Macrom M-AVM6030 User manual

New MAZDA 6 Car Audio & Video Entertainment System
M-AVM6030
Quick Guide

★★★★
Copyright
The copyright of this manual is reserved by our company. All rights are reserved.
This manual may not be copied, reproduced or translated in whole or in part without the
express written permission of our company.
Our company reserves the right to improve the product, and its hardware and
software.
This manual is an operating guide, but not the warranty of the product. Our company
doesn't guarantee the contents included in this manual.
Since we adhere to the strategy of sustainable development, printing error in the
manual, incompliance with latest materials, software upgrade, and product improvement
may be performed at any time. The product is subject to change without further notice,
and revision will be directly edited to the manual of new edition.
Our company reserves the right of final interpretation for the manual.

Pre cautionsPre cautions
To ensure the traffic safety and avoid contravening the traffic regulations, do not
watch any program or operate the system during driving.
For safety and correction operation of the product, the product shall be installed
by professional. Do not disassemble or repair the product by yourself to avoid an
accident or damage to the product.
To avoid electric shock, damage and fire resulting from short-circuit, do not place
the product in water or places where are wet.
Since the screen of the product adopts precision electronic structure, do not knock
the TFT display to avoid damage to the product.
As for car backing, this system works simply as an assistant tool. Our company is
not responsible for any potential car backing accidents.
1

NOTE
Trademark
Licence：
In order to use the product correctly and safely, please read this manual carefully.
Specification and design due to technical improvement are subject to variation
without notice！
Please read this manual carefully before using this product and properly keep the
manual for future use.
Remark: The above symbol indicates that this product hasn't any harmful
material or elements, it is environmental and recyclable, and shouldn't be littered
at random.
①Manufactured under license from Dolby Laboratories;
②Dolby and the “double-D” symbol are trademarks of Dolby Laboratories.“ ”
2

Brief Introduction
Thank you for purchasing our high-quality car electronic product. This system is a multi-
function car AV entertainment system with a brand-new GUI, which is designed for
. combines DVD player, radio, bluetooth communication, navigation, TV (optional), iPod
player (externally plugged) and audio power amplifier together. The
system adopts dedicated slot-loading car DVD chip, which can play DVD, VCD, MP3, WMA,
MPEG4, JPEG, etc.In addition, the system adopts high-sensitivity FM and AM digital tuner
making you master the world's trends and financial information at any time and any place while
you are in your car; with 16:9 extra-clear TFT LCD, which can adjust brightness of the
screen automatically according to the light intensity of outside. The screen
but also offering a best visual status all the time as well.With optional
reverse radar, reverse camera, , AV and other interfaces for auxiliary functions (reverse
radar, reserve camera, etc.), you can use these functions to realize more functions. The
structural dimensions of the system conform to the installation dimensions of ISO TWO DIN.
Car electronic product is specially designed, fully intelligent, humanized, and featuring
GUI operation; featuring OSD menu, various functions can be realized through function keys on
the panel and touch screen, thus realizing perfect HMI and meeting your requirements of
comfort. If your cell phone is a bluetooth cell phone, you can answer your call through the
system without picking up your phone.
To correctly install and use the system, please read this manual carefully to understand
operations of common functions quickly.
New Mazda
6 It
,CDC disc box(optional)
7’
NAV
angle can be adjusted.
Not only wide angle view,
NAV,
3

Product Functions
Built-in Functions:
Built-in RADIO,DVD player,TV (if the host
unit has a built-in TV module) navigation,
Bluetooth hand-free,display and high power
amplifier.(external navigation box is optional).
DVD Player:
It could play DVD/VCD/CD/MP3/WMA/
JPEG/MPEG4 disc.
Radio Receiving:
High sensitive AM/FM receiving, could
restore 24 stations.
Bluetooth Hand-free:
Supports Bluetooth hand-free communication
and bluetooth play function.
4
SD Card Port
Display Screen:
Adopt 16:9 TFT high definition LCD.
iPod Play:
It supports music and video from iPod.
AV Function：
It support AV input of the external equipment.
Optional Function:
USB Port:
It support USB 1.1 and able to play
MP3,WMA audio and skim picture.
The host unit with built-in NAV module
possess double SD card portable,separately
plays audio and video files as well as the
stored navigation map data.
The host unit without built-in NAV module
possess single SD card interface,separately
paly audio and video files function.
iPod play function;TV receiving (with our
transferring wire)AV function(one of two).
Navigation Function(Optional):
An intelligent system capable of ntellectually
optimizing the best driving route according
to the user's destination and guiding the
driver smoothly to high-precision graphical
display of both the road names of the whole
and phonic playing of traffic identification
and signs.

5
The following is the other function:
Mobile GUI:
Complete graphic operation interface, more
visual and humanized.
Menu Display:
All operations can display on the screen.
Car Backing Display(Optional)：
You can observe the backing condition
when you are backing the car by connecting
the car backing camera.
Car Backing Sensor(Optional)：
Connect with the car backing radar, the
distance detected by sensor is displayed on
the TFT high definition LCD, so we can
view car-backing status more directly.
Handwriting for Navigation:
During navigation state, you can enter
character by handwriting through the touch
screen, thus operating conveniently and
quickly.
Navigation AV and Music Navigation:
When there is no voice navigation
indication, you can enjoy the music and
watch video normally, thus being happy and
relaxed in your trip!
Touch Screen:
It is convenient to operate the host unit.
Black Screen:
The function is specially set up for prevent
intensive light glaring and hindering of
normal driving at night.
EQ Modes:
Standard, Custom, Pop, Rock, Classic, and
Jazz.
Audio Output Port:
It has 4 channel and 5.1 channel audio output
ports, compatible with the outside amplifier.
Features Treble, Mid and Bass adjustments.
Tone Modes:
Auto Memory:
All the set parameters can be memorized
and restored automatically.
Display System:
Auto PAL 、NTSC and SECAM，wide
application range，highly compatible.
Spectrum Display Modes:
5 spectrum modes are available.

Connection diagram for Built-in amplifier of CX-7
To make the system functions the most perfect, please be strict to connect the wires according
to the connection diagram.
To prevent from short-circuit, please cover the insulation casing of audio and video when they
have not been used.
6
Radio antenna
BRAKE
BACK
CDC GND
CDC BATT
CDC ACC

Conned oi
cte t Pod
V-I N
R-I N
i a aptr (o i nal
Pod d ept o )
Multi-function compound interface
Left chnnel udio inut
aap
o d toT b
Cnnecte V ox
Veo input
id
L-I N
Red
V- IN
R-IN
L- IN
White
Camera/radar wire (Accessory of camera/ adar)
r
u i oo lAV inpt w re A ( pti na)
1 out of 2
T
co ct ng wr (aes oroTV boxV nne i i e ccs y f )
ted radar
Connec to
cted came
Conne to ra
Connected came
to ra
V-IN
ig c l puR ht hanne audio in t
u
Video inp t
gt an elauioi n uRi hchn d p t
Let cha n l dio in ut
f n e au p
Yellow
Yellow
White
Red
Yellow
(Male radar)
(Female lens)
(Optional)
e ut
Vid o inp
A
V input wire B (optional)
1 out of 3
Left hannel audi
co
input
Right channel audio
input
o
Videinput
Lef chaaoinput
t nnel udi
R ght channe audio inpi l ut
Veo inut
id p
7
Useless if built in TV
BRA KE
BA CK
CD C GN D
CD C BATT
CD C ACC
Connected to power
socket of the car
i h
Steerngweel
connecting wire
AM P-C
Amplifier control cable
Ud i t le i n
A X auio npu cab from Or gial car

5.1 channel audio
output wire
A p reV oututwi
Multi-function compound interface
NV tra fe r ng w r nsr i i e(o i alA pt on )
te h ne a io utp
Cen r c anl ud o ut
Subw ofer udouto a io utp
Dig udio ou
ital a tput
rna a lif r w
Exte l mpie poer
ono w e
c tr l ir
ou1
Vide otput port
noe
Data cotr l wir
C-OUT
FR-OUT
SW-OUT
SPDIF
AMP-C
RR-OUT
RL-OUT
L-OUT
KEY-CON
R-OUT
V2-OUT
V1-OUT
t f a l u utFronle t chnne a dio outp
t
Con ece to external n d
o
naviationmdule
g
FL-OUT
Fr nt t ha el au tput
o righ c nn dioou
R ar le t chnne a dio outpe f a l u ut
R ar right c ann l udio ouute h e a tp
l u
Left channeadio output
Rt channe a dio outpuigh l u t
o u
Vide o tput port 2
White
Red
White
Red
White
Black
Yellow
White
Red
Yellow
Yellow
8

Turn on/off
Volume Adjustment
Insert or pull out the car key to turn on or
off the system.
When the system is in standby state,press
the left knob on the panel to turn on the
system.
9
Rotate the left knob on panel to adjust
volume.
When the system is on, press and hold the
left knob on the panel to enter standby
state.
GPS
ME NU
GPS
ME NU

Descriptions of Buttons
10
3
1
2
45
6
When it is on, press the button once to enter
night mode, and press the button again to
enter black screen mode; press and hold the
button to enter standby state; when it is in
standby state, press it to turn on the system.
Turn the knob to adjust the volume.
Press it to switch the DVD mode at other
mode.When it is in DVD status, press it
repeatedly to switch the mode among USB/
SD/DVD in turn.
At other mode, press it to switch the radio mode.
When it is in radio status, press
to switch band among FM1/FM2/FM3/AM
in turn.
it repeatedly
Press and hold it to tune to high- low-
frequency band semi-automatically
/
.
When it in DVD, CDC, iPod play status,
press it to select the next/ song or
chapter.
previous
When it is in radio status, press it to select the
next/ station.previous
GPS
ME NU
1
2
3
4
7
8
10
5
9
12 13
15
6
14
11
Eject/inject button at DVD status.
At other mode, press it switch to DVD mode.
7
8Enter into system to set up main menu
When it is in radio status, turn the knob to
fine tune the station;
When it is in DVD status, turn the knob to
select the previous/next chapter or song;
Press it vertically to And
then turn it to adjust it.
Treble/Middle/Bass,

11
10
12
11 Connect to portable hard disc.
9Enter /exit navigation mode.
Turn on/off volume.
14
15
This port is used for connecting SD card
with host unit( ).For playing a multi-media
13
This port is used for connecting SD card
with host unit( ).For storing map data
Insert this hole and press the button inside
the hole, and the system will be reset to the
factory settings.
This is the window used for communication
with others when using the bluetooth
handfree function.

12
Remark: methods for set up original car small display :adjust interface in time interface of host unit:
press SET for a period of time until time on original car small display tremor ,then press + to adjust
hour ,press - to adjust minutes ,after finished ,press SET for exit adjustment.
Main Menu
Bluetooth
hand-free interface
iPod interface Setup interfaceDisc changer
play interface
AV interface
Click to enter main menu
（ ）Optional
For detailed information of these functions, please refer to “User's Manual”.
As the figure shows, main menu includes
Radio, DVD,TV,Navigation,bluetooth, iPod,
disc changer(unavailable), AV, camera and
Setup function modules, through which
corresponding function operation can be
enter directly.
Radio interface TV interfaceDVD play interface NAV interface
(External navigation
box is optional).
Camera interface
（ ）Digital TV box is optional
(Unavailable)

Product Specifications
DVD Parameters
20Hz~20KHz( 3dB)±
Audio Parameters
Frequency response
Tone
control
Bass
Mid
Treble
100Hz±8dB
1KHz±8dB
10KHz±8dB
Channel imbalance
Separation
≤2dB
≥55dB
Test voltage
Max output power
Speaker resistance 8Ω（4－8 could be
Ω
accepted）
13.8V
4×45W
Amplifier Parameters
1±0.2Vp-p（75Ω）
Video output
Diameter 12cmDisc format
DVD/VCD/CD/MP3/WMA/
JPEG/MPEG4
Disc compatible
Working voltage
Working current
MAX 15Ａ
Standby current
＜10mA
Working temperature
Screen dimensions
Weight 2.8Kg
Video system
-20 60 ℃℃~+
154.08mm(H)×86.58mm(V)
System Parameters
DC 11V 14V~
Auto PAL/NTSC/SECAM
Radio Parameters
Range of frequency
Display mode
Memory capacity
Search mode
FM: 87.50 -108.00MHz
AM: 522 - 1620KHz
MHz
KHz
18 FM stations;6 AM stations
Automatic/manual
TFT panel display or OSD
13
Storage temperature -30 80 ℃℃~+

Optional Accessories
1pcs
1pcs
AV output wire
5.1 AV output wire
1pcs
1pcs
AV output wire
5.1 AV output wire
14
Qty.
Model
Standard Accessories
Packing List Without Bulit-in NAV Module Packing List With Bulit-in NAV Module
1set
1pcs
1set
1pcs
1pcs
1pcs 1copy
1copy
Optional Accessories
iPod adapter
External TV box
External navigation box
Remote control
Power loudspeaker wire(Luxurious version)
USB transferring wire
1pcs
AV input wire B
User's manual
Quick guide
AV input wire A 1pcs
Qty.
Model
Standard Accessories
1pcs
1pcs
1pcs
1copy
1pcs
AV input wire A
NAV receiving antenna
Writing pen
USB transferring wire
1pcs
AV input wire B
Quick guide
1pcs
1pcs
1set
NAV map card
iPod adapter
External TV box
1pcs
Remote control
1copy
User's manual
1pcs
Steering wheel connecting wire 1pcs
Steering wheel connecting wire 1pcs
Power loudspeaker wire(Luxurious version)
AUX audio input wire
1pcs
AUX audio input wire
1pcs
