1. Unpacking and Placing the Unit
Lay the box on a table and open it by separating it from the external paperwork and
removing or cutting the adhesive tape seal. The following items are included:
• one MARLEY;
• one wall wart;
• this manual.
Should one or more item be missing, please contact your dealer.
Extract the MARLEY from the foam enclosure and place it onto a stable base, far from
heat sources. Avoid full sunlight on the unit. Allow for ample room around the unit for
venting.
The MARLEY is a high bias amplifier which dissipates 30W while operating, even when
idle, thus a lot of heat is produced. t is thus necessary to guarantee adequate air
flow.
Avoid smoke, moisture, dirt and water reaching the unit.
Do not place the unit on thick carpets nor inside a box or piece of furniture, not even
close to curtains.

mar ey
DUAL-DRIVE CLASS-A HEADPHONES AMPLIFIER
REVISION P R .A – OCTOBER 2013
Copyright © 2013, M2Tech Srl
10
M2Tech
www.m2tech.biz

mar ey
DUAL-DRIVE CLASS-A HEADPHONES AMPLIFIER
REVISION P R .A – OCTOBER 2013
Copyright © 2013, M2Tech Srl
11
M2Tech
www.m2tech.biz
2. Front Panel
Figure 1
1) On/off/mute/menu escape button. Push this button to turn the MARLEY on when
it’s off. When the MARLEY is on, a short push will toggle muting, unless the menu has
been previously accessed: in the latter, a short push will cause immediate menu
escape and configuration changes discard. A prolonged button push while the MARLEY
is on will cause its switch-off.
2) Display. Multi-function LCD display. During normal operation, it indicates the
listening level for the active outputs, the selected source and the mute status. When

mar ey
DUAL-DRIVE CLASS-A HEADPHONES AMPLIFIER
REVISION P R .A – OCTOBER 2013
Copyright © 2013, M2Tech Srl
12
M2Tech
www.m2tech.biz
the menu is accessed, the display shows the selected menu item and the current
value associated to it.
3) Encoder. Allows for accessing and navigating the menu, as well as volume
setting. t may be rotated and pushed. Please read chapter 6 for details on its use.

mar ey
DUAL-DRIVE CLASS-A HEADPHONES AMPLIFIER
REVISION P R .A – OCTOBER 2013
Copyright © 2013, M2Tech Srl
13
M2Tech
www.m2tech.biz
3. Back Panel
Figure 2
4) Inputs. Connect stereo music sources to these two inputs. Gold-flashed RCA
sockets. Black indicates left channel, red indicates right channel.
5) Tape output. Connect the input of a tape recorder to this output to record the
selected source. Gold-flashed RCA sockets. Black indicates left channel, red
indicates right channel.
6) Preamplifier output. f needed, connect a power amplifier to this output, to use
the MARLEY as a preamplifier. Gold-flashed RCA sockets. Black indicates left channel,
red indicates right channel.

mar ey
DUAL-DRIVE CLASS-A HEADPHONES AMPLIFIER
REVISION P R .A – OCTOBER 2013
Copyright © 2013, M2Tech Srl
14
M2Tech
www.m2tech.biz
7) Output for single-ended headphones. Connect the jack of a headphones set to
each of these two outputs. t is possible to use one output or both outputs at the
same time. These two connectors should be used as alternative to the balanced
headphones connector (item 8). 6,35mm (1/4”) stereo socket.
8) Output for balanced headphones. Connect the XLR connector of a headphones
set to this output. This connector should be used as alternative to the single-ended
headphones connectors (item 7). 4-pin female XLR socket.
9) Input for high-current, low-noise power supply. Connect the plug from the
dedicated high-current, low-noise power supply dedicated for the MARLEY. 4-pin, male
XLR socket.
10) Input for power from wall wart. Connect the jack from the 15V-2A wall wart
included in the package. 5.5/2.1mm jack with positive on tip.

mar ey
DUAL-DRIVE CLASS-A HEADPHONES AMPLIFIER
REVISION P R .A – OCTOBER 2013
Copyright © 2013, M2Tech Srl
15
M2Tech
www.m2tech.biz
4. Connecting and Powering the Unit
W RNING: all connections between the MARLEY
MARLEYMARLEY
MARLEY and other equipment must be
made when all units are off. Failing to do so may cause damage to the MARLEY
MARLEYMARLEY
MARLEY
and/or other units.
Please refer to chapter 3, “Back Panel”.
Connect one or two high-level stereo audio sources (CD/SACD/DVD player, DAC
USB, tuner, preamplifier) to the inputs (Figure 2, 4). Low-level sources, such as
magnetic pick-ups, cannot be connected to the inputs.
f needed, connect MARLEY’s “TAPE OUT” output to a recorder’s input (Figure 2, 5).
f MARLEY‘s operation as preamplifier is desired or required, connect the “PRE OUT”
output to the input of a power amplifier (Figure 2, 6).
Connect one or two headphones to headphones outputs, avoiding using single-
ended and balanced outputs at the same time (Figure 2, 7/8).
Connect the wall wart jack to the MARLEY ‘s power supply input (Figure 2, 10).
Connect the wall wart to a mains outlet. The wall wart is designed to automatically fit
ant mains voltage 90V
AC
to 265V
AC
.
Turn the MARLEY on by pushing the front panel button (Figure 1, 1).
NOTE: it is possible to use a dedicated high-current, low-noise power supply
in place of the included wall wart for increased sonic performance. In this case,

mar ey
DUAL-DRIVE CLASS-A HEADPHONES AMPLIFIER
REVISION P R .A – OCTOBER 2013
Copyright © 2013, M2Tech Srl
16
M2Tech
www.m2tech.biz
the power supply must be connected to the dedicated connector on MARLEY
MARLEYMARLEY
MARLEY‘s
back panel (Figure 2, 9).
W RNING: when the dedicated power supply is used, DO NOT connect the wall
wart also.

mar ey
DUAL-DRIVE CLASS-A HEADPHONES AMPLIFIER
REVISION P R .A – OCTOBER 2013
Copyright © 2013, M2Tech Srl
17
M2Tech
www.m2tech.biz
5. Cleaning the Unit
The MARLEY should be cleaned with a soft, damp cloth. Do not use alcohol nor other
cleaning fluids as they could damage the unit.
Avoid fluids from dropping or leaking through the venting grid holes.
Pay attention not to scratch the plexiglas front screen.

mar ey
DUAL-DRIVE CLASS-A HEADPHONES AMPLIFIER
REVISION P R .A – OCTOBER 2013
Copyright © 2013, M2Tech Srl
18
M2Tech
www.m2tech.biz
6. Using the Marley
At power up, the MARLEY observes a start-up heating wait lasting a few seconds,
during which the flashing writing in Figure 3 is displayed.
HEATING UP
POWER AMPLIFIERS
Figure 3
Once heating is completed, some general information about MARLEY operation appear
on the display, as shown in Figure 4 and Figure 5. The two pictures refer to the two
different output configurations (balanced and double single-ended). n Figure 4 the
word “MUTE” appears to indicate that muting is on.
MUTE VOL:-40DB
IN:1
Figure 4
>VOLA:-40DB
IN:1 VOLB:-40DB
Figure 5

mar ey
DUAL-DRIVE CLASS-A HEADPHONES AMPLIFIER
REVISION P R .A – OCTOBER 2013
Copyright © 2013, M2Tech Srl
19
M2Tech
www.m2tech.biz
6.1. Volume Setting
Volume setting is performed by encoder knob rotation (Figure 1,3). Depending on the
output configuration, it is possible to set one or two volumes.
When the MARLEY is configured in balanced, The two stereo amplifiers which fit it are
bridged and make for a single balanced amplifier. This is why only one balanced
output is present and only one volume can be set (Figure 4).
When the MARLEY is configured in dual single-ended, each amplifier drives one jack
output. Each amplifier has its dedicated volume control, it is thus possible to set the
listening level of each amplifier independently. Two volumes are thus shown: “VOLA”,
related to output “A,” and “VOLB”, related to output “B”. The “>” sign indicates which
volume can be set. As shown in Figure 5, output “A” volume can be set by rotating
the encoder knob.
To set volume for output “B” it is necessary to push the encoder once, so that the “>”
moves to the front of “VOLB” (Figure 6).
VOLA:-40DB
IN:1 >VOLB:-40DB
Figure 6
NOTE: after setting output “B” volume, the button to the left of the front panel
may be pushed to restore equipment’s “idle” status as in Figure 4. s an
alternative, after a few seconds past the encoder rotation the unit automatically
reverts to “idle” status.

mar ey
DUAL-DRIVE CLASS-A HEADPHONES AMPLIFIER
REVISION P R .A – OCTOBER 2013
Copyright © 2013, M2Tech Srl
20
M2Tech
www.m2tech.biz
6.2. Muting Toggle
The MARLEY is provided with a feature (muting) which allow for lowering the volume
20dB without touching the encoder knob. This feature is useful when user needs to
listen to another person for a moment, or while changing music program in the
source, etc.
Muting is toggled by pushing the button to the left of the front panel (Figure 1, 1).
When muting is engaged, the word “MUTE” appears on the display (Figure 4).
n dual single-ended mode, muting affects both outputs.
W RNING: carefully operate on volumes when muting is engaged: if volume is
raised too much and muting is disengaged, the resulting listening level could
be so high that damages to the headphones set or to listener ears may happen.
6.3. Source Selection
The MARLEY is provided with two inputs, it is thus possible to connect two sources to it
and select one for listening. To do this, it is necessary to push the encoder once in
balanced mode or twice in dual single-ended mode: the input selection feature is
then accessed as shown in Figure 7.
INPUT SELECT
INPUT:1
Figure 7
