Mac Faucets ADA Grab Bar Series User manual

PAGE | 01
Installaon Instrucons
User Manual
ADA Grab Bar Series
Models: GB-36 & GB-42
36” Grab Bar for ADA Applicaon
42” Grab Bar for ADA Applicaon
Stainless Steel Construcon
Concealed mounng for a clean look
1-1/4" bar diameter
2-1/2" flange diameter
Bar extends 1-1/2" from wall
Supports up to 250 lbs.
Meets ADA load requirements when properly installed
All hardware necessary for sasfactory installaon
Package Includes
866 558 3200 310 919 3073 [email protected] www.macfaucets.com
MAC FAUCETS California, USA
D
E
S
I
G
N
E
D
&
A
S
S
E
M
B
L
E
D
I
N
T
H
E
U
S
A
Tools Needed
Safety Glasses
Drill bit
Ø 1/4” Carbide
Drill for le
Cordless DrillLevel Phillips Screw Driver Pencil
Stud Finder
Level
02 Unscrew flanges and pull back from the two ends of the
grab bar. Posion the grab bar so that the mounng
ends are against the studs. Make sure the bar is leveled.
Mark drill hole locaons.
01
Mark The studs
Stud
Finder
FOR SAFETY
REASONS, GRAB
BARS MUST
MOUNT TO STUDS
ONLY. With the stud
finder tool, locate
and mark posion of
the studs.
Important notes for proper Installaon
DO NOT INSTALL this product without reading and understanding the warning instrucons. If you are unable
to understand these warnings and instrucons, contact professional or technical personnel for assistance-
otherwise injury may occur.
GRAB BAR LOCATION
For proper mounng heights and locaon, consult with your state and local code official, they have jurisdicon
over the installaon
SOLID SUPPORT
* Grab Bar ends must be mounted with both end posion over a wall stud. Stud finder must be used to locate
wall studs, Contractor is responsible for installing Grab Bar to wall studs as instructed.
* Secure through wallboard or le to the wall so as to hold a minimum of 250 pounds.
* At least two (2) of the three (3) wood screws provided must be used on each end of the Grab Bar, top and
boom, to properly secure Bar to wall. Standard size wall studs limit using more than two (2) wood screws.
* If using a drill to install wood screws, a drill bit extension must be used to avoid damaging the Grab bar.

User Manual
ADA Grab Bar Series
Models: GB-36 & GB-42
D
E
S
I
G
N
E
D
&
A
S
S
E
M
B
L
E
D
I
N
T
H
E
U
S
A
Ø 7/64” Drill Bit for the Wood Stud
Ø 1/4” Carbide Tip Drill for ceramic Tile
03 Remove Grab Bar
from wall, use drill
to drill holes into
the wall and wall
studs at the marked
posion.
05 Once the grab bar is
SECURELY installed,
screw flanges onto
threaded base. Feel free
to use BLUE locte if
needed.
04 Tighten all screws using a Phillips screwdriver. Secure
grab bar to wall. If a cordless drill is used, MAKE
SURE TO USE A DRILL BIT EXTENSION in order to
avoid damage to finish.
Wall Studs
Wall
Grab Bar must be secured
with at least two (2) of the
three (3) screws at each end
06
866 558 3200 310 919 3073 [email protected] www.macfaucets.com
MAC FAUCETS California, USA
PAGE | 02
MAC FAUCETS warrant all MAC Faucets products to be free of defects for a period of one year from date of purchase. MAC
FAUCETS will replace, free of charge, during this warranty period, parts that prove defecve when properly installed and under
normal use and service. Damage that occurs as a result of abuse, improper installaon, environmental condions, or improper
applicaon will void this warranty. Products or components that have been altered or in any way modified will not be covered
under this warranty. This warranty does not cover installaon or any other labor charges. This warranty does not cover shipping
and handling of both replacement parts and returned defecve parts. Defecve products must be shipped back to MAC
FAUCETS facilies with postage and handling prepaid, along with dated proof of purchase. Replacement parts are under
warranty only for the remaining period under the inial warranty.
Limited Warranty
Other Variants
MPGB-8 Matching Pair, One 36" & One 42" Grab Bars
