M-system 20VS5-100 User manual

20VS5-100
P. 1 / 3EM-4420 Rev.1
ISOLATION AMPLIFIER
(bi-directional amplier) MODEL
20VS5-100
INSTRUCTION MANUAL
BEFORE USE ....
Thank you for choosing M-System. Before use, please check
contents of the package you received as outlined below.
If you have any problems or questions with the product,
please contact M-System’s Sales Office or representatives.
■PACKAGE INCLUDES:
Amplifier ....................................................................... (1)
■MODEL NO.
Confirm Model No. marking on the product to be exactly
what you ordered.
■INSTRUCTION MANUAL
This manual describes necessary points of caution when
you use this product, including installation, connection and
basic maintenance procedures.
POINTS OF CAUTION
■POWER INPUT RATING & OPERATIONAL RANGE
•PowerSupply
Operational voltage range: 11.5 – 16V DC
 Powerconsumption:approx.7mADC(noload)
Install the filter for the power supply as indicated below.
■ENVIRONMENT
•Indooruse
•Whenheavydustormetalparticlesarepresentintheair,
install the unit inside proper housing with sufficient ven-
tilation.
•Donotinstalltheunitwhereitissubjectedtocontinuous
vibration.Donotsubjecttheunittophysicalimpact.
•Environmentaltemperaturemustbewithin-10to+70°C
(14to158°F)withrelativehumiditywithin30to90%RH
in order to ensure adequate life span and operation.
■WIRING
•Do not install cables (power supply, input and output)
close to noise sources (relay drive cable, high frequency
line, etc.).
•Do not bind these cables together with those in which
noises are present. Do not install them in the same duct.
■INSTALLING THE MODULE
Whenitisinstalledontheprintedwiringboard,landdiam-
eterø1.5andthrough-holeø0.9arerecommended.
■AND ....
•Theunitisdesignedtofunctionassoonaspowerissup-
plied,however,awarmupfor10minutesisrequiredfor
satisfying complete performance described in the data
sheet.
•With voltage output, do not leave the output terminals
shortcircuited for a long time. The unit is designed to en-
dure it without breakdown, however, it may shorten ap-
propriate life duration.
CHECKING
1) Terminal wiring: Check that wiring is correctly connect-
ed according to the connection diagram.
2) Powerinputvoltage:Checkvoltageacrossthepins.
3) Input:Checkthattheinputsignaliswithin0–100%of
the full-scale.
4) Output: Check that the load resistance meets the de-
scribed specifications.
10µF
+
–
COM
POWER
560µH
14
15
+15V
10µF
+
–

20VS5-100
P. 2 / 3EM-4420 Rev.1
TERMINAL CONNECTIONS
■EXTERNAL DIMENSIONS mm (inch)
■TERMINAL ASSIGNMENTS
PIN ASSIGNMENT
6
5
4
3
2
1
REFERENCE VOLTAGE SOURCE (–)
REFERENCE VOLTAGE SOURCE (+)
(–)
NC
17
16
15
14
OUTPUT (INPUT) (+)
OUTPUT (INPUT) (–)
POWER SUPPLY (–)
POWER SUPPLY (+)
NC
INPUT (OUTPUT) (+)
MAX 53 (2.09)
161417
MAX 18 (.71)
MAX 24 (.94)6.7
(.26)
12.7 (.5) 20.32 (.8) 7.62
(.3)
0.5 (.02)
2.54 (.1) 0.25
(.01) 5.65
(.22)
20.32 (.8)
INPUT (OUTPUT)
+
–
+
–
OUTPUT (INPUT)
1
6
14
15
5
4
17
16
+
–
POWER
*To be used in the printed wiring board on which the unit is mounted.
Note. The reference voltage source is common to the terminal 4 (–).
REFERENCE VOLTAGE SOURCE*
–
INPUT (OUTPUT)
+

20VS5-100
P. 3 / 3EM-4420 Rev.1
APPLICATION EXAMPLES
MAINTENANCE
Regularcalibrationprocedureisexplainedbelow:
■CALIBRATION
Warmuptheunitforatleast10minutes.Apply0%,25%,
50%, 75% and 100% input signal.  Check that the output
signal for the respective input signal remains within accu-
racy described in the data sheet.
M-SYSTEM WARRANTY
M-System warrants such new M-System product which it manufactures to be free from defects in materials and workmanship during the 36-month period following the date that such
product was originally purchased if such product has been used under normal operating conditions and properly maintained, M-System’s sole liability, and purchaser’s exclusive
remedies, under this warranty are, at M-System’s option, the repair, replacement or refund of the purchase price of any M-System product which is defective under the terms of this
warranty. To submit a claim under this warranty, the purchaser must return, at its expense, the defective M-System product to the below address together with a copy of its original
sales invoice.
THIS IS THE ONLY WARRANTY APPLICABLE TO M-SYSTEM PRODUCT AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. M-SYSTEM SHALL HAVE NO LIABILITY FOR CONSEQUENTIAL, INCIDENTAL OR
SPECIAL DAMAGES OF ANY KIND WHATSOEVER.
M-System Co., Ltd., 5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN, Phone: [phone], Fax: [phone], E-mail: [e-mail]
–
+
–
–
+
+
4
1
5
6
17
16
15
14
+15V
–15V
+
–
Non-inverting amplifier circuit: G = 0.95 (Isolation: Input to output or power)
INPUT ±5V DC
POWER 15V DC
OUTPUT approx. ±4.75V DC
–
+
–
–
+
+
16
17
14
15
1
4
6
5
+
–
Non-inverting amplifier circuit: G = 0.95 (Isolation: Output to input or power)
INPUT ±5V DC
POWER 15V DC
OUTPUT approx. ±4.75V DC
A1
–
+
REFERENCE VOLTAGE SOURCE
Note: The amplifier A1 requires a power source independent from the Reference Voltage Source.
The primary amplifier in this unit is high accurate.
