MACROMEDIA BREEZE 5 User manual

Installing and Configuring Breeze Edge Server

Trademarks
1 Step RoboPDF, ActiveEdit, ActiveTest, Authorware, Blue Sky Software, Blue Sky, Breeze, Breezo, Captivate, Central,
ColdFusion, Contribute, Database Explorer, Director, Dreamweaver, Fireworks, Flash, FlashCast, FlashHelp, Flash Lite,
FlashPaper, Flex, Flex Builder, Fontographer, FreeHand, Generator, HomeSite, JRun, MacRecorder, Macromedia, MXML,
RoboEngine, RoboHelp, RoboInfo, RoboPDF, Roundtrip, Roundtrip HTML, Shockwave, SoundEdit, Studio MX, UltraDev,
and WebHelp are either registered trademarks or trademarks of Macromedia, Inc. and may be registered in the United States or
in other jurisdictions including internationally. Other product names, logos, designs, titles, words, or phrases mentioned within
this publication may be trademarks, service marks, or trade names of Macromedia, Inc. or other entities and may be registered in
certain jurisdictions including internationally.
Third-Party Information
This guide contains links to third-party websites that are not under the control of Macromedia, and Macromedia is not
responsible for the content on any linked site. If you access a third-party website mentioned in this guide, then you do so at your
own risk. Macromedia provides these links only as a convenience, and the inclusion of the link does not imply that Macromedia
endorses or accepts any responsibility for the content on those third-party sites.
Copyright © 2005 Macromedia, Inc. All rights reserved. This manual may not be copied, photocopied, reproduced,
translated, or converted to any electronic or machine-readable form in whole or in part without written approval from
Macromedia, Inc. Notwithstanding the foregoing, the owner or authorized user of a valid copy of the software with which
this manual was provided may print out one copy of this manual from an electronic version of this manual for the sole
purpose of such owner or authorized user learning to use such software, provided that no part of this manual may be
printed out, reproduced, distributed, resold, or transmitted for any other purposes, including, without limitation,
commercial purposes, such as selling copies of this documentation or providing paid-for support services.
Acknowledgments
Project Management: Stephanie Gowin
Writing: John Norton
Editing: John Hammett
Production Management: Patrice O’Neill
Media Design and Production: AdamBarnett, Paul Benkman, JohnFrancis, Mario Reynoso
Second Edition: October 2005
Macromedia, Inc.
601 Townsend St.
San Francisco, CA 94103

3
Contents
Introduction to edge servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Connecting to Breeze through edge servers . . . . . . . . . . . . . . . . . . . . . . . 8
System requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Installing Breeze Edge Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
The Breeze Edge Server license file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Configuring FCS for Breeze Edge Server . . . . . . . . . . . . . . . . . . . . . . . . 14
Configuring FCS for SSL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Stopping and starting Breeze Edge Server . . . . . . . . . . . . . . . . . . . . . . 24
Deploying an edge server cluster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Scheduling maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

4Contents

5
Macromedia Breeze Edge
Server
For a successful installation and configuration of Macromedia Breeze Edge Server, read the
information provided in this document. It contains the following sections:
■“Introduction to edge servers” on page 6
■“Connecting to Breeze through edge servers” on page 8
■“System requirements” on page 8
■“Installing Breeze Edge Server” on page 9
■“The Breeze Edge Server license file” on page 14
■“Configuring FCS for Breeze Edge Server” on page 14
■“Mapping the DNS entry for Breeze Edge Server” on page 15
■“Configuring FCS for SSL” on page 16
■“Alternative SSL implementations” on page 16
■“HTTP tunneling” on page 17
■“Adding the required SSL tags in the Adaptor.xml file” on page 17
■“Locating the required SSL tags in the Server.xml file” on page 17
■“Stopping and starting Breeze Edge Server” on page 24
■“Deploying an edge server cluster” on page 25
■“Scheduling maintenance” on page 26

6 Macromedia Breeze Edge Server
Introduction to edge servers
Edge servers are configured to allocate and balance access to a Breeze server by using the
existing bandwidth resources more efficiently. Once the edge servers are deployed, users access
Breeze through their edge server. Edge servers authenticate these users and authorize their
requests for web services such as Macromedia Breeze Meeting rather than forwarding every
request to the Breeze server and consuming its resources for these tasks. If the data requested is
found in the edge server’s cache, it returns the Breeze Meeting data to the requesting client
(the user’s computer) without calling upon the Breeze server. This detour to the Breeze server
is transparent to users. In this scenario, no demands are placed on the origin Breeze server.
If the data requested is not found in the edge server’s cache, it forwards the client’s request to
the Breeze server, where the user is authenticated and the request for services authorized. The
Breeze server returns the results to the requesting edge server, which in turn delivers the results
to the requesting client. The edge server also stores this information in its cache, where other
authenticated users can access it. In this scenario, fewer requests for services are forwarded to
the origin Breeze server.

Introduction to edge servers 7
An edge server is configured to intercept the requests for Breeze services from a particular
zone, to collect or aggregate these requests, and transmit them to the origin Breeze server. The
Breeze server returns the results to the edge server, which forwards the data to the user’s client
computer. A networked Breeze deployment might have multiple edge servers installed. For
example, one edge server might aggregate and forward requests from San Francisco and
another might aggregate and forward requests from Boston. Each edge server gathers the
requests from its clients and forwards them to the origin Breeze server located in a data center
in Chicago, receives the responses from the origin Breeze server, then transmits and distributes
them to the clients in its zone.
Boston
Meeting X Breeze Edge
San Francisco
Meeting X Breeze Edge
Breeze
Chicago
Company A

8 Macromedia Breeze Edge Server
Connecting to Breeze through edge
servers
When edge servers are present on an organization’s network, Breeze users connect to Breeze
Meeting indirectly through the edge (or proxy) server. This connection occurs transparently.
To Breeze users, it appears that they are connected directly to the Breeze server hosting Breeze
Meeting, but they are most likely connected through the proxy or edge server servicing their
local network. Edge servers offload traffic to the origin Breeze server caching static content
like recorded Breeze meetings and presentations.
These take place behind the network connection to the Breeze server. The client (the user’s
computer) connects to the edge (proxy) server instead of making a direct connection to Flash
Communication Server (FCS) (Breeze Meeting) directly. The edge server in turn connects to
the origin Breeze server. Many additional steps, such as user authentication and permissions
authorization, are hidden from the Breeze user.
Edge servers provide an additional layer of defense between the user’s Internet connection and
the Breeze server. All traffic coming from the Internet and with Breeze as its destination goes
through the edge server.
System requirements
This release of Edge Server is certified to support up to 500 users or 50 meeting rooms. The
following table lists the hardware requirements for edge servers.
Component Requirement
Operating System Windows Server 2000
Windows Server 2003
Server Processor Pentium IV 3.6 GHz
Cache Processor 2 MB cache processor
Memory 4 GB RAM recommended
2 GB RAM minimum
Hard Drive 80 GB 10K RPM recommended
40 GB 7200 RPM minimum
Network Adaptor TCP/IP Adaptor supporting 1 GB over CAT5 Ethernet
Display SGVA supporting 800x600 or higher resolution
Drive CD-ROM or DVD-ROM

Installing Breeze Edge Server 9
Installing Breeze Edge Server
Use the procedures described in this section to install the Breeze Edge Server. Macromedia
recommends that you close all other applications before starting to install.
To install and configure Breeze Edge Server:
1. Insert the installation CD into the CD-ROM drive. If the Macromedia Breeze Edge Server
Setup wizard does not start automatically, double-click the setup.exe file in the installation
CD’s root folder.
The Welcome to the Macromedia Breeze Edge Server Setup Wizard window appears.

10 Macromedia Breeze Edge Server
2. Click Next to continue.
The License Agreement window appears.
3. Read the agreement, select I Accept the Agreement, and click Next to continue.
The Select Destination Location window appears.

Installing Breeze Edge Server 11
4. Click Next to accept the default installation location, or click Browse to select a different
location, and then click Next.
If the wizard detects a previous installation of a Breeze Edge Server, you will see the
following screen.
5. Click Next to continue.
The Select Start Menu Folder window appears.

12 Macromedia Breeze Edge Server
6. Accept the default shortcut, or click Browse to select a different location, and then click
Next.
The Ready to Install window alerts you that the Breeze installation is about to begin.
7. Review the choices for the destination folder where Breeze will be installed and for adding
Macromedia Breeze Edge Server to the Start Menu folder.

Installing Breeze Edge Server 13
8. Click Back if you want to review or change these settings, or click Install to continue.
The Installing Breeze window appears. The wizard is beginning to extract the Breeze Edge
Server files on the installation CD and install them. This process takes less than two
minutes.
9. Click Cancel at any time if you want to abort or cancel the installation.
When the installation is complete, the Completing the Macromedia Breeze Edge Server
Setup Wizard window appears.
10. Click Finish to exit the Edge Server installation.

14 Macromedia Breeze Edge Server
The Breeze Edge Server license file
When your order for Breeze Edge Server is processed, Macromedia Order Services dispatches
an e-mail with the Breeze Edge Server license file (license.lic) attached.
To install the Breeze Edge Server license file, do the following:
1. Go to c:\{install_path}\edgeserver\conf\win32\.
2. Create a folder named licenses, if it does not already exist.
3. Open the e-mail from Macromedia.
4. Save the license.lic file in the licenses folder.
With the license file in place, you can now stop and start Breeze Edge Server and FCS services
to verify that the installation was successful.
For more information, see “Stopping and starting Breeze Edge Server” on page 24.
Configuring FCS for Breeze Edge Server
Each organization configures its network differently, reflecting its business rules and
geographical distribution. The key for a successful edge server deployment is making sure that
the user’s computers (Breeze clients) receive an edge server’s IP address when resolving the
Domain Name Server (DNS) entry for the BREEZEHOST variable (formerly known as
ADMIN_HOST).
Here is a scenario for large Breeze deployments that builds upon the graphic in “Introduction
to edge servers” on page 6.
■On-site clients (Chicago users) can access the Breeze origin server directly. The Breeze
Host DNS mapping for these clients resolves to the Breeze origin server’s IP address.
■Edge servers collect off-site clients’ (Boston and San Francisco users) requests for services
and route the requests to the Breeze origin server.
■The Breeze Host DNS mapping for these remote clients resolves to the appropriate edge
server’s IP address.
■San Francisco clients access Breeze through edge server 1; Boston clients use edge server 2.
No clients in these regions communicate directly with the Breeze origin server.
Access to Breeze is determined by modifying the DNS server that is nearest to the client. To
direct Breeze users to their nearest edge server, the Breeze administrator creates a DNS entry
in the edge server’s custom.ini configuration file. For edge servers, the
FCS.HTTPCACHE_BREEZE_SERVER_NORMAL_PORT variable contains the DNS entry.

Configuring FCS for Breeze Edge Server 15
Mapping the DNS entry for Breeze Edge Server
Mapping the DNS entry for an edge server is comparable to mapping the BREEZE_HOST
variable for Breeze Server on the Breeze Application Management Console. For example, if
the value for BREEZE_HOST (the host name to use in a URL for accessing the Breeze origin
server) is breeze.mycompany.com, the DNS entry for an edge server maps
breeze.mycompany.com to the IP address of the nearest edge server.
To configure Breeze Edge Server manually:
1. Open the {install_path}\root directory.
2. Delete the custom.ini file in this directory, if there is one.
3. Create a new text file and save it as custom.ini.
4. Open the custom.ini file with a text editor, such as Notepad.
5. Add the following line to the custom.ini file:
FCS.HTTPCACHE_BREEZE_SERVER_NORMAL_PORT=yourbreezeserver:80
where yourbreezeserver:80 is the IP address or domain name and port number of the
machine where the Breeze server is installed.
The value for this variable configures the edge server to connect to the Breeze server at this
location.
6. Save the custom.ini file.
You can now start and stop Breeze Edge Server. For more information, see “Stopping and
starting Breeze Edge Server” on page 24.
Configuring the Breeze Edge Server ports
Edge servers are configured to listen on ports 80 and 443 in addition to the default port of
1935. You configure the ports by modifying the DEFAULT_FCS_HOSTPORT variable. If this
variable is not found in the custom.ini configuration file, you must add the following line to
the file:
DEFAULT_FCS_HOSTPORT=:1935,80,-443
NOTE
The values in the custom.ini file override the values in the config.ini file. The
FCS.HTTPCACHE_BREEZE_SERVER_NORMAL_PORT variable also appears in the
config.ini file. Do not change the values for any variable in the config.ini file.
NOTE
FCS.HTTPCACHE_BREEZE_SERVER_NORMAL_PORT should be the only entry in the edge
server custom.ini file.

16 Macromedia Breeze Edge Server
This tag now specifies that edge servers listen on ports 1935, 80, and 443. A port is defined as
a secure port by placing a minus sign in front of the port number in a configuration variable
or file. For example, you can configure a secure port by editing the HostPort tag of the
Adaptor.xml file.
<HostPort>:1935,80,-443</HostPort>
Port 443 is designated as a secure port that receives only RTMPS connections. Attempting an
RTMPS connection request to ports 1935 or 80 results in a failure to connect. Similarly, an
unsecured RTMP connection request to port 443 fails to connect.
Configuring FCS for SSL
To use FCS for Secure Sockets Layer (SSL)–enabled communications, a secure protocol for
transmitting private documents over the Internet, you must configure the FCS Adaptor.xml
and Server.xml files for native SSL support by defining the appropriate SSL tags.
For example, the default settings for the Redirect tag in the HTTPTunneling section of
Adaptor.xml configures FCS to handle only traffic with the RTMP and RTMPS protocols.
<Redirect enable="true">
<Host port="80">:8080</Host>
<Host port="443">:8443</Host>
</Redirect>
The default location of the FCS files is c:\breeze\conserv. The configuration files for FCS are
found in c:\breeze\comserv\win32\conf.
Alternative SSL implementations
FCS also supports the following implementations for SSL-secured transmissions:
■SSL through an external hardware accelerator
■SSL through an internal PCI card
NOTE
If your Breeze Edge Server uses an external hardware accelerator, port 443 does not
have to be configured as a secure port.
NOTE
The PCI-card based implementation has not been tested at this writing.

Configuring FCS for SSL 17
HTTP tunneling
For SSL to work properly, HTTP tunneling must be enabled. Clients use HTTP tunneling to
connect to the server via SSL.
Adding the required SSL tags in the Adaptor.xml file
All SSL tags in the Server.xml file are included by default. Not all of the required SSL tags in
Adaptor.xml are present by default, however.
You need to insert the following SSL-specific tags in the Adaptor.xml file.
<SSL>
<SSLServerCtx>
<SSLCertificateFile></SSLCertificateFile>
<SSLCertificateKeyFile type="PEM"></SSLCertificateKeyFile>
<SSLPassPhrase></SSLPassPhrase>
<SSLCipherSuite></SSLCipherSuite>
<SSLSessionTimeout>5</SSLSessionTimeout>
</SSLServerCtx>
</SSL>
Place this section right after the end tag </HTTPTunneling> but before the </Adaptor> end
root tag.
Locating the required SSL tags in the Server.xml file
The SSL-enabling tags in the Server.xml file occur in the following sequence:
■<SSLEngine>
■<SSLRandomSeed>
■<SSLSessionCacheGC>
■<SSLVerifyCertificate>
■<SSLCACertificatePath>
■<SSLCACertificateFile>
■<SSLVerifyDepth>
■<SSLCipherSuite>
NOTE
HTTP tunneling is enabled by default. No user action is required.

18 Macromedia Breeze Edge Server
Defining the SSL tags in FCS
The following table lists alphabetically all the SSL-specific tags in both the Adaptor.xml and
Server.xml files. You must configure these tags to enable SSL in FCS.
FCS File XML Tag Default Description
Adaptor.xml Redirect [none] Specifies whether unknown
requests are redirected to an
external server such as Breeze.
When FCS receives an
unknown request, the request is
redirected to the specified
redirect host. For redirection to
work, HTTP tunneling must be
enabled.
You can control which port on
the redirect host listens for
redirected traffic.
A request for redirection to a
specific host can be:
Redirect enable=false>
<Host port="80">:8080</Host>
<Host port="443">:8443</Host>
</Redirect>
Adaptor.xml SSLCertificateFile [none] Specifies the location of the
certificate file to send to the
client. If an absolute path is not
specified, the certificate is
assumed to be located relative
to the Adaptor directory.
Adaptor.xml SSLCertificateKeyFile type =
PEM
PEM Specifies the location of the
private key file for the certificate.
If an absolute path is not
specified, the key file is assumed
to be located relative to the
Adaptor directory. If the key file
is encrypted, the pass phrase
must be specified in the
SSLPassPhrase tag.
The type attribute specifies the
type of encoding used for the
certificate key file. This can be
either PEM or ASN1.

Configuring FCS for SSL 19
Adaptor.xml SSLCipherSuite Specifies the ciphers to use.
This is a list of colon-delimited
components. A component can
be a key exchange algorithm,
authentication method,
encryption method, digest type,
or one of a selected number of
aliases for common groupings.
For a list of components, see the
FCS documentation.
The default setting for this tag is:
ALL:!ADH:!LOW:!EXP:!MD5:@STRE
NGTH
Contact Breeze Technical
Support before changing the
default settings.
Adaptor.xml SSLPassPhrase [none] Specifies the pass phrase to use
for decrypting the private key
file. If the private key file is not
encrypted, leave this tag empty.
Adaptor.xml SSLSessionTimeout 5Specifies in minutes how long a
session remains valid.
FCS File XML Tag Default Description

20 Macromedia Breeze Edge Server
Server.xml SSLCACertificateFile This tag configures the server to
act as an SSL client (out-going
SSL connections), and is used
only when making outgoing SSL
connections.
This tag specifies the name of a
file that contains one or more
certificates issued by a valid
Certificate Authority (CA) in the
Privacy Enhanced Mail (PEM)
encryption format.
A CA is an organization such as
Verisign that issues certificates
to people. A certificate is
normally signed by a CA. The CA
is saying that the owner of the
certificate is who he says he is.
The CA has done the necessary
research and background
checks before issuing the
certificate to this person.
This directory specifies the
certificates for CA's that are
considered trusted. If you
encounter a certificate signed by
one of these CA's, you can trust
that the person is who he says
he is because you trust the
issuer of the certificate. Each
certificate in the directory must
be named by the subject name's
hash, and an extension of ".0".
FCS File XML Tag Default Description
