Magicfx CO2JET II User manual

PRODUCT CODE : MFX1160
VERSION : 1.0
DATE
: 18.10.2017

User Manual MAGICFX® CO2 Power Jet
Page 1
1. CONGRATULATIONS!
You have bought a great new product from MAGICFX®.
MAGIC FX is a Dutch manufacturer of professional special effects machines and equipment. We have
been experts in special effects since our establishment in 1995. All our products are made under the
brand name MAGICFX® which by now has acquired a great reputation on account of its quality and
reliability. All products are made in accordance with the European Machinery Directive. MAGIC FX
manages the entire production process in-house, from the design stages and prototyping to
production. In short, we cover everything from concept to ready-to-use product.
Moreover, MAGIC FX is Europe's largest supplier of high-quality and fireproof confetti products and
streamers. Thanks to our very large stock levels, we can deliver quickly and at low prices.
MAGICFX® is used by special effects professionals all over the world and our products are distributed
through a dealer network which covers more than 80 countries.
Congratulations and enjoy your purchase!

Version 1.0
Page 2
2. CE MARKING
PLEASE NOTE:
We presume that you, your employees and others who use or come
into contact with the machine are familiar with how the machine must
be dealt with. This includes the correct use, maintenance and repair of
the machine as described in this user manual. This also means that the
employees are familiar with the use of machines through training or
experience.
DANGER WARNING:
Only use the CO2 Power Jet in accordance with the regulations and
instructions in this manual. Consult MAGIC FX in case of doubt.
Disclaimers:
MAGIC FX B.V. excludes liability for unsafe situations, accidents and damage that are the result of:
- Disregard for the warnings or regulations as set out on the CO2 Power Jet or in this
documentation.
- Use for other purposes or under other circumstances than those set out in this documentation.
- Alterations to the CO2 Power Jet. This also includes the use of replacement parts other than the
original ones.
- Insufficient maintenance.
- Unauthorised removal of safety caps and/or safeguards.
- Incompetent operation of the machine.
MAGIC FX B.V. is not liable for any consequential loss in the event of a CO2 Power Jet breakdown.
© Copyright 2012
All rights are reserved. Nothing from this manual may be duplicated, or kept in an automated data file,
or made public, or in any form or manner, whether electronically, mechanically, by photocopying, by
incorporation, or in any other manner duplicated without the permission of MAGIC FX B.V.
MAGIC FX at all times retains the right to make alterations without the direct knowledge of the client.
The contents of this user manual can also be changed.
Please contact the technical department of your supplier for extra information with regard to, for
example, maintenance and repair. This user manual has been drawn up with the utmost care. MAGIC
FX cannot be held responsible for any mistakes made in this publication or for any consequences
thereof.

User Manual MAGICFX® CO2 Power Jet
Page 3
3. DECLARATION OF CONFORMITY
DECLARATION OF CONFORMITY
(according to Annex II.1.A of the Machinery Directive)
Concerning the Machinery Directive.
We; MAGIC FX B.V.
Schouwrooij 27
5281 RE Boxtel
The Netherlands
State under personal responsibility:
We are the manufacturer of the product:
MFX1160 - MAGICFX®CO2 Power Jet
to which this statement relates and which is in accordance with the provisions of the following
Directive(s):
- Machinery Directive 2006/42/EC
- Low Voltage Directive 2006/95/EC
- EMC Directive 2004/108/EG
- Pressure Equipment Directive 97/23/EC
The following harmonising standards have been applied:
- NEN-EN-ISO 12100
- NEN-EN-ISO 60204-1
Place : Boxtel
Date : 18-10-2012
Name: MAGIC FX
Director: B. Veroude

Version 1.0
Page 4
4. FOREWORD
This manual describes the MAGICFX® CO2 Power Jet. The information in this manual is important for
the proper and safe functioning of the CO2 Power Jet. If you are not familiar with the installation,
operation, preventative maintenance etc. of the CO2 Power Jet then please read this user manual
carefully from beginning to end. MAGIC FX also insists that all new users (operators, installers,
maintenance workers and cleaners) receive a training course in which this user manual can serve as a
starting point.
MAGIC FX advises that the original of this user manual, including appendices, is kept at a safe and
central place. It is best that another original or copy is kept close to the CO2 Power Jet at the
workplace.
If you are familiar with these matters, then you can use this manual as a work of reference.
The following standard markings are used in this manual for drawing attention to certain subjects or
actions.
TIP:
Gives you suggestions and advice regarding easier or more
convenient ways to carry out certain tasks.
PLEASE NOTE:
A comment with additional information: alerts you to certain problems.
CAUTION:
The machine can be damaged if you do not follow the procedures
carefully.
DANGER WARNING:
You can get (seriously) hurt if you do not carefully carry out the
procedures.

User Manual MAGICFX® CO2 Power Jet
Page 5
CONTENTS
1. CONGRATULATIONS!.................................................................................... 1
2. CE MARKING................................................................................................... 2
3. DECLARATION OF CONFORMITY................................................................. 3
4. FOREWORD .................................................................................................... 4
5. INTRODUCTION.............................................................................................. 6
5.1 DESCRIPTION AND APPLICATION OF THE CO2 POWER JET.......................................... 6
5.2 NECESSARY ACCESSORIES .............................................................................................. 6
6. SAFETY............................................................................................................ 7
6.1 INTRODUCTION.................................................................................................................... 7
6.2 GENERAL SAFETY RULES ................................................................................................. 7
6.3 WARNINGS ........................................................................................................................... 8
7. MAIN PARTS ................................................................................................. 9
8. ACCESSOIRES.............................................................................................. 10
9. PREPARATIONS ........................................................................................... 10
10. INSTALLATION.............................................................................................. 11
11. USAGE ........................................................................................................... 15
12. SWITCHING OFF ........................................................................................... 15
13. TROUBLESHOOTING ................................................................................... 17
14. TECHNICAL DATA......................................................................................... 17
15. MAINTENANCE ............................................................................................. 17
16. GUARANTEE ................................................................................................. 17

Version 1.0
Page 6
5. INTRODUCTION
5.1 DESCRIPTION AND APPLICATION OF THE CO2 POWER JET
The CO2 Power Jet is intended to electronically blow white smoke plumes of CO2 from a distance. As
soon as the CO2 leaves the cylinder through the CO2 Power Jet’s secured high-pressure hoses, it
converts into gas. This formation of gas is accompanied by a strong hissing sound and a solid white
plume of smoke will be visible. The length of this plume is on average 8 metres. This depends on the
air humidity: in case of a high degree of air humidity, the smoke plume will be larger and in case of a
low degree of air humidity it will be smaller.
The CO2 Power Jet must be connected to a carbon dioxide (CO2) bottle with dip pipe.
The CO2 Power Jet is not suitable for other gases than those described above.
Any use other than that described above will exclude your supplier from any liability.
5.2 NECESSARY ACCESSORIES
The following parts belong to the CO2 Power Jet:
Talel 5.1
Manual
MFX0308 –Power cable
4 CO2 Bottles (with dip pipe)
4x CO2High Pressure
Hose 3/8 Male - Female
4x CO2Bottle to Hose connector CO2High Pressure Hose
3/4 Male - Female
CO2High Pressure Distribution Block
4x 3/8 Hose In 1x 3/4 Hose Out

User Manual MAGICFX® CO2 Power Jet
Page 7
6. SAFETY
6.1 INTRODUCTION
The CO2 Power Jet has been designed and constructed in such a manner that it can be used safely.
This applies to the use, the circumstances and the regulations as described in this documentation.
Reading this documentation and following the instructions are therefore necessary for everyone who is
authorised to work with the CO2 Power Jet.
The CO2 Power Jet must be placed and used in surroundings that preferably:
- Have a reasonably stable temperature of between 0 and 30ºC.
- Have a relative humidity degree of no more than 75%.
- Are reasonably free of dust, corrosive gases and high concentrations of organic vapours.
- Are not situated in the vicinity of a source of vibration.
6.2 GENERAL SAFETY RULES
-Only use the CO2 Power Jet if there are no people, animals or other objects in the direction of the
output within the output distance. The shooting direction is the direction in which the output pipe
on the CO2 Power Jet is pointed. The output distance depends on the humidity in the air.
- Make sure that children, unauthorised people and animals do not obtain access to the CO2 Power
Jet!
- Safety devices may not be removed or disabled.
- All required safety devices must be in good condition and function properly.
- Ensure sufficient lighting of the surroundings.
- Keep the workplace clean.
- Only authorised persons may carry out work with the CO2 Power Jet.

Version 1.0
Page 8
6.3 WARNINGS
Warning texts have been attached to the CO2 Power Jet. With regard to these the following rules
apply:
- These texts may not be removed or damaged. The operator must regularly check if this is the
case.
- The operator must ensure that the texts are and remain clearly visible and legible.
DANGER WARNING:
One must replace texts or signs if these are absent, damaged or
illegible.
Sign and explanation
PIC 323 Low temperatures
In case of low temperatures a low temperature
warning must be issued by means of warning
sign 323.
This is attached to the top of the CO2 Power
Jet.
Sign and explanation
PIC 616 Follow the instructions
The operator must be told that he/she may only
operate the CO2 Power Jet after reading the
user manual.
A warning is given for this by means of the
command sign of PIC 616. This sign should be
attached to the type sign. See also the photo.

User Manual MAGICFX® CO2 Power Jet
Page 9
7. MAIN PARTS
1. CO2 input 3/4 Quick Connector
2. powerCON input
3. powerCON output
4. Handle
5. LED indicator
6. Lock pin
7. CO2 output pipe
1
2
3
4
5
6
7
4

Version 1.0
Page 10
9. PREPARATIONS
Unpack the CO2 Power Jet. Dispose of the packaging material without harming the environment.
Inspect the machine for any damage. If damage is noticed this must be reported to MAGIC FX.
MAGIC FX B.V.
Schouwrooij 27
NL-5281 RE BOXTEL
The Netherlands
T. [phone]
F. [phone]
W. http://www.magicfx.eu
E. [e-mail]
8. ACCESSORIES
Please contact Magic FX for additional accessories:

User Manual MAGICFX® CO2 Power Jet
Page 11
10. INSTALLATION
CAUTION:
The machine can be damaged if you do not follow the procedures
carefully.
DANGER WARNING:
The MAGICFX® CO2 Power Jet may only be installed by adults and
authorised persons.
DANGER WARNING:
MAGIC FX is not liable for working with CO2 gas and CO2 bottles or for
the correct use thereof.
Exclusively use approved CO2 bottles (liquid carbon dioxide with dip
pipe) and consult your gas supplier about the installation, instructions,
guidelines and regulations for the safe use of the CO2 bottles.
For installing the CO2 Power Jet work in the following manner:
2.
If required you can adjust the blow pipe
to change the direction of the output.
Pull the lock pin backwards to unlock the
pipe and adjust it to the required
position.
1.
Place the CO2 Power Jet on a solid and
even surface or mount it in a truss
system using quick trigger clamps.
Always make sure that there are no people
within 3 metres of the CO2 Power Jet.

Version 1.0
Page 12
5.
Place the CO2 bottles (liquid CO2 with
dip pipe) on an even and solid surface.
Place the bottles in such a position that
the valve opening does not point in the
direction of persons or objects.
Place the CO2 bottles preferably
outdoors or in a properly ventilated
space with a CO2 detection system.
CO2 bottles are pressure containers.
That is why you must secure them with
special gas bottle brackets or chains to
prevent them falling over.
4.
Now connect the 2m long high pressure
CO2 hoses to the CO2 bottles.
Firmly secure the couplings by hand.
Turning it by hand will suffice! You should
only use a wrench if the coupling continues
to leak.
3.
In order to test it, you first need to check
if the gas valve on the CO2 bottle is still
in a closed position. Now you can check
if the CO2 Power Jet has been installed
properly by switching the electricity on
and off.
If the system has been connected
properly you will hear a clicking sound
which is produced by the opening and
closing of the magnetic valve in the CO2
Power Jet.

User Manual MAGICFX® CO2 Power Jet
Page 13
8.
Connect the hose to the CO2 Power Jet
and let it click into place so it is firmly
secure.
7.
Now connect the 3/4'’ CO2 high pressure
hose to the distribution block and check
if it is firmly connected.
6.
Connect the other ends of the CO2 high
pressure hoses to the distribution block
and check that these are properly
connected.

Version 1.0
Page 14
1
0.
When the system is properly connected
you can open the valvesof the CO2
bottles. Check for leaks.
When the gas hoses are not properly
connected gas can escape.
If this is the case then turn the couplings
tighter until gas is no longer escaping.
The CO2 Power Jet is now ready for use.
9.
The CO2 Power Jet is activated as soon
as it is powered by a 230V electricity
source. Use a 230V plug and make sure
that the electricity is switched off!
Plug the CO2 Power Jet into the
electricity socket.

User Manual MAGICFX® CO2 Power Jet
Page 15
11. USAGE
TIP:
Gives you suggestions and advice regarding easier or more
convenient ways to carry out certain tasks.
CAUTION:
The machine can be damaged, if you do not follow these procedures
carefully.
DANGER WARNING:
The MAGICFX® CO2 Power Jet may only be installed by adults and
authorised persons.
The CO2 Power Jet may only be operated if all parts are completely
and correctly installed/connected.
For using the CO2 Power Jet take the following steps:
The CO2 Power Jet can be operated with
a DMX controlled power supply. For
example a DMX FX Switchpack.
Ensure that you always have the
CO2 Power Jet in clear sight.
1.
To operate the CO2 Power Jet you press
the switch on and off. As soon as you
press the switch the magnetic valve will
immediately open and a white smoke
plume will exit from the CO2 Power Jet.
When you press the switch again to the
off position the valve will immediately
close.
Never switch for more than 3 seconds.
This way you prevent dry ice from
forming on the blow pipe and you will not
cause an accumulation of CO2 in the
room.

Version 1.0
Page 16
12. SWITCHING OFF
To switch off the CO2 Power Jet, take the following steps:
4.
Only when there is no more gas in the
hose it can be disconnected from the
gas bottle and the CO2 Power Jet.
3.
Disconnect the plug(s) of the CO2 Power
Jet from the power supply.
2.
Activate the CO2 Power Jet one more
time to remove the remaining pressure
from the hose.
Make sure that you only activate the jet
when there are no people, animals or
objects in the trajectory of the cannon.
1.
Close the valves of the gas bottles.

User Manual MAGICFX® CO2 Power Jet
Page 17
13. TROUBLESHOOTING
-The CO2 Power Jet is leaking
Check if the coupling of the gas hose is connected properly to the coupling of the CO2 Power Jet. If it
is not entirely secured then press it firmly. This is only possible when there is no pressure on the hose.
If the problem persists, then consult the technical service of MAGIC FX.
-Only a small smoke plume is visible when the CO2 gas exits the CO2 Power Jet.
Visibility can vary due to air humidity. The output will be more visible when there is high absolute air
humidity.
-There is no white smoke plume visible when the CO2 gas exits the CO2 Power Jet.
You may not have the right carbon dioxide cylinders. Connect cylinders with liquid carbon dioxide and
a dip pipe to the CO2 Power Jet.
In some cases the dip pipe may be broken. In that case replace the carbon dioxide cylinder with
another and inform your gas supplier about the cylinder with the defective dip pipe.
-The CO2 Power Jet is still malfunctioning after troubleshooting
Always contact your dealer or the technical service of MAGIC FX first in case of uncertainties,
questions about the CO2 Power Jet works or other issues with regard to the CO2 Power Jet.
14. TECHNICAL DATA
Measurements
and weight
Length:
270mm (10.6”)
Width:
260mm (10.2”)
Height:
350mm (13.8”)
Weight:
7,5 Kg (16,5lbs.)
Power
Input:
AC 230V~50-60Hz
Output:
AC 230V~50-60Hz
Power:
100W
CO2
Input:
Liquid CO2
Output:
CO2 Gas
Usage:
2 Kg/s (1.1 lbs/s)
Quick Connector:
3/4
Design and product specifications can be changed without prior notification.
15. MAINTENANCE
To achieve the maximum service life of the CO2 Power Jet you must regularly clean the CO2 Power Jet
and test if it is working correctly.
Should the CO2 Power Jet not work for some reason then please contact MAGIC FX.
DANGER WARNING:
Do not replace parts yourself; always consult MAGIC FX if necessary.
16. GUARANTEE
A manufacturer's guarantee of 3 years applies to the MAGIC FX CO2 Power Jet.
- The guarantee expires if the CO2 Power Jet is used for improper purposes and for applications
which are not stated in this manual.
- The guarantee also expires if the machine is used incorrectly or in violation of the regulations.
- The guarantee expires if the machine is altered without permission from the supplier.

WWW.MAGICFX.EU
