Magic Sing EB2 User manual

EB2 Manual
WIRELESS MICROPHONE
MAGICSING

Product Overview
1. Overview
•Wireless Microphone with
2. Specifications
•Transmission
1) Group 1: 904, 906, 908, 910 MHz
2) Group 2: 918, 920, 922, 924 MHz
•RF Power: 0.003W/MHz
•Power: AA Battery 2EA (Alkaline Battery
recommended)

3. Microphone controller buttons guide

Group and Frequency channel Selection
1. Connecting a wireless microphone (pairing)
- If the wireless microphone can not be connected, connect the wireless
microphone to the unit via group and channel settings. When connected,
the microphone volume icon is displayed in the upper right corner of the
screen.
2. Group & channel setting
1) How to set group and channel Turn on the wireless microphone power
and press the corresponding number button while holding down the power
button, Change the channel.
※ When using one wireless microphone, it can be used regardless of
group A or group B. However, When two units are used, one unit must be
set to A group and the other one to B group.
2) Group and channel setting button
i. A group (LED: blue) Button 1: 1 channel Button 2: 2 channels Button 3: 3
channels Button 4: 4 channels
ii. B group (LED: green) Button 5: 5 channels Button 6: 6 channels Button
7: 7 channels Button 8: 8 channels
