2.1 30.3 27.0 23.7 20.4 17.1 - - 35.5 2.1 26.5 23.2 19.8 16.5 13.2 - -

67 37.6 2.1 36.5 34.1 30.8 27.5 24.1 20.8 17.5 32.4 2.1 31.4 28.9 25.5 22.2 18.9 15.6 12.2

62 35.1 2.1 35.1 35.6 36.4 33.1 29.8 26.4 23.1 31.5 2.1 31.5 31.5 30.6 27.3 24.0 20.7 17.4

57 35.1 2.1 35.1 35.6 36.4 33.1 29.8 26.4 23.1 31.5 2.1 31.5 31.5 30.6 27.3 24.0 20.7 17.4

1250

72 39.8 2.1 32.0 28.3 24.6 20.8 17.1 - - 36.1 2.1 28.4 24.7 20.9 17.2 13.5 - -

67 37.5 2.1 37.5 35.7 31.9 28.2 24.5 20.8 17.0 32.9 2.1 32.9 30.7 27.0 23.2 19.5 15.8 12.1

62 35.0 2.1 35.0 35.0 37.1 33.4 29.6 25.9 22.2 32.0 2.1 32.0 32.0 32.0 28.3 24.6 20.8 17.1

57 35.0 2.1 35.0 35.0 37.1 33.4 29.6 25.9 22.2 32.0 2.1 32.0 32.0 32.0 28.3 24.6 20.8 17.1

95°F 105°F

750

72 28.2 2.1 16.7 14.6 12.4 10.3 8.1 - - 24.8 2.2 15.7 13.6 11.4 9.3 7.2 - -

67 24.7 2.0 20.1 17.9 15.8 13.6 11.5 9.4 7.2 22.2 2.2 19.0 16.9 14.7 12.6 10.4 8.3 6.2

62 25.3 2.0 23.6 21.5 19.3 17.2 15.1 12.9 10.8 22.5 2.2 21.6 19.6 17.5 15.3 13.2 11.0 8.9

57 25.3 2.0 23.6 21.5 19.3 17.2 15.1 12.9 10.8 22.5 2.2 21.6 19.6 17.5 15.3 13.2 11.0 8.9

875

72 29.0 2.1 18.6 16.0 13.5 11.0 8.5 - - 25.5 2.2 17.5 15.0 12.5 9.9 7.4 - -

67 25.4 2.0 22.2 19.7 17.2 14.7 12.1 9.6 7.1 22.8 2.2 20.7 18.6 16.0 13.5 11.0 8.5 5.9

62 26.0 2.1 25.2 23.6 21.1 18.5 16.0 13.5 11.0 23.1 2.2 22.7 21.4 19.0 16.5 14.0 11.4 8.9

57 26.0 2.1 25.2 23.6 21.1 18.5 16.0 13.5 11.0 23.1 2.2 22.7 21.4 19.0 16.5 14.0 11.4 8.9

1000

72 29.8 2.1 20.5 17.5 14.6 11.7 8.8 - - 26.2 2.3 19.3 16.4 13.5 10.6 7.6 - -

67 26.1 2.1 24.4 21.5 18.6 15.7 12.8 9.8 6.9 23.3 2.2 22.5 20.3 17.4 14.4 11.5 8.6 5.7

62 26.7 2.1 26.7 25.7 22.8 19.9 17.0 14.0 11.1 23.7 2.2 23.7 23.2 20.6 17.7 14.8 11.8 8.9

57 26.7 2.1 26.7 25.7 22.8 19.9 17.0 14.0 11.1 23.7 2.2 23.7 23.2 20.6 17.7 14.8 11.8 8.9

1125

72 31.1 2.1 22.6 19.3 16.0 12.6 9.3 - - 27.1 2.3 21.4 18.0 14.7 11.4 8.1 - -

67 27.2 2.1 26.4 23.6 20.3 17.0 13.6 10.3 7.0 24.2 2.2 23.8 22.0 19.0 15.6 12.3 9.0 5.7

62 27.9 2.1 27.9 27.4 24.9 21.5 18.2 14.9 11.6 24.5 2.2 24.5 24.3 22.5 19.2 15.8 12.5 9.2

57 27.9 2.1 27.9 27.4 24.9 21.6 18.2 14.9 11.6 24.5 2.2 24.5 24.3 22.5 19.2 15.8 12.5 9.2

1250

72 32.4 2.2 24.8 21.0 17.3 13.6 9.8 - - 28.1 2.3 23.4 19.7 16.0 12.2 8.5 - -

67 28.4 2.1 28.4 25.7 22.0 18.3 14.5 10.8 7.1 25.0 2.2 25.0 23.7 20.6 16.8 13.1 9.4 5.7

62 29.1 2.1 29.1 29.1 26.9 23.2 19.5 15.8 12.0 25.4 2.2 25.4 25.4 24.4 20.6 16.9 13.2 9.4

57 29.1 2.1 29.1 29.1 27.0 23.2 19.5 15.8 12.0 25.4 2.2 25.4 25.4 24.4 20.6 16.9 13.2 9.5

115°F 125°F

750

72 21.5 2.3 14.7 12.6 10.4 8.3 6.2 - - 18.1 2.5 13.7 11.6 9.5 7.3 5.2 - -

67 19.6 2.3 17.9 15.8 13.7 11.5 9.4 7.2 5.1 17.0 2.4 16.9 14.7 12.6 10.5 8.3 6.2 4.0

62 19.6 2.3 19.6 17.7 15.6 13.4 11.3 9.2 7.0 16.8 2.4 16.8 15.8 13.7 11.6 9.4 7.3 5.2

57 19.6 2.3 19.6 17.7 15.6 13.4 11.3 9.2 7.0 16.8 2.4 16.8 15.8 13.7 11.6 9.4 7.3 5.1

875

72 22.0 2.4 16.4 13.9 11.4 8.9 6.3 - - 18.5 2.5 15.4 12.8 10.3 7.8 5.3 - -

67 20.1 2.3 19.2 17.4 14.9 12.4 9.8 7.3 4.8 17.4 2.4 17.4 16.3 13.7 11.2 8.7 6.2 3.6

62 20.1 2.3 20.1 19.2 17.0 14.5 11.9 9.4 6.9 17.2 2.4 17.2 17.0 14.9 12.4 9.9 7.4 4.8

57 20.1 2.3 20.1 19.2 17.0 14.5 11.9 9.4 6.9 17.2 2.4 17.2 17.0 14.9 12.4 9.9 7.4 4.8

1000

72 22.5 2.4 18.2 15.2 12.3 9.4 6.5 - - 18.9 2.5 17.0 14.1 11.2 8.3 5.3 - -

67 20.6 2.3 20.6 19.0 16.1 13.2 10.3 7.4 4.5 17.8 2.5 17.8 17.8 14.9 12.0 9.1 6.1 3.2

62 20.6 2.3 20.6 20.6 18.4 15.5 12.6 9.6 6.7 17.6 2.5 17.6 17.6 16.2 13.3 10.4 7.4 4.5

57 20.6 2.3 20.6 20.6 18.4 15.5 12.6 9.6 6.7 17.5 2.5 17.5 17.5 16.2 13.3 10.4 7.4 4.5

1125

72 23.2 2.4 20.1 16.8 13.5 10.2 6.8 - - 19.2 2.5 18.9 15.6 12.2 8.9 5.6 - -

67 21.1 2.3 21.1 20.4 17.6 14.3 11.0 7.7 4.3 18.1 2.5 18.1 18.1 16.3 13.0 9.7 6.3 3.0

62 21.2 2.3 21.2 21.2 20.1 16.8 13.4 10.1 6.8 17.8 2.5 17.8 17.8 17.7 14.4 11.0 7.7 4.4

57 21.2 2.3 21.2 21.2 20.1 16.8 13.4 10.1 6.8 17.8 2.5 17.8 17.8 17.7 14.4 11.0 7.7 4.4

1250

72 23.8 2.4 22.1 18.4 14.6 10.9 7.2 - - 19.5 2.6 19.5 17.0 13.3 9.6 5.9 - -

67 21.7 2.4 21.7 21.7 19.1 15.4 11.7 8.0 4.2 18.4 2.5 18.4 18.4 17.7 14.0 10.3 6.5 2.8

62 21.8 2.4 21.8 21.8 21.8 18.0 14.3 10.6 6.9 18.1 2.5 18.1 18.1 18.1 15.4 11.7 8.0 4.3

57 21.8 2.4 21.8 21.8 21.8 18.0 14.3 10.6 6.9 18.1 2.5 18.1 18.1 18.1 15.4 11.7 8.0 4.3

246836-LTG-E-0107

Unitary Products Group 17

PHP036 (3.0 Ton)

Air on

Evaporator Coil Temperature of Air on Condenser Coil

Total

Capacity1

(MBh)

1. These capacities are gross ratings. For net capacity, deduct air blower motor, MBh = 3.415 x kW. Refer to the appropriate Blower Performance Table for the

kW of the supply air blower motor.

Total

Input

(kW)2

2. These ratings include the condensate fan motors (total .25 kW) and the compressor motors but not the supply air blower motor.

Sensible Capacity (MBh) Total

Capacity1

(MBh)

Total

Input

(kW)2

Sensible Capacity (MBh)

CFM WB

(°F) Return Dry Bulb (°F) Return Dry Bulb (°F)

86 83 80 77 74 71 68 86 83 80 77 74 71 68

75°F 85°F

900

72 48.2 2.6 25.4 22.8 20.2 17.7 15.1 - - 41.6 2.8 23.7 21.1 18.6 16.0 13.4 - -

67 42.9 2.5 30.6 28.1 25.5 22.9 20.4 17.8 15.2 38.2 2.7 29.0 26.4 23.9 21.3 18.7 16.2 13.6

62 43.3 2.6 36.6 34.1 31.5 28.9 26.4 23.8 21.2 37.6 2.7 33.7 31.1 28.6 26.0 23.4 20.9 18.3

57 43.3 2.6 36.6 34.1 31.5 28.9 26.4 23.8 21.2 37.6 2.7 33.7 31.1 28.6 26.0 23.4 20.9 18.3

1050

72 48.8 2.6 27.9 24.9 21.9 18.8 15.8 - - 42.7 2.8 26.3 23.3 20.2 17.2 14.2 - -

67 43.4 2.5 33.6 30.6 27.5 24.5 21.5 18.4 15.4 39.2 2.7 32.1 29.0 26.0 23.0 19.9 16.9 13.9

62 43.8 2.6 40.5 37.1 34.0 31.0 28.0 24.9 21.9 38.6 2.7 36.7 34.2 31.1 28.1 25.1 22.0 19.0

57 43.8 2.6 40.5 37.1 34.0 31.0 28.0 24.9 21.9 38.6 2.7 36.7 34.2 31.1 28.1 25.1 22.0 19.0

1200

72 49.4 2.6 30.5 27.0 23.5 20.0 16.5 - - 43.8 2.8 28.9 25.4 21.9 18.4 14.9 - -

67 43.9 2.5 36.6 33.1 29.6 26.1 22.6 19.1 15.6 40.2 2.8 35.1 31.6 28.1 24.6 21.1 17.6 14.1

62 44.3 2.6 44.3 40.0 36.5 33.0 29.5 26.0 22.6 39.6 2.8 39.6 37.2 33.7 30.2 26.7 23.2 19.7

57 44.4 2.6 44.4 40.0 36.5 33.0 29.6 26.1 22.6 39.6 2.8 39.6 37.2 33.7 30.2 26.7 23.2 19.7

1350

72 51.0 2.7 33.3 29.3 25.4 21.4 17.4 - - 44.6 2.8 31.5 27.5 23.5 19.5 15.5 - -

67 45.3 2.6 41.3 35.9 31.9 28.0 24.0 20.0 16.0 40.9 2.8 38.1 34.2 30.2 26.2 22.2 18.2 14.2

62 45.8 2.6 45.8 43.6 39.5 35.5 31.5 27.6 23.6 40.3 2.8 40.3 39.1 36.1 32.1 28.2 24.2 20.2

57 45.8 2.6 45.8 43.6 39.5 35.5 31.5 27.6 23.6 40.3 2.8 40.3 39.1 36.1 32.1 28.2 24.2 20.2

1500

72 52.6 2.7 36.2 31.7 27.2 22.8 18.3 - - 45.3 2.8 34.0 29.5 25.1 20.6 16.1 - -

67 46.8 2.6 46.0 38.8 34.3 29.9 25.4 20.9 16.4 41.6 2.8 41.2 36.7 32.2 27.7 23.3 18.8 14.3

62 47.2 2.6 47.2 47.2 42.5 38.0 33.5 29.1 24.6 40.9 2.8 40.9 40.9 38.6 34.1 29.6 25.2 20.7

57 47.2 2.6 47.2 47.2 42.5 38.0 33.5 29.1 24.6 40.9 2.8 40.9 40.9 38.6 34.1 29.6 25.2 20.7

95°F 105°F

900

72 35.1 2.9 22.0 19.5 16.9 14.3 11.8 - - 32.3 3.2 21.5 18.9 16.4 13.8 11.2 - -

67 33.5 2.9 27.4 24.8 22.2 19.7 17.1 14.5 12.0 30.2 3.1 26.4 23.9 21.3 18.7 16.2 13.6 11.0

62 31.9 2.9 30.8 28.2 25.7 23.1 20.5 18.0 15.4 29.1 3.1 28.5 26.8 24.2 21.6 19.1 16.5 13.9

57 31.9 2.9 30.8 28.2 25.7 23.1 20.5 18.0 15.4 29.1 3.1 28.5 26.8 24.2 21.6 19.1 16.5 13.9

1050

72 36.7 3.0 24.7 21.7 18.6 15.6 12.6 - - 33.4 3.2 24.0 20.9 17.9 14.9 11.8 - -

67 35.0 2.9 30.5 27.5 24.5 21.4 18.4 15.4 12.3 31.2 3.2 28.7 26.3 23.3 20.3 17.2 14.2 11.2

62 33.4 2.9 32.8 31.3 28.2 25.2 22.2 19.1 16.1 30.1 3.1 29.8 28.8 26.4 23.4 20.4 17.3 14.3

57 33.4 2.9 32.8 31.3 28.2 25.2 22.2 19.1 16.1 30.1 3.1 29.8 28.8 26.4 23.4 20.4 17.3 14.3

1200

72 38.3 3.0 27.3 23.8 20.3 16.8 13.3 - - 34.5 3.3 26.4 22.9 19.4 15.9 12.4 - -

67 36.5 3.0 33.7 30.2 26.7 23.2 19.7 16.2 12.7 32.3 3.2 30.9 28.8 25.3 21.8 18.3 14.8 11.3

62 34.8 2.9 34.8 34.3 30.8 27.3 23.8 20.3 16.8 31.1 3.2 31.1 30.8 28.7 25.2 21.7 18.2 14.7

57 34.8 2.9 34.8 34.3 30.8 27.3 23.8 20.3 16.8 31.1 3.2 31.1 30.8 28.7 25.2 21.7 18.2 14.7

1350

72 38.2 3.0 29.6 25.6 21.6 17.6 13.6 - - 34.7 3.3 28.8 24.8 20.8 16.8 12.8 - -

67 36.4 3.0 35.0 32.4 28.4 24.4 20.4 16.5 12.5 32.5 3.2 31.8 30.3 27.1 23.1 19.1 15.1 11.1

62 34.8 2.9 34.8 34.5 32.7 28.8 24.8 20.8 16.8 31.3 3.2 31.3 31.2 30.1 26.1 22.1 18.1 14.2

57 34.8 2.9 34.8 34.5 32.7 28.8 24.8 20.8 16.8 31.3 3.2 31.3 31.2 30.1 26.1 22.1 18.1 14.2

1500

72 38.1 3.0 31.8 27.4 22.9 18.4 14.0 - - 35.0 3.3 31.1 26.7 22.2 17.7 13.3 - -

67 36.3 3.0 36.3 34.6 30.1 25.6 21.2 16.7 12.2 32.7 3.2 32.7 31.8 28.9 24.4 20.0 15.5 11.0

62 34.7 2.9 34.7 34.7 34.7 30.2 25.7 21.2 16.8 31.5 3.2 31.5 31.5 31.5 27.1 22.6 18.1 13.6

57 34.7 2.9 34.7 34.7 34.7 30.2 25.7 21.2 16.8 31.5 3.2 31.5 31.5 31.5 27.1 22.6 18.1 13.6

115°F 125°F

900

72 29.4 3.4 21.0 18.4 15.8 13.3 10.7 - - 26.6 3.7 20.4 17.9 15.3 12.7 10.2 - -

67 26.9 3.4 25.5 23.0 20.4 17.8 15.3 12.7 10.1 23.6 3.6 23.6 22.0 19.5 16.9 14.3 11.8 9.2

62 26.2 3.3 26.2 25.3 22.7 20.2 17.6 15.0 12.5 23.4 3.6 23.4 23.4 21.3 18.7 16.1 13.6 11.0

57 26.2 3.3 26.2 25.3 22.7 20.2 17.6 15.0 12.5 23.4 3.6 23.4 23.4 21.3 18.7 16.1 13.6 11.0

1050

72 30.0 3.5 23.2 20.2 17.2 14.1 11.1 - - 26.7 3.7 22.5 19.5 16.4 13.4 10.4 - -

67 27.4 3.4 26.8 25.1 22.1 19.1 16.0 13.0 10.0 23.7 3.6 23.7 23.7 20.9 17.9 14.8 11.8 8.8

62 26.8 3.4 26.8 26.3 24.6 21.6 18.6 15.5 12.5 23.5 3.6 23.5 23.5 22.8 19.8 16.8 13.7 10.7

57 26.8 3.4 26.8 26.3 24.6 21.6 18.6 15.5 12.5 23.5 3.6 23.5 23.5 22.8 19.8 16.8 13.7 10.7

1200

72 30.6 3.5 25.5 22.0 18.5 15.0 11.5 - - 26.8 3.8 24.6 21.1 17.6 14.1 10.6 - -

67 28.0 3.4 28.0 27.3 23.8 20.3 16.8 13.3 9.8 23.7 3.7 23.7 23.7 22.4 18.9 15.4 11.9 8.4

62 27.3 3.4 27.3 27.3 26.5 23.0 19.5 16.0 12.5 23.6 3.6 23.6 23.6 23.6 20.9 17.4 13.9 10.4

57 27.3 3.4 27.3 27.3 26.5 23.0 19.5 16.0 12.5 23.6 3.6 23.6 23.6 23.6 20.9 17.4 13.9 10.4

1350

72 31.2 3.5 28.0 24.0 20.0 16.0 12.0 - - 27.8 3.8 27.1 23.2 19.2 15.2 11.2 - -

67 28.6 3.5 28.6 28.2 25.7 21.8 17.8 13.8 9.8 24.6 3.7 24.6 24.6 24.4 20.4 16.4 12.5 8.5

62 27.9 3.4 27.9 27.9 27.5 23.5 19.5 15.5 11.5 24.4 3.6 24.4 24.4 24.4 20.8 16.9 12.9 8.9

57 27.9 3.4 27.9 27.9 27.5 23.5 19.5 15.5 11.5 24.4 3.6 24.4 24.4 24.4 20.8 16.9 12.9 8.9

1500

72 31.8 3.5 30.4 26.0 21.5 17.0 12.6 - - 28.7 3.8 28.7 25.3 20.8 16.3 11.8 - -

67 29.1 3.5 29.1 29.1 27.7 23.2 18.7 14.3 9.8 25.5 3.7 25.5 25.5 25.5 22.0 17.5 13.1 8.6

62 28.4 3.4 28.4 28.4 28.4 23.9 19.5 15.0 10.5 25.3 3.7 25.3 25.3 25.3 20.8 16.3 11.9 7.4

57 28.4 3.4 28.4 28.4 28.4 23.9 19.5 15.0 10.5 25.3 3.7 25.3 25.3 25.3 20.8 16.3 11.9 7.4

246836-LTG-E-0107

18 Unitary Products Group

PHP042 (3.5 Ton)

Air on

Evaporator Coil Temperature of Air on Condenser Coil

Total

Capacity1

(MBh)

1. These capacities are gross ratings. For net capacity, deduct air blower motor, MBh = 3.415 x kW. Refer to the appropriate Blower Performance Table for the

kW of the supply air blower motor.

Total

Input

(kW)2

2. These ratings include the condensate fan motors (total .25 kW) and the compressor motors but not the supply air blower motor.

Sensible Capacity (MBh) Total

Capacity1

(MBh)

Total

Input

(kW)2

Sensible Capacity (MBh)

CFM WB

(°F) Return Dry Bulb (°F) Return Dry Bulb (°F)

86 83 80 77 74 71 68 86 83 80 77 74 71 68

75°F 85°F

1050

72 52.6 2.8 29.0 26.1 23.1 20.1 17.1 - - 48.2 3.0 28.0 25.0 22.0 19.0 16.0 - -

67 51.1 2.8 36.6 33.6 30.6 27.6 24.6 21.7 18.7 46.6 3.0 35.2 32.2 29.2 26.2 23.2 20.2 17.2

62 48.2 2.7 42.2 39.2 36.2 33.2 30.2 27.2 24.2 44.3 3.0 40.1 37.1 34.1 31.1 28.1 25.1 22.1

57 48.1 2.7 42.1 39.1 36.1 33.1 30.1 27.1 24.1 44.3 3.0 40.0 37.0 34.0 31.1 28.1 25.1 22.1

1225

72 53.0 2.8 32.0 28.5 24.9 21.4 17.9 - - 49.4 3.1 31.1 27.5 24.0 20.5 16.9 - -

67 51.5 2.7 40.2 36.7 33.1 29.6 26.0 22.5 19.0 47.8 3.0 38.8 35.3 31.8 28.2 24.7 21.1 17.6

62 48.6 2.7 45.6 42.7 39.1 35.6 32.1 28.5 25.0 45.5 3.0 43.3 40.7 37.1 33.6 30.0 26.5 23.0

57 48.5 2.7 45.5 42.6 39.1 35.5 32.0 28.4 24.9 45.4 3.0 43.3 40.6 37.1 33.5 30.0 26.5 22.9

1400

72 53.5 2.7 35.0 30.9 26.8 22.7 18.6 - - 50.7 3.1 34.1 30.0 26.0 21.9 17.8 - -

67 52.0 2.7 43.8 39.7 35.6 31.5 27.4 23.4 19.3 49.0 3.1 42.5 38.4 34.4 30.3 26.2 22.1 18.0

62 49.0 2.7 49.0 46.2 42.1 38.0 33.9 29.8 25.8 46.6 3.0 46.6 44.2 40.2 36.1 32.0 27.9 23.8

57 48.9 2.7 48.9 46.1 42.0 37.9 33.8 29.7 25.7 46.6 3.0 46.6 44.2 40.1 36.0 31.9 27.9 23.8

1575

72 55.4 2.8 38.2 33.6 28.9 24.3 19.7 - - 51.5 3.1 37.2 32.5 27.9 23.2 18.6 - -

67 53.8 2.8 49.1 43.1 38.5 33.8 29.2 24.5 19.9 49.8 3.1 46.2 41.6 36.9 32.3 27.6 23.0 18.3

62 50.8 2.7 50.8 49.3 45.4 40.8 36.1 31.5 26.8 47.4 3.0 47.4 46.2 43.2 38.5 33.9 29.2 24.6

57 50.7 2.7 50.7 49.2 45.3 40.7 36.0 31.4 26.8 47.3 3.0 47.3 46.1 43.1 38.5 33.8 29.2 24.5

1750

72 57.3 2.8 41.5 36.3 31.1 25.9 20.7 - - 52.3 3.1 40.3 35.1 29.8 24.6 19.4 - -

67 55.7 2.8 54.4 46.5 41.3 36.1 30.9 25.7 20.4 50.6 3.1 49.9 44.7 39.5 34.3 29.1 23.9 18.6

62 52.5 2.8 52.5 52.5 48.8 43.6 38.4 33.2 27.9 48.1 3.0 48.1 48.1 46.2 41.0 35.7 30.5 25.3

57 52.4 2.8 52.4 52.4 48.7 43.5 38.3 33.1 27.8 48.1 3.0 48.1 48.1 46.1 40.9 35.7 30.5 25.3

95°F 105°F

1050

72 43.7 3.3 27.0 24.0 21.0 18.0 15.0 - - 41.7 3.7 26.1 23.1 20.1 17.1 14.1 - -

67 42.0 3.3 33.7 30.7 27.7 24.7 21.7 18.7 15.7 38.5 3.6 32.3 29.3 26.3 23.3 20.3 17.3 14.3

62 40.4 3.2 38.0 35.0 32.0 29.0 26.0 23.0 20.0 38.0 3.6 35.8 32.8 29.8 26.8 23.8 20.8 17.8

57 40.4 3.2 38.0 35.0 32.0 29.0 26.0 23.0 20.0 38.0 3.6 35.8 32.8 29.8 26.8 23.8 20.8 17.8

1225

72 45.8 3.4 30.1 26.6 23.1 19.5 16.0 - - 43.2 3.8 29.1 25.6 22.1 18.5 15.0 - -

67 44.0 3.3 37.5 33.9 30.4 26.9 23.3 19.8 16.2 39.9 3.6 35.6 32.4 28.9 25.3 21.8 18.3 14.7

62 42.3 3.3 41.1 38.6 35.1 31.6 28.0 24.5 20.9 39.3 3.6 38.2 36.2 32.7 29.1 25.6 22.1 18.5

57 42.3 3.3 41.1 38.6 35.1 31.6 28.0 24.5 20.9 39.3 3.6 38.2 36.2 32.7 29.1 25.6 22.1 18.5

1400

72 47.9 3.4 33.3 29.2 25.1 21.0 16.9 - - 44.7 3.8 32.2 28.1 24.0 19.9 15.9 - -

67 46.0 3.4 41.3 37.2 33.1 29.0 24.9 20.9 16.8 41.3 3.7 38.9 35.5 31.4 27.3 23.3 19.2 15.1

62 44.2 3.3 44.2 42.3 38.2 34.1 30.1 26.0 21.9 40.7 3.7 40.7 39.7 35.6 31.5 27.4 23.3 19.3

57 44.2 3.3 44.2 42.3 38.2 34.1 30.1 26.0 21.9 40.7 3.7 40.7 39.7 35.6 31.5 27.4 23.3 19.3

1575

72 47.6 3.4 36.1 31.5 26.8 22.2 17.5 - - 45.4 3.8 35.1 30.5 25.8 21.2 16.5 - -

67 45.8 3.4 43.4 40.0 35.4 30.7 26.1 21.4 16.8 41.9 3.7 40.7 38.4 33.8 29.2 24.5 19.9 15.2

62 44.0 3.3 44.0 43.0 40.9 36.2 31.6 26.9 22.3 41.3 3.7 41.3 40.8 38.3 33.6 29.0 24.3 19.7

57 44.0 3.3 44.0 43.0 40.9 36.2 31.6 26.9 22.3 41.3 3.7 41.3 40.8 38.3 33.6 29.0 24.3 19.7

1750

72 47.3 3.4 39.0 33.8 28.6 23.4 18.2 - - 46.1 3.9 38.1 32.9 27.7 22.4 17.2 - -

67 45.5 3.4 45.5 42.9 37.7 32.5 27.3 22.0 16.8 42.5 3.7 42.5 41.2 36.2 31.0 25.8 20.5 15.3

62 43.7 3.3 43.7 43.7 43.5 38.3 33.1 27.9 22.7 41.9 3.7 41.9 41.9 41.0 35.7 30.5 25.3 20.1

57 43.7 3.3 43.7 43.7 43.5 38.3 33.1 27.9 22.7 41.9 3.7 41.9 41.9 41.0 35.7 30.5 25.3 20.1

115°F 125°F

1050

72 39.8 4.1 25.2 22.2 19.2 16.2 13.2 - - 37.8 4.6 24.3 21.3 18.3 15.3 12.3 - -

67 35.0 3.9 30.9 27.9 24.9 21.9 18.9 15.9 12.9 31.5 4.2 29.5 26.5 23.5 20.5 17.5 14.5 11.6

62 35.6 3.9 33.6 30.6 27.6 24.6 21.6 18.6 15.6 33.2 4.3 31.4 28.4 25.4 22.4 19.4 16.4 13.4

57 35.6 3.9 33.6 30.6 27.6 24.6 21.6 18.6 15.6 33.2 4.3 31.4 28.4 25.4 22.4 19.4 16.4 13.4

1225

72 40.7 4.2 28.1 24.6 21.1 17.5 14.0 - - 38.1 4.6 27.1 23.6 20.1 16.5 13.0 - -

67 35.8 3.9 33.8 30.9 27.3 23.8 20.3 16.7 13.2 31.7 4.2 31.7 29.3 25.8 22.3 18.7 15.2 11.7

62 36.4 4.0 35.4 33.8 30.3 26.7 23.2 19.7 16.1 33.4 4.3 32.5 31.4 27.9 24.3 20.8 17.2 13.7

57 36.4 4.0 35.4 33.8 30.3 26.7 23.2 19.7 16.1 33.4 4.3 32.5 31.4 27.9 24.3 20.8 17.2 13.7

1400

72 41.6 4.2 31.1 27.0 22.9 18.8 14.8 - - 38.4 4.6 30.0 25.9 21.8 17.8 13.7 - -

67 36.6 4.0 36.6 33.8 29.8 25.7 21.6 17.5 13.4 31.9 4.3 31.9 31.9 28.1 24.0 19.9 15.8 11.8

62 37.2 4.0 37.2 37.0 32.9 28.9 24.8 20.7 16.6 33.6 4.4 33.6 33.6 30.3 26.2 22.1 18.1 14.0

57 37.2 4.0 37.2 37.0 32.9 28.9 24.8 20.7 16.6 33.6 4.4 33.6 33.6 30.3 26.2 22.1 18.1 14.0

1575

72 43.2 4.3 34.1 29.5 24.8 20.2 15.5 - - 41.0 4.7 33.1 28.5 23.8 19.2 14.5 - -

67 38.1 4.0 38.1 36.7 32.2 27.6 22.9 18.3 13.6 34.2 4.4 34.2 34.2 30.6 26.0 21.3 16.7 12.0

62 38.7 4.1 38.7 38.6 35.7 31.0 26.4 21.7 17.1 36.0 4.5 36.0 36.0 33.1 28.4 23.8 19.1 14.5

57 38.7 4.1 38.7 38.6 35.7 31.0 26.4 21.7 17.1 36.0 4.5 36.0 36.0 33.1 28.4 23.8 19.1 14.5

1750

72 44.9 4.4 37.2 31.9 26.7 21.5 16.3 - - 43.6 4.8 36.2 31.0 25.8 20.6 15.4 - -

67 39.5 4.1 39.5 39.5 34.7 29.5 24.2 19.0 13.8 36.5 4.5 36.5 36.5 33.2 28.0 22.7 17.5 12.3

62 40.1 4.2 40.1 40.1 38.4 33.2 28.0 22.8 17.5 38.4 4.6 38.4 38.4 35.8 30.6 25.4 20.2 15.0

57 40.1 4.2 40.1 40.1 38.4 33.2 28.0 22.8 17.5 38.4 4.6 38.4 38.4 35.8 30.6 25.4 20.2 15.0

246836-LTG-E-0107

Unitary Products Group 19

PHP048 (4.0 Ton)

Air on

Evaporator Coil Temperature of Air on Condenser Coil

Total

Capacity1

(MBh)

1. These capacities are gross ratings. For net capacity, deduct air blower motor, MBh = 3.415 x kW. Refer to the appropriate Blower Performance Table for the

kW of the supply air blower motor.

Total

Input

(kW)2

2. These ratings include the condensate fan motors (total .25 kW) and the compressor motors but not the supply air blower motor.

Sensible Capacity (MBh) Total

Capacity1

(MBh)

Total

Input

(kW)2

Sensible Capacity (MBh)

CFM WB

(°F) Return Dry Bulb (°F) Return Dry Bulb (°F)

86 83 80 77 74 71 68 86 83 80 77 74 71 68

75°F 85°F

1200

72 57.2 2.7 33.8 30.4 27.0 23.6 20.2 - - 53.9 3.2 31.5 28.1 24.7 21.3 17.8 - -

67 52.0 2.7 40.2 36.8 33.4 30.0 26.5 23.1 19.7 49.5 3.1 38.9 35.5 32.1 28.6 25.2 21.8 18.4

62 50.2 2.7 45.3 41.9 38.5 35.0 31.6 28.2 24.8 48.1 3.1 43.2 39.8 36.3 32.9 29.5 26.1 22.7

57 50.2 2.7 45.3 41.9 38.5 35.0 31.6 28.2 24.8 48.1 3.1 43.2 39.8 36.3 32.9 29.5 26.1 22.7

1400

72 58.5 2.7 37.4 33.4 29.4 25.3 21.3 - - 55.1 3.2 35.0 30.9 26.9 22.8 18.8 - -

67 53.2 2.7 44.4 40.4 36.3 32.3 28.2 24.2 20.1 50.6 3.1 43.0 39.0 34.9 30.9 26.8 22.8 18.7

62 51.4 2.7 48.9 45.9 41.8 37.8 33.7 29.7 25.6 49.1 3.1 46.7 43.6 39.6 35.5 31.5 27.5 23.4

57 51.4 2.7 48.9 45.9 41.8 37.8 33.7 29.7 25.6 49.1 3.1 46.7 43.6 39.6 35.5 31.5 27.5 23.4

1600

72 59.8 2.7 41.1 36.4 31.7 27.1 22.4 - - 56.3 3.2 38.4 33.8 29.1 24.4 19.8 - -

67 54.4 2.7 48.6 43.9 39.2 34.6 29.9 25.2 20.6 51.7 3.2 47.1 42.5 37.8 33.1 28.5 23.8 19.1

62 52.5 2.7 52.5 49.9 45.2 40.5 35.9 31.2 26.5 50.2 3.1 50.2 47.5 42.8 38.2 33.5 28.8 24.2

57 52.5 2.7 52.5 49.9 45.2 40.5 35.9 31.2 26.5 50.2 3.1 50.2 47.5 42.8 38.2 33.5 28.8 24.2

1800

72 62.0 2.7 45.0 39.7 34.4 29.1 23.8 - - 57.2 3.2 41.9 36.6 31.3 26.0 20.6 - -

67 56.4 2.8 53.5 47.9 42.6 37.3 32.0 26.7 21.3 52.6 3.2 50.3 45.9 40.6 35.3 30.0 24.7 19.4

62 54.5 2.7 54.5 53.1 49.1 43.7 38.4 33.1 27.8 51.0 3.1 51.0 49.7 46.1 40.7 35.4 30.1 24.8

57 54.5 2.7 54.5 53.1 49.1 43.7 38.4 33.1 27.8 51.0 3.1 51.0 49.7 46.1 40.7 35.4 30.1 24.8

2000

72 64.2 2.8 49.0 43.1 37.1 31.2 25.2 - - 58.1 3.2 45.4 39.4 33.5 27.5 21.5 - -

67 58.4 2.8 58.4 51.9 46.0 40.0 34.0 28.1 22.1 53.4 3.2 53.4 49.4 43.5 37.5 31.5 25.6 19.6

62 56.4 2.8 56.4 56.4 52.9 47.0 41.0 35.0 29.1 51.9 3.1 51.9 51.9 49.3 43.3 37.4 31.4 25.4

57 56.4 2.8 56.4 56.4 52.9 47.0 41.0 35.0 29.1 51.9 3.1 51.9 51.9 49.3 43.3 37.4 31.4 25.4

95°F 105°F

1200

72 50.6 3.6 29.2 25.8 22.4 18.9 15.5 - - 49.5 4.1 29.1 25.7 22.3 18.9 15.4 - -

67 47.0 3.6 37.6 34.1 30.7 27.3 23.9 20.5 17.0 44.7 4.1 36.7 33.3 29.9 26.5 23.0 19.6 16.2

62 45.9 3.5 41.1 37.7 34.2 30.8 27.4 24.0 20.5 45.0 4.1 39.8 36.4 32.9 29.5 26.1 22.7 19.3

57 45.9 3.5 41.1 37.6 34.2 30.8 27.4 24.0 20.5 45.0 4.1 39.8 36.4 32.9 29.5 26.1 22.7 19.2

1400

72 51.6 3.6 32.5 28.4 24.4 20.4 16.3 - - 49.9 4.1 32.3 28.3 24.3 20.2 16.2 - -

67 48.0 3.6 41.6 37.6 33.5 29.5 25.4 21.4 17.4 45.2 4.1 40.3 36.6 32.5 28.5 24.4 20.4 16.4

62 46.9 3.5 44.5 41.4 37.4 33.3 29.3 25.2 21.2 45.4 4.1 42.8 39.9 35.9 31.8 27.8 23.7 19.7

57 46.9 3.5 44.5 41.4 37.4 33.3 29.3 25.2 21.2 45.4 4.1 42.8 39.9 35.9 31.8 27.8 23.7 19.7

1600

72 52.7 3.6 35.8 31.1 26.4 21.8 17.1 - - 50.4 4.1 35.6 30.9 26.2 21.6 16.9 - -

67 49.0 3.6 45.7 41.0 36.3 31.7 27.0 22.3 17.7 45.6 4.0 43.9 39.9 35.2 30.5 25.9 21.2 16.5

62 47.8 3.6 47.8 45.2 40.5 35.8 31.2 26.5 21.8 45.8 4.1 45.8 43.5 38.8 34.1 29.5 24.8 20.1

57 47.8 3.6 47.8 45.2 40.5 35.8 31.2 26.5 21.8 45.8 4.1 45.8 43.5 38.8 34.1 29.5 24.8 20.1

1800

72 52.4 3.6 38.8 33.4 28.1 22.8 17.5 - - 51.4 4.1 38.7 33.4 28.1 22.7 17.4 - -

67 48.7 3.6 47.0 44.0 38.7 33.3 28.0 22.7 17.4 46.5 4.1 45.7 43.0 37.6 32.3 27.0 21.7 16.4

62 47.6 3.5 47.6 46.2 43.1 37.8 32.4 27.1 21.8 46.8 4.1 46.8 45.6 41.5 36.2 30.9 25.6 20.2

57 47.6 3.5 47.6 46.2 43.1 37.8 32.4 27.1 21.8 46.8 4.1 46.8 45.6 41.5 36.2 30.9 25.6 20.2

2000

72 52.1 3.6 41.7 35.8 29.8 23.9 17.9 - - 52.4 4.2 41.8 35.9 29.9 23.9 18.0 - -

67 48.4 3.5 48.4 46.9 41.0 35.0 29.0 23.1 17.1 47.4 4.1 47.4 46.1 40.1 34.1 28.2 22.2 16.2

62 47.3 3.5 47.3 47.3 45.6 39.7 33.7 27.8 21.8 47.7 4.1 47.7 47.7 44.2 38.2 32.3 26.3 20.3

57 47.3 3.5 47.3 47.3 45.6 39.7 33.7 27.8 21.8 47.7 4.1 47.7 47.7 44.2 38.2 32.3 26.3 20.3

115°F 125°F

1200

72 48.4 4.7 29.0 25.6 22.2 18.8 15.3 - - 47.3 5.2 28.9 25.5 22.1 18.7 15.3 - -

67 42.5 4.6 35.9 32.5 29.0 25.6 22.2 18.8 15.3 40.2 5.1 35.0 31.6 28.2 24.8 21.3 17.9 14.5

62 44.2 4.6 38.5 35.1 31.6 28.2 24.8 21.4 18.0 43.3 5.1 37.2 33.8 30.3 26.9 23.5 20.1 16.7

57 44.1 4.6 38.5 35.1 31.6 28.2 24.8 21.4 18.0 43.3 5.1 37.2 33.8 30.3 26.9 23.5 20.1 16.7

1400

72 48.2 4.6 32.2 28.1 24.1 20.1 16.0 - - 46.5 5.1 32.0 28.0 24.0 19.9 15.9 - -

67 42.3 4.5 39.0 35.6 31.5 27.5 23.4 19.4 15.4 39.5 5.0 37.7 34.6 30.5 26.5 22.4 18.4 14.4

62 44.0 4.6 41.2 38.4 34.4 30.3 26.3 22.2 18.2 42.6 5.1 39.5 36.9 32.9 28.8 24.8 20.7 16.7

57 44.0 4.6 41.2 38.4 34.4 30.3 26.3 22.2 18.2 42.5 5.1 39.5 36.9 32.9 28.8 24.8 20.7 16.7

1600

72 48.1 4.6 35.3 30.7 26.0 21.3 16.7 - - 45.7 5.1 35.1 30.5 25.8 21.1 16.5 - -

67 42.2 4.5 42.2 38.7 34.0 29.4 24.7 20.0 15.4 38.8 5.0 38.8 37.5 32.9 28.2 23.5 18.9 14.2

62 43.8 4.6 43.8 41.8 37.1 32.4 27.8 23.1 18.4 41.8 5.1 41.8 40.1 35.4 30.7 26.1 21.4 16.7

57 43.8 4.6 43.8 41.8 37.1 32.4 27.8 23.1 18.4 41.8 5.1 41.8 40.1 35.4 30.7 26.1 21.4 16.7

1800

72 50.4 4.7 38.6 33.3 28.0 22.7 17.4 - - 49.4 5.2 38.6 33.2 27.9 22.6 17.3 - -

67 44.3 4.6 44.3 41.9 36.6 31.3 26.0 20.7 15.4 42.0 5.0 42.0 40.9 35.6 30.3 25.0 19.7 14.4

62 46.0 4.6 46.0 45.0 39.9 34.6 29.3 24.0 18.7 45.2 5.1 45.2 44.3 38.3 33.0 27.7 22.4 17.1

57 46.0 4.6 46.0 45.0 39.9 34.6 29.3 24.0 18.7 45.2 5.1 45.2 44.3 38.3 33.0 27.7 22.4 17.1

2000

72 52.8 4.7 41.9 35.9 30.0 24.0 18.1 - - 53.2 5.2 42.0 36.0 30.1 24.1 18.1 - -

67 46.3 4.6 46.3 45.2 39.2 33.3 27.3 21.3 15.4 45.3 5.1 45.3 44.3 38.3 32.4 26.4 20.5 14.5

62 48.2 4.6 48.2 48.2 42.7 36.8 30.8 24.9 18.9 48.6 5.2 48.6 48.6 41.3 35.3 29.4 23.4 17.5

57 48.2 4.6 48.2 48.2 42.7 36.8 30.8 24.9 18.9 48.6 5.2 48.6 48.6 41.3 35.3 29.4 23.4 17.4

246836-LTG-E-0107

20 Unitary Products Group

PHP060 (5.0 Ton)

Air on

Evaporator Coil Temperature of Air on Condenser Coil

Total

Capacity1

(MBh)

1. These capacities are gross ratings. For net capacity, deduct air blower motor, MBh = 3.415 x kW. Refer to the appropriate Blower Performance Table for the

kW of the supply air blower motor.

Total

Input

(kW)2

2. These ratings include the condensate fan motors (total .25 kW) and the compressor motors but not the supply air blower motor.

Sensible Capacity (MBh) Total

Capacity1

(MBh)

Total

Input

(kW)2

Sensible Capacity (MBh)

CFM WB

(°F) Return Dry Bulb (°F) Return Dry Bulb (°F)

86 83 80 77 74 71 68 86 83 80 77 74 71 68

75°F 85°F

1500

72 58.4 3.3 35.8 31.5 27.3 23.0 18.7 - - 63.8 3.9 36.8 32.6 28.3 24.0 19.7 - -

67 58.6 3.3 49.3 45.0 40.7 36.4 32.2 27.9 23.6 59.4 3.9 47.6 43.3 39.1 34.8 30.5 26.2 22.0

62 53.6 3.2 51.8 47.5 43.2 38.9 34.7 30.4 26.1 58.9 3.9 50.3 46.1 41.8 37.5 33.2 29.0 24.7

57 53.6 3.2 51.8 47.5 43.2 38.9 34.7 30.4 26.1 58.9 3.9 50.3 46.1 41.8 37.5 33.2 29.0 24.7

1750

72 61.9 3.4 39.5 34.5 29.4 24.4 19.3 - - 65.2 4.0 41.1 36.1 31.0 26.0 20.9 - -

67 61.8 3.4 54.2 49.1 44.1 39.0 34.0 28.9 23.8 60.7 3.9 52.9 47.9 42.8 37.8 32.7 27.7 22.6

62 56.9 3.2 56.9 51.8 46.7 41.7 36.6 31.6 26.5 60.2 3.9 55.9 50.9 45.8 40.8 35.7 30.7 25.6

57 56.9 3.2 56.8 51.8 46.7 41.7 36.6 31.6 26.5 60.2 3.9 55.9 50.9 45.8 40.8 35.7 30.7 25.6

2000

72 65.4 3.5 43.3 37.4 31.6 25.8 19.9 - - 66.6 4.0 45.4 39.6 33.7 27.9 22.1 - -

67 65.1 3.4 59.1 53.2 47.4 41.6 35.7 29.9 24.1 62.0 3.9 58.3 52.4 46.6 40.8 35.0 29.1 23.3

62 60.1 3.3 61.9 56.1 50.3 44.4 38.6 32.8 26.9 61.5 3.9 61.5 55.7 49.9 44.0 38.2 32.4 26.5

57 60.1 3.3 61.9 56.1 50.3 44.4 38.6 32.8 26.9 61.5 3.9 61.5 55.7 49.9 44.0 38.2 32.4 26.5

2250

72 64.3 3.5 46.8 40.1 33.5 26.8 20.2 - - 68.2 4.0 49.2 42.6 35.9 29.3 22.6 - -

67 64.3 3.4 61.3 56.9 50.3 43.6 37.0 30.3 23.7 63.5 3.9 61.6 56.3 49.6 43.0 36.3 29.7 23.1

62 59.0 3.3 60.0 59.9 53.3 46.7 40.0 33.4 26.7 63.0 3.9 63.0 59.7 53.1 46.4 39.8 33.1 26.5

57 59.0 3.3 59.9 59.9 53.3 46.7 40.0 33.4 26.7 63.0 3.9 63.0 59.7 53.1 46.4 39.8 33.1 26.5

2500

72 63.1 3.4 50.3 42.8 35.4 27.9 20.5 - - 69.8 4.0 53.0 45.5 38.1 30.6 23.2 - -

67 63.5 3.4 63.5 60.6 53.1 45.7 38.2 30.8 23.3 64.9 3.9 64.9 60.1 52.6 45.2 37.7 30.3 22.8

62 58.0 3.3 58.0 63.8 56.3 48.9 41.4 34.0 26.5 64.4 3.9 64.4 63.7 56.3 48.8 41.4 33.9 26.5

57 58.0 3.3 58.0 63.8 56.3 48.9 41.4 34.0 26.5 64.4 3.9 64.4 63.7 56.3 48.8 41.4 33.9 26.5

95°F 105°F

1500

72 69.2 4.6 37.8 33.6 29.3 25.0 20.7 - - 57.9 5.1 34.9 30.6 26.3 22.1 17.8 - -

67 60.1 4.5 46.0 41.7 37.4 33.1 28.9 24.6 20.3 52.1 5.0 43.5 39.3 35.0 30.7 26.4 22.1 17.9

62 64.2 4.5 48.9 44.6 40.4 36.1 31.8 27.5 23.3 54.1 5.0 45.0 40.7 36.4 32.1 27.9 23.6 19.3

57 64.2 4.5 48.9 44.6 40.4 36.1 31.8 27.5 23.3 54.1 5.0 45.0 40.7 36.4 32.1 27.9 23.6 19.3

1750

72 68.5 4.5 42.7 37.6 32.6 27.5 22.5 - - 58.2 5.0 39.5 34.4 29.4 24.3 19.3 - -

67 59.5 4.4 51.7 46.7 41.6 36.6 31.5 26.5 21.4 52.5 4.9 47.8 44.1 39.0 34.0 28.9 23.9 18.8

62 63.6 4.5 55.0 50.0 44.9 39.8 34.8 29.7 24.7 54.5 5.0 49.4 45.7 40.6 35.6 30.5 25.5 20.4

57 63.6 4.5 55.0 50.0 44.9 39.8 34.8 29.7 24.7 54.5 5.0 49.4 45.7 40.6 35.6 30.5 25.5 20.4

2000

72 67.8 4.4 47.5 41.7 35.9 30.0 24.2 - - 58.6 5.0 44.1 38.3 32.4 26.6 20.8 - -

67 58.9 4.3 57.5 51.7 45.8 40.0 34.2 28.3 22.5 52.8 4.9 52.1 48.9 43.1 37.2 31.4 25.6 19.7

62 62.9 4.4 61.1 55.3 49.4 43.6 37.8 31.9 26.1 54.8 4.9 53.9 50.7 44.9 39.0 33.2 27.4 21.5

57 62.9 4.4 61.1 55.3 49.4 43.6 37.8 31.9 26.1 54.8 4.9 53.9 50.7 44.9 39.0 33.2 27.4 21.5

2250

72 72.1 4.5 51.6 45.0 38.3 31.7 25.1 - - 61.3 5.0 47.3 40.7 34.0 27.4 20.7 - -

67 62.6 4.4 61.9 55.6 49.0 42.3 35.7 29.1 22.4 55.2 4.9 54.9 51.6 45.2 38.5 31.9 25.2 18.6

62 66.9 4.5 66.0 59.5 52.8 46.2 39.6 32.9 26.3 57.4 5.0 56.9 53.5 47.1 40.4 33.8 27.1 20.5

57 66.9 4.5 66.0 59.5 52.8 46.2 39.6 32.9 26.3 57.4 5.0 56.9 53.5 47.1 40.4 33.8 27.1 20.5

2500

72 76.4 4.5 55.7 48.3 40.8 33.4 25.9 - - 64.1 5.0 50.5 43.1 35.6 28.2 20.7 - -

67 66.4 4.4 66.4 59.6 52.1 44.7 37.2 29.8 22.3 57.7 5.0 57.7 54.3 47.2 39.8 32.3 24.9 17.4

62 70.9 4.5 70.9 63.7 56.2 48.8 41.3 33.9 26.4 59.9 5.0 59.9 56.3 49.3 41.8 34.4 26.9 19.5

57 70.9 4.5 70.9 63.7 56.2 48.8 41.3 33.9 26.4 59.9 5.0 59.9 56.3 49.3 41.8 34.4 26.9 19.5

115°F 125°F

1500

72 46.6 5.5 32.0 27.7 23.4 19.1 14.8 - - 35.3 6.0 29.0 24.7 20.5 16.2 11.9 - -

67 44.1 5.5 41.1 36.8 32.5 28.3 24.0 19.7 15.4 36.2 6.0 36.2 34.4 30.1 25.8 21.6 17.3 13.0

62 44.1 5.5 41.0 36.8 32.5 28.2 23.9 19.7 15.4 34.0 6.0 34.0 32.8 28.6 24.3 20.0 15.7 11.5

57 44.1 5.5 41.0 36.8 32.5 28.2 23.9 19.7 15.4 34.0 6.0 34.0 32.8 28.6 24.3 20.0 15.7 11.5

1750

72 48.0 5.5 36.3 31.3 26.2 21.1 16.1 - - 37.7 6.0 33.1 28.1 23.0 18.0 12.9 - -

67 45.4 5.5 43.9 41.5 36.4 31.4 26.3 21.3 16.2 38.4 6.0 38.4 38.4 33.8 28.8 23.7 18.7 13.6

62 45.3 5.5 43.8 41.4 36.4 31.3 26.3 21.2 16.2 36.2 6.0 36.2 36.2 32.1 27.1 22.0 17.0 11.9

57 45.3 5.5 43.8 41.4 36.4 31.3 26.3 21.2 16.2 36.2 6.0 36.2 36.2 32.1 27.1 22.0 17.0 11.9

2000

72 49.3 5.5 40.7 34.8 29.0 23.2 17.3 - - 40.0 6.0 37.2 31.4 25.6 19.7 13.9 - -

67 46.7 5.5 46.7 46.2 40.3 34.5 28.7 22.8 17.0 40.6 6.0 40.6 40.6 37.6 31.7 25.9 20.1 14.2

62 46.6 5.5 46.6 46.1 40.3 34.4 28.6 22.8 16.9 38.4 6.0 38.4 38.4 35.7 29.8 24.0 18.2 12.3

57 46.6 5.5 46.6 46.1 40.3 34.4 28.6 22.8 16.9 38.4 6.0 38.4 38.4 35.7 29.8 24.0 18.2 12.3

2250

72 50.5 5.5 43.0 36.4 29.7 23.1 16.4 - - 39.7 6.0 38.7 32.1 25.4 18.8 12.1 - -

67 47.8 5.5 47.8 47.6 41.3 34.7 28.1 21.4 14.8 40.4 6.0 40.4 40.4 37.5 30.9 24.2 17.6 10.9

62 47.8 5.5 47.8 47.5 41.3 34.6 28.0 21.3 14.7 38.2 6.0 38.2 38.2 35.5 28.9 22.2 15.6 8.9

57 47.8 5.5 47.8 47.5 41.3 34.6 28.0 21.3 14.7 38.2 6.0 38.2 38.2 35.5 28.9 22.2 15.6 8.9

2500

72 51.8 5.5 45.4 37.9 30.5 23.0 15.5 - - 39.5 6.0 39.5 32.7 25.3 17.8 10.4 - -

67 49.0 5.5 49.0 49.0 42.3 34.9 27.4 20.0 12.5 40.3 6.0 40.3 40.3 37.5 30.0 22.6 15.1 7.6

62 48.9 5.5 48.9 48.9 42.3 34.8 27.4 19.9 12.5 37.9 6.0 37.9 37.9 35.3 27.9 20.4 13.0 5.5

57 48.9 5.5 48.9 48.9 42.3 34.8 27.4 19.9 12.5 37.9 6.0 37.9 37.9 35.3 27.9 20.4 13.0 5.5

This manual suits for next models

Table of contents

Other Luxaire Air Conditioner manuals

Luxaire

Luxaire LX Series Quick start guide

Luxaire

Luxaire TCJD30 THRU 76 Quick start guide

Luxaire

Luxaire TC17B2421S Quick start guide

Luxaire

Luxaire LX SERIES TW4B18 Quick start guide

Luxaire

Luxaire LX Series Quick start guide

Luxaire

Luxaire ACCLIMATE AL21B2421S Quick start guide

Luxaire

Luxaire TC4B18 THRU 60 Quick start guide

Luxaire

Luxaire K*BU060A Series User manual

Luxaire

Luxaire ACCLIMATE AL6B024F3 Quick start guide

Luxaire

Luxaire R-410A Quick start guide

Popular Air Conditioner manuals by other brands

Daikin

Daikin FTKE25BVM Service manual

GE ANK12D Use and care guide

Sanyo

Sanyo KS2432 instruction manual

LG MultiV Series installation manual

CLIMAVENETA

CLIMAVENETA a-CHD U-2T 606+2209 OPERATING AND INSTALLATION Manual

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries DXK05ZTLA-WF user manual

Daikin

Daikin FTXS50EV1B installation manual

Snap-On

Snap-On POLARTEK EEAC330B manual

Argo

Argo Relax Service manual

York

York PCG4 Series installation manual

Midea

Midea PD series manual

Carrier

Carrier DB-O Series Use and maintenance

Hokkaido

Hokkaido HKEI-HCNI 263 XR Service manual

Sanyo

Sanyo THX2452 user manual

Gree

Gree Neo COZY9K owner's manual

Convair

Convair ClimateMaster CM12RW instruction manual

Frigidaire

Frigidaire GHWQ103WC1 use & care

INVENTOR

INVENTOR OMI-09 owner's manual

Luxaire Climasure PAC030 Quick start guide

Popular Air Conditioner manuals by other brands
