LYBESS LFP Portable 5000 User manual

5120Wh Portable Power Station
User Manual
LFP Portable 5000
Anhui LEAD-WIN New Energy Technology Co., Ltd.
First floor, No. 8-5, Liandong U Valley Shushan
International Enterprise Port, 1499 Zhenxing Road,
Shushan District, Hefei City, Anhui, China
Tel: [phone]
E-mail: [e-mail]
Website: www.lybess.com
Get to know us

About this Document
This document describes the operation of 5120Wh Portable Power Station (hereafter simply put LFP Portable 5000). Before use LFP Portable 5000,
ensure that you are familiar with product features, functions, and safety precautions provided in this document.
1. Product Information
C O N T E N T S 2. Safety Information
3. Attentions
1.1 Battery Overview
1.2 Appearance
1.3 Front Panel
2.1 General Safety
2.2 Personal Safety
2.3 Electrical Safety
2.4 Transportation Safety

1 Product Information
1.1 Battery Overview
The 5120Wh portable power station from LYBESS is designed as a complete unit and is
also equipped with sturdy wheels and a suitcase-style telescopic pull handle, making it
more convenient to carry on the go. It uses high quality EV-grade LiFePO4 (LFP)
batteries with a cycle life of ≥ 3500 cycles, while using a high precision BMS system to
protect the batteries in all aspects, for the safety of battery use.
Features
Premium EV-grade LiFePO4 (LFP) battery
2200W AC Super Charge
Wireless Charge
4000W Surge Power Capability
1400W UPS Backup
Versatile Output Ports
1.2 Appearance
1.3 Front Panel
(1) Power Key
(2) 30A MAX AC Output
(3) 20A MAX AC Output
(4) Display Screen
(5) USB-5V/2.4A
(6) 12V10A DC Output
(7) 24V/10A DC Output
(8) 12V/3A DC Output
(9) USB-QC 3.0 18W
(10) USB-PD 100W

2 Safety Information
2.1 General Safety
Please carefully read the manual safety precautions, and observe all the safety
instructions on the equipment and in this document.
The "DANGER”，"WARNING", and "NOTICE” statements in this document do not
cover all the safety instructions. They are only supplements to the safety instructions.
For user safety and utilization efficiency of this manual, a list of symbols are
designed to alert people from danger. You must understand and comply with the
emphasized information to avoid personal injury and property damage. Relative
safety symbols have been listed below.
DANGER indicates a hazardous situation
which, if not avoided will result in serious
injury and fire.
WARNING indicates a hazardous
situation which, if not avoided will result
in property loss or void warranty.
NOTICE indicates normal situation which,
if not avoided will result in that battery
doesn't work.
Danger
Warning
Notice
Follow local laws and regulations when operating, or maintaining the equipment.
The safety instructions in this document are only supplements to local laws and
regulations.
2.2 Personal Safety
Personal Requirements
People who plan to maintain battery equipment must be trained, understood all
necessary safety precautions, and are able to perform all operations correctly.
Only qualified professionals or trained people are allowed to operate and maintain
the equipment.
Personal Safety
ØDo not place battery at a children or pet touchable area.
ØDo not touch the energized battery, as the enclosure is hot.
ØDo not touch the energized battery terminals.
ØDo not stand on, lean on, or sit on the battery.
2.3 Electrical Safety
Symbols on Battery
There are some electrical symbols on battery relate to electrical safety. Please make
sure you have fully understand them before installation.
Electrical danger
Voltage exits when the battery is powered on.
Only qualified engineers are allowed to operate.
Earth connector
Earth connection.
DC positive and
negative connectors
Identify positive and negative connectors of DC
power source.
CE mark
The product meets CE certification.
WEEE tag
Can't leave battery as garbage disposal.
Recycle
Battery can be recycled.

Electrical Safety
2.3 Electrical Safety
ØBefore use, ensure that the equipment is intact. Otherwise, electric shocks or fire
may occur.
ØDo not connect or disconnect power cables when battery is power-on. Which may
cause electric arcs and sparks more overfire or personal injury. Before connecting a
power cable, check the positive or negative connectors are correct.
ØDo not connect battery to faulty or unqualified charger.
ØDo not create short circuits with the external connection.
ØMake sure the grid is cut off and the battery is powered off before maintenance.
ØRecharge battery in every six months.
ØRecharge battery within 10 days after battery is fully discharged.
ØWhen the battery is being use or repaired, make sure the battery is powered off
and using a multimeter to make sure there is no voltage in the positive and
negative terminals.
ØPlease use dedicated insulated tools for maintenance.
ØPlease check lights on sequence when battery power-on.
Environment Safety
ØThe use position must be away from fire sources and direct sun and rain.
ØThe use position must be far away from water sources such as taps, sewer pipes,
and sprinklers to prevent water seepage.
ØDo not expose the equipment to flammable or explosive gas or smoke.
ØThe operation and service life of the battery depends on the operating
temperature.The recommended operating temperature range is from 0°C to 30°C.
2.4 Transportation Safety
ØThe products passed certification UN38.3.
ØThe products have MSDS.
ØThe products belong to class 9 dangerous goods.
ØPlease protect the packing case from the below situations.
ØBeing dampened by rains, snows, or falling into water.
ØFalling or mechanical impact.
ØBeing upside-down or tilted.
3 Attentions
Before using the battery pack, please read the manual carefully to
understand the usage and precautions;
Non-professionals shall not disassemble the battery without authorization;
Be sure to use the original special charger for charging or the charger
agreed by both parties;
During use or storage, if you find abnormal heating, discoloration,
deformation or other abnormalities in the battery, please stop using the
battery;
The storage temperature of the battery is -10~35℃, please place the
battery in a dry and cool environment
Do not bump, apply external force or make the battery fall from high
altitude during use;
If the battery is not used for a long time, the battery pack needs to be
charged to more than 80%, turn off the power switch, and store it in a
ventilated and dry environment.
