Mackie C200 User manual

C200 PRECISION PASSIVE
LOUDSPEAKER
1/6 PAGES
FEATURES:
■2-way portable Precision Passive loudspeaker system
■500W peak / 200W RMS power handling at 8
■10”long-throw low-frequency transducer with
2” voice coil
■High-output 1.4" titanium compression driver
■Ultra-wide, smooth dispersion via HF horn design
■ Integrated Low Impedance Compensated Crossover (LICC)
with full driver protection
■Lightweight for ultimate portability (26 lb / 11.8 kg)
■Asymmetrical trapezoidal cabinet for floor monitor
positioning
■Stand / Pole-mountable
■Flyable via optional hanging bracket kit
C200
Featuring legendary Mackie sound quality and durability, the
lightweight C Series 2-way Precision Passive loudspeakers
deliver optimum performance in portable PA, stage
monitor and permanent installation applications. The C200
is a full-range portable loudspeaker providing high-output,
ultra-wide dispersion and low-distortion performance in a
compact, composite molded enclosure.
A heat-treated titanium compression driver directs pristine
highs through an exponential high-frequency waveguide,
allowing for ultra-wide dispersion of highs and mids. This
allows the C200 to deliver clear, smooth sound to audience
members up to 45° off axis.
The custom-designed high-power 10-inch woofer with a
2-inch voice coil allows the driver to run cooler, delivering
consistent performance even after long hours of use at near
peak volumes.
The crossover in the C200 is a unique Low Impedance
Compensated Crossover (LICC) design with an asymmetrical
slope. With EQ and crossover points meticulously chosen so
that beamwidth patterns match in both drivers, C200
loudspeakers offer natural sound at all volume levels.
The center of gravity, handle locations, handle design,
position of fly-points and ease of use have been
ergonomically designed. There is also an integrated pole
mount on the bottom of the cabinet and a weather-resistant
steel grille. The asymmetrical trapezoidal cabinet has been
designed to provide an ideal floor monitoring position.
The cabinet is constructed of high-pressure injected
polypropylene. The enclosure features reinforcement ribbing
and structural strengthening resulting in a strong, super-
rigid design providing ideal acoustical characteristics.
APPLICATIONS
Small club/band PA systems, houses of worship,
DJs, vocal/band monitor wedges, gymnasiums, banquet
halls, conference rooms and many, many more.

C200 PRECISION PASSIVE
LOUDSPEAKER
2/6 PAGES
C200 SPECIFICATIONS
Acoustic Performance
Frequency Response (–3 dB) 89 Hz-20 kHz
Frequency Range (–10 dB) 59 Hz-22 kHz
Max SPL long-term 118 dB @ 1 m
Low-Frequency Crossover Type 6 dB / octave,
time offset corrected
High-Frequency Crossover Type 12 dB / octave
Crossover Point 1800 Hz
Audio
Input / Thru Connector Type Speakon™-style NL-4 jack
1/4" TS jack
Input Impedance 8
Power Handling
RMS 200 watts
Music 350 watts
Peak 500 watts
Operating Temperature Range –10º C to 45º C
14º F to 113º F
Low-Frequency Transducer
Diameter 10 in / 250 mm
Voice Coil Diameter 2 in / 51 mm
Magnet Material Ferrite
High-Frequency Transducer
Diaphragm Diameter 1.4 in / 36 mm
Diaphragm Material Heat treated titanium
Horn Exit Diameter 1 in / 24.5 mm
Horn Design
Type Conical and Exponential
Mouth Size 12 in / 305 mm (W) x 7 in / 178 mm (H)
Horizontal Coverage 90º (1 kHz - 20 kHz)
Vertical Coverage 80º (1 kHz - 20 kHz)
Safety Features
Driver Protection Dynamic protection for compression driver
Construction Features
Basic Design Asymmetrical Trapezoidal
Material Polypropylene
Finish Black, textured finish
Handles One on right side, one on top
Grille Perforated metal with weather-resistant coating
Physical Properties (packaged product)
Height 21.5 in / 546 mm
Width 13.2 in / 335 mm
Depth 12.4 in / 315 mm
Shipping Weight 30.0 lb / 13.6 kg
Physical Properties (product)
Height 20.8 in / 527 mm
Width 13.1 in / 333 mm
Depth 12.3 in / 311 mm
Net Weight 26.0 lb / 11.8 kg
Mounting Methods
Floor mount, pole mount, or fly via optional bracket
Options
SPM200 Loudspeaker Pole Mount P/N 2035170-01
C200 Bracket Kit P/N 0016404
Ordering Information
C200 Passive 2-way Loudspeaker P/N 2033791
C200 Passive 2-way Loudspeaker, CN P/N 2033791-05

3/6 PAGES
C200 PRECISION PASSIVE
LOUDSPEAKER
(

á

#
$
á


á


#
$
á


(

á


"
$
á

'

á

"
$
á
(

á

#
$
á


á


#
$
á


(

á


"
$
á

'

á

"
$
á
(

á

#
$
á


á


#
$
á


(

á


"
$
á

'

á

"
$
á
(

á

#
$
á


á


#
$
á


(

á


"
$
á

'

á

"
$
á
(

á

#
$
á


á


#
$
á


(

á


"
$
á

'

á

"
$
á
(

á

#
$
á


á


#
$
á


(

á


"
$
á

'

á

"
$
á
7i
!$7i
%7i
!7i
!$7i
" $7i
#7i
$7i
%"7i
'7i
7i
!$7i
%7i
!7i
!$7i
" $7i
#7i
$7i
%"7i
'7i
7i
!7i
%7i
C200 HORIZONTAL POLARS
Gridlines: 6 dB axial / 15 degrees radial

4/6 PAGES
C200 PRECISION PASSIVE
LOUDSPEAKER
(

á

#
$
á


á


#
$
á


(

á


"
$
á

'

á

"
$
á
(

á

#
$
á


á


#
$
á


(

á


"
$
á

'

á

"
$
á
(

á

#
$
á


á


#
$
á


(

á


"
$
á

'

á

"
$
á
(

á

#
$
á


á


#
$
á


(

á


"
$
á

'

á

"
$
á
(

á

#
$
á


á


#
$
á


(

á


"
$
á

'

á

"
$
á
(

á

#
$
á


á


#
$
á


(

á


"
$
á

'

á

"
$
á
7i
!$7i
%7i
!7i
!$7i
" $7i
#7i
$7i
%"7i
'7i
7i
!$7i
%7i
!7i
!$7i
" $7i
#7i
$7i
%"7i
'7i
7i
!7i
%7i
C200 VERTICAL POLARS
Gridlines: 6 dB axial / 15 degrees radial

5/6 PAGES
C200 PRECISION PASSIVE
LOUDSPEAKER
">2C0E4A4B?>=B4
=^a\P[XiTSc^S1B?;
5aT`dT]Rh7i
 

¸ 
¸!
¸"
¸#
¸$
!       :!:
C200
1. SYMBOL INDICATES CENTER OF BALANCE.
2. WEIGHT APPROX. 26.0 lb [11.8 kg].
3. SHIPPING WEIGHT APPROX. 30.0 lb [13.6 kg].
INPUT THRU
PARALLEL
C200 FREQUENCY RESPONSE C200 INPUT PANEL
C200 DIMENSIONS

6/6 PAGES
C200 PRECISION PASSIVE
LOUDSPEAKER
Part No. SW0767 Rev. B 06/10
M5 inserts for mounting
optional hanging bracket
Bottom
Pole
Mount
Top
Since we are always striving to make our products better by
incorporating new and improved materials, components, and
manufacturing methods, we reserve the right to change these
specications at any time without notice. “Mackie” and the “Running
Man” gure are registered trademarks of LOUD Technologies Inc.
All other brand names mentioned are trademarks or registered
trademarks of their respective holders, and are hereby acknowledged.
©2010 LOUD Technologies Inc. All Rights Reserved.
Electronic les for this product are available at:
www.mackie.com
Specification Sheet C200_SS.PDF
Owner’s Manual C200_OM.PDF
C200 FLY POINTS
