M-Edge StealthPro Keyboard Folio User manual

INSTRUCTION MANUAL

PRODUCT FEATURES
• Built-in wireless Bluetooth® 3.0 keyboard
• Compatible across iOS, Android, and Windows, enabling you to mix and
match with devices
• Ultra-thin, lightweight aluminum keyboard.
• Quiet key design
• Micro USB interface for convenient charging
• Moisture resistant and dust-proof keyboard design
• Energy-saving keyboard with self-activating sleep mode
KEY
➊
On/Off switch
➋
Bluetooth Connect Button
(ashes when searching)
➌
LED Indicators
➍
Micro USB Port
➎
Operating System Toggle Keys
➏
Foam Screen Protectors
KEYBOARD SPECIFICATION
Bluetooth Specification:
Bluetooth® 3.0 interface standard
Operating Range: Up to 10 meters
Modulating System:
Gaussian Frequency-Shift Keying (GFSK)
Operation Voltage: 3.0-4.2V
Operation Current: < 2.5mA
Standby Current: < 0.3mA
Sleeping Current: < 40UA
Charging Current: ≥ 200mA
Standby Time: 100 days
Charging Time: < 2hours
Lithium Battery Capacity: 280mA
Uninterrupted working time: 100 hours
Lithium Battery Life: 3 years
Lithium Battery Specification:
3.8*20*35mm
Keystroke Strength: 80±10g
Keystroke life: 5 million strokes
Operation Temperature: −10±55 C
3 EASY STEPS
1. Wrap the silicone mount around the device corners for installation.
2. Easily position or remove magnetic keyboard for desired viewing angle
Tablet and case can be used separately.
3. Connect Bluetooth® keyboard to your device.
➏ ➏
➊➋➏
➌
➍
➎

PAIRING INSTRUCTIONS (PAIR TO IPAD AS EXAMPLE)
1. Turn on the power toggle switch. The [Power] and [ ] indicator light will be on
for 5 seconds and then go off.
2. Press on the [Connect] button, the indicator light [ ] will blink. The keyboard
is now ready to connect to your device.
3. Turn on and unlock iPad. Click on the iPad [Settings] icon.
4. On the setting menu, select item [General] to access [Bluetooth] turn on the
connection. iPad will automatically search for a Bluetooth-enabled device.
5. Once the Bluetooth 3.0 keyboard has been identied, click on Bluetooth 3.0
keyboard to connect to your device.
6. Enter the random four digit password code as displayed on the screen on the
keyboard and hit enter.
7. Once the Bluetooth keyboard has successfully connected to your device, the
indicator light [status] will be off.
OPERATING SYSTEM INSTRUCTIONS
1. The default mode is for the iOS system. If you need to use it for android or
Windows, please shift it by pressing Fn key and W key for Android (or E key for
Windows) together before you start to type.
2. Please make sure your Android or Windows device is equipped with a
Bluetooth HID prole before pairing.
CHARGING INSTRUCTIONS
When the battery power is low, the indicator light [power] will start blinking. This
means that it is time to recharge the keyboard.
1. Connect the micro end of the USB power cable to the micro USB port on
the keyboard.
2. Connect the other end of the cable to a wall plug power adapter or computer
USB interface.
3. The indicator light [charge] will stay on red while the keyboard is charging.
Once it is fully charged, the power indicator light will shut off.
THE POWER SAVING MODE
The keyboard will enter sleep mode after being idle for 15 minutes. To activate it from
sleep mode, press any key and wait 3 seconds.
TROUBLESHOOTING
Unable to connect
1. Check whether the power switch is on or not.
2. Verify that the keyboard is within the operating distance (the available
distance is 10 meters).
3. Make sure the battery is not depleted.
4. Ensure your device’s Bluetooth function is turned on.
5. Conrm the Bluetooth keyboard has been paired with your device.
Unable to Charge Keyboard
1. Identify if the USB power cable is connected properly to the keyboard and the
power source.
2. Check of the wall charger has plugged into power outlet.
USAGE TIPS
1. Do not place any heavy objects on top of the key board.
2. Do not knock or dismantle the keyboard.

3. Keep the keyboard away from oil, chemicals, and organic liquids.
4. Clean the keyboard with the water, alcohol, or an alcohol-based disinfectant.
5. Dispose of batteries according to local laws.
TECHNICAL SUPPORT
For technical questions, please visit:
www.medgestore.com/about/contact/
877-MEDGE-43 or 877-633-4343
REGULATORY COMPLIANCE
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions. (1) This device may not cause harmful interference, and (2)
This device must accept any interference received, including interference that may
cause undesired operation.
FCC STATEMENT
Tested to Comply
This equipment has been tested and found to comply with the limits of a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does not
cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the
interfere by one or more of the following measures:
• Reorient or relocate the receiving antenna;
• Increase the separation between the equipment and receiver;
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected;
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modications not authorized by the party responsible for compliance
could void the user’s authority to operate this product.
Compliance with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to
Laser Notice No. 50 dated June 24, 2007.
BATTERY WARNING
You are cautioned that changes or modications not expressly approved by the party
responsible for compliance could void your authority to operate the equipment.
RF EXPOSURE WARNING
The equipment complies with FCC RF exposure limits set forth for an
uncontrolled environment.
The equipment must not be co-located or operating in conjunction with any other
antenna or transmitter.

MEDGESTORE.COM
