Mad Catz Kunai User manual

User Guide
[ENGLISH/05-13]

[2] [3]
Package Contents .................................................. 3
Connecting the Microphone ......................................... 4
In-line Controls .................................................... 6
Connect To
Mobile Devices ................................................. 7
PC/Mac ........................................................ 8
Speaker Tags ...................................................... 9
Warranty ......................................................... 10
Technical Support ................................................. 11
Table of Contents Package Contents
Quick Start Guide
Kunai Headset
In-line Audio Controller with Breakaway
Removable Microphone

[4] [5]
Connecting the Microphone Connecting the Microphone
1. Line up the arrows on the microphone and the headset. 2. Insert the microphone into the port on the left earcup of the headset.
Firmly push it into place, and then twist it clockwise to lock it in place.
3. Reverse the above steps to remove the microphone.

[6] [7]
In-line Controls
Game Audio Volume:
Use to adjust the volume
of the game audio.
Mic Mute: Slide the mic mute switch
so that others cannot hear you. The
orange area behind the switch will
show when the mic is muted.
AA
BB
XX
YY
SELECTSELECT HOMEHOME STARTSTART MICMIC BATTERYBATTERY POWERPOWER
Wii U™
PlayStation®Vita Tablets/Phones
Nintendo 3DS™
Connect to Mobile Device
Connect the 3.5mm jack to the
headphone output on the device.

[8] [9]
Connect to PC/Mac Speaker Tags
1. The speaker tags are held in place with magnets. Remove them by pulling
on the slots located at the top of the speaker plates.
2. To replace the speaker tags, line up the tabs on the speaker tag with the
holes at the bottom of the earcup, and then tilt the speaker tag forward so that
the magnets hold it in place.
Replacement and customized speaker tags are available at trittonaudio.com

[10] [11]
WARRANTY
2-YEAR LIMITED WARRANTY
Mad Catz warrants this product to be free from defects in materials and workmanship for the
warranty period. This non-transferable, two- (2) year limited warranty is only to you, the first end-user
purchaser. If a defect covered by this warranty occurs AND you provide proof of purchase, Mad Catz,
at its option, will repair or replace the product at no charge.
The Mad Catz two- (2) year limited warranty is available to North American and European customers.
Your sole and exclusive remedy is repair or replacement of your Mad Catz product. In no event shall
Mad Catz liability exceed the original purchase price of the product. This warranty does not apply
to: (a) normal wear and tear or abusive use; (b) industrial, professional or commercial use; (c) if the
product has been tampered with or modified.
NORTH AMERICA AND EUROPE
To receive warranty service, you must:
Obtain a Return Authorization Number from Mad Catz Technical Support via ONE
of the following methods:
a. Submit a Ticket at http://support.madcatz.com
b. Call the Mad Catz Tech Support Center nearest you:
North America: 1-800-659-2287 (USA) or 1-619-683-2815 (outside USA)
United Kingdom: 08450 508418
Europe (outside UK): [phone]
France: 01 82 88 01 80
Germany: 089-21094818
Spain: 93 181 63 94
Once you have your unique Return Authorization Number, do the following:
1. Ship the product to Mad Catz at your expense for service.
2. Enclose a copy of the original sales receipt showing a purchase date.
3. Enclose a full return address with daytime and evening phone numbers.
TECHNICAL SUPPORT
Online Support: http://support.madcatz.com
North American telephone, available Monday through Friday
(excluding holidays): 1-800-659-2287 (USA only) or 1-619-683-2815 (outside USA).
United Kingdom telephone, available Monday through Friday
(excluding bank holidays): 08450 508418.
European telephone (outside UK), available Monday through Friday
(excluding bank holidays): [phone].

[12] [13]
CAUTIONS
• Long-termexposuretoloudmusicorothersoundsinheadphonesmaycausehearingdamage.Itisbest
to avoid extreme volume levels when using headphones, especially for extended periods.
• Usethisunitonlyasintended.
• Topreventreorshockhazard,donotexposethisunittorainormoisture.Donotusewithin30’ofany
water such as swimming pools, bathtubs, or sinks.
• Toavoidelectricalshock,donotdisassemble.Referservicingtoqualiedpersonnelonly.
• Neverinsertobjectsofanykind,otherthanauthorizeditems,intotheproductastheymaytouch
dangerous voltage points or short out parts that could result in fire or electrical shock.
• Stopusingthisunitimmediatelyifyoubegintofeeltiredorifyouexperiencediscomfortorpaininyour
hands and/or arms while operating the unit. If the condition persists, consult a doctor.
• Avoidprolongeduseofthisunit.Takebreaksevery30minutes.
• Routeallcordssothattheyarenotlikelytobewalkedonortrippedover.Makesurethatcordsarenot
placed in a position or areas where they may become pinched or damaged.
• Donotwrapcordsaroundanypartofanyone’sbody.
• Donotallowchildrentoplaywithcords.
• This product contains small parts that may cause choking if swallowed. Not intended for use by children
under 3 years of age.
FCC & IC WARNING
This device complies with part 15 of the FCC Rules and Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that may cause undesired
operation.
Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’sauthoritytooperatetheequipment.
FCC Radiation Exposure Statement:
ThisequipmentcomplieswithFCCradiationexposurelimitssetforthforanuncontrolledenvironment.This
transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
IC RF Exposure Statement:
The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and compliance
with RSS-102 RF exposure, users can obtain Canadian information on RF exposure and compliance.
CAUTIONS
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type
and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential
radiointerferencetootherusers,theantennatypeanditsgainshouldbesochosenthat,theequivalent
isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.
EU DECLARATION OF CONFORMITY:
Asrequired,certainoftheseproductshavebeentestedandconformtotherequirementsofthe
European Union Directives 2002/95/EC, 2002/96/EC, and 2004/108/EC. Authorized signatory of the
manufacturer is Mad Catz, Inc., 7480 Mission Valley Road, Suite 101, San Diego, CA 92108.
05/13
