M2TECH TOSH User manual

M2TECH
TOSH
BALANCED LINE PREAMPLIFIER
USER MANUAL
REV. PrA – 6/2023

M2Tech
www.m2tech.biz
TOSH
BALANCED LINE PREAMPLIFIER
REVISION PRA – JUNE 2023
Copyright © 2023, M2Tech Srl
2

M2Tech
www.m2tech.biz
TOSH
BALANCED LINE PREAMPLIFIER
REVISION PRA – JUNE 2023
Warning!
Modifications or alterations not authorized by the manufacturer can invalidate
compliance with CE regulations and make the appliance no longer suitable for use.
The manufacturer declines all responsibility for damage caused to people or things
due to improper use or malfunctioning of an appliance subject to unauthorized
modifications.
This appliance complies with CE standards: CEI EN 022:2009 Class B (Irradiated Emissions), CEI EN
024:1999, CEI EN 024:A2/2003, CEI EN 024:IS1/2008 (Radio Frequency Electromagnetic Fields,
Immunity Test to the 0Hz Magnetic Field and Electrostatic Discharges – ESD).
For correct operation of this appliance, all connections to other appliances in the system must be
made with all appliances switched off. Failure to comply with this rule may cause damage to the
TOSH.
The label above, visible on the shell of the appliance, indicates that the product, at the end of its use, cannot
be improperly managed as generic waste, but must be treated as an electrical and electronic appliance by an
adequate disposal system in accordance with the regulations by the WEEE directive (or WEEE directive,
Waste of Electrical and Electronic Equipment).
Once this product is recycled properly, you will avoid potential damage to the environment and human
health, which could be caused by being disposed of as unsorted municipal waste. Proper reuse of materials
also reduces waste of resources. For more detailed information on the disposal of this product, please
contact M2Tech Srl.
WARN NG: The information contained in this manual is believed to be reliable and accurate. M2Tech
reserves the right to change or modify this information at any time, without notice. Customers are
invited to make sure they are consulting the most recent version of this manual.
Copyright © 2023, M2Tech Srl
3

M2Tech
www.m2tech.biz
TOSH
BALANCED LINE PREAMPLIFIER
REVISION PRA – JUNE 2023
Dear Customer,
Thank you for purchasing TOSH. You are in possession of a very high quality line
preamplifier with many unique features, designed to obtain the maximum performance
together with any other M2Tech product.
TOSH implements a unique package of functional and technological solutions, from the
totally discrete component design, to the balanced amplifier structure, to the rich set of
inputs, to the Bluetooth® module for control and configuration, to the trigger output.
TOSH is designed for low noise and high dynamic operation, to ensure that all the sound
quality of the music provided by the sources is delivered to the power amplifiers without
any loss.
The remarkable drive capabilities make the TOSH perfect for driving even active
loudspeakers in the best possible way, even with connection cables of considerable
length.
We are sure that your expectations will be fulfilled by purchasing TOSH: you will hear your
favorite music like never before, get ready for a new listening experience!
Marco Manunta, CEO
Please note the serial number of your TOSH for future reference:
S/N: _______________________ Date of Purchase: _________________________
Place of purchase: __________________________
Copyright © 2023, M2Tech Srl
4

M2Tech
www.m2tech.biz
TOSH
BALANCED LINE PREAMPLIFIER
REVISION PRA – JUNE 2023
ND CE
1. Opening the Packing and Positioning the Device.............................................................7
2. Front Panel.......................................................................................................................9
3. Back Panel.....................................................................................................................11
4. Remote Control..............................................................................................................13
. Connections and Power Delivery to the Appliance.........................................................1
6. Cleaning the Appliance..................................................................................................1
7. Using the TOSH................................................................................................................17
7.1. Source selection......................................................................................................17
7.2. Menu navigation......................................................................................................17
7.2.1. BALANCE: channels balance setting................................................................18
7.2.2. DISPLAY BACKLIGHT: display dimming..........................................................18
7.2.3. VOLUME STEPS: setting the granularity of the volume control........................19
7.2.4. VOLUME MODE: setting the listening level indication......................................20
7.2. . FADE CONTROL: setting of the gradual transition from one input to another. .20
7.2.6. POWER ON VOLUME: setting the listening level at power on/activation.........20
7.2.7. AUTO OFF: automatic shutdown setting...........................................................20
7.2.8. STANDBY LED: setting the behaviour of the front panel LED..........................21
7.2.9. POWER MODE: setting the behaviour of the TOSH when power is applied.......21
7.2.10. REMOTE POWER: istruct the TOSH to accept/ignore the IR remote ON/OFF
command....................................................................................................................22
7.2.11. BLE CONTROL: enabling/disabling the Bluetooth® LE receiver.....................22
7.2.12. SET STARTUP ITEM: decide which menu item to see first at each access...22
7.2.13. FIRMWARE REVISION: display the firmware revision number......................23
7.2.14. DEFAULT: restore the factory settings............................................................23
7.2.1 . EXIT: menu exit...............................................................................................23
8. Trigger Output................................................................................................................2
9. Tosh Gain and Output Level Considerations..................................................................31
10. Specifications...............................................................................................................33
Copyright © 2023, M2Tech Srl

M2Tech
www.m2tech.biz
TOSH
BALANCED LINE PREAMPLIFIER
REVISION PRA – JUNE 2023
Copyright © 2023, M2Tech Srl
6

M2Tech
www.m2tech.biz
TOSH
BALANCED LINE PREAMPLIFIER
REVISION PRA – JUNE 2023
1. Opening the Packing and Positioning the Device
Place the box on a table and open it with a cutter or knife, being careful not to damage the
inner box. Take out the inner box and open it. The following items are contained in a
cardboard tray:
one TOSH;
one remote control;
two AAA type batteries;
one 1 V wall adaptor;
two 7-pole male XLR to 3 x female 3-pole XLR adaptors.
If one or more items are missing, contact your dealer.
Remove the TOSH from the cardboard tray and place it on a stable base away from heat
sources. Avoid direct sunlight. Leave ample space around it to the device to ensure
adequate ventilation and for easy connection between the TOSH Bluetooth® module and
your smartphone/tablet.
The TOSH is a highly efficient device; for this reason it does not produce much heat during
its operation. Nevertheless, it is recommended to allow adequate ventilation around the
unit. Furthermore, in all situations in which the remote control is used, it is recommended
to position it so that the infrared signals from the remote control can easily reach its front
panel.
Prevent smoke, humidity, dirt and water from reaching the appliance. Note that any sign of
abuse will void the warranty.
Do not place the appliance on thick carpets or inside a box or inside a mobile, or in close
contact with curtains.
Copyright © 2023, M2Tech Srl
7

M2Tech
www.m2tech.biz
TOSH
BALANCED LINE PREAMPLIFIER
REVISION PRA – JUNE 2023
Copyright © 2023, M2Tech Srl
8

M2Tech
www.m2tech.biz
TOSH
BALANCED LINE PREAMPLIFIER
REVISION PRA – JUNE 2023
2. Front Panel
6
42 31
Figure 1
1) Bluetooth® receiver. The area behind this area of the front panel houses the
Bluetooth® receiver which allows you to control the TOSH from any smartphone. Keep this
area clear of metal objects.
2) Display. OLED multifunction display. During normal operation, it indicates the selected
source and listening level. When entering the menu, the display shows the selected menu
item and the current value.
3) Encoder. It allows user to access and navigate the menu, select inputs and adjust the
volume. It can be rotated and pressed. Refer to Chapter 7 for more details.
4) Standby LED. When the TOSH is in standby, this LED is lit to indicate to the user that
the device can be turned on using the supplied remote control. It is possible to change the
operation of the LED when the TOSH is in standby from the menu.
5) Activation/standby/mute/menu exit button. Press this button to activate the TOSH
when in standby. When the TOSH is active, a short press activates/deactivates the mute,
unless the menu is active: in this case, a short press will cause the exit of the menu and
the cancellation of any modification to the configuration. A longer press while the TOSH is
active will put it in standby.
6) R Receiver. Aim the remote at this point to send commands to the TOSH.
Copyright © 2023, M2Tech Srl
9

M2Tech
www.m2tech.biz
TOSH
BALANCED LINE PREAMPLIFIER
REVISION PRA – JUNE 2023
Copyright © 2023, M2Tech Srl
10
