M ULTI P OINT ™ Workstation MWS8820
USER MANUAL

M ULTI P OINT ™ Workstation MWS8820
1
TABLE OF CONTENTS
INTRODUCTION........................................................................................... 2
FEATURES .............................................................................................. 2
APPLICATION......................................................................................... 3
PACKAGE CONTENTS............................................................................. 3
MINIMUM SYSTEM REQUIREMENTS .................................................... 4
OPERATING SYSTEMS SUPPORTED ....................................................... 4
FOR OPTIMUM VIDEO DISPLAY ............................................................ 4
REGULATORY COMPLIANCE .................................................................. 5
SUPPORTED DISPLAY RESOLUTIONS..................................................... 5
DEVICE INSTALLATION - SOFTWARE ........................................................... 5
INSTALLING MWS8820 HARDWARE............................................................ 8
VERIFYING THE MWS8820 CONNECTION ................................................... 8
ADJUSTING THE SCREEN RESOLUTION ..................................................... 10
DEVICE DRIVER UN-INSTALLATION ........................................................... 12
VESA MOUNTING...................................................................................... 15
TROUBLESHOOTING TIPS.......................................................................... 16

M ULTI P OINT ™ Workstation MWS8820
2
INTRODUCTION
Thank you for purchasing the MultiPoint Workstation 8820. The MultiPoint Workstation
(MW S8820) is designed specifically for Windows MultiPoint Server 2011. Simply connect it
to an available USB port on the server and attach a monitor, keyboard, and mouse to add a
new workstation. The MWS8820 features two high-speed USB 2.0 ports, audio and
microphone ports and a VGA port that supports resolutions up to 1600 x 1200. Add up to
ten MW S8820 per server. The MW S8820 provides an inexpensive and reliable way to
expand your Windows MultiPoint Server 2011 for school and office running “office
application”; “Home Entertainment” and “Full Screen Movie Playback” are not
recommended.
© 2011 Microsoft. All rights reserved.
Microsoft, Active Directory, MultiPoint Server, Office, .NET Framework, Windows, and
Windows Server are trademarks of the Microsoft group of companies. All other trademarks
are property of their respective owners.
FEATURES
zResolutions up to 1680 x 1050 (recommend), 1600 x 1200
z2 USB 2.0 Ports
zStereo Audio Output (Speaker/Headphone) and Mono audio input (Mic)
zUSB 2.0 compliant
zPlug-and-Play compliant

M ULTI P OINT ™ Workstation MWS8820
3
APPLICATION
PACKAGE CONTENTS
zMW S8820
zVESA Mounting kits
zUSB cable (2 Meters)
zDriver CD
zUser Manual

M ULTI P OINT ™ Workstation MWS8820
4
MINIMUM SYSTEM REQUIREMENTS
zAvailable USB 2.0 Port
zCPU –One of the following:
•x64-based Intel Pentium, Intel quad core (i7, i5, i3), XEON, Intel dual core.
•Compatible processor (MultiPoint Server supports up to four core & eight core CPUs
on one server)
Note:
1)AMD Opteron / Athlon, AMD Embed chipset is not recommend due to unstable
keyboard/mouse operation which may not recognize under USB1.1 device.
2)Intel Itanium Processor is not supported.
zRAM –The required RAM depends on the number of Workstation is needed:
•2 GB for 4 stations
•4 GB for 6 stations
•8 GB for 10 stations
zMulti-core processor support
•Support up to 4 & 8 multi-core processors; dual-core is less powered and therefore
only 2 to 3 workstation can be supported.
zMinimum disk space for setup
•32 GB
OPERATING SYSTEMS SUPPORTED
For optimal multimedia performance, we recommend the following CPUs:
zDual-core processor: support up to 3 stations under low processing application.
zQuad-core processor: support up to 6 stations under low processing application.
zCore-i5 processor: support up to 6 stations under low processing application.
zCore-i7 processor: support up to 8 or 10 stations under low processing application.
zWindows MultiPoint Server 2011
FOR OPTIMUM VIDEO DISPLAY
Technically, short video playbacks can be supported but the operating system needs
to be
- i7 processor
- Intel Sandy bridge chipset
Note: Extended video display at full screen is not recommended; it often exhausts CPU and
force system with much lower performance.

M ULTI P OINT ™ Workstation MWS8820
5
REGULATORY COMPLIANCE
FCC / CE / C-tick / VCCI
Tested to comply with FCC Standards.
SUPPORTED DISPLAY RESOLUTIONS
DEVICE INSTALLATION -SOFTWARE
Installing the device driver enables Windows MutliPoint Server 2011 to recognize the
MWS8820. Please make sure the MWS8820 is unplugged from your server before
executing the setup program.
Step 1
Insert the Driver installation CD into the CD-ROM drive. The installer should start
automatically. If it does not, double click Setup.exe to start the Installation Wizard.

M ULTI P OINT ™ Workstation MWS8820
6
Step 2
Driver Installation Wizard, click Next to continue
Step 3
License Agreement; review it and check I accept the terms of the license agreement
Click Next to accept the License Agreement.

M ULTI P OINT ™ Workstation MWS8820
7
Step 4
Setup is searching for installed features... *You may notice the screen flashes during
hardware installation. It is part of the normal process. .
Step 5
Driver Installation Wizard, click Finish to continue and restart the computer.

M ULTI P OINT ™ Workstation MWS8820
8
INSTALLING MWS8820 HARDWARE
Step 1
Connecting monitor to the VGA connector of the MW S8820, turn on the monitor.
Connecting power adapter, USB cable, keyboard, and mouse to the MWS8820.
Step 2
Connect one end of the USB cable to the MW S 8820 and the other end to an available USB
2.0 port of your computer. The driver installation will proceed automatically.
Step 3
Repeat steps 1 & 2 for the remaining MWS8820 on to other workstation.
VERIFYING THE MWS8820 CONNECTION
Step 1
Right click ‘Manage’from the ‘computer’ as the screen

M ULTI P OINT ™ Workstation MWS8820
9
Step 2
Point to ‘Device Manager’ on the left panel under ‘Server Manager’ go to ‘View’and click
‘Devices by type’ as the picture showed.

M ULTI P OINT ™ Workstation MWS8820
10
ADJUSTING THE SCREEN RESOLUTION
By default, Windows MultiPoint Server 2011 will select the recommended resolution for
each connected display. However, if you would like to choose a different resolution, follow
these steps:
Step 1
Please follow up the procedure on illustration for getting into “MultiPoint Manager” as 1.
Start -> 2. All Programs -> 3. Windows Multipoint Server -->Mu ltiP o in t Manager
Step 2:
Go to MultiPoint Manager => Home =>Local Station => switch to maintenance mode

M ULTI P OINT ™ Workstation MWS8820
11
Step 3:
Click OK to continue
Step 4
Press “Ctrl + Alt + Delete” to log in administrator into Maintenance Mode
Step 5
Right click on the desktop and choose Screen Resolution from the contextual menu.

M ULTI P OINT ™ Workstation MWS8820
12
Step 6
Click Identify to identify each display. Then click on the display to be adjusted and choose
the desired resolution from the Resolution dropdown menu. (suggest: better using the
system recommend resolution)
DEVICE DRIVER UN-INSTALLATION
The following procedure allows you to uninstall the MWS8820 device driver. Please
make sure all MWS8820 are unplugged from your server before executing the device
driver uninstallation program.
Step 1
1. Click Start -> 2. All Programs -> 3. Control Panel

M ULTI P OINT ™ Workstation MWS8820
13
Step 2
Double click “Uninstall a program” as illustrated on the screen.
Step 3
Select the “Magic Control Technology – MWS xx.xx.xxxx.xxxx” item. Click Uninstall button.

M ULTI P OINT ™ Workstation MWS8820
14
Step 4
Click “OK” to continue
Step 5
Select “Yes, I want to restart my computer now”and click “Finish”to reboot. The driver is
now uninstalled.

M ULTI P OINT ™ Workstation MWS8820
15
VESA MOUNTING

M ULTI P OINT ™ Workstation MWS8820
16
TROUBLESHOOTING TIPS
The following troubleshooting tips may help if you are experiencing any difficulties
using our device.
•Check to make sure that all connectors are plugged in correctly.
•Make sure that the USB port that you are using is USB 2.0.
•Try a different USB 2.0 port
•Check to see that the monitor is connected correctly and the power is ON.
•Make sure to restart the server after the driver installation.
•Unplug the USB connector from MW S8820, re-insert after 10 seconds.
•Check the website to make sure you have the latest drivers.
•Reset/refresh/resynchronize your monitor.
•Full screen video display is not recommended; use Intel Sandy Bridge chipset may help
with better performance.
For immediate support, visit http://www.mct.com.tw to find the latest documentation,
Knowledge Base articles, and software for your device.
