Luxor WB4836LB User manual

Luxor 48" x 36" Wall-
Mounted Magnetic Ghost
Grid Whiteboard
Instruction Manual

Wall-mounted Whiteboard
Instructions
Note: After assembly, remove the
a utility knife.
Slide tray into grove
on bottom of wall
board. Snap two
horizontal chalk
lines at the heights
indicated from the
floor. If attaching to
drywall drill four 1⁄4˝
Insert drywall anchors
Binto holesthen attach
brackets Aat the bottom
with screw Cmaking
sure the bracket is in the
lowest position.
Attach brackets Aat the top
with screw Cmaking sure
the bracket is in the highest
position. Tighten screw just
enough so that the bracket
can be tapped down with
hammer.
Place white board on
lower brackets making
sure to center it with
middle lower bracket
A. Attach bracket to
wallboard using screw D
starting with the middle
lower bracket.
Tap the top brackets
down so they are
touching the top of
the board. Attach
bracket to wallboard
using screw D.
1 2 3 4 5
Parts List
-Tape Measure
-Chalk Line
-Drill
-1/4˝ Drill Bit
-Extended Drive
Phillips
-Hammer
Ax4 Bx4 Cx4 Dx4
Tools Required
Note: Hardware provided is for drywall installation. If attaching
to other material fasteners are to be furnished by other.
Chalk Line 1˝
above the desired
bottom position.
Recommended
371⁄4
Chalk Line
331⁄2˝ above the
bottom Chalk
Line
75⁄8˝
75⁄8˝
75⁄8˝
75⁄8˝
32˝
32˝
351⁄2˝ x 471⁄4˝ Board
471⁄4˝
351⁄2˝
Drill Holes
Drill Holes
Questions or Feedback Call Us at:
1-800-944-4573
