Lynxter S600D Operating instructions

S600D
V1.1
All manuals and user guides at all-guides.com
all-guides.com

CONFIDENTIAL. DO NOT DIFFUSE.
1. Introduction..........................................................................................................................................................................4
2. Terminology.........................................................................................................................................................................5
Regulations..................................................................................................................................................................6
Safety and operating limits.......................................................................................................................................7
2.2.1 Environment and working conditions.............................................................................................................7
2.2.1 Pictograms and labels ......................................................................................................................................7
General guidelines......................................................................................................................................................8
Safety features......................................................................................................................................................... 10
3. Installation, software configuration and printing....................................................................................................... 11
Introduction .............................................................................................................................................................. 11
Installation ................................................................................................................................................................ 13
3.2.1 Installation package........................................................................................................................................ 13
3.2.2 Installing Simplify3D....................................................................................................................................... 14
3.2.3 Network deployment ...................................................................................................................................... 15
3.2.4 Software/firmware updates.......................................................................................................................... 18
Build process............................................................................................................................................................ 19
3.3.1 Main software interface and virtual build table ......................................................................................... 19
3.3.2 Overview of slicing settings .......................................................................................................................... 20
3.3.3 Animated print preview .................................................................................................................................. 21
3.3.4 Web control interface..................................................................................................................................... 23
3.3.5 Overview of the touchscreen ........................................................................................................................ 29
3.3.6 Regular checks ................................................................................................................................................ 39
4. Machine ............................................................................................................................................................................. 40
S600D ........................................................................................................................................................................ 40
4.1.1 Overview ........................................................................................................................................................... 40
4.1.2 Specifications .................................................................................................................................................. 43
4.1.3 Startup, connection and calibration............................................................................................................. 45
4.1.4 Maintenance .................................................................................................................................................... 61
5. Filament materials........................................................................................................................................................... 67
Filament material bay ............................................................................................................................................. 67
5.1.1 Overview ........................................................................................................................................................... 67
5.1.2 Mounting/installation ..................................................................................................................................... 68
5.1.3 Priming/unloading .......................................................................................................................................... 70
5.1.4 Maintenance/servicing .................................................................................................................................. 74
Triple extrusion filament toolhead ....................................................................................................................... 77
5.2.1 Overview ........................................................................................................................................................... 77
5.2.2 Specifications .................................................................................................................................................. 77
5.2.3 Installation........................................................................................................................................................ 78
5.2.4 Unloading.......................................................................................................................................................... 80
5.2.5 Maintenance/servicing .................................................................................................................................. 81
6. Liquid materials................................................................................................................................................................ 87
Liquid material bay.................................................................................................................................................. 87
6.1.1 Overview ........................................................................................................................................................... 87
6.1.2 Mounting/installation ..................................................................................................................................... 88
Single-component liquid toolhead........................................................................................................................ 89
6.2.1 Overview ........................................................................................................................................................... 89
All manuals and user guides at all-guides.com

CONFIDENTIAL. DO NOT DIFFUSE.
6.2.2 Specifications .................................................................................................................................................. 89
6.2.3 Installation........................................................................................................................................................ 90
6.2.4 Priming and use............................................................................................................................................... 92
6.2.5 Unloading.......................................................................................................................................................... 93
6.2.6 Maintenance/ servicing ................................................................................................................................. 94
7. Troubleshooting............................................................................................................................................................... 98
8. Moving and transporting the machine.......................................................................................................................101
9. Customer support..........................................................................................................................................................102
All manuals and user guides at all-guides.com

S600D USER AND MAINTENANCE MANUAL
4
All information and visual elements provided by LYNXTER in this document are believed to be accurate
and precise. LYNXTER reserves the right to modify the specifications without notice , at any time and to
make regular modifications to the product without notice to any person or thir d party.
All instructions, visual elements and information provided in this document are of restricted technical
nature and may not be reproduced, duplicated, sold or distributed, in whole or in part, without the prior
written consent of LYNXTER, the unique owner of all information herein. The product comes with a one -
year parts and labor limited warranty.
LYNXTER is liable for all design and manufacturing defects with the exclusion of any defects that the
buyer was aware of or that were visible at the time of delivery.
This warranty will become invalidated if modifications are made or repairs are performed directly or
indirectly by the client.
Our liability is limited to the timely replacement of any parts found to be defective by LYNXTER and
excludes all other forms of compensation.
The customer will bear the cost of any travel expenses associated with the assembly and installation of
parts replaced under warranty.
LYNXTER will not accept liability for and our warranty will be voided in the event of:
-Incorrect installation and setup
-Improper use that is not in accordance with product instructions
-Inadequate maintenance
-Abnormal wear and tear
-Modification of any component without the specific consent of LYNXTER
-Use of non-genuine parts (that are not approved by LYNXTER)
-Negligence during storage, transport, operation or maintenance.
All manuals and user guides at all-guides.com

S600D USER AND MAINTENANCE MANUAL
5
FFF: Fuse Filament Fabrication, the 3D printing process used by this machine and based on
the principle of depositing melted material in layers.
3D Printing: An additive manufacturing process.
Delta Geometry: A robot architecture with 3 parallel axes that moves in a three -dimensional,
cylindrical space.
Toolhead: Tool carried in the toolholder affecting raw material state to dispense it to generate
the part.
Extruder: Motorized part that feeds the build material (filament) into the toolhead.
Hotend: The lower part of the toolhead that reaches high temperatures. Do not touch the
hotend during operation; risk of burns.
Coldend: The upper portion of the toolhead that is actively cooled to limit heat spreading from
the hotend.
Nozzle: Cone-shaped metallic part located at the lowest tip of the hotend. The diameter of
the nozzle determines the extrusion width and restricts the maximal layer height.
Heated build plate: Build platform located in the lower portion of the machine. Hot zone,
hazardous during operation. Ensures maximum adhesion of the print. Prevents warping and
layer delamination.
G-code: Standard machine command language used by the S600D.
Firmware: Computer code flashed onto the machine controller board.
Slicer: Computer software that generates G-code from a 3D file.
STL: 3D file format commonly used for 3D printing.
Autoleveling: Automatic calibration and leveling of the print bed.
All manuals and user guides at all-guides.com

S600D USER AND MAINTENANCE MANUAL
6
All manuals and user guides at all-guides.com
all-guides.com

S600D USER AND MAINTENANCE MANUAL
7
Place the machine on a platform such as a desk or workbench. This platform must:
be a minimum of 60 and a maximum of 85 cm high,
be able to continuously and comfortably support a minimum weight of 250 kg,
be sufficiently firm and level in order to correctly support the machine.
Keep the work area clean and well-lit.
As a precaution, place the machine close to an air vent and in an area with low frequentation.
No special power supply is required.
Hot zone:The hot surface sign indicates the presence of components
with high temperatures. Always use caution and wear safety gloves
when working near hot components.
Safety footwear (not provided): When handling the device, wear
safety shoes to help prevent injuries.
Gloves (not provided):When performing certain maintenance
procedures, the components may be hot. Wear heat-resistant safety
gloves to avoid burns.
All manuals and user guides at all-guides.com

S600D USER AND MAINTENANCE MANUAL
8
While the machine is in operation, do not disconnect the power supply/ do not
move the machine/ do not try to open the door/ do not try to access the print
zone.
Carefully read this manual before operating, performing maintenance tasks ,
moving or interacting in any way with the 3D printer.
Any modification or adjustment that has not been expressly approved by the
manufacturer or its designated representative may void the warranty .
Do not modify the environmental conditions in any way that could damage the
machine.
Before using or touching the machine, the user or operator must first put on heat-
resistant safety gloves (not supplied).
Do not lean on the machine. Do not interfere with the stability of the machine.
The machine contains moving parts that are potentially dangerous. Never reach
inside the machine during operation.
For monitoring puroposes, an operator must stay near the machine while it is
running.
Do not print with materials that have not been approved by LYNXTER for the
S600D.
All manuals and user guides at all-guides.com

S600D USER AND MAINTENANCE MANUAL
9
The power outlet must be easy to access and located close to the machine.
In the event of an emergency, disconnect the power cord of the machine from the power
outlet.
All manuals and user guides at all-guides.com

S600D USER AND MAINTENANCE MANUAL
10
The S600D is equipped with the following safety features to protect the user:
An indicator light located at the edge of the build plate indicates that the temperature
of a component inside the machine is over 50°C. When this light is on, you must wear
gloves that resist to temperatures of up to 500°C when touching the machine.
A door-locking mechanism prevents access to the build area during printing. When
pressed, an indicator light located on the door button uses the follo wing color codes
to show the state of the machine:
oGREEN: The door is unlocked, press again to open.
oORANGE: Printing is in progress. The door can only be opened if the print-job is
paused via the control interface. Warning, some components may still be hot
when the door is opened.
oWHITE: The machine is powered on. Warning, some components may still be
hot when the door is opened.
All manuals and user guides at all-guides.com

S600D USER AND MAINTENANCE MANUAL
11
Printing can be launched in one of two ways, the main characteristics of which are outlined
below:
1. Printing via the LYNXTER WEB CONTROL interface (recommended). This is the
preferred solution if you have access to a LAN using Ethernet (from a computer, tablet
Create a 3D model and save it as an
STL file
Download a model in STL format
directly from a repository of 3D
models.
Import and position the STL file(s)
in the 3D printing software
(Simplify 3D)
Generate the “G-code”
Choose a print profile (.fff file)
and define your FFF settings for
each of the models
Save the “G-code”in a dedicated
folder.
Import the file in the machine
via the Web interface
Launch the print via the
LYNXTER WEB CONTROL
INTERFACE
Launch the print via the
touchscreen on the machine
All manuals and user guides at all-guides.com
all-guides.com

S600D USER AND MAINTENANCE MANUAL
12
or smartphone) It enables import-export of files and total control of the machine in
optimal conditions.
2. Printing directly from the touchscreen on the machine. This is the preferred solution for
standalone printing. No additional devices are required.
All manuals and user guides at all-guides.com

S600D USER AND MAINTENANCE MANUAL
13
The installation package is available for download from: https://ressources.techno.lynxter.fr/
This package includes default profiles to simplify your first prints.
Note:
LYNXTER does not provide the computer hardware required for the installation .
The software must be installed on a computer with an Internet connection ; An Internet
connection is needed to download the software installation package and updates
(subsequently available online).
If your computer does not have an Internet connection, please inform us of this when you place
your order and/or set up your machine.
All manuals and user guides at all-guides.com

S600D USER AND MAINTENANCE MANUAL
14
To install the G-code generation software (Simplify3D) on your computer, open the installation
file received with your machine, or download the installer directly from the Simplify3D website.
You will need the Simplify3D license key received with your machine.
To begin the installation, run the Setup.exe file as administrator.
A window with a setup wizard opens. Follow the prompts to set up your machine to work with
Simplify3D.
When the installation is complete, you will be required to log in and provide the license key
when starting the program for the first time.
All manuals and user guides at all-guides.com

S600D USER AND MAINTENANCE MANUAL
15
The S600D has both a USB port and an Ethernet port. Because transmission speeds via
Ethernet are much faster, you should control the machine via the Lynxter Web Control interface
(Ethernet) rather than the USB port. The USB port is dedicated to accessories.
Connect the machine to the PC via the Ethernet cable.
Open the Windows control panel and click on Network and Sharing Center.
All manuals and user guides at all-guides.com

S600D USER AND MAINTENANCE MANUAL
16
In the Active networks section, click on Local Area Connection
In the Local Area Connection status dialog box, click the Properties button.
All manuals and user guides at all-guides.com
all-guides.com

S600D USER AND MAINTENANCE MANUAL
17
In the Networking tab, double-click on Internet Protocol Version 4 (TCP/IPv4)
Select Use the following IP address , as shown below, and enter IP/Subnet matching the
machine IP/Subnet (displayed on the machine interface). The computer and the
machine must be on the same network in order to connect.
Ex: Machine IP is 192.168.1.10, Subnet is 255.255.255.0. PC IP can be
192.169.1.9 (if available), PC subnet is 255.255.255.0.
You can now save your settings and close all windows by successively clicking
OK –OK –Close –X –X
All manuals and user guides at all-guides.com

S600D USER AND MAINTENANCE MANUAL
18
Open your Internet browser (we recommend using Chrome) and access the LYNXTER
WEB CONTROL interface at the machine IP, here http://192.168.1.10/.
Contact your IT administrator if facing any issues. Machine network parameters can be edited from the
web interface in the Settings tab.
The S600D comes with the latest software updates and stable firmware. In the event of a major
upgrade to either of these, we will provide you with the detailed implementation procedure.
All manuals and user guides at all-guides.com

S600D USER AND MAINTENANCE MANUAL
19
1–List of models (3D files) imported into Simplify3D.
2–Buttons to import and delete the models (3D files) in the virtual build table. The “Center
and Arrange” button will automatically position the models in the center of the build plate.
3–List of processes (a collection of print settings) to apply to the different models.
4–Buttons to add and delete processes. These processes can be edited by clicking “Edit
Process Settings”(see the following section for details).
5–Preparation of the G-code file as per the process settings applied to the models. For
multiple processes, be sure to specify if printing should be continuo us or sequential (part by
part).
6–Interactive display showing the 3D view of the STL files in the build area.
7- Cross section view of the selected models, machine control panel (not used) and automatic
generation of support structures.
8–Display settings for the models on the build table. Display of coordinate axes, solid model
or wireframe views and display of normal vectors for the mesh surface of the 3D model.
9–Shortcuts to access standard views (default view, top view, front view, side view)
10 –Select, move, scale or rotate an object.
4
1
2
3
5
6
10
9
8
7
All manuals and user guides at all-guides.com

S600D USER AND MAINTENANCE MANUAL
20
Click the “Edit Process Settings”button to configure the selected print process settings by
choosing the desired material, print quality and extruder. You can also adjust the interior
solidity of your model by changing the “Infill Percentage”as well as generate a “raft”and/or
support structures.
Click “Select Models”to select the models to which these settings will be applied.
Click “Show Advanced” to display and configure the settings in more detail.
All manuals and user guides at all-guides.com
