USER MANUAL
1. Introduction
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that disposal of the device after its lifecycle
could harm the environment. Do not dispose of the unit (or batteries) as unsorted municipal
waste; it should be taken to a specialized company for recycling. This device should be returned
to your distributor or to a local recycling service. Respect the local environmental rules.
If in doubt, contact your local waste disposal authorities.
Thank you for choosing Luxibel®! Please read the manual thoroughly before bringing this device into
service. If the device was damaged in transit, do not install or use it and contact your dealer.
2. Safety Instructions
Be very careful during the installation: touching live wires can cause life-threatening
electroshocks.
Always disconnect mains power when device not in use or when servicing or
maintenance activities are performed. Handle the power cord by the plug only.
Indoor use only. Keep this device away from rain, moisture, splashing and dripping
liquids. Never put objects filled with liquids on top of or close to the device.
Keep this device away from children and unauthorized users.
Caution: device heats up during use.
There are no user-serviceable parts inside the device. Refer to an authorized dealer for
service and/or spare parts.
This is a Safety Class 1 device. It is therefore essential that the device be earthed.
Have a qualified person carry out the electric connection.
Make sure that the available voltage does not exceed the voltage stated in the specifications of this
manual.
Do not crimp the power cord and protect it against damage. Have an authorised dealer replace it if
necessary.
Install the device at a minimal distance of 0.5 m from flammable and explosive objects or
substances.
The maximum ambient temperature is 40 °C. Do not operate the device at higher temperatures.
3. General Guidelines
Refer to the Velleman®Service and Quality Warranty on the last pages of this manual.
Keep this device away from dust and extreme temperatures. Make sure the ventilation
openings are clear at all times. For sufficient air circulation, leave at least 1" (± 2.5 cm)
in front of the openings.
Protect this device from shocks and abuse. Avoid brute force when operating the
device.
Familiarise yourself with the functions of the device before actually using it. Do not allow operation
by unqualified people. Any damage that may occur will most probably be due to unprofessional use
of the device.

LX195
V. 02 –04/03/2016 5 ©Velleman nv
All modifications of the device are forbidden for safety reasons. Damage caused by user modifications
to the device is not covered by the warranty.
Only use the device for its intended purpose. All other uses may lead to short circuits, burns,
electroshocks, lamp explosion, crash, etc. Using the device in an unauthorised way will void the
warranty.
Damage caused by disregard of certain guidelines in this manual is not covered by the warranty and
the dealer will not accept responsibility for any ensuing defects or problems.
Mechanical wear and LEDs are not covered by warranty.
A qualified technician should install and service this device.
Do not switch the device on immediately after it has been exposed to changes in temperature.
Protect the device against damage by leaving it switched off until it has reached room temperature.
This device is designed for professional use on stage, in discos, theatres, etc. The device should only
be used indoors with an alternating current of 100-240 V~, 50-60 Hz.
Use the original packaging if the device is to be transported.
Product images are for illustrative purposes only.
Keep this manual for future reference.
4. Features
The A-NODE 4 is an Ethernet node that serves four DMX512 outlets, compatible with the Artnet or Kling-
Net protocols. All outlets are conform to DMX512. The LX195 also features two RJ45 etherCON
connectors on the front for Ethernet linking. It is ideal for large pixel mapped DMX systems and
compatible with most popular pixel mapping software controllers. The A-NODE 4 comes in a metal 19"
housing which can be rack-mounted.
4 universes (2048 DMX channels)
each universe can be in input, output and disable mode
each universe supports DMX merge (HTP, LTP)
2 RJ45 ports, 10 M/100 M/1000 Mb/s Auto MDI/MDIX
supports DHCP and Static IP
Artnet –sACN –Kling-Net protocol
multiple colour-type in Kling-Net
firmware can be updated on-line
1U 19” standard rack installation
can be used as a DMX splitter
IP address can be set manually
supporting DMX-512 protocol
DMX output for DMX-512 protocol control
512 channels per connector
housing: sheet metal with black powder finish
frame rate changeable per channel
5. Overview
Refer to the illustrations on page 2 of this manual.
1
on-off switch
5
navigation buttons
2
RJ45 ports
6
M10 mounting hole
3
DMX inputs and outputs
7
power input with fuse
4
display

LX195
V. 02 –04/03/2016 6 ©Velleman nv
6. Operation
6.1 Renaming the Device
Enter the main menu by pressing the UP or DOWN button. Choose the Rename option and then press
ENTER to confirm your selection. Now you can rename the device by pressing UP or DOWN. Confirm your
change and move to next the option by pressing ENTER.
6.2 Setting the Dynamic Host Configuration Protocol (DHCP)
Choose the Set DHCP option and then press ENTER to confirm your selection. Now you can switch the
DHCP function on or off by pressing UP or DOWN. Confirm your change and move to the next option by
pressing ENTER.
6.3 Setting the IP Address
Choose the Set IP Address option and then press ENTER to confirm your selection. Now you can set the
IP address by pressing UP or DOWN. Confirm your change and move to the next option by pressing
ENTER.
Each IP address must be unique.
6.4 Setting the Netmask
Choose the Netmask option and then press ENTER to confirm your selection. Now you can set the
netmask by pressing UP or DOWN. Confirm your change and move to the next option by pressing ENTER.

LX195
V. 02 –04/03/2016 7 ©Velleman nv
6.5 Setting the DMX Port
Choose the DMX Port X option and then press ENTER to confirm your selection. Now you can set the
parameter for each port by pressing UP or DOWN. Confirm your change and move to the next option by
pressing ENTER.
Set DMX Port X parameters
Disp Type
decimal or hexadecimal system
DMX Status
input, output, disable
DMX Mode
normal input,
backup input,
single universe data-out,
two universe data HTP-out,
two universe data LTP-out
Protocol
ArtNet、sACN(E1.31) 、KlingNet
Framerte/fs
data out rate: 10~40 f/s
Network
set the DMX network parameters
Sub Network
set the DMX sub network parameters
Principal
set the first universe parameters
Secondary
set the second universe parameters
Resend
resend universe parameters
Pixel Type
RGB、RGBW、RGBA、RGBD、RGBAW
Pixel Width
set the pixel width
Pixel Height
set the pixel height
6.6 Setting the Device ID
Choose the Set Device ID option and then press ENTER to confirm your selection. Select the ID number,
e.g. 001, and press ENTER. Press UP or DOWN and select the unit’s ID number from 000 to 255. The ID
is only used to easily recognize each of the units.
6.7 Setting the LCD Backlight
Choose the Set LCD Backlight option and then press ENTER to confirm your selection. Choose its status
between on and off, on meaning that the LCD will be lit all the time and off meaning that the LCD will
turn off automatically after idle for 30 seconds.
6.8 Setting the Display
Choose the Set Display option and then press ENTER to confirm your selection. Choose Inversion to
inverse the display.

LX195
V. 02 –04/03/2016 8 ©Velleman nv
6.9 User Preset
Choose the User Preset option and then press ENTER to confirm your selection. This setting helps you
to easily use the application and to avoid complicated setup procedures. Simply choose your desired
mode by pressing UP or DOWN.
1
4 X Input
set the 4 ports as inputs
2
DMX Split 1-3
set the device as a splitter with 1 input and 3 outputs
(note that the LED indicator of the output port will
light up in green)
3
DMX Clone
used to replicate a standard DMX signal from 2 input
ports (1 and 2) to 2 output ports (3 and 4)
4
Isolated mode
set the 4 ports as outputs
6.10 Default Setting
All of the settings will be restored to the original status.
6.11 Version
Select this option to check the version number.
6.12 Port Status
In standby status, press UP or DOWN to move to the Port Status display page. This page displays the
status of every port.
NET
S/D
S: both ports as static IP
D: both ports DHCP enabled
√/x
√: network cable connected
x: network cable not connected
(flash between √and x under the DHCP mode: fixture is still
searching for the IP address or no IP address)
1/2/3/4
4 DMX ports
I/O/—
I: input status
O: output status
—: disabled status
√/x/—
√: DMX signal available
x: no DMX signal
—: disabled status

LX195
V. 02 –04/03/2016 9 ©Velleman nv
7. Cleaning and Maintenance
All screws should be tightened and free of corrosion.
The housing, the lenses, the mounting supports and the installation location (e.g. ceiling, suspension,
trussing) should not be deformed, modified or tampered with; e.g. do not drill extra holes in
mounting supports, do not change the location of the connections…
The electric power supply cables must not show any damage. Have a qualified technician maintain
the device.
Disconnect the device from the mains prior to maintenance activities. Let the device cool down.
Wipe the device regularly with a moist, lint-free cloth. Do not use alcohol or solvents.
Do not immerse the device in any liquid.
There are no user-serviceable parts, apart from the fuse.
Contact your dealer for spare parts if necessary.
Replacing the Fuse
Only replace the fuse by a fuse of the same type and rating.
1. Before replacing the fuse, unplug the mains lead.
2. Open the fuse holder with an appropriate screwdriver.
3. Remove the old fuse and install the new fuse in the fuse holder.
4. Place the fuse holder back in the housing and tighten it.
8. Technical Specifications
power supply.........................................................................100-240 V~, 50/60 Hz
data input ..............................................RJ45 socket for Ethernet and 3-pin XLR male
data output ...........................................................4 x 3-pin/5-pin XLR female socket
IP rate ........................................................................................................... IP20
dimensions.................................................. 482 x 130 x 44 mm (1U 19" rack mount)
weight ........................................................................................................... 2 kg
Use this device with original accessories only. Velleman nv cannot be held responsible in the
event of damage or injury resulting from (incorrect) use of this device. For more info
concerning this product and the latest version of this manual, please visit our website
www.luxibel.com. The information in this manual is subject to change without prior notice.
© COPYRIGHT NOTICE
The copyright to this manual is owned by Velleman nv. All worldwide rights reserved. No part
of this manual may be copied, reproduced, translated or reduced to any electronic medium or otherwise
without the prior written consent of the copyright holder.

Velleman® Service and Quality Warranty
Since its foundation in 1972, Velleman® acquired extensive experience in the electronics world
and currently distributes its products in over 85 countries.
All our products fulfil strict quality requirements and legal stipulations in the EU. In order to
ensure the quality, our products regularly go through an extra quality check, both by an
internal quality department and by specialized external organisations. If, all precautionary
measures notwithstanding, problems should occur, please make appeal to our warranty (see
guarantee conditions).
General Warranty Conditions Concerning Consumer Products (for EU):
• All consumer products are subject to a 24-month warranty on production flaws and defective
material as from the original date of purchase.
• Velleman® can decide to replace an article with an equivalent article, or to refund the retail
value totally or partially when the complaint is valid and a free repair or replacement of the
article is impossible, or if the expenses are out of proportion.
You will be delivered a replacing article or a refund at the value of 100% of the purchase price
in case of a flaw occurred in the first year after the date of purchase and delivery, or a
replacing article at 50% of the purchase price or a refund at the value of 50% of the retail
value in case of a flaw occurred in the second year after the date of purchase and delivery.
• Not covered by warranty:
- all direct or indirect damage caused after delivery to the article (e.g. by oxidation, shocks,
falls, dust, dirt, humidity...), and by the article, as well as its contents (e.g. data loss),
compensation for loss of profits;
- consumable goods, parts or accessories that are subject to an aging process during normal
use, such as batteries (rechargeable, non-rechargeable, built-in or replaceable), lamps, rubber
parts, drive belts... (unlimited list);
- flaws resulting from fire, water damage, lightning, accident, natural disaster, etc.…;
- flaws caused deliberately, negligently or resulting from improper handling, negligent
maintenance, abusive use or use contrary to the manufacturer’s instructions;
- damage caused by a commercial, professional or collective use of the article (the warranty
validity will be reduced to six (6) months when the article is used professionally);
- damage resulting from an inappropriate packing and shipping of the article;
- all damage caused by modification, repair or alteration performed by a third party without
written permission by Velleman®.
• Articles to be repaired must be delivered to your Velleman® dealer, solidly packed
(preferably in the original packaging), and be completed with the original receipt of purchase
and a clear flaw description.
• Hint: In order to save on cost and time, please reread the manual and check if the flaw is
caused by obvious causes prior to presenting the article for repair. Note that returning a non-
defective article can also involve handling costs.
• Repairs occurring after warranty expiration are subject to shipping costs.
• The above conditions are without prejudice to all commercial warranties.
The above enumeration is subject to modification according to the article
(see article’s manual).
Made in PRC
Imported by Velleman nv
Legen Heirweg 33, 9890 Gavere, Belgium
www.velleman.eu
