USB 2.0 DUAL DISPLAY HUB USER MANUAL
3
I
IN NT TR RO OD DU UC CT TI IO ON N
Thank you for purchased the USB 2.0 Dual Display HUB!
USB 2.0 Dual Display HUB, this brilliant solution enables connection to any display
device such as LCD monitor and attachment of any two USB 2.0 devices, simply
through a universal USB 2.0 cable.
This device extends your working desktop to additional two displays from the main
screen and provides considerate support of both VGA and DVI-I outputs.
By using USB 2.0 technology, there is no need to open the computer or struggling
with compatibility issues related to installation of a second / third video card.
F EATURES
Design for display device connecting to PC / laptop
USB 2.0 compliant
Support display resolution up to VGA : 1600 x 1200 / DVI : 1680 x1050
2 port USB 2.0 Hub
Plug-and-Play USB connectivity
Suspend and Hibernation modes are supported
Support Function
Display Modes: Primary, Extended, Mirror
Display Rotation: 0°, 90°, 180°, 270°
Friendly software targeted to ease your daily USB Display experience
Identify Monitors
Multi-Display Control Panel
Shortcut to access Windows Display Setting dialog
S YSTEM R EQUIREMENTS
Available USB 2.0 port
VGA or DVI compatible display device
Dual-Display (on board dual USB Displays)
CPU: Intel/AMD Single Core 3.0 GHz or higher processor
RAM: 1GB memory or higher
Additional USB 2.0 Dual Display Hub
CPU: Intel/AMD Dual Core 2.0 GHz or higher processor
RAM: 2GB memory or higher
Windows 2000 SP4 & Windows XP / Vista / 7 (32-bit or 64-bit)

USB 2.0 DUAL DISPLAY HUB USER MANUAL
4
P ACKAGE C ONTENTS
Quick Installation Guide
Driver CD (Driver & User Manual))
USB 2.0 Dual Display HUB
USB A-to-Mini-B cable (1.8M)
 2A 5V Adapter
Quick Installation Guide
H ARDWARE D RIVER S ETUP P ROCESS
Please do not plug the USB VGA Docking Station into the computer system before
the driver is completely installed.
Follow these steps to quickly install your new USB 2.0 Dual Display Hub.
1. Insert the driver CD and follow the instructions to install the device driver.
2. Connect the display monitor to the VGA (DB15) and DVI connector of USB 2.0
Dual Display Hub and switch it on.
3. Connect the AC power adapter to USB 2.0 Dual Display Hub.
4. After reboot the PC / laptop, plug the USB 2.0 Dual Display Hub into an
available USB 2.0 port of your PC/laptop.
5. You will see an icon t on the lower right toolbar on Windows 2000SP4 / XP
/Vista, or an icon ”Super Utility”under the “Shown hidden icons”on
Windows 7. And the extended displays have shown on the attached monitors.
The USB 2.0 Dual Display Hub is ready to use now.

USB 2.0 DUAL DISPLAY HUB USER MANUAL
5
S UPPORTED C OMMON D ISPLAY R ESOLUTION :
Resolution
USB-VGA
USB-DVI
Refresh Rate
Frequency
800 * 600
16bit, 32bit
16bit, 32bit
60Hz,75Hz
1024 *768
16bit, 32bit
16bit, 32bit
60Hz,75Hz
1152 * 864
16bit, 32bit
16bit, 32bit
60Hz
1280 * 720
16bit, 32bit
16bit, 32bit
60Hz
1280 * 768
16bit, 32bit
16bit, 32bit
60Hz
1280 * 800
16bit, 32bit
16bit, 32bit
60Hz
1280* 960
16bit, 32bit
16bit, 32bit
60Hz
1280 * 1024
16bit, 32bit
16bit, 32bit
60Hz
1360 * 768
16bit, 32bit
16bit, 32bit
60Hz
1400 * 1050
16bit, 32bit
16bit, 32bit
60Hz
1440 * 900
16bit, 32bit
16bit, 32bit
60Hz
1600 * 900
16bit, 32bit
16bit, 32bit
60Hz
1680 * 1050
16bit, 32bit
16bit, 32bit
60Hz
1600 * 1200
16bit, 32bit
60Hz

USB 2.0 DUAL DISPLAY HUB USER MANUAL
6
I
IN NS ST TA AL LL LA AT TI IO ON N O ON N W WI IN ND DO OW WS S 2 20 00 00 0 / / X XP P / /V VI IS ST TA A
D EVICE D RIVER I NSTALLATION
Installing the device driver enables your computer‟s operating system to recognize the
USB 2.0 DUAL DISPLAY HUB once it‟s connected. Please check your operating system
and refer to the appropriate installation procedure to begin installing the device driver.
This section illustrates the simple device driver installation procedure for computer
running Windows XP operating system. Please make sure the USB 2.0 DUAL
DISPLAY HUB is unplugged from your PC or Notebook before executing the setup
program.
Step 1.
Insert the Driver CD into the CD-ROM drive; the setup program should be launched
automatically. If setup program does not begin automatically, click Start, Run and
double click “D:\Setup.exe”(where D: is the path of your CD-ROM drive).
Step 2.
Driver Installation Wizard, click “Next”to continue.

USB 2.0 DUAL DISPLAY HUB USER MANUAL
7
Step3.
License Agreement; please read it and select “I accept the terms of the license
agreement.”Click “Next”to accept the License Agreement.
Step4.
Setup is searching for installed features…..
※ You may notice the screen flashes during hardware installation. It is part of the normal
process.
※ When the Microsoft Windows Security warning dialogue box appears, please select
“Continue Anyway” to continue with the installation. This will not affect the device driver
installation and the device usage.

USB 2.0 DUAL DISPLAY HUB USER MANUAL
8
Step 5.
Click “Finish”to complete the software installation.
Step 6.
Plug the USB 2.0 Dual Display Hub into an available USB port of your computer.
The device driver will be configured automatically, and you will see below
notification balloons.

USB 2.0 DUAL DISPLAY HUB USER MANUAL
9
※ When the Hardware Installation Wizard dialog appears, please select “No, not this time”
and click “Next” to continue. Click “Continue Anyway” when the Microsoft Software
warning dialogue box appears. Then, click “Finish” to complete the Hardware Wizard.
Step 7.
Please reboot the computer to complete the installation. After reboot, the extended
display will be shown on the attached display device, and have two icons on the
lower right taskbar. The USB 2.0 DUAL DISPLAY HUB is ready to use now.

USB 2.0 DUAL DISPLAY HUB USER MANUAL
10
V ERIFYING D EVICE D RIVER I NSTALLATION
The following procedure allows you to verify the device driver installation.
Please right click “My Computer”→“Properties”→ “Hardware” → “Device
Manager”.
Plug-in the USB 2.0 DUAL DISPLAY HUB, then double click “Display adapters”, and
“Universal Serial Bus controllers”.Begin verification by making sure highlighted
devices were added to the system.

USB 2.0 DUAL DISPLAY HUB USER MANUAL
11
D EVICE D RIVER U N - INSTALLATION
Step 1. Click “Start”→“Control Panel”→“Add or Remove Programs”
Select “Trigger External Graphics Family 12.xx.xxxx.0179”(driver version).
Click “Uninstall”button.
Step 2. Unplug the USB 2.0 DUAL DISPLAY HUB and click “OK” to continue.
Step 3. Select “Yes, I want to restart my computer now” and click “Finish” to reboot.
After reboot, you will complete the driver un-installation.

USB 2.0 DUAL DISPLAY HUB USER MANUAL
12
I
IN NS ST TA AL LL LA AT TI IO ON N O ON N W WI IN ND DO OW WS S 7 7
D EVICE D RIVER I NSTALLATION
Installing the device driver enables your computer‟s operating system to recognize
the USB 2.0 DUAL DISPLAY HUB once it‟s connected. Please check your operating
system and refer to the appropriate installation procedure to begin installing the
device driver.
This section illustrates the simple device driver installation procedure for computer
running Windows 7 operating system. Please make sure the USB 2.0 DUAL
DISPLAY HUB is unplugged from your PC or Notebook before executing the setup
program.
Step1.
Insert the Driver CD into the CD-ROM drive; the setup program should be launched
automatically. If setup program does not begin automatically, click Start, Run and
double click “D:\Setup.exe”(where D: is the path of your CD-ROM drive).
Step 2.
Driver Installation Wizard, click “Next” to continue.

USB 2.0 DUAL DISPLAY HUB USER MANUAL
13
Step3.
License Agreement; please review it and check “I accept the terms of the license
agreement.”Click “Next”to accept the License Agreement.
Step 4.
Setup is searching for installed features.....
*You may notice there a screen flashes during hardware installation. It is part of the
normal process.

USB 2.0 DUAL DISPLAY HUB USER MANUAL
14
Step 5.
Select “Yes, I want to restart my computer now”, and click “Finish”to reboot.
Step 6. HARDWARE DEVICE DRIVER INSTALLATION
After reboot, please connect the external display device (monitor/projector) to the
VGA/DVI connector of USB 2.0 DUAL DISPLAY HUB and turn on the display
device.
Then plug the USB 2.0 DUAL DISPLAY HUB
into an available USB 2.0 port of your PC or
Notebook. The device driver software
setup will begin automatically.
After the driver is configured, you also could
click “Show hidden icon”and will see the
“Super Utility”icon on taskbar.
The extended display will be shown on the
attached display device. You may begin
to use the USB 2.0 DualDisplay Hub with
your display device.

USB 2.0 DUAL DISPLAY HUB USER MANUAL
15
If the extended display come out with the duplicate or blind screen, please right click
on the desktop of your system, it will pop up a screen and select “Screen resolution”
(a),or go to “START”→ “Control Panel”→ “Appearance and
Personalization”→ “Adjust screen resolution” (b). Then, select “Extend these
displays”(c) on the Display Property.

USB 2.0 DUAL DISPLAY HUB USER MANUAL
16
After reboot the computer, the USB extended display will be shown on the attached
display device.

USB 2.0 DUAL DISPLAY HUB USER MANUAL
17
V ERIFYING D EVICE D RIVER I NSTALLATION
The following procedure allows you to verify the device driver installation.
Please right click “Computer”→ “Properties”→“Device Manager”.
Plug-in the USB 2.0 DUAL DISPLAY HUB, then double click “Universal Serial Bus
controllers”. Begin verification by making sure highlighted devices were added to
the system.

USB 2.0 DUAL DISPLAY HUB USER MANUAL
18
D EVICE D RIVER U N - INSTALLATION
Step 1. AccessProgramUninstall:
Click “Start”→“Control Panel”→“Programs”. Click “Uninstall a program”
Look for “Trigger External Graphics Family 12.xx.xxxx.0179” (driver version).
Click “Uninstall” button.
Step 2. Unplug theUSB 2.0 DUAL DISPLAY HUB and click “OK”to continue.
Step 3. Select “Yes, I want to restart my computer now” and click “Finish” to
reboot. After reboot, you will complete the driver un-installation.

USB 2.0 DUAL DISPLAY HUB USER MANUAL
19
F
FU UN NC CT TI IO ON N D DE ES SC CR RI IP PT TI IO ON N
This section describes several friendly functions provided by the USB 2.0 DUAL
DISPLAY HUB designed to ease your single or multiple USB display experience.A
display device described in this section means devices such as CRT, LCD monitor,
TV display, projector….
ACCESS USB 2.0 DUAL DISPLAY HUB UTILITY
Make sure the USB 2.0 Dual Display Hub is attached to the PC. Look for the two
icons on the lower right toolbar on Windows
2000/XP/Vista or an icon
”Super Utility”under the
“Shown hidden icons”on
Windows 7.
Right-click the icon to access the variety of functions associated to the adapter.
DISPLAY ID –Smart Display Device ID Detection
The USB 2.0 Dual Display Hub supports VESA
defined DDC/EDID. The utility could show the
display device ID whenever it is attached to the USB
2.0 Dual Display Hub.
If there is no display device attached to the USB 2.0 Dual Display Hub, an “Unknown
Monitor”ID will be shown. In some cases, the attached display device does not
support EDID, the ID will also defined as “Unknown Monitor”.
DISPLAY RESOLUTION
- Fast Access to Display Resolution Setting
The default setting resolution is:
1024 * 768 * 32bit.

USB 2.0 DUAL DISPLAY HUB USER MANUAL
20
DISPLAY ROTATION
4 options available: “0°, 90°, 180°, 270°under
the Extended or Primary display modes. It is a
useful function for some rotatable display
device.
DISPLAY MODES
“EXTENDED”DISPLAY MODE (DEFAULT)
A default display mode; this feature allows the
attached USB Display enabled display device to
work as “Extended”display of the on-board
screen. The extended working space improves
work efficiency.
You may change the relative position of this
extended USB Display enabled display device
under the Display Settings.
“MIRROR”DISPLAY MODE
This feature allows the same contents of on-
board screen to be displayed (mirroring) to the
USB Display enabled display device.
The screen resolution setting on the USB
Display enabled device will follow the on-board
screen‟s resolution. For example, if the on-
board screen‟s resolution is 1024x768x32bit,
and the USB Display enabled device will set as
the same resolution.
