M-Spa MONO User manual

Where Luxury Is Affordable
®
www.the-mspa.com
Owner’s Manual
C-MO049 / C-MO069
MONO
EN
DO NOT RETURN MERCHANDISE TO YOUR DEALER STORE DIRECTLY.
CALL MSPA AFTER SALES SERVICE CENTER FOR PRODUCT QUESTIONS
OR CONTACT MSPA AT [email protected]
Due to MSpa continuous product improvement, MSpa reserves the right to change
specifications and product appearance, which may result in updates to the
instruction manual without notice.

2
ENTER THE WORLD OF MSPA
Thank you for choosing MSpa and for your confidence in our brand. We believe that you will enjoy many benefits
of using MSpa products for years to come.
To guide you in your initial MSpa experience, we are pleased to present you with this instruction manual. Please
carefully and thoroughly read this manual entirety before using the product for the first time.
We are delighted to welcome you to the MSpa family, and look forward to sharing with you the full spectrum of
our expertise.
Enjoy your MSpa!
Welcome,
CONTENT
Safety precautions............................………………………….........……………………...........................………
Specifications…………………………………........................................................................................…….....
Product overview………………………............................……..............................................................……….
First use and set-up preparation......................................................................................................................
Spa set-up........................................................................................................................................................
Controller operation…………………….............................................................................................................
Water maintaince and chemicals……………................................………..…...................................................
Drainage, cleaning and storage.......................................................................................................................
Disposal and environmental protection.......................................…..................................................................
Troubleshooting…………………………….....……………………….….........................................…..................
MSPA limited warranty........………....................................………...................................................................
3
8
9
10
12
14
16
18
20
21
23
MSpa official site MSpa Set up videos

3
SAFETY PRECAUTIONS
For your own safety and that of your product, make sure to follow the safety
precautions below. Fail to follow the instruction may result in serious injury,
property damage or death. Improper installation or operation will void the warranty.
READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS
KEEP THE MANUAL FOR FUTURE REFERENCE
! DANGER
Risk of Accidental Drowning. Extreme caution must be exercised to prevent
unauthorized access by children.
Risk of drowning. Inspect the spa cover regularly for leak, premature wear and
tear, damage or signs of deterioration. Never use a worn or damaged cover: it
will not provide the level of protection required to prevent unsupervised access
to the spa by a child.
Risk of drowning. Always lock the spa cover after each use.
Risk of injury. If the supply cord is damaged, it must be replaced by the manu-
facturer, its service agent or similarly qualified persons in order to avoid a
hazard.
Risk of Electric Shock. Do not permit any electrical appliances, such as a light,
telephone, radio or television within 1.5m (5 feet) of a spa tub.
Risk of Electric Shock. Do not use the spa when it is raining, thundering or
lightning.
●
●
●
●
●
●
To reduce the risk of electric shock, do not use an extension cord, timers, plug
adaptors or converter plugs to connect the unit to electric supply; provide a
properly located outlet.
This appliance with incorporated heating elements must be connected to a
ground mains with a supply cord fitted with a plug and PRCD with a tripping
current of 10mA.
This appliance with earthing must only be plugged directly into an earthed
socket-outlet of the fixed wiring.
Parts containing live parts, except parts supplied with safety extra-low voltage
not exceeding 12V, must be inaccessible to occupants in the spa.
●
●
●
●
! WARNING

4
●
●
●
●
●
●
●
●
●
Parts incorporating electrical components, except remote control devices, must
be located or fixed so that they cannot fall into the spa.
Electric installation should fulfill the local requirement or standards.
The wired controller shall be properly stored at the side pocket when not used,
to protect the controller from falling or other factors.
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
To reduce the risk or injury, do not permit children use this product unless they
are closely supervised all times.
To reduce the risk of child drowning, supervise children all times. Attach and
lock spa cover after each use.
Make sure the floor is capable of supporting the expected load, which you can
find from the spec sheet, calculate the expected load of water capacity plus total
weight.
Adequate draining system must be provided around the spa to deal with
overflow water.
To reduce the risk of injury:
a) Lower water temperatures are recommended for young children and when
spa use exceeds 10 minutes. In order to avoid the possibility of hyperthermia
(heat stress) occurring it is recommended that the average temperature of
spa-pool water should not exceed 40°C(104°F).
b) Since excessive water temperatures have a high potential for causing fetal
damage during the early months of pregnancy, pregnant or possibly pregnant
women should limit spa water temperatures to 38°C(100°F).
c) Before entering a spa or hot tub the user should measure the water
temperature with an accurate thermometer since the tolerance of water
temperature regulating devices varies.
d) The use of alcohol, drugs or medication before or during spa use may lead to
unconsciousness with the possibility or drowning.
e) The use of alcohol, drugs, or medication can greatly increase the risk of fatal
hyperthermia in spas.
f) The causes and symptoms of hyperthermia may be described as follows:
Hyperthermia occurs when the internal temperature of body reaches a level

5
several degrees above the normal body temperature 37°C(98.6°F). The
symptoms of hyperthermia include an increase in the internal temperature of
body, dizziness, lethargy, drowsiness, and fainting. The effect of hyperemia
include failure to perceive heat; failure to recognize the need to exit spa;
unawareness of impending hazard; fetal damage in pregnant women;
physical inability to exit the spa; and unconsciousness resulting in the danger
of drowning.
g) Obese persons or persons with a history of heart disease, low or high blood
pressure, circulatory system problem, or diabetes should consult a physician
before using a spa.
h) Persons using medication should consult a physician before using a spa
since some medication may induce drowsiness while other medication may
affect heart rate, blood pressure, and circulation.
i) Check with doctor before use if pregnant, diabetic, in poor health, or under
medical care.
People with infectious disease should not use a spa or hot tub.
To avoid injury exercise care when entering or existing the spa or hot tub.
Water temperature in excess of 40°C(104°F) may be injurious to your health.
Never use a spa or hot tub alone or allow others to use the spa alone.
Do not use a spa or hot tub immediately following strenuous exercise.
Spa heat in conjunction with alcohol, drugs, or medication can cause uncon-
sciousness.
Exit immediately if uncomfortable, dizzy, or sleepy. Spa heat can cause hyper-
thermia and unconsciousness.
Do not put the spa under 0°C(32°F) environment in order to avoid freezing if
there is still water in the pool.
It’s helpful to put temp barrier mat in between the spa pool and the ground.
Similar mat which is made of foam material or other materials with heat barrier
function can also be used. Do not turn on the spa when the water is frozen.
Never pour water with a temperature higher than 40°C(104°F) into the spa
directly.
Always unplug this product from the electrical outlet before removing, cleaning,
servicing or making any adjustment to the product.
Never jump or dive into a spa or any shallow body of water.
No part of the electric appliance is to be located above the bath during use.
Do not bury the electrical cord. Locate the cord where it will not be damaged by
lawn mowers, hedge trimmers and other equipment.
●
●
●
●
●
●
●
●
●
●
●
●

6
Do not attempt to plug in or unplug this product while standing in water or when
your hands are wet.
Do not use the spa if damaged in delivery and/or malfunctioning in any way.
Contact the MSpa service center for further direction.
Keep all pets away from the spa to avoid any damage.
Do not add bath oil or bath salt to the spa water.
●
●
●
●
●
Always add chemicals to water, never add water to chemicals. Adding water to
chemicals may cause strong fumes or violent reactions and hazardous chemical
spray.
For water already used, discharge it in time or use water chemicals for cleaning.
Usually,change water every 3-5 days.
Use Mspa chemical kit for disinfection in accordance with manufacture’s
instructions.
Do not leave or set up the spa in temperature lower than 4°C(39°F) if heater is
not operating.
Always enter and exit the spa or hot tub slowly and cautiously. Caution of wet
floor.
To avoid damage to the pump, never turn on the spa or hot tubs unless it is
filled with water to the minimum water line.
Place the spa or hot tub only on a properly prepared site that can withstand the
floor loading requirement of the spa.
Do not leave the spa empty for extended period of time. Drain away water
inside the pool thoroughly for long time disuse. Do not expose the spa under
direct sunshine. Check regularly before each use. Put away the spa or fence it
up in time after using.
Open the spa top lid when the Bubble function is on.
In order to avoid a hazard due to inadvertent resetting of the thermal cut-out,
this appliance must not be supplied through an external switching device, such
as a timer, or connected to a circuit that is regularly switched on and off by the
utility.
Refer to relevant chapter for details concerning cleaning and other
maintenance.
●
●
●
●
●
●
●
●
●
●
●
! CAUTION

Zone 2 Zone 2
h
h
Zone 1
Zone 0
Zone 0
2.5 m
2.5 m
1.5 m 1.5 m2.0 m 2.0 m
7
Warning: Water protection levels of appliance at different product zones are
different see the following scheme. ( Installation regulations comply to IEC
60364-7-702)
NOTE - The measured zone dimensions are limited by walls and fixed partitions.
Zones
Zone 0
Zone 1
Zone 2
Description of the zones
Zone 0 is the interion of the basin including any recesses in their
walls or floors.
Zone 1 is limited by
• Zone 0
• A vertical plane 2m from the rim of the basin.
• The floor or the surface expected th be occupied by persons
• The horizontal plane 2.5m above the floor or the surface
Zone 2 is limited by
• A vertical plane external th zone 1 and parallel plane 1.5m
from the former.
• By the floor or surface intended to be occupied by persons.

8
Model No.
/ Code Shape Seating
Capacity
Water
Capacity
Outside
Dimensions
Inside
Dimensions Height Weight
Round
720 L
(190 Gal)
φ1.53m
60”
φ1.43m
56”
0.65m
26”
0.65m
26”
34.5kg
(76lbs)
SPECIFICATIONS
Control System
Total Power
Heater
Massage Air Blower
Filter Pump
Integrated Ozone Generator
Control System Specs
AC 220-240V~ 50Hz
2300W
1500W
720W - 3 Levels (Level 1: 300W, Level 2: 500W, Level 3: 720W)
12V/60W
5.5W, 30-50mg/Hr
C-MO049 / C-MO069
4
Round 6
BUBBLE SPA
C-MO049
Mono
C-MO069
Mono
930 L
(245 Gal)
φ1.73m
68”
φ1.63m
64”
37kg
(81.5lbs)

9
PRODUCT OVERVIEW
Packaging content
NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.
A. B. C.
D.
E. F. G.
H. I. J.

10
REF. NO. PARTS DESCRIPTION QTY.
SPA cover with buckle and inflatable bladder
Spa tub
All-in-one Control Box
23.5” high pressure pump, inflation hose, pressure gauge, seal ring
Heat preservation foam mat
Filter cartridge*2, cartridge base
Spa drain valve adaptor
Wrench for inlet and outlet
Wrench for inflation valve
Repair kit
NOTE: When ordering parts, be sure to quote the model number, part numbers and description.
A
B
C
D
E
F
G
H
I
J
1
1
1
1
9
1
1
1
1
1
FIRST USE AND SET-UP PREPARATION
The spa can be installed indoor and outdoor around 15 minutes by at least one person. For household use
only.
The spa must be set up on a flat, smooth and supporting surface that is capable of supporting the
maximum load of the filled spa with listed maximum occupants.
Make sure the area is free of sharp objects under or around the spa. Uneven of unsound surfaces can
damage the spa and void your warranty. Level the surface before filling spa with water.
Provide adequate drainage system around the spa to deal with overflow water and splashes.
Make sure there is enough clearance around the spa for full access to the spa equipment for maintenance
and/or service.
●
●
●
●
●
Site preparation and requirements
Verify the supporting floor can support the filled weight of spa with maximum number of occupants. Check
with a qualified contractor or structural engineer to verify the requirement.
Make sure the floor is water resistant and provides non-slip surface. Do not install the spa on a carpet of
any other material that could damaged by the moisture.
Humidity is a naturally side effect of indoor spa installation. The room shall be properly ventilated to allow
moisture to escape. Install a ventilating system to prevent excess condensation moisture in the room.
●
●
●
Additional requirements for indoor installation

11
Spa Control Unit Connected External Equipotential Bonding Conductors
A qualified electrician shall wire the spa control unit to the household equipotential terminal using a minimum
1.5mm² solid copper conductor.
2. 3.
1. Plug the machine into the mains.
2. Press the RESET button on the PRCD. The indicator turns red.
3. Press the TEST button on the PRCD. The red color shown on the indicator should disappear. Otherwise the
PRCD is faulty. Do not use the spa if the spa is faulty. Contact a qualified electrician to correct the fault.
4. Press the RESET button on the PRCD again. The indicator should turn red. If yes, the spa is ready for use.
PRCD Testing
Risk of electric shock: This product is provided with a PRCD located at the end of the power cord. The
PRCD must be tested before each use. Do not use the spa if the PRCD does not function properly.
Disconnect the power cord until the fault has been identified and corrected. Contact a licensed electrician to
correct the fault. There are no serviceable parts inside the PRCD. Opening the PRCD will void the warranty.
! WARNING
RESET
TEST
RESET
Indicator TEST
RESET
TEST
1.
√
PRCD doesn’t
work on faulty
sockets or plug
boards.
Additional requirements for outdoor installation
● Make sure to set up the spa on a firm, level and smooth surface that is strong enough to support the full
weight of the filled spa and maximum occupants.
● Do not set up the spa on grass or dirt, as this increases the amount of debris entering the spa, and can
damage the spa floor.
● Do not leave the spa tub exposed to direct sun light for long timespan
● Always keep the manometer on yellow section when using the spa at a temperature higher than 20°C
(68°F) or exposed to sunlight for a short time..
● Do not install or use the spa outdoor at a temperature lower than 4°C (39°F). Do not use the spa when the
water inside the circulation system, the pump, and the pipes is frozen. Put a Heat Preservation Mat in
between the spa bottom and the ground to prevent heat loss from the bottom of the spa and to provide
better heat retention.

12
SPA SET-UP
1
3
2
3. Connect the control box to the spa pool in right order. (There should be sealing ring at each connection point.)
4. Unscrew the valve cap and make sure that the center valve pin is in the “UP” position. If it is in the “DOWN”
position, press down on the valve pin and turn it counterclockwise until it pops up.
5. Attach the pressure gauge and the pump hose to the pump and secure it tightly. Connect the pump nozzle into
the valve receptacle on the spa body, and tighten it clockwise.
6. Start pumping air into the SPA tub by sliding the pump piston up and down, inflate the spa to 12 - 15PSI.
1. Spread out and connect the 9 pcs foam mat at a cleared area. Heat Preservation Mat prevents heat loss from
the bottom of the unit.
2. Put the pool body on the mat (note that the drain valve is in the appropriate area)
1
2
3

13
7.8 Turn on the Heater on the controller, refer to the “Controller operation” section. Maximum heating
temperature is 40°C(104°F). Hourly heating rate is about 1.5°C-2°C(2.5°F-3.5°F) for 4 persons and
1.2°C-1.8°C(2°F-3°F) for 6 persons.
7
7.7
7.6
Lock Unlock
7. Water Filling
7.1 Ensure the spa liner is at the selected area and point the
drain valve toward a suitable draining area before filing
water. Make sure the drain valve is securely tightened.
7.2 Fill the spa tub with fresh water to a level between
Minimum and Maximum line marked on the inside of the
spa wall.
Do not over fill the spa. It is recommended to fill the spa with lukewarm water for quick heating and energy
saving.
WARNING:
● Water level must reach the Minimum water line but not exceed the Maximum line to avoid pump
failure.
● Never pour water with a temperature higher than
40°C(104°F) into the spa directly.
● To avoid control system failure, do not operate the spa until
water reaches the Minimum line.
7.3 Check the connecting tubes and make sure there is no water
seeping. Assemble the “U” shape cover.
7.4 Install the filter cartridge. Please refer to the instruction on P17.
7.5 Insert the inflatable bladder into the buckled cover. (Keep valve
and printing towards outside)
7.6 Inflate the bladder with the hand pump.
7.7 Place the cover over the spa tub and insert the buckle to the
base that attached on the spa tub.
7.3
Lock the Buckle
● Insert the buckle on the Spa tub into the Spa cover
buckle, until you hear a “Click” sound.
Unlock the Buckle
● Pinch both sides of the locked buckle, and press
down the round dot in center in the same time. Press
down the center button and release the lock.

14
Heater Button
- Adjust the bubble level by
pressing the button
(L1:300W, L2: 500W, L3:720W)
Bubble Button
Up Button
Filter Button
Timer Button
Down Button
Celsius/Fahrenheit
Toggle Button
Ozonator Button
Temperature display: press RESET on PRCD, read the current temperature on the screen.
Heater Button: Press HEATER button to start or stop heating.
The filter will automatically be running for 15 seconds to test the working condition once the HEATER
function is started. If there is no abnormality, the heater will keep working until water temperature
reaches the set value. When water temp goes below the set temp, the heater will restart to heat the
water automatically. The constant lighting HEATER icon means the heating system is on working
status. The flash lighting HEATER icon means the heating system is initiating or on insulation mode.
Filter Button: Press FILTER button to turn the function on/off. The FILTER icon should be
constantly lighting when the function is activated.
NOTE: Filtration cannot be turned off when heating function is on (Whether the heater is running or at
rest). When Heating function is turned off, filtration will be stopped after 30 seconds. Filtration
function can then be activated separately.
NOTE: The auto-filtration system is automatically activated every 4 hours.
Bubble Button: Can adjust among 3 levels of bubbling power. The default bubbling massage
power is at level 2 (500W). Press the BUBBLE button again, switching to level 3 (720W). Press again
to enable level 1 (300W). To shut down the function, press the BUBBLE button for 3 seconds.
NOTE: The bubbling massage function will be shut down automatically after every 20 minutes
operation for safety concern. It cannot be operated within 10 minutes after shutting down.
FILTER
HEATER
BUBBLE
ALL-IN-ONE CONTROL PANEL

15
Adjustment Buttons: Press UP or DOWN button, the screen flashes setting temperature. Re-set
the temperature within 3 seconds. Otherwise the temperature setting mode will end automatically. If
the other button is pressed during the setting , the setting will also stop. The current temperature
shown on the screen is confirmed.
NOTE: Default setting temperature is 38°C; Temperature setting range: 20 - 40°C.
Controller Locking: Press UP and DOWN button at the same time for 3 seconds, the buzzer will ring
3 times, meaning that the controller is locked. In this mode, the function will not be turned on if the
button is pressed. Press UP and DOWN button at the same time again for 3 seconds to unlock the
controller.
Timer Button: Press the TIMER button to enter the intelligent pre-setting mode. By pressing UP
and DOWN button, you can set and start heating automatically with in up to 99 hours. The TIMER
setting is confirmed if no further operation in more than 3 seconds or press TIMER button again. The
heater will start working after current setting hours. The setting hour can also be changed by entering
the pre-setting mode again. The TIMER icon should be constantly lighting when activated.
Cancel: Press the TIMER button for 3 seconds to cancel the pre-setting.
NOTE: The pre-setting function cannot be turned on during heating process. The pre-setting mode
will also end once the heating function is on or after the spa is reboot.
Celsius/Fahrenheit Toggle Button: The temperature can be displayed in either Celsius or
Fahrenheit.
Ozonator Button: Activate the Ozone. The Ozone icon should be constantly lighting when
activated. For bathers' safety concern, the ozonator cannot be operated at the same time when the
Bubbling or Jet function is on. The Ozonator will be off automatically after operating for 2 hours. The
ozone output is 30-50mg/Hr.The filter will be activated automatically when ozonator is running. It
cannot be shut down during this period.
NOTE: Please do not soak in the spa when the Ozone is on. The Ozonator will not work when the
spa has no water or when the Bubble Button is on. The filtration cannot be turned off when Ozonator
is in use.
TIMER
Filter Cartridge Cleaning Reminder: When the FILTER icon keeps flashing, it
means that the filter cartridge needs to be cleaned or replaced. After that,
press Filter button for 3 seconds to clear the reminder.
Cumulative use up to 150hrs, or cleaning
reminder is activated
Check water quality in time and adjust to
recommended range
Not in used for 2~3 days or longer Use an overall cover for protection
Use water treatment products to adjust
FREQUENCY ACTION
Filter
Cartridge
SPA
Clean the filter cartridge or replace it with a
new one.The filter cartridge may need to be
replaced within 150hrs for initial use.

16
WATER MAINTENANCE AND CHEMICALS
Water Sanitation
The spa owner must regularly check and keep the spa water sanitized with scheduled maintenance (daily, if
necessary). Adding sanitizer or other chemical will control bacteria and viruses present in the spa water. The
maintenance of a proper water balance through appropriate use of sanitizers is the most important factor in
maximizing the life and appearance of the spa as well as ensuring clean, healthy and safe water.
Proper technique is important for water testing and treating the spa water. See your spa professional for
chemical, sanitizer, test kit and testing procedures questions.
IMPORTANT: The following conditions will lead to slow water heating
● The ambient temperature is lower than 10°C(50°F)
● Outdoor wind speed is above 3.5-5.4m/s(8-12mph)
● The air bubble function is activated when heater is on
● The spa is not properly covered with the spa cover when the heater is on
Water Treatment:
● Always follow the chemical manufacturer’s direction, and the health and hazard warning.
● Never mix chemicals together. Add the chemicals to the spa water separately. Thoroughly dissolve each
chemical before adding one to the water.
● Please note that chlorine and bromine products should never be mixed. This is extremely dangerous. If you
usually use chlorine-based products and you want to switch to bromine-based products, or vice versa, it is
mandatory to completely change the spa water before any product changes.
● Do not add chemicals if the spa is occupied. This can cause skin or eye irritation.
● Do not over use the chemicals, or use concentrated Chlorine. This can damage the spa tub and cause
potential hazard to your skin. Improper chemical use will void the warranty.
NOTE:
● Low pH will damage the spa tub and pump. Damage resulting from the chemical imbalance will void the
warranty.
● High pH (hard water) will result in white coagulations inside the filter pump; which may lead to pump
damage.
Water Balance
Follow below instructions to maintain the spa water.
pH
Free Chlorine
Bromine residual
Total Alkalinity (TA)
Total Hardness (TH)
Daily
Daily
Daily
Weekly
Weekly
3-5 ppm
2-4 ppm
80-120 ppm
200-500 ppm
CORRECT LEVEL
7.2-7.6 when using Chlorine;
7.2-7.8 when using Bromine
PARAMETER TEST FREQUENCY

17
Maintenance of Spa Water and Cartridge
Protect all the spa occupants from possible water related illness by keeping the spa water clean and sanitized.
Always practice good hygiene. Ensure proper spa water quality by following these procedures:
2. Change the spa water every 3-5 days depends on the spa use. See “Cleaning, draining and storage”
section for instruction.
3. Use spa chemicals to maintain proper water conditions. Spa damage resulting from misuse of chemicals
and mismanagement of spa water is not covered by the warranty. Consult with your local spa or pool
retailer for more information on chemical use.
4. All occupants must shower before entering the spa.
Do not use skin care or sunscreen products while
using the spa.
5. When spa inlet or outlet is stuck with dirt, use the
wrench to unscrew it and clean the inlet or outlet.
5
1.1
1.2
1.1 Install clean filter cartridge to water inlet.
● First install the cartridge base to the inlet by rotating it clockwise.
Then install the filter cartridge to the base. Push and fix it. It should always stay in place when the spa
is filled with water.
1.2 Inspect and clean the filter cartridge after each use. Change the filter cartridge after it works continuously
for 150 hours, or after seeing cleaning reminder.
● Pull out the filter cartridge from the base.
● Use a garden hose to rinse off the cartridge.
● Reinstall the clean or spare cartridge back onto the spa tub wall.
Note: Do not throw away the cartridge base when replacing the filter cartridge. Only
change the base when it gets loose after long term using.

18
Spa Tub Cleaning
If dirt is visible in the water or water becomes cloudy and proper water chemistry does not clear it up, change
the water and clean the spa tub.
While spa water is empty, remove the cartridge from the inside of the spa tub wall, clean and /or replace the
filter cartridge. Use a sponge and mild soap solution to wipe away any soil or stains on the inside of the spa
wall. Rinse thoroughly before refilling with clean water.
IMPROTANT: Do not use steel wool, hard brushes or abrasive cleaners.
Spa Tub and Air Bladder Repair
Use the enclosed repair patch to repair any puncture:
1. Clean and dry the area to be repaired thoroughly
2. Apply the glue to the PVC patch and quickly attach it onto the damaged surface. (Glue is not included)
DRAINAGE, CLEANING AND STORAGE
garden hose
Spa Drainage
1. Turn off all the buttons (heater, filter and bubble).
2. Connect the drain valve adapter to a garden hose and point the other end of the garden hose to a
suitable draining area with local environmental regulations (Fig.1)
3. Remove the drain valve cap from the outside of the spa tub and attach the drain valve adapter with the
garden hose to the drain valve (Fig.2)
4. From the inside of the spa tub, open the drain valve cap, water will start to flow out through the garden
hose (Fig.3)
5. When the water stops draining, lift the spa tub wall from the opposite to the drain, leading any remaining
water to the drain and empty the spa water completely. (Fig.4)
6. Press Bubble button to dry out any water in the piping system. Operate the bubbling function for
15 minutes to blow out all the remaining water. (Fig.5)
7. When the water stops draining, use a clean towel to wipe up any remaining water and moisture on the spa
tub and spa control panel. (Fig.6)
BUBBLE
123
4 5 6
15
minutes

1 32
pin holepin hole
19
3. Smooth the surface to remove any air bubbles and allow it dry for 5-10 minutes
NOTE: Glue is not included.
How to fix a leaking valve
open
close
open
close
1. Inflate your spa up to the max air pressure
2. Stick your valve wrench down inside of valve and turn clockwise
to tighten the valve back down onto the spa
1. Completely deflate your spa
2. Undo the dust cap and insert the valve wrench into the valve and twist counterclockwise to
remove the valve
A. Try to tighten the valve
B. Re-install or replace a valve
3. Check the rubber ring to make sure that it is in the correct position, tight around the valve and there
is no debris in the way
4. Be sure the pin spring is functioning properly and that there are no cracks along the edges
Rubber Ring

20
DISPOSAL AND ENVIRONMENTAL PROTECTION
This marking indicates this product should not be disposed with other household
wastes. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of
material resources. You can obtain information on disposal from your local authorities.
To return your used device, please use the return and collection systems or contact
the retailer where the product was purchased. They can take this product for
environmental safe recycling.
Storage and Prepare for the Next Time Use
1. Drain and clean the spa by following the
“Drainage” and “Spa Cleaning” sections
2. Reserve the set up instructions to deflate and
disassemble the spa tub, spa control unit and air
bladder
3. Make sure all the spa components and
accessories are thoroughly clean and dry before
storage. Air-dry the spa tub in the mild sun for
an hour before folding
4. Fold the spa tub loosely and avoid any sharp
corners to prevent damage or leakage to the spa
liner
SUN
®
5. Prepare new additional cartridge for next time use
6. Store the spa and accessories in a dry, temperature controlled, between 0°C- 40°C(32°F- 104°F) storage
location
7. Original packaging is recommended to be used for storage
NOTE: Correctly use the wrench by pressing it with one hand on top.
open
close
5. Ensure there are no strings from the drop stitching material
6. Note the bottom piece of the valve is not attached to anything
7. Fit the valve back into your spa
8. Align all the threads and twist to tighten
9. Once the valve is hand tight, use the valve wrench to seal completely
