LYSON MINIMA Series User manual

Manual
Honey extractors –MINIMA series
with manual or electric drive
Przedsiębiorstwo Pszczelarskie Tomasz Łysoń
Spółka z o.o. Spółka Komandytowa
34-125 Sułkowice, ul. Racławicka 162, Polska
www.lyson.com.pl, email: [email protected]
tel.[phone]
Siedziba Firmy Klecza Dolna 148 , 34-124 Klecza Górna

This manual encompasses the
devices with the following codes:
W224B , W2026B , W2027B , W2029B ,
W2030B , W 2033B
Manual
1. General safety operational
principles
1.1.Operational principles
1.2. Electrical safety
1.3. Operational safety
2. Honey extractor manual
2.1. General principles for
preparing the device for operation
2.2.Operational principles
3. Characteristics of the honey
extractors - MINIMA series
3.1. Technical parameters for electric
honey extractors
3.2. technical parameters for manual
honey extractors
3.3. Dismantling the basket in case of
manual and electric honey extractors
4. Device storage
5. Maintenance and cleaning
6. Recycling
7. Guarantee

1. GENERAL SAFETY
OPERATIONAL PRINCIPLES
Prior to device usage initiation, refer to the
following manual and act according the
guidelines contained therein. The manufacturer
shall not be held accountable for any damages
caused by improper usage of the device or its
improper handling
.
1.1. Operational principles
1. The honey extractor is intended to centrifuge
the honey from the frames.
2. The honey extractor must be washed
thoroughly prior to usage with water containing
slight amount of agents admissible to be used in
cleaning the devices coming into contact with food
or by means of a pressure washer.
1.2. Electrical safety
1. Power supply electric installation must be
equipped with RCD with nominal tripping
current In below 30 mA. Functioning of
overcurrent circuit breaker must be checked
periodically .
2. If non-detachable power supply cable gets
damaged and must be replaced, it must be
performed at a guarantor’s or by a
specialised repair centre or by a qualified
person in order to avoid any threat. Do not
operate the honey extractor when the power
supply cable is damaged.
3. Prior to plugging in the device to the mains,
check whether controller is switched off. 0/1
switch on the controlling panel should be in
“0” position.
4. Check the honey extractor and the power
source for nominal voltage compliance.
5. Be careful while connecting the device to the
mains.
Hands must be dry!
The floor on which the extractor has been
placed must be dry!
6. The honey extractor lid must be closed during
spinning!. It is forbidden to open the lid during
spinning.
7. While spinning, the honey extractor must not be
displaced.
8. In case of the honey extractor with electric
controlling, the engine and the controller must be
protected against damping; ( also during the
storage).
9. It is forbidden to pull the supply cable. The
supply cable must be kept away from heat
sources, sharp edges and its good technical state
must be taken care of.
1.3. Operational safety
1. The following equipment is not intended to be
used by persons with limited physical, sensory or
mental capabilities (including children) or persons
inexperienced or unfamiliar with that type of
equipment unless the usage occurs under
supervision or in line with the equipment operating
manual provided by safety supervising persons.
One must make sure that children do not play with
the honey extractor.
2. In case of any damage to the honey
extractor, in order to avoid the danger, the repairs
may be performed solely by a specialist servicing
centre or a qualified person.
3. It is forbidden to perform any
maintenance works or repairs when the device is
in operation.
4. All shields must be permanently attached to
the honey extractor while operating it.
5. The device cannot be activated and stored
with the ambient temperature below 0º C.
Honey extractor cannot be activated when the
ambient temperature drops below 5º C. When the
honey extractor has been moved from a room with
a lower temperature to a room with a higher
temperature, prior to its activation one must wait
until the device has achieved the ambient
temperature.
It is forbidden to make any repairs while the
device is under operation
It is forbidden to remove any shields while the
device is under operation

.2.HONEY EXTRACTOR MANUAL
2.1 General principles for preparing
the honey extractor for operation
1. Place the honey extractor in the place
specified for the purpose and kept in order
and cleanliness.
2. Fix the honey extractor to the ground in order
to avoid its displacement during spinning.
2.2. Operating principles
1.Honey extractor is intended to centrifuge the
honey from the frames.
2. Prior to first extraction and after the honey
harvesting, the honey extractor must be washed
thoroughly in line with the guidelines contained in
the chapter Honey extractor maintenance.
3. Previously prepared frames must be placed
inside the basket, with special attention paid to
their arrangement. Erroneous frame arrangement
may bring about the damages which are not
subject to guarantee terms!
4. Prior to the honey extractor activation, one
must:
Put the plug into the socket, switch the
controlling activation button on the controlling
cabinet from “0” to “1” position.
5. The first phase of extraction shall be performed
slowly in order to prevent the honeycombs from
breaking out. Special attention must be paid to the
so called “young frames”.
6. Rotations are regulated by a potentiometer.
NOTE!!! Frames may be rearranged only when
the honey extractor basket has come to a
complete hold!
9. Once the basket has stopped, reverse the
frames by 180 degrees and centrifuge the other
side of the honeycomb. The frames are to be
centrifuged in two stages, first with lower rotations
on both sides of the honeycomb. Subsequently,
with higher rotations of the basket on both sides of
the honeycomb again.
10. The spinning basket should not be blocked by
the honey accumulating inside the drum. If that is
the case, the honey extractor must be stopped in
order to avoid any damage. Once the honey has
drained to the containers, spinning may be
restarted.
11. A container intended for the honey shall be
placed under the drain valve.
While spinning the drain valve should be opened
in order for the honey to flow freely.
3. Characteristics for the honey
extractors –Minima series.
Diagonal, 3-4-honeycomb honey extractor can be
used in small apiaries as well as by the apiarists
treating beekeeping as a hobby. Its distinguishing
features include compact dimensions and easy
handling. Designing solutions applied make it
possible to centrifuge even the densest honey .
The conical shape of the extractor’s bottom allows
for the honey do drain freely. Honey extractors are
packed in carton boxes, for self-assembling.
3.1. Technical parameters of electric
honey extractor
Drum of the honey extractor is made of stainless
and acid-resistant steel plate, thickness 0.6 mm.
The proper arrangement of the rabbets reinforces
the drum construction even more.
Basket design
Diagonal basket made of stainless and acid-
resistant rods, thickness 2 and 5 mm, arranged in
the way protecting the frames from honeycombs
breaking out during spinning. Meshing size 20x20
mm. The basket placed on the sliding-retaining
sleeve.
Electric drive
The honey extractors are supplied by the mains
voltage 230V. The rotation potentiometer has
been applied as well. The engine with
transmission is mounted on the upper beam.
Lid
Transparent lid made of metaplex, thickness 3
mm, protects a user against the hazard of coming
into contact with a spinning basket and getting
dirty.
Drain valve
Made of plastic, 6/4”
•Drum height (without the drive)-610

•Drum height with the drive, with legs-
950mm.
•Honey extractor’s weight – 24.5 kg
diameter 600mm
•Honey extractor’s weight – 21 kg
diameter 500 mm
•Legs and beam ate powder-coated
Components of the honey extractor
with electric drive:
•Drum with the engine installed
•Assembling elements (list below)
•Lid (2 pcs).
•Plastic valve (c)
•MDD controlling
•Honey extractor’s legs (b)
•Manual
•Guarantee
Leg fixing:
Lid fixing:
d. Upper lid made of Plexiglas with five
orifices - 1 pc
d1. Rear lid made of
Plexiglas with four orifices - 1 piece
e. bolt to screw the handle –1 piece
f. handle to lift the lid –1 piece
g. lid hinge –4 pcs
h. plastic washers –8 pcs
conical Allen screw 5x25 –8 pcs.
i1. Conical Allen screw
M5x30 –8 pcs.
j. washer extended to hold the nuts
for
Plexiglas –8 pcs
j1. washer 5 for beam nuts 8 pcs.
k. nut for conical Allen bolts for
Plexiglas and beam M5 –16 pcs
wrench 8/10 –1 pc
Allen wrench 3 –1 pc.
Controller fixing:
I. honey extractor’s control unit
I1. Cap nut M8 –2 pcs
b. legs –3 pcs
The list of assembling elements:
a. leg fixing knob - 6 spcs

I2. washer 8 –2 pcs.
I3. bolt M8x25 –2 pcs
Wrench 10/13 –2 pcs
Assembling the MINIMA-series honey
extractor with electric drive
1. Take the drum with installed engine out of
the carton box
2. Take out the elements for self-assembling
3. Assemble the legs and the valve
4. assemble the Plexiglas
5. assemble the controlling unit
a. b.
Screwing the hinges to the beam
Knob folding to the plexiglass
3.2. Technical parameters of the
manual honey extractor
Drum of the extractor is made of stainless and
acid-resistant steel plate, thickness 0.6 mm.
The proper arrangement of the rabbets
reinforces the drum construction even more.
Basket design
Diagonal basket made of stainless and acid-
resistant rods, thickness 2 and 5 mm, arranged in
the way protecting the frames from honeycombs
breaking out during spinning. Meshing size 20x20
mm. The basket placed on the sliding-retaining
sleeve.
Fixing the controlling unit
Fixing the valve
Fixing the legs

Manual drive with a brake mounted on the upper
beam of the extractor. Makes it possible to
operate the device when the access to electricity
is impossible. Manual drive casing is made of
powder-coated metal. Steel rolled gears transfer
the torque to the basket axis.
Lid
Transparent lid made of metaplex, thickness 3
mm, protects a user against the hazard of coming
into contact with a spinning basket and getting
dirty .
Drain valve-plastic, 6/4”
•Drum height (without drive)-610mm.
•Drum height, without drive, with legs-
950mm.
•Extractor weight –24.5 kg d= 600mm
•Extractor weight –21 kg d= 500 mm
•Legs and beam powder-coated
Components of the Minima-
series extractor with manual
drive
•Drum with engine mounted
•Assembling elements (list below)
•lid 2 pcs
•plastic valve
•extractor’s legs
•manual
•guarantee
List of assembling elements:
Fixing the legs
a. knob to fix the legs - 6 pcs.
b. extractor’s legs –3 pcs
Fixing the handle
d. Allen bolt
M8x110 - 1 piece
e. handle - 1 piece
f.cap nut M8 - 1 piece
Wrench 10/13 –1 piece
Allen wrench 6 –1 piece
Fixing the lid:
g. front lid made of Plexiglas with five orifices - 1
piece
g1. Rear lid made of Plexiglas with four orifices –
1 piece.
h. bolt to screw up the handle to
plexiglas –1 piece
i. grip to lift the extractor
lid –1 piece
j. lid hinge –4 pcs
k. plastic washers –8 pcs

m. conical Allen bolt M5x25 –8 pcs.
m1. Conical Allens bolt
M5x30 –8 pcs
n. washer 5 widened for the nuts for
the
plexiglas –8 pcs.
n1. washer 5 for the nuts for the
beam –8 pcs
o. nut for a conical Allen bolt for
plexiglas and beam M5 –16 pcs
Wrench 8/10 –1 piece
Allen wrench 3 –1 piece
ASSEMBLING THE HONEY
EXTRACTOR WITH MANUAL DRIVE
1. Extractor drum with assembled manual
drive shall be taken out of the carton box
2. Take out the set of assembling elements for
self-assembly
3. Assembling the legs and valve
4. Assembling the handle
5. Assembling the Plexiglas
ASSEMBLING THE HANDLE
d. b. a.
Valve assembling Leg assembling
SCREWING UP THE LID TO THE TOP
BAR
Plexiglass cover folding to the top bar

Knob folding to the plexiglass
3.3. Dismantling the basket in manual
and electric honey extractors
•Unscrew the upper beam by means of
black knob together with drive and lids
•Remove the basket
•Clean the extractor
•Insert the basket to the drum
•Fix the beam with the drive and lids
4. Storing the honey extractors
Once the honey harvesting has terminated the
device is to be washed thoroughly.
Prior to the honey extractor start-up, in case when
it has been transferred from a room with a lower
ambient temperature to a room with a higher one ,
one must wait until the device has reached the
ambient temperature.
The device is to be stored in dry rooms with the
temperature above 0º C.
The honey extractor must not be activated when
the ambient temperature drops below 5 degrees C
Before every season, an additional technical
inspection must be performed and n case when
any defects have been detected , a service centre
must be contacted
5. Extractor maintenance and cleaning
Prior to starting the maintenance, the
plug must be taken out!
After honey harvesting time honey extractor shall
be washed thoroughly with hot water containing
slight quantities of agents accepted to be used in
devices intended to come into contact with food or
by means of a pressure washer. Be careful during
the washing and prevent dumping the honey
extractor engine or controller ( they may be
covered with water-resistant materials)
After washing, the honey extractor must be rinsed
with pure water and dried. Before every season
additional technical inspection must be performed
and in case any faults are detected a service point
must be contacted.
6. Recycling
Worn-out product must be removed as waste only
within selective waste collection organised by the
Network of Communal Electric and Electronic
Waste Collecting Points. A customer is entitled to
return the used equipment to the electrical
equipment distributor network, at least free of
charge and directly, if the device to be returned is
of proper type and serves the same purpose as
the newly purchased device.
7. Guarantee
Product purchased from “Łysoń’ company are
encompassed by the manufacturer’s guarantee.
The guarantee duration equals 2 years Na A
receipt or a VAT invoice is issued for each product
purchased
Details on the guarantee terms, see the
regulation on:
www.lyson.com.pl
