Lynx 30” Universal Cart
L30(PS)R, L30AG, and LSMK
The following instrucons are provided to help you install the Asado, 30” Grill, or Sonoma Smoker on the L30CART.
IMPORTANT: Be sure the L30CART’s casters are locked to avoid movement when installing the grill.
Warning: the L30AG is approximately 208lbs., the LSMK is approximately 135 lbs., and the L30PSR is approximately 241 lbs. you will require assistance to li and
install any of these items onto the cart.
Tools required: Rags, newspaper (to place any items on), Philips head screwdriver, and gloves.
This cart is intended for use with the Lynx 30” Professional Grill, 30” Asado Grill, and the 30” Sonoma Smoker only.
Lynx Grills, Inc.
7300 Flores St.
Downey, CA 90242
www.lynxgrills.com
Ph. 562-299-6900
L30AG LSMK
L30

1. Remove the four screws on the back panel.
2. Slide out drawer and remove completely.
3. Next remove the screws which aach the rails and remove the rails to begin installaon.
L30AG
5. Place the Asado Grill inside the cart
frame.
6. Re-aach the rear panel with the previously removed screws.
4. Carefully li the Asado Grill and posion
it above the cart.

L30PSR
5. Place the grill inside the cart frame.
Once the grill has been placed inside the cart. You will want to remove
the following screws and replace them with the supplied screws.
1. Remove the four screws on the back panel.
2. Slide out drawer and remove completely.
3. Next remove the screws which aach the rails and remove the rails to begin installaon.
6. Re-aach the rear panel with the previously removed screws.
4. Carefully li the 30” Grill and posion it above
the cart.

1. Remove the four screws on the back panel.
2. 2. Slide out drawer or remove completely to begin installaon.
LSMK
4. Place the smoker inside the cart frame.
3. Carefully li the Sonoma Smoker and posion it
above the cart.
Once the grill has been placed inside
the cart. You will want to remove the
following screws and replace them with the supplied screws.
5. Re-aach the rear panel with the previously removed screws.
