MAAX xstream User manual

Owner’s Manual
Swim Spas

11
Swim Spa
ALERT
Your new Swim Spa GFCI will trip.
A Ground Fault Interrupter (GFCI) Trip Test must occur to al-
low proper spa function.
Your Swim Spa came with special instructions for the install-
er / electrician. If they have not already advised you on what
to do or expect form the GFCI Trip Test, please contact them
for instructions.
If the GFCI breaker connected to your spa trips, this is normal
behavior. Please reset the breaker and enjoy your spa. The
trip test has been completed successfully.
If your Swim Spa was not wired to a GFCI breaker or your
breaker fails the GFCI Trip Test, the spa will repeatedly at-
tempt (at preset intervals) to trip the breaker in the future
until such time that it triggers a GFCI Trip.
GFCI breakers are important safety devices required by code
for your Swim Spa. For more information, refer to your deal-
er or to the section in your Owner’s Manual titled “Ground
Fault Circuit Interrupter.”

22
Swim Spa
SAVE THESE INSTRUCTIONS.
NOTE: When installing and using this
equipment, basic safety precautions should
always be taken to reduce the risk of
electrical shock, to ensure safe usage, and
to safeguard the user’s health. Failure to
follow instructions and warnings contained
in this Owner’s Manual, in the Swim Spa
Installation Guide, and on the Swim Spa
itself may result in severe personal injury,
including death, as well as property
damage.
WARNING:
Children should not use Swim Spa or hot tubs
without adult supervision.
WARNING:
Do not use Swim Spa or hot tubs unless all
suction guards are installed to prevent body
and hair entrapment.
WARNING:
People using medications and/or having an
adverse medical history should consult a
physician before using a Swim Spa or hot tub.
WARNING:
People with infectious diseases should not
use a Swim Spa or hot tub.
WARNING:
To avoid injury exercise care when entering
or exiting the Swim Spa or hot tub.
WARNING:
Water temperature in excess of 38° C may
be injurious to your health.
WARNING:
Do not use drugs or alcohol before or during
the use of a Swim Spa or hot tub to avoid
unconsciousness and possible drowning.
WARNING:
Pregnant, or possibly pregnant, women should
consult a physician before using a Swim Spa or
hot tub.
WARNING:
Before entering the Swim Spa or hot tub
measure the water temperature with an
accurate thermometer.
WARNING:
Do not use a Swim Spa or hot tub immediately
following strenuous exercise.
WARNING:
Prolonged immersion in a Swim Spa or hot tub
may be injurious to your health.
WARNING:
Do not permit electric appliances (such as a
light, telephone, radio, or television) within
1.5m of the Swim Spa or hot tub.
WARNING:
Maintain water chemistry in accordance with
manufacturer’s instruction.
WARNING:
The use of alcohol or drugs can greatly
increase the risk of fatal hyperthermia in hot
tubs and Swim Spa.
IMPORTANT SAFETY WARNINGS

33
Swim Spa
GFCI Alert 1
Important Safety Warnings 2
Table of Contents 3
Important Safety Instructions 5
Do’s and Don’ts 6
Hyperthermia 7
Swim Spa installation 8
Site and Positioning 8
Outdoor Installation 9
Indoor Installation 9
Swim Spa System Components 10
Swim Spa Components 11
Jets and Air Controls 12
Jets 12
Cleaning or Replacing Jets 12
Air Controls 13
Electrical Information 14
Important Safety Instructions 14
Installation Options 14
Start Up Procedures 16
Priming Your Swim Spa 16
Swim Spa Control System (Swim Zone) 17
Operating Instructions 17
User’s Pads 18
Temperature Controls 18
Temperature Lock 19
Temperature Unlock 19
Panel Lock 19
Panel Unlock 19
Operating Modes 19
Time and Filtration Cycles 20
Setting the Time 20
Preset Filter Cycles 20
Changing Filter Cycles 20
Clean-Up Cycle 21
Inversion Feature 21
Light 21
Swim Spa Control System (Spa Side) 22
Operating Instructions 22
User’s Pads 23
Temperature Controls 23
Temperature Lock 24
Temperature Unlock 24
Panel Lock 24
Panel Unlock 24
Operating Modes 24
Time and Filtration Cycles 25
Preset Filter Cycles 25
Changing Filter Cycles 25
Light 25
Swim Spa Options & Features 26
Ozone Operation (Optional) 26
UV Sanitizer (Optional) 26
Digital Optic Lighting 26
Entertainment System (Optional) 27
Safety Features 28
Automatic Time Outs 28
Common LCD Equipment Messages 28
Common LCD Messages 29
Maintenance 30
Water Chemistry 30
Sanitizing 30
TABLE OF CONTENTS

44
Swim Spa
pH Level 30
Water Maintenance 30
Sanitizing With Ozone 31
Specialty Chemicals 31
Draining Your Swim Spa 31
Filter Maintenance 32
Winterizing 32
Swim Spa Cabinet Care 33
Swim Spa Surface Care and Cleaning 33
Underwater LED light cluster 33
Common Water Problems 34
Common Hardware Problems 37
Swim Spa Soaking Guidelines 39
460 Series System Wiring Diagram 41
167 Series System Wiring Diagram 42

55
Swim Spa
IMPORTANT SAFETY INSTRUCTIONS
1. READ AND FOLLOW ALL
INSTRUCTIONS
2. WARNING - To reduce the risk of injury,
do not permit children to use this prod-
uct unless they are closely supervised at
all times.
3. A wire connector is provided on this unit
to connect a minimum 6 AWG (5.15 mm2)
solid copper conductor between this unit
and any metal equipment, metal enclosu-
res of electrical equipment, metal water
pipe, or conduit within 5 feet (1.5m) of
the unit.
4. (For cord-connected/convertible units)
DANGER - Risk of injury.
a. Replace damaged cord immedi-
ately.
b. Do not bury cord.
c. Connect to a grounded, ground-
ing type receptacle only.
5. DANGER - Risk of Accidental Drown-
ing. Extreme caution must be exercised
to prevent unauthorized access by
children. To avoid accidents, ensure that
children cannot use this spa unless they
are supervised at all times.
6. DANGER - Risk of injury. The suction
ttings in this spa are sized to match the
specic water ow created by the pump.
Should the need arise to replace the
suction ttings or the pump, be sure that
the ow rates are compatible.
Never operate spa if the suction ttings
are broken or missing. Never replace a
suction tting with one rated less than
the ow rate marked on the original suc-
tion tting.
7. DANGER - Risk of Electric Shock. Install at
least 5 feet (1.5m) from all metal surfaces.
As an alternative, a spa may be installed
within 5 feet of metal surfaces if each
metal surface is permanently connected
by a minimum 6 AWG (5.15 mm2) solid
copper conductor to the wire connector
on the terminal box that is provided for
this purpose.
8. DANGER - Risk of Electric Shock. Do not
permit any electric appliance, such as a
light, telephone, radio, or television,
within 5 feet (1.5m) of a spa.
9. WARNING - To reduce the risk of injury:
a. The water in a spa should never
exceed 40°C (104°F).Water tem-
peratures between 38°C (100°F)
and 104°F (40°C) are considered safe for a
healthy adult. Lower water temperatures
are recommended for young children and
when spa use exceeds 10 minutes.
b. Since excessive water temperatures
have a high potential for causing fetal
damage during the early months of preg-
nancy, pregnant or possibly pregnant
women should limit spa water tempera-
tures to 38°C (100°F).
c. Before entering a spa the user should
measure the water temperature since the
tolerance of water temperature-regulat-
ing devices varies.
d. The use of alcohol, drugs, or medica-

66
Swim Spa
tion before or during spa use may lead
to unconsciousness with the possibility of
drowning.
e. Obese persons and persons with a
history of heart disease, low or high
blood pressure, circulatory system prob-
lems, or diabetes should consult a physi-
cian before using a spa.
10. SAVE THESE
INSTRUCTIONS
NOTE: Check with your state/local code
enforcement ocer to determine electrical
code requirements and compliance. Use a
qualied licensed electrician to complete all
spa nal electric connections.
TO AVOID RISK OF ELECTRICAL SHOCK:
1. A green colored terminal or a terminal
marked G, GR, Ground, Grounding, or the
international symbol is located on
the side of the supply terminal box or
compartment. This terminal must be
connected to the grounding means
provided in the electric supply service
panel, using a continuous copper wire
equivalent in size to the circuit conduc-
tors supplying this equipment.
*IEC Publication 417, Symbol 5019.
2. At least two lugs marked “BONDING
LUGS” are provided on the external sur-
face or on the inside of the supply termi-
nal box or compartment. Connect the
local common bonding grid (house-hold
ground) in the area of the hot tub or spa
to these terminals, using an insulated or
bare copper conductor not smaller than
No. 6 AWG.
3. All eld-installed metal components such
as rails, ladders, drains or similar hard
ware located within 5 ft. of the spa or
hot tub shall be bonded to the equip-
ment grounding bus with copper con-
ductors not smaller than No. 6 AWG.
4. Never connect unit to a power supply
with a load controller.
5. Install to provide drainage of compart-
ment for electrical components.
6. The electrical supply for this product
must include a suitably rated switch
or circuit breaker to open all ungrounded
supply conductors. This disconnecting
means must be readily accessible for
operation but installed at least 1.5m
from the spa. All electrical connections
should comply with local regulations.
Do’s and Don’ts
For years of spa enjoyment:
Do:
• Save these instructions!
• Replace the cover immediately after use.
•
Keep the cover locked when spa is not
in use.
• Be aware of the dangers of a wet and
slippery surface. Use caution when
entering and exiting your spa.
• Have a licensed electrician make all nal
electrical connections.
•
Replace worn, frayed or broken electrical cords.
• Keep the water chemistry correctly
balanced. Untreated spa water will cause
Caution: Risk of electrical shock.
Read and follow all instructions.

77
Swim Spa
problems with your spa and equipment
as well as being a health risk.
• Clean the spa lter monthly or as needed.
• Position the spa so that all sides remain
accessible for maintenance.
• Use a bathing cap for long hair.
• Refer to information on hyperthermia,
next page.
• Use only authorized spa care products
for the best performance and to keep
the water properly balanced.
Don’t:
• Use the spa at 104°F (40°C) for long
periods of time (more than 30 minutes).
See Hyperthermia, below.
• Use an extension cord to power your spa.
• Allow anyone to stand on the spa cover.
It is not designed to support weight.
• Power the spa unless it is lled with water
to the water level mark on the Weir door.
• Operate the pump on high speed for ex-
tended periods of time with the cover in
place. Extended operation can cause heat
build-up and interfere with spa operation.
Hyperthermia
The causes, symptoms, and eects of
hyperthermia may be described as follows:
Hyperthermia occurs when the internal
temperature of the body reaches a level
several degrees above the normal body
temperature of 98.6°F (37°C). The symptoms
of hyperthermia include an increase in the
internal temperature of the body, dizziness,
lethargy, drowsiness, and fainting. The eects
of hyperthermia include:
a. Failure to perceive heat
b. Failure to recognize the need to exit spa
or hot tub
c. Unawareness of impending hazard
d. Fetal damage in pregnant women
e. Physical inability to exit the spa or hot
tub, and
f. Unconsciousness resulting in the danger
of drowning.
WARNING - The use of alcohol, drugs,
or medication can greatly increase the
risk of fatal hyperthermia.

88
Swim Spa
SWIM SPA INSTALLATION
Danger: Electrical shock risk. Install at
least 1.5m from all metal surfaces.
The electrical supply for this product must
include a suitably rated switch or circuit
breaker to open all ungrounded supply
conductors. The disconnecting means must
be readily accessible but installed at least 1,5
meters from the Swim Spa water. All electrical
connections should comply with local
regulations.
The appliance should be
supplied through a residual
current device (RCD) with a
rated tripping current not
exceeding 30 mA. Means
for disconnection must
be incorporated in the
xed wiring in accordance
with the wiring rules. Parts containing live
parts, except parts supplied with safety
extra-low voltage not exceeding 12 V, must be
inaccessible to a person in the bath. Earthed
appliances must be permanently connected
to xed wiring.
Site and Positioning
MAAX® Spas recommends that a Swim Spa be
placed in its nal installation site by crane. In
any installation where a crane cannot be used,
you may want to consult with a professional
rigging company.
When utilizing a crane for delivery, be sure
that crane operator understands the weight
of the Swim Spa, the height it must be lifted,
and the distance that the crane boom must
travel. Be sure that the crane operator uses
an 8’ spreader bar and that the straps wrap all
the way around the bottom frame of the Swim
Spa.
Locate the Swim Spa on a solid, level
foundation keeping in mind the weight of
the lled Swim Spa (in excess of 18,000 lb.
(8165 kg.) on some models). If you have any
doubts about the load bearing ability of your
chosen site, contact an architect or a building
contractor. The entire perimeter of the Swim
Spa Frame and bottom must be evenly
supported.
We recommend that you provide a concrete
foundation pad for the Swim Spa. The
foundation pad should be wider and longer
than the Swim Spa by at least 12 inches (30
cm) in each direction. Failure to provide a
level surface could structurally damage your
Swim Spa and void the warranty.
The Swim Spa must be installed to allow
access for service and maintenance on all
four sides; therefore, if you choose to install
your Swim Spa below grade level, you will be
required to have a vault or pit constructed
to prevent ground water, rain, snow melt, or
sources of water from collecting around the
equipment of the Swim Spa. The vault must
have either sucient drainage through a drain
line or through the use of a sump pump. The
vault must have adequate safe access as to
allow for routine maintenance of the Swim
Spa components.
WARNING: ACCESS TO THE Swim Spa
SHOULD BE CONTROLLED IN ACCORDANCE

99
Swim Spa
WITH ALL APPLICABLE NATIONAL AND
LOCAL CODES. IN SOME LOCATIONS THIS
MAY INCLUDE AN APPROVED FENCE WITH
SELF-CLOSING, SELF-LOCKING GATE
AND/OR A LOCKABLE SAFETY HARDCOVER
FOR OUTDOOR USE AND A LOCKABLE
DOOR AND/OR SAFETY HARDCOVER FOR
INDOOR USE.
Outdoor Installation
The following considerations apply when
installing your Swim Spa outdoors:
1. Local codes pertaining to fencing.
2. Local electrical and plumbing codes.
3. View from your house.
4. Wind direction.
5. Exposure to sunlight.
6. Location relationship to trees (twigs,
leaves and shade).
7. Dressing and bathroom location.
8. Storage area for maintenance equipment
and chemicals.
9. Location to facilitate adult supervision.
10. Landscaping and night time lighting.
11. Accessibility to equipment.
12. Location and routing of power supply to
Swim Spa and foot trac.
Indoor Installation
In addition to the Outdoor installation
consideration, please also understand that the
following considerations apply when installing
your Swim Spa indoors:
1. Indoor Swim Spa promote high
humidity. Using either ventilation fans or
commercial grade de-humidiers will help
to reduce the humidity. Consult your
dealer for details.
2. Floor drains must be provided near the
Swim Spa to drain o water that
may cause falls and /or water damage.
Water will splash out of the Swim Spa
during normal use when swimming and
when exiting the Swim Spa.
3. Surface area of foundation pad and
surrounding area should be at with a
non-skid nish. Carpeting or other
porous materials may retain moisture,
which leads to mold, mildew and odors
and is not recommended.
4. Walls, ceilings, woodwork should be made
of materials capable of withstanding high
humidity.
5. MAAX® Spas only recommends the use of a
concrete foundation pad to support your
Swim Spa. If you intend to install your
Swim Spa in an area where you cannot
utilize a concrete foundation pad, you
must consult with a structural engineer
to ensure the oor load bearing capacities
are adequate to support the concentrated
Swim Spa weight, the weight of the
Swim Spa occupants, and any furniture
or people that will be using the immediate
area of the Swim Spa.
6. During shipment from the factory,
plumbing components may loosen;
therefore it is imperative that the
Swim Spa is double checked for leaks
before installing to avoid possible water
damage. Your dealer may include this
service in their installation procedures.
7. Indoor sun rooms are capable of
maintaining high ambient temperatures
which may aect the Swim Spa water
temperature. It is NOT recommended that
you operate your lter cycles for longer
than 4 hours per day under these
conditions.
Danger: Electrical shock risk. Install at least
5 feet (1.5 m) from all metal surfaces.

10 10
Swim Spa
SWIM SPA SYSTEM COMPONENTS
A. Filter Skimmer/Weir Door: Removes
oating debris from the water surface,
provides a water return path to equipment,
and houses water lter elements.
Swim Spa Pro and Pro models utilize
2 Filter Skimmers and the Swim Spa
Duo-Pro model utilizes 3 Filter Skimmers.
B. Topside Control Panel: Used to control
temperature setting, jet pumps, circulation
system, underwater lights and ambient
eect lighting. Swim Spa Lounge and Pro
models utilize one topside control panel.
The Swim Spa Duo-Pro model utilizes
two topside control panels, one for the hot
tub portion and one for the swim area.
C. Air Controls: Increases or decreases air
entering the jets. Close during heating
for maximum eciency. It is recom-
mended that air controls to the Turbo
Swim jets remain closed during
swimming to provide a clearer stream of
water which is free from air bubbles.
D. Equipment Pack Service Panel (no user
serviceable parts): Spa support system
consisting of electronic control pack,
pumps, heater, UV water sanitizer, plasma
UV ozone generator, LED lighting interface
and associated electrical controls (not
shown). The Swim Spa Lounge and
Pro models feature one control pack,
three jet pumps, one UV sanitizer, one
plasma UV ozone generator and one LED
lighting interface. The Swim Spa
Duo-Pro model features two independent
electronic control packs, four jet pumps,
two UV sanitizers, two plasma UV ozone
generators and two LED lighting interfaces.
E. Drain Access (Adjacent to the equipment
service panel): Swim Spa drain faucets
are located immediately behind the front
door panel. Remove panel to access.
F. Manufacturer’s Identication Label:
Contains identication information for
warranty service (serial number, model
number, etc.) and electrical information
(ampere rating and ampere requirements).
Located on the lower right side of the front
door panel.
G. Diverter Valve: Used to direct the ow
of water between the massage jets in
the hydrotherapy seats and the swim
jets. By turning the diverter valve
clockwise, the water is directed to the
massage jets in the hydrotherapy seats and
by turning the diverter jet counterclockwise,
the water is directed to the swim jets.
F
D
G
B
A
E
C

11 11
Swim Spa
SWIM SPA COMPONENTS
Reference only. Equipment is not always as shown
Note: No consumer serviceable parts. We
recommend that only an authorized service
technician perform Swim Spa repair or
service.
A. Pumps: Each pump features dual-speed
capacity. Low speed is utilized for ecient
water circulation during ltration and
heating, and for lighter therapy and exercise
programs; high speed is engaged for
maximum action of the jets when deeper
therapy or more rigorous exercise programs
are desired. All pump functions are activated
by topside controls.
B. Electronic Control Pack: All Swim Spa
functions are operated by this control. There
are no user-serviceable components in this
control. Opening this control may subject
you to high voltage and danger of electrical
shock or electrocution.
Warning and Installation Label: Contains
important safety information, hazard
warnings and installation instructions.
C. Slice Valve: Used to shut o water ow
from the Swim Spa vessel to pumps
and electronic control pack while servicing.
Quantity will vary depending on model.
All valves should be open during normal
operations.
D. Electrical Connections: Contains outlets for
electrical plug connections. Connections are
made during manufacture of the pool.
E. Heater Assembly: Thermostatically
controlled and equipped with an overheat
safety shut-o.

12 12
Swim Spa
JETS AND AIR CONTROLS
Swim Area Jets
Swim Spa Turbo Swim jets are designed to
produce a smooth ow of water with high
output to create a consistent swim stream.
Whether you want to swim or walk/jog against
the force of the jets, you will nd the ow of
water deep enough and swift enough to meet
your individual needs.
Hydrotherapy Area Jets
All of the hydrotherapy jets are individually
engineered to provide a unique hydro-
massage. Depending on the model, your Swim
Spa will have a combination of the following
jets:
Cyclone Therapeutic
(XL Cyclone, LS Cyclone, & Cyclone):
Positioned to focus on large muscle groups,
these jets deliver a concentrated, high volume
stream of water for a deep massage. Each jet
is fully adjustable, allowing users to set the
water ow to the most comfortable setting.
The nozzle can be rotated to target sore
muscle areas.
Cyclone Turbo Swirl Jets
(XL Cyclone, LS Cyclone, & Cyclone):
Positioned to focus on muscle tension zones,
these jets deliver a spinning V-shaped water
stream for a gentle, pulsating massage. Each
jet is fully adjustable, allowing users to set
the water ow to the most comfortable setting.
Cluster Jets:
Positioned in the foot well or shoulder areas of
the Swim Spa, these jets deliver a penetrating
massage to dissolve tension. This jet may be
the entry point for ozone produced during the
automatic ltration cycles, and, as such, is not
adjustable.
Note: Ozone production is suspended when
other functions are activated on the control
panel by the Swim Spa user.
All full sized jets are adjustable from a fully
open to closed position. It is very important
that you NEVER SHUT ALL FULL SIZED JETS
OFF AT ONE TIME!
Cleaning or Replacing Jets
Hard water can cause calcium/mineral buildup
that can restrict or bind the jets. A jet consists
of a face plate and a nozzle. Rotate these parts
weekly and remove/clean monthly to ensure
free movement.
NOTE: It is not necessary to drain the pool
or spa to clean or remove the jets.
Rotating the jet face plate and nozzle
• Rotate the jet face left and right
(open and closed).
• Return the face plate to the full open
position.
• Turn the jets on to high speed.
• Twist the nozzle left and right.
• Rotate the nozzle in the socket.
NOTE: If the jet insert disengages from the
Swim Spa housing, see steps to reinstall
below.
Cleaning the jets
To remove the jet insert, use the palm of your
hand to exert pressure on the face of the jet.
Turn counterclockwise until the jet‘clicks’.

13 13
Swim Spa
Gently pull the jet assembly from the housing.
To clean the jet insert and housing, use a
pressurized hose and spray the inside of the
jet. Soak the jet in a diluted Swim Spa cleaning
solution, rinse. Wipe the inside of the housing
to remove any debris.
To reinstall the jet, line up the tab on the
backside of the barrel with the groove in the
body. Use the palm of your hand to gently tab
the jet until it snaps into position.
Air Controls
The intensity of the jet action can be
controlled by altering the amount of air
injected with water through the jets. Your
Swim Spa has 2 to 4 air controls located on the
lip of the Swim Spa. Each control activates air
to specic jets in the Swim Spa allowing you
to create various combinations and levels of
jet action to suit individual preferences. Turn
the control counter- clockwise to turn the air
o and clockwise to turn air on.
NOTE: Air controls should be closed during
heating cycles for maximum energy
eciency.

14 14
Swim Spa
ELECTRICAL INFORMATION
Important Safety Instructions
All electrical connections to this spa package
MUST be accomplished by a qualied
licensed electrician in accordance with the
National Electrical Code (NEC) and with state/
local electrical codes in eect at the time
of installation.
NOTE: Prior to performing any service to
the spa equipment, turn OFF all primary
electrical power at the main circuit breaker
or disconnect panel.
To make spa electrical connections, remove
the exterior equipment access panel, locate
the electrical control box, remove the control
box cover and follow the wiring diagram on
the inside of the control box cover.
Connections should be made using copper
conductors only. Connecting wires, circuit
breakers, or fuses must all be sized to accom-
modate the Total Ampere load as specied
on the equipment label.
This equipment is designed to operate on
60Hz alternating current only, at 240 volts.
NOTE: All unions must be hand-tight and
all slice valves must be locked in the OPEN
position before lling or relling spa!
A clip is provided to help keep the slice
valve open. Run spa and check for union
leaks before reinstalling front panel.
Ground-Fault Circuit Interrupter
A qualied licensed electrician shall connect
the spa to a circuit protected by a GFCI. This
is a requirement by the National Electric
Code, article 680-42, and is also in compli-
ance with Underwriter’s Laboratories, Inc.
Installation Options
While knockouts are provided in the cabinet
base to bring the conduit to the equipment
compartment, a hole may need to be drilled
in the pedestal or base if an alternate electri-
cal service entrance is desired.
Refer to the manufactures’s nameplate
located on the kick plate to determine your
spa’s ampere requirements.
240 Volt Installation
Permanently Connected:
The Duo-Pro spa side must be connected to a
240 volt electric service.
Electrical Requirements:
240 volt, 60 Hz, single phase, 40 amp.,•
4-wire service (line 1, line 2, neutral,
and ground or,
*30 Amp Option
Note: The heater can be activated only with
the pump on low speed. Only the spa light
can be operating at the same time without
disabling the heater. See your authorized
MAAX Spas dealer to select this option.
240 Volt Installation
Permanently Connected:
The Lounge, Pro and Duo-Pro swim side must
be connected to a 240 volt electric service.
Caution: Risk of electrical shock.
Read and follow all instructions.

15 15
Swim Spa
Electrical Requirements:
240 volt, 60 Hz, single phase, 60 amp.,•
4-wire service (line 1, line 2, neutral,
and ground or,
*40 Amp Option
Note: The heater can be activated only with
the pump on low speed. Only the spa light
can be operating at the same time without
disabling the heater. See your authorized
MAAX Spas dealer to select this option.
Spas installed for 240 volt, 60 Hz, single
phase operation require a 4-wire, 60 amp
240 volt sub-feed in non-metallic pipe to the
spa equipment compartment (line 1, line 2,
neutral and ground). A green colored termi-
nal (or wire connector marked “G”, or “GR”, or
“Grounding”) is provided in the control box.
To reduce the risk of electrical shock, connect
this terminal or connector to the grounding
terminal of your electrical service or supply
panel with a continuous green insulated cop-
per wire equivalent to the circuit conductor
supplying this equipment, but no smaller
than No. 12 AWG. A second pressure wire
connector is provided on the surface of the
control box for bonding to local ground
points. To reduce the risk of electrical shock.
This connector should be bonded with a No.
6 AWG copper wire to any metal ladders,
water pipes, or any metal within 5 feet (1,5m)
of the spa.
Note: Copper wire is strongly recommend-
ed for all electrical connections.

16 16
Swim Spa
START UP PROCEDURES
Follow recommendations for site location and
electrical connection.
1. Use standard “tap water” to ll the
Swim Spa by draping a garden hose
over the wall. Take care to wrap the metal
end of the hose with a soft cloth or set the
end of the hose in the lter canister to
protect the Swim Spa surface from
the metal end of the hose. The metal end
of your hose can become rough or jagged
and may scratch the surface of your
Swim Spa, and this damage is not
covered under your warranty. Fill the
Swim Spa until the water level is 4 1/2” to
5” from the top lip.
Never use “softened” water in your pool
or spa. Softened water can impact the
chemical balance of the water and lead to
degradation of metal plumbing ttings.
2. After you have assured that the
Swim Spa is full of water and that all
plumbing valves are open, turn power on
at circuit breaker or disconnect panel.
3. Open the air controls, located on the top
lip, and cycle the jets from high to low.
Water should come from the therapy jets. If
water ow is not established, turn o jets
and see Priming Your Swim Spa
(this page).
4. Add chemicals. See Chemical Treatment
and Water Maintenance section. Follow
Operating Instructions for your particular
model to set heat to the desired
temperature. Initially, you may nd that the
Swim Spa requires 18 to 24 hours on
230 Volt installations to reach temperature.
Keep your thermal cover on the unit and
close the air controls to help the heating
process.
Priming Your Swim Spa
When lling your Swim Spa for the rst
time or, after draining and relling the Swim
Spa, you may need to bleed air from the
system. Should you experience an air-lock on
Pump 1, remove the lter basket cover, insert
a garden hose through the center
hole of the lter as far as possible without
using force. Hold the hose in place and
turn on the water. This forces water into the
pump and forces the air out.
Important: Do not operate the Swim Spa
without full water ow.

17 17
Swim Spa
SWIM SPA SERIES CONTROL SYSTEM
The 460 Control System oers you the
ultimate in Swim Spa control. The backlit,
Liquid Crystal Display (LCD) displays
current water temperature, set point water
temperature, time, and operating mode
settings. Each feature of the system is actuated
through a control panel touch pad. Touch
the appropriate pad to activate the desired
function. At start up, when power is supplied
to the Swim Spa, the controls will operate
properly and safely under the factory settings.
The Swim Spa will be in Standard Mode, a
temperature setting of 100°F (38°C), and a
ltration cycle duration of 2 hours. To fully
utilize the unique capabilities of the control
system, it is important to know how to set the
temperature, operate the pumps, operate the
light, adjust the mode setting, and change the
ltration cycles.
NOTE: In event of a power outage or
failure, the Control System should retain all
settings, except time of day. If settings are
lost, re-program per the instructions in this
manual and contact your dealer.
Swim Spa swim zone control
All Swim Spa models utilize the topside control panel shown above. This control panel operates
all functions of the swim zone on all models. This control supports the following features:
• 2 Dual-speed Jet Pumps
• Underwater LED lighting
• Ambient Interior LED
Mood Lighting
• Temperature Setting
• Customized Filtration
Settings

18 18
Swim Spa
Temperature
The maximum set temperature is 104°F (40°C)
and the minimum set temperature is 80°F
(26°C). The current water temperature will show
on the display unless the primary pump has
not been running, in which case two dashes
(--) will show on the display. If two dashes are
displayed, you must rst start the pump by
pressing the JETS 1 pad. Wait until the water
temperature is displayed (approximately 2
minutes).
The set temperature of your Swim Spa may
easily be increased or decreased at any time
using the UP or DOWN pads. When either of
these pads is touched, the set temperature
will be displayed in the LCD display window.
Each successive touch will change the set
temperature 1°F (0.5°C) in the chosen direction.
After 3 seconds the LCD will automatically
display the water temperature or dash lines.
If the Swim Spa is set in Standard mode or in a
ltration cycle, adjusting the set temperature
may result in activating the heater. When
the heater is operating, the heat icon will be
displayed in the LCD.
JETS 1
Touch the JETS 1 pad to activate the primary
ltration and jet pump. The sequence of the
jet action is: 1 touch = Low jets
2 touches = High jets
3 touches = O
JETS 2
Touch the JETS 2 pad to activate the number 2
Jet pump. The sequence of jet action is:
1 touch = Low jets
2 touches = High jets
3 touches = O
The low speed operation of Pump 1 and 2
User’s Pads
User’s Pads are the buttons located on the
topside control panel and are used to program
various Swim Spa functions (i.e., turn on Swim
Spa light, set temperature, etc.). The following
table denes the pads:
Pad Use
UP
• Increase temperature
• Change time settings
• Used in alternate programming
sequences
Down
• Decrease temperature
• Change time settings
• Used in alternate programming
sequences
Time
• Exit programming
• View time of day
• Change set times of Swim Spa
lter cycles
•Lock/unlock temperatures
• Lock/unlock temperatures
Prog
• Switch modes
• Set time and ltration cycles
Light
• Turn all spa light on or o
Jets 1
• Activate primary ltration pump
•Used in alternate programming
sequences
Jets 2
• Activate therapy pump

19 19
Swim Spa
When the control panel lock is engaged, all
automatic Swim Spa functions will operate
normally but cannot be altered.
Panel Unlock
To unlock the panel, touch the TIME, JETS
1, and DOWN within 3 seconds. The ‘PL’
indicator light will go out when the panel lock
is cleared.
Light
Touch the LIGHT pad to turn the digital
lighting system on and o. The light will
automatically turn o after 60 minutes of
operation.
Operating Modes
Your Swim Spa comes with three primary
operating modes.
Standard Mode maintains the water at the
desired set temperature. Note that the last
measured Swim Spa temperature displayed
is current only when the pump has been
running for at least 2 minutes. The pump will
run for approximately 2 minutes every 30
minutes to test the water temperature. The
‘STANDARD’ icon will be displayed in the LCD
window when this mode is selected.
Economy Mode heats the water to the desired
set temperature ONLY during lter cycles.
The ‘ECONOMY’ icon will be displayed in the
LCD window when this mode is selected.
While in the Economy mode, pressing the
JETS 1 button will put the Swim Spa into the
Standard-In-Economy mode, which operates
the same as the Standard Mode, then reverts
back to the Economy mode after 1 hour. The
Swim Spa can be immediately reverted back
into the Economy mode at any time by simply
is timed to automatically turn o after four
hours of operation.
The high speed operation of Pump 1, and the
low and high speed operation of Pump 2 and
Pump 3, is timed to automatically turn o after
15 minutes of operation.
Note: Pump 1 will automatically operate in
low speed whenever the Swim Spa calls for
a ltration cycle or heat.
When this automatic activation occurs, the
low speed of Pump 1 cannot be turned o;
however, all other control functions can be
activated.
Temperature Lock
Once you have set the desired water
temperature, you may lock-in the new
setting to prevent unauthorized temperature
adjustments to your Swim Spa. To lock the set
temperature:
Touch UP or DOWN, then touch TIME, JETS 1,
and UP within 3 seconds. The ‘TL’ indicator will
light when the set temperature is locked.
Temperature Unlock
To unlock the temperature, touch either UP or
DOWN, then touch TIME, JETS 1, and DOWN
within 3 seconds. The ‘TL’ indicator light will go
out when the set temperature lock is cleared.
Panel Lock
To help prevent unauthorized use of your
Swim Spa, the control system has a unique
panel locking system. To lock the panel, touch
TIME, JETS 1, then UP within 3 seconds.
When locked, the ‘PL’ indicator light will be
on. Except for the time button, all function
settings will be frozen.
Table of contents
Other MAAX Hot Tub manuals
Popular Hot Tub manuals by other brands

Jacuzzi
Jacuzzi lodge M installation manual

KIRAMI
KIRAMI Original Woody Instructions for use

Marquis
Marquis Crown Summit owner's manual

Hydropool
Hydropool Serenity Hot Tubs owner's manual

REVLON
REVLON MoistureStay RVSP3501 Important safety instructions

Master Spas
Master Spas Master Spas Series owner's manual

HotSpring
HotSpring Pulse instructions

Jacuzzi
Jacuzzi PROJECTA lagoon 170x70 Instructions for preinstallation

Takara Belmont
Takara Belmont YUME installation instructions

Premium Leisure
Premium Leisure Leisure Edge LE852 owner's manual

Strong Pools and Spas
Strong Pools and Spas Grand Cayman Spa owner's manual

Canadian Spa
Canadian Spa Winnipeg UV Spa KH-10159 owner's manual
