Magic Flight MD BOX User manual

muad -dIb
muad0dIb
IIIIIIIIIIIIIIIII
IIIIIIIIIIIIIIII
MD BOX
MD BOX MD NOIR

IntroductIon
Welcome to the MD BOX Flight Guide. This guide
is designed to lead you and encourage creative
exploration.
You'll discover the benefits and nuances of this
powerhouse device especially designed to make
concentrates easy. You will become a dab expert
with your MD BOX, we affectionately refer to as
the DOC BOX.

IntroductIon
Replaceable
or Rheostat Plug
for the POWER
UP 3.0 or JET PAC
* NOTE: MD BETA DAB BOX does not have brass bowl
Lens

•Brass lid with optical-grade MONOCLE magnification lens inset
•Replaceable screen made of surgical grade 304 stainless steel
•Draw Whip is FDA Food Grade Silicon Tubing with Brass Tips
MD BETA - solid Maple hardwood with brass fittings & infused
with non-toxic India ink
MD NOIR - solid Maple hardwood with brass fittings, lined with a
brass bowl & infused with non-toxic India ink
MD BOX - solid Walnut hardwood with brass fittings, lined with
a brass bowl & finished with food-grade mineral oil
materials

quick start guide
•The MONOCLE LID can be closed or open during use.
•Apply a TINY dab to the screen, enough for a single hit, BEFORE
engaging Power & you may then leave the lid open or closed...
oBegin to draw immediately, just before engaging Power.
•OR you may wish to leave the lid open, engage Power & then
apply a TINY dab (like a traditional dab rig).
oBegin to draw immediately, once you lightly touch the
hot screen with your dab.
•Your dab will vaporize INSTANTLY, do not to hesitate your draw.
•ALWAYS USE THE DRAW WHIP or try one of our popular BUBBLERS
(Water Filtration) !

quick start guide
•The MD BETA BOX has a fixed screen that can be removed.
• The MD REPLACEMENT SCREEN restores any of three DAB BOX
styles (MD BETA, MD NOIR & MD BOX) to its original functionality.
oSimply unclip to remove & clip in to replace
oDO handle the screens gently.
• You may use a variety of different types of concentrates
including: wax, shatter, batter, crumble, diamonds, ice hash,
rosin, shatter, budder & more.
oRecommended: a more creamy consistency to easily
measure/apply a TINY amount.
• Applying excess dab will ONLY create a mess & waste material.

quick start guide
• You want to apply a tiny dab, so you draw in all the material at
one time.
• Excess will create a mess & waste material.
• BURN-OFF any remaining traces of residue after each use.
• DO handle your MD screens gently.

Swivel the MONOCLE LID open. Gently load a TINY amount of dab
material (enough for one hit) in proportion to above center of the
screen. Experiment to find your sweet spot.
quick start guide

Swivel the MONOCLE LENS closed (or it can remain open) & ALWAYS
insert the DRAW WHIP into the DRAW HOLE.
oAlternatively: you may prefer to pair with a BUBBLER
option (Orbiter, UFO or Bottle Rocket) attachment for
the smoothest vape experience.
quick start guide

1) Insert power supply into the chamber on the side:
A) Magic Flight Rechargeable AA Battery & press in to engage
B) Rheostat & push the button to engage
2) Begin to inhale immediately & continue drawing at a quick rate until your
draw is complete. All vapor should be captured in one breath. DO NOT PAUSE.
quick start guide

1
• Recommended: Use MAGIC FLIGHT RECHARGEABLE AA BATTERIES
o(not intended for use with any other unapproved electronic
devices or appliances)
• Insert positive nipple end of battery into the side chamber of the BOX.
oPress in battery to engage power.
oRelease pressure to disengage power.
• Disengage the battery from the MD BOX when not actively vaporizing.
oCap batteries with the black protective caps when not in use.
oDO NOT use battery if too hot. Remove & let cool.
oImproper storage, prolonged use or contact with other batteries
or metal can lead to overheating & damage the battery.
• The MD BOX will only work with NiMH batteries, 2000 mAh or higher
oIf using 3rd party batteries, the entire outer label & any
adhesive must be removed to ensure proper contact.
battery safety

3
load & draw
The MD BOX is exclusively intended for use with herbal concentrates that
melt down to a liquid.
•These types of concentrates fully vaporize & leave no plant matter
residue behind on the screen.
While we recommend only using herbal concentrates that melt down
to a liquid, other types of concentrates can also be used.
•This may however, sometimes leave small amounts of ash in the
screen which can be gently swept clean with Magic Flight's
Cleaning Brush (sold separately).

4
The inability to capture all of the vapor that is formed in one
breath is a sure sign that you've overloaded your screen with
too much concentrate material.
The screen is not meant to be scraped... if your material is sticky, engage the
power before use to warm the screen prior to loading your
material.
Doing so will allow your concentrate to slide on & absorb
optimally into the screen before vaporization.
load & draw
USE A TINY DAB... SINGLE HIT only! Overloading the screen leads to a waste of
your concentrate material & only makes a mess!
Begin to draw IMMEDIATELY... just before engaging the battery or rheostat &
continue to until there is no more visible vapor.

5
burn-off
AFTER EACH USE... simply BURN-OFF any excess concentrate to clear the screen,
reduce build up & maintain optimum taste.
To BURN-OFF... after each hit, be sure to engage your power for a few seconds.
This will heat up the screen & burn away any residue to clear
the screen before your next use & maximize the longevity of
your screen.
Replacing the SCREEN: It is time to replace the screen when the screen turns
ashy white, or if it breaks or sometimes the performance
may decrease.
Replacement time depends on usage... 1-3 months or
longer.

6
replacIng screens
SCREENS ARE FRAGILE -BECAREFUL
Remove old screen & clean all residue from
the rails
Prepare your new screen by making sure the
U-CLIPS are facing straight down (see fig. a)
Align each clip with the rails & press each clip
onto the rail with your finger (see fig. b)
Make sure the clips are fully seated on the
rails (see fig c.)

7
cleanIng
Md box
Perform BURN-OFF... Once the screen has cooled down, remove the screen.
Clean the RAILS... Dip a Q-Tip in Isopropyl Alcohol (ISO) & gently wipe the rails
clean. Then wipe down the inside of the brass bowl.
If there’s residue on the MONOCLE LENS, you can use a bit
of ISO on it as well.
BUILD-UP on the rails can impede heating...
Avoid building residue on your rails, always load a tiny
dab...enough for single use.
For Best Results: DON’T OVERLOAD material onto the screen

8
cleanIng
WHIP
Soak in hot water for about 5 minutes to loosen buildup inside of the
whip.
Hold securely from brass end and squeeze residue out of the open end
like toothpaste. Apply continuous pressure as you work your fingers
along the length of the whip.
Dry whip thoroughly & re-insert & enjoy your LAUNCH!

9
DIAGNOSTICS
When your battery has lost its juice, insert it in to your charger to recharge.
•It generally takes between 2-4 hours to fully charge.
•Batteries do have a limited life & need to occasionally be replaced.
oDepending on usage, suggested battery replacement is every
4-6 months.

11
ABOUT MAGIC FLIGHT
Magic Flight began in 2009 with the introduction of the LAUNCH BOX for
Dried Herb & then the MD BOX for Concentrates to literally help others
able breathe easier in their lives because of what we do in ours. Our
quality materials, solid construction, reliability & meticulous attention to
detail to deliver the cleanest vape possible.
Our products are the result of our conviction to make functional art that
is beautiful, useful & sustainable.
The MD DAB BOX for Concentrates is handmade in San Diego, California
by talented local artisans who infuse their handcrafted work with love &
care.
