M2TECH EVO PHONODAC TWO Operating instructions

HOW TO USE THE EVO PHONODAC TWO
1. Phono preamplifier. Connect a turntable to the Evo PhonoDAC Two analog input. Connect the
Evo PhonoDAC analog output to any line-level input of your hifi system’s amplifier to listen to
records. Set the hiFace PhonoDAC Two input gain and impedance to suit your turntable’s cartridge
requirements. A computer may be connected to the Evo PhonoDAC Two USB port to rip vinyl during
playback.
2. Analog front-end for ripping to a computer. Connect any analog source to the Evo PhonoDAC
Two analog input to digitize its signal and send it to a computer for ripping. Real-time monitoring
can be achieved by connecting the Evo PhonoDAC Two analog output to an amplifier.
3. Digital-to-analog converter. Connect a computer to the Evo PhonoDAC Two USB port and
another digital source to the Evo PhonoDAC Two coax input. Connect the analog output of the Evo
PhonoDAC Two to any line-level input of your hifi system’s amplifier to listen to music from files and
digital discs.
M2TECH
EVO PHONODAC Two
DXD-DSD A/D-D/A CONVERTER
PHONO PREAMP
CLIP
M2TECH
EVO PHONODAC Two
DXD-DSD A/D-D/A CONVERTER
PHONO PREAMP
CLIP
M2TECH
EVO PHONODAC Two
DXD-DSD A/D-D/A CONVERTER
PHONO PREAMP
CLIP

5. Increase performance. Add the Evo Clock Two: your files will sound clearer and more focussed,
with richer details. Vinyl playback and rip will be more accurate. A proprietary connection between
Evo PhonoDAC Two and Evo Clock Two allows for automatic clock management. Please note that
the S/PDIF input is not available when the Evo Clock Two is used.
M2TECH
EVO CLOCK TWO
PRECISION CLOCK GENERATOR
DOWN UP
FREQUENCY SELECT
6. Maximize performance. Add the Evo Supply Two to power both Evo PhonoDAC Two and Evo
Clock Two with stable, clean energy. Your music files will sound like never before. Of course, the
Evo PhonoDAC Two will take advantage of the Evo Supply Two even when the Evo Clock Two is
not used.
M2TECH
EVO CLOCK TWO
PRECISION CLOCK GENERATOR
DOWN UP
FREQUENCY SELECT
EVO SUPPLY TWO
LOW NOISE POWER SUPPLY
OUTPUTS
POWER ON
M2TECH
4. Analog front-end for DSP (Digital Signal Processing) Connect any analog source to the Evo
PhonoDAC Two analog input to digitize its signal and send it to a computer for digital signal
processing. Connect the Evo PhonoDAC Two analog output to an amplifier.
You can also connect the Evo PhonoDAC Two between a preamplifier and a power amplifier or in
the processor loop or tape loop of an integrated amplifier.
DSP include: equalizing, DRC (Digital Room Correction), filtering, speaker response compensation.
M2TECH
EVO PHONODAC Two
DXD-DSD A/D-D/A CONVERTER
PHONO PREAMP
CLIP
M2TECH
EVO PHONODAC Two
DXD-DSD A/D-D/A CONVERTER
PHONO PREAMP
CLIP
M2TECH
EVO PHONODAC Two
DXD-DSD A/D-D/A CONVERTER
PHONO PREAMP
CLIP
