LYSON W4090 User manual

MANUAL
MINI CANDLE WAX EXTRACTOR WITH WATER JACKET
AND LID
Przedsiębiorstwo Pszczelarskie Tomasz Łysoń
Spółka z o.o. Spółka Komandytowa
34-125 Sułkowice, ul. Racławicka 162, Polska
www.lyson.com.pl, email; [e-mail]
tel. [phone]
Company based in Klecza Dolna 148, 34-124 Klecza Górna

The following manual includes the device
bearing the following code:
W4090
POWER SUPPLY 230V:
Manual
1. General safety operational principles
1.1. Electrical safety
1.2. Operational safety
2. Device characteristics
2.1. Device description
2.2. Device technical parameters
3. Temperature regulator
3.1. Temperature setting
4. Storing the device
5. Cleaning and maintenance
6. Recycling
7. Guarantee

MINI WAX EXTRACTOR
Prior to operating the device please refer to the manual and
act according to the guidelines contained therein. The
manufacturer cannot be held accountable for the damages
cause by misusing the device or its improper handling
1. GENERAL SAFETY OPERATIONAL
PRINCIPLES
1.1. ELECTRICAL SAFETY
a) The device must be connected to the socket , having the
voltage specified on the product nominal plate.
b) Electric installation must be equipped with RCD having
the nominal activation current below 30 mA. The
operation of the over-current circuit breaker must be
checked periodically .
c) Regularly check the supply cable. If a non-detachable
power supply cable gets damaged, they must be
replaced. In order to avoid the threat, it must be
performed by a guarantor or by a specialised servicing
centre or by an authorised person. Do not operate the
device when a supply cable is damaged .
d) d) In case of damage and in order to avoid the threat, the
repairs must be performed by a guarantor or by a
specialised servicing centre or by an authorised person.
e) It is forbidden to pull the supply cable.
Power supply cable must be kept away from the heat sources,
sharp edges and its good technical state must be taken care of.
1.2. OPERATIONAL SAFETY
a) The following equipment is not intended to be used by
persons with limited physical, sensory or mental
capabilities (including children) or persons inexperienced
or unfamiliar with that type of equipment unless the usage
occurs under supervision or in line with the equipment
operating manual provided by safety supervising persons.
b) The floor on which the device has been placed ought to
be dry!
c) The lid must be closed during operation!
d) Do not displace the device while in operation.
e) Protect the heating element against humidity (also during
the storage)
f) Do not operate the device in the vicinity of flammable
materials.
g) It is forbidden to make any maintenance works while
device is under operation.
h) The device may be activated indoors only. It has not been
adjusted to be operated outdoors.
WARNING !!!
While in operation, the device gets hot
excessively from the outside (external
jacket)
2. DEVICE CHARACTERISTICS
The device with water jacket is intended to melt the wax.
Proper design allows to heat the wax evenly along the entire
surface of the device.
2.1. DEVICE DESCRIPTION
3 4 5 2 1
Description:
1- wax discharge valve ½”
2- vent ¾” , maximum water level inside the heating
jacket, water refilling
3- heating element with temperature regulator
4- lid
5- tank the wax
2.2. DEVICE TECHNICAL PARAMETERS:
•Insulated tank made of stainless and acid-resistance
steel plate
•Heating element power supply – 230V
•Heating element power – 2000W
•Temperature regulation from 0 to 75ºC
•Discharge valve 1/2” (1)
•Capacity 12 litres
•Dimensions: l.*w.*h.
500*400*380mm.

ATTENTION !!!
Check the water level inside the water jacket
on regular basis (vent „2”)
3. TEMPERATURE REGULATOR
The device has been equipped with a heating elements with a
regulator for the temperature range between 0 and 80ºC and
the power of 2000W.
3.1. Temperature setting
1. Prior to connecting the device to the mains, make sure the
heating element is switched off.
2. The knob on the heating element panel should be in the
position on the minimum value of the scale (switched off).
3. Once connected to the mains, turn the knob on the panel
to the proper position and control the temperature with a
thermometer regularly (thermometer is not included ).
4. If needed, correct the knob position depending on the
required temperature value .
4. Storing the device
Once the operation terminates, the device must be cleaned
and dried thoroughly.
Prior to activation, when the device has been displaced from
the room with the lower temperature to the room with the
higher one, wait until the device has reached the ambient
temperature.
The device is to be stored in dry rooms with the temperature
above 0º C.
Prior to every season, an additional technical check-up
must be performed and if any defects have been detected,
contact the service centre
5. Cleaning and maintenance
IMPORTANT!
Prior to the maintenance, unplug the device.
Prior to the first usage, device must be cleaned and dried
thoroughly.
The device is to be washed with hot water with the agents
admissible to come into contact with the equipment used in
food processing added.
The device is to be washed with soft fabrics, make sure to
protect electric components.
After washing, rinse with clean water and dry. The device is to
be stored in a dry room.
The device components must not be protected with chemical
agents.
6. Recycling
Worn-out product must be removed as waste only within
selective waste collection organised by the Network of
Communal Electric and Electronic Waste Collecting Points. A
customer is entitled to return the used equipment to the
electrical equipment distributor network, at least free of charge
and directly, if the device to be returned is of proper type and
serves the same purpose as the newly purchased device
7.Guarantee
Products purchased from “Łysoń’ company are encompassed
by the manufacturer’s guarantee.
The guarantee duration equals 24 months
A receipt or a VAT invoice is issued for each product
purchased
Guarantee terms, see www.lyson.com.pl
