Mach Daimond Series User manual

美刚商用钻石系列
Mach Daimond Series
DC-10 /DC-12
⼆路全频⾼端⾳箱
2-way full range high-end speaker
说 明 书
User Manuel

美刚 DC-10 / DC-12 说明书 - 2 -

- 3 - Mach DC-10 / DC-12 user manuel
目录
INDEX
1. 封面 Cover ----------------------------------------------------------------------------------------- P.1
2. 目录 Index ------------------------------------------------------------------------------------------ P.3
3. 引言 Introduction --------------------------------------------------------------------------------- P.4
4. 基本指引 General Instructions ---------------------------------------------------------------- P.4
5. 缆线 Cables ---------------------------------------------------------------------------------------- P.5
6. 安全信息 Safely Information ------------------------------------------------------------------- P.5
7. 技术规格 Technical Specifications --------------------------------------------------------- P.6-7

美刚 DC-10 / DC-12 说明书 - 4 -
1. 引言
Introduction
Mach 美刚钻石商用系列推出最新款高端挂墙式全频两分频音箱，分别有 DC-10（10 寸两分频）及 DC-
12（12 寸两分频）型号，无源分频，高级哑光漆面，配合仟薄式简易强身安装挂架，另有顶部及底部
各两个 8mm 安装螺丝孔，是应用及安装都简易方便。DC10/12 采用薄式箱体设计，最大限度减少了
占用空间，延续 DC 系列风格要求，确保最佳音质，面网更采用高端可拆卸式棉网，既确保声音纯正，
又高档典雅。无论厅堂欣赏音乐，会议室，商场，咖啡酒吧，甚至影院系统配置，都能灵活应用自如。
可搭配现有 DW-8P 及DW-12 低音，以后会再推出 DW-15（15 寸低音）已满足更大场地声压要求。
Mach DC-10 and DC-12 are latest high-end full-range two-way speakers, DC-10 (10-inch two-way) and DC-
12 (12-inch two-way), passive crossover, high-grade matt painted, with thin and simple hanging mount, and
two 8mm mounting screw holes on the top and bottom, which are easy to use and install. The DC-10/12
adopts a thin cabinet design, which minimizes the space occupied and continues the DC series style
requirements to ensure the best sound quality. The high-end detachable cotton mesh to ensure pure sound
and high-grade elegance. Whether you enjoy music in the hall, conference rooms, shopping malls, coffee
bars, or even theater systems, you can use it flexibly. DC-10/DC-12 can be used with the existing DW-8P
and DW-12 sub-woofers. And we will later launch DW-15 to hit the sound pressure requirements of larger
venues.
2. 基本指引
General Instructions
1. 请勿在水源附近使用本系统。
2. 音箱必须经常保持清洁和干爽，只能用干布进行清洁。
3. 此系统之功率使用必须保持在其标示的功率上限之内，不能过载。
4. 不要堵塞任何通风孔。请按照说明进行安装
5. 一般电子产品，电流可能会加速金属表面锈蚀，因此，建议定期检查接线端子有否出现腐蚀。特
别是若果扬声器是安装在恶劣的环境之中。
6. 请勿将产品（包括放大器）安装在靠近任何热源的地方，包括电暖炉、加热器、炉子或其他可发
热的设备。
7. 请勿使极化插头或丧失安全作用的接地型插头。
8. 防止踩踏或挤压电源线，尤其是插头、电源插座以及设备上的出口位置。
9. 只能使用制造商指定的附件/配件。
10. 在雷雨天或长时间不用时，请切断本系统电源。
11. 如果本系统在任何方面受到损坏需进行维修，任何维修事宜请向合格的人员咨询。
1. Do not use the speakers near water.
2. Always keep the speaker clean and dry, clean only with dry cloth.
3. Never overload your system – stay within the specified limits for power handling.
4. Do not block any ventilation slots. Install in accordance with the instructions.
5. As with any electrical product, currents will accelerate corrosion of metal surfaces. Therefore it is
recommended to check the terminals for corrosion at regular intervals, especially if the speaker is
mounted in a hostile environment.
6. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
7. Do not defeat the safety purpose of the polarized or grounding-type plug.
8. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
9. Only use attachments/accessories specified by the manufacturer.
10. Unplug this device during lightning storms or when unused for a long period.
11. Refer all servicing to qualified service personnel. Servicing is required when the speaker has been
damaged in any way.

- 5 - Mach DC-10 / DC-12 user manuel
3. 缆线
Cables
为使本音箱系统能发挥最佳效能，请使用高品质电缆。高电容、高电感和高阻抗电缆对音质，以
及放大器的安全性会造成较大的负面影响。
To get the best possible performance from your Shine Series speaker, use high quality cable. Cables with
high capacitance, high inductance and high impedance have a strong negative influence on sound quality
as well as amplifier reliability.
4. 安全信息
Safely Information
音箱系统在安全的方式下使用至为重要。请花一些时间细阅下列有关使用美刚音箱的安全信息。专业
音箱能够产生极高的声压，应小心使用，不要近距离站在音箱前，长时间暴露于 90 分贝以上水平，将
导致人渐进地失去听力。请按照如下的规则：
1. 在安装之前请检查所有的组件，切勿使用有问题的组件。
2. 请细阅随每各配件的装配说明指引。
3. 不要让没有经验的人操作本系统，须由曾经接受扬声器技术培训的人员进行安装。
4. 工作区域应与公众隔离，确保公众不会在安装过程中处身音箱系统之下。
5. 音箱堆叠：确保地板或舞台是水平状态和坚实的。请注意，在地板和音箱之间及音箱和音箱之间
加上防滑摩擦材料，可避免音箱因发出很高功率而出现的蠕动移位。
6. 警告：为避免火灾或触电的危险，请勿让本系统受到雨淋或受潮。
7. 只能使用制造商指定或随本设备一起销售的推车、支架、三角
架、托架或工作台。如果使用推车，则在移动推车/设备时应格外
小心，以避免因倾倒而造成伤害。
8. 本产品不得受液体淋溅或喷洒，不得将装有液体的物体（如花瓶
等）置于本产品之上。
It is important that loudspeaker systems are used in a safe manner. Please take some time to review the
following points concerning safe use of the Mach loudspeakers. Professional loudspeakers are capable of
producing extremely high sound levels and should be used with care. Hearing loss is cumulative and can
result from levels above 90dB if people are exposed for a long period. Never stand close to loudspeakers
driven at high level. Please follow the rules as below:
1. Inspect all the components before assembly. Those affected should NOT be used.
2. Carefully read the assembly instructions shipped with each accessory.
3. Do not allow inexperienced persons to handle the systems. Installation personnel should be trained in
loudspeaker techniques.
4. Ensure that public and personnel are not allowed to pass beneath the system during the installation
process. The work area should be isolated from public access.
5. Stacking: Ensure that the floor or stage is level and solid. Be aware that speakers producing very high
power levels can move or creep. To avoid this, place friction material between the floor and speaker
and between each speaker.
6. WARNING : To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
7. Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart / apparatus combination to avoid
injury from tip-over.
8. Do not expose to dipping or splashing. Do not place objects filled with liquid, such as vases on this
apparatus.

美刚 DC-10 / DC-12 说明书 - 6 -
5. 技术规格
Technical Specifications
DC-12
520mm
240mm
400mm
240mm
600mm
450mm
240mm
240mm

- 7 - Mach DC-10 / DC-12 user manuel
技术参数 Specifications
型号
Models
DC-10
DC-12
高音单元
High frequency driver
1-inch compression driver
1寸压缩高音驱动器
1-inch compression driver
1寸压缩高音驱动器
低音单元
Low frequency driver
10-inch rubber edge bass unit
10 寸橡皮边特制低音
10-inch rubber edge bass unit
12 寸橡皮边特制低音
连续功率
Power rating (AES)
350 瓦
350 Watts
400 瓦
400 Watts
最大输出声压级
Max SPL
125 dB
128 dB
灵敏度(1w/1m)
Sensitivity 1w/1m
92 dB
96 dB
阻抗（欧姆）
Nominal Impedance
8 Ω
8 Ω
频率范围 +/-3dB
Frequency response +/-3dB
60 Hz - 19kHz
60 Hz - 19kHz
擴散度 (水平 x垂直)
Dispersion (H x V)
100 ° x 60 °
100 ° x 60 °
输入
Connection
接线柱端子
Speakers stud terminal
接线柱端子
Speakers stud terminal
尺寸 (深x 阔 x 高)
Dimensions (D x W x H)
240 x 400 x 520 毫米
240 x 400 x 520 mm
240 x 450 x 600 毫米
240 x 450 x 600 mm
净重
Net weight
15 千克
15 kg
18 千克
18 kg
訂貨編號
Order information
#94005050 黑色
#94005050 black
#94005060 黑色
#94005060 black

美刚 DC-10 / DC-12 说明书 - 8 -
本手册的内容如有变更，恕不另行通告。
美刚音响公司将不会为此手册作出所引起（或声称引起的）直接或间接损失负责。
© 2019 Mach Audio Ltd 美刚音响公司
版权所有，未经美刚音响公司书面许可，不得以任何形式或方法复制本手册内任何内容。
The contents of the manual may be subject to change without notice.
Mach Audio Limited makes no warranty of any kind with regard to these instructions.
© 2019 Mach Audio Ltd
No part of this manual may be reproduced, in any form or by any means,
without permission in writing from Mach Audio Limited
