Magicfx PSYCO2JET Operating manual

PSYCO2JET.®
CO2 FX
PART01127
rev 01-00
USER AND INSTALLATION MANUAL
ENGLISH

2 MAGICFX® PSYCO2JET —User and Installation Manual
DISCLAIMER
WARNING
Read this manual carefully before installing and/or using this product. Failure to
read the manual and to follow the printed instructions may lead to personal
injury and/or damage to the product.
© 2017 MAGICFX®
All rights reserved.
Nothing from this publication may be copied, reproduced and/or published by means of printing,
photocopying or by any other means, without the prior written approval of MAGIC FX.
MAGIC FX reserves the right to modify specications stated in this manual.
TRADEMARKS
Any brand names mentioned in this manual are registered trademarks of their respective owners.
LIABILITY
MAGIC FX accepts no liability for claims from third parties arising from unauthorised use, use other
than that stated in this manual, and use other than in accordance with the General Conditions
registered at the Chamber of Commerce.
Refer further to the General Conditions. These are available on request, free of charge.
Although considerable care has been taken to ensure a correct and suitably comprehensive
description of all relevant components, the manual may nonetheless contain errors and
inaccuracies.
Should you detect any errors or inaccuracies in the manual, we would be grateful if you would
inform us. This helps us to further improve our documentation.

MAGICFX® PSYCO2JET —User and Installation Manual 3
TABLE OF CONTENTS
Disclaimer 2
Trademarks 2
Liability 2
Foreword 4
Language 4
Revision table 4
1 Meet the MAGICFX®PSYCO2JET! 5
1.1 Main parts 5
1.2 Technical data 6
1.3 Productidentication 7
1.4 Accessories 7
1.5 Displaypanel 7
1.6 RAW mode 9
1.7 PRESETmode 10
1.8 RDM capability 13
2 Blast safely! 14
2.1 General safety rules 14
2.2 CO2 14
2.3 Indoor use 14
2.4 Rigging 15
2.5 Noise level 15
2.6 Safety symbols 15
2.7 Precautionsforoperation 15
3 Let’s blast! 16
3.1 Mount on a stage 16
3.2 Mount on a truss 18
3.3 Connect DMX and power 21
3.4 Setup multiple machines in a sequence 22
3.5 Connect CO2 23
3.6 Blast with DMX 25
3.7 ReplaceaCO2cylinder 26
3.8 Clean up 28
4 Maintenance 30
5 Troubleshooting 30
6 Correctdisposal 30
7 ECDeclarationofConformity 31

4 MAGICFX® PSYCO2JET —User and Installation Manual
LANGUAGE
This document contains the original instructions in English. In case you require other languages
please contact MAGIX FX.
REVISION TABLE
Document nr Revision Date Description Authored by Checked by
PART01127 01-00 13-02-2017 Initial release TFR TVA
FOREWORD
Congratulations! You have bought a great new product from MAGIC FX.
This manual contains all information required for the intended use of the equipment. Deviation
from the described intended use can result in a hazardous situation and/or property damage.
This manual includes notes and warnings on safe operation of the equipment. These notes and
warnings are accompanied by the following icons. Read them attentively!
DANGER Indicates a hazardous situation that, if not avoided, will result in death or serious
injury. This signal word is to be limited to the most extreme situations.
WARNING Indicates a hazardous situation that, if not avoided, could result in death or
serious injury.
CAUTION Indicates a hazardous situation that, if not avoided, could result in minor or
moderate injury.
NOTICE Indicates information considered important, but not hazard-related
(e.g. messages relating to property damage).

MAGICFX® PSYCO2JET —User and Installation Manual 5
1 MEET THE MAGICFX®PSYCO2JET!
The MAGICFX® PSYCO2JET is a special eects machine that blasts CO2into the air.
The MAGICFX®PSYCO2JET is equipped with a CO2powered rotating nozzle. A solenoid valve
controls the supply of liquid CO2to the nozzle. From the nozzle, the CO2escapes through the
output pipe. A blast of escaping CO2is accompanied by a strong hissing sound and a white
plume of smoke will be visible from the output pipe. The nozzle with output pipe is mounted on
a180° rotatable pipe, driven by an electric motor. By blasting and varying the output direction the
MAGICFX® PSYCO2JET delivers spectacular eects.
The MAGICFX® PSYCO2JET is outtted for operation:
• with DMX and optionally RDM;
• in RAW mode or in PRESET mode;
• in sequence with multiple machines.
The MAGICFX®PSYCO2JET is mounted on a truss or on stage.
1.1 MAIN PARTS
FX LED INDICATOR
OUTPUT PIPE
CO2INPUT
DMX INPUT & OUTPUT
(5-POLE)
DISPLAY AND BUTTONS
POWER INPUT & OUTPUT
(100-250VAC)
SAFETY EYE
FRONT SIDE
as seen by the audience in most cases
BACK SIDE
with display, buttons and connections
Main parts in backside view
All operational tasks and soware presets are oriented as if one is facing the front side of the unit.

6 MAGICFX® PSYCO2JET —User and Installation Manual
1.2 TECHNICAL DATA
Product Product Name MAGICFX® PsyCO₂Jet
Product Code MFX1117
Product Type CO2FX
Main
Dimensions
Length (mm/in.) 330 13
Width (mm/in.) 250 9,8
Height (mm/in.) 165 6,5
Weight Empty weight (kg/lb.) 8,2 18,1
Package Length (mm/in.) 480 18,9
Width (mm/in.) 350 13,8
Height (mm/in.) 270 10,6
Packaged weight (kg/lb.) 9 19,8
Environment Minimum Temperature (ºC/ºF) -10 14
Maximum Temperature (ºC/ºF) 50 122
Humidity (Relative) 20% to 90% (non condensing)
IEC 60529 (IP) Rating IP23
Electrical Voltage Input (Vac) 100 – 250 Vac
Voltage Frequency 50 – 60 Hz
Power Consumption (Vac) 35 W
Power Connector (Vac) Neutrik®powerCON TRUE1 (in & out)
Voltage Input (Vdc) -
Power Consumption (Vdc) -
Power Connector (Vdc) -
Battery -
Controlling Control Options DMX
Control Protocols DMX512-A (ANSI E1.11) / RDM (ANSI E1.20)
Control Connectors Neutrik®5 pole male / female XLR
Conguring Congure Options On Device & RDM
Usage Consumable(s) -
Consumable Consumption -
Propellant Liquid CO2
Propellant Connector CO2 Quick Connector 3/8”
Propellant Consumption 0,5 L/s
Technical data

MAGICFX® PSYCO2JET —User and Installation Manual7
1.3 PRODUCT IDENTIFICATION
Type plate
1.4 ACCESSORIES
Code Product
MFX1114 CO₂ High Pressure Hose 3/8 Male - Female, 1.25M
MFX1105 CO₂ High Pressure Hose 3/8 Male - Female, 2M
MFX1106 CO₂ High Pressure Hose 3/8 Male - Female, 3M
MFX1107 CO₂ High Pressure Hose 3/8 Male - Female, 6M
MFX1108 CO₂ High Pressure Hose 3/8 Male - Female, 10M
MFX1109 CO₂ High Pressure Hose 3/8 Male - Female, 15M
MFX1110 CO₂ 90 Degrees Connector 3/8
MFX1103 CO₂ Bottle to Hose Connector
MFX1115 CO₂ Bottle to Hose Connector 90 Degrees
Accessories
Please contact MAGIC FX for additional possibilities.
1.5 DISPLAY PANEL
MAIN MENU
DMX/RDM SETTINGS
BACK PREV NEXT
SELECT
Display panel
The display panel is located on the backside of the MAGICFX®PSYCO2JET. Check the
followingmenu structure for all options in the menu. Use the buttons for navigation and selection.
The le-hand LED blinks red when DMX is active. The right-hand LED blinks red when anerror
hasoccurred.

8 MAGICFX® PSYCO2JET —User and Installation Manual
Idle Display
Main Menu
DMX Start Address (1-512)
DMX Safety Address (1-512)
Control Mode (RAW/PRESET)
DMX Footprint (1-511)
RDM (On/O)
Lock/Unlock Controller
Reset Errors
DMX/RDM Settings
Error History
Serial Number (DDDDD)
Unique ID (HHHHHHHHHHHH)
Soware Version
Soware CRC
Bootloader CRC
Build Date
Information
Nozzle Mirror Function (On/O)
Conguration
Nozzle Block Le (140-255)
Output When Blocked (On/O)
Display Dimmer (On/O)
Display Flip (On/O)
Nozzle Block Right (0-116)
Nozzle Calibration (-5-5)
Factory Defaults (Yes/No)
Type (Alarm/Error)
Menu structure

MAGICFX® PSYCO2JET —User and Installation Manual 9
1.6 RAW MODE
In RAW mode, the operator controls the output of the MAGICFX®PSYCO2JET directly. With DMX the
operator controls the following variables:
• The angle of the rotating nozzle and output pipe, see gure
• The speed of rotation
• The output (CO2valve open or closed)
RAW mode is selected from the operator menu. Check Section 1.5 for the menu structure.
0°
+90°-90°
OUTPUT PIPE
ROTATING NOZZLE
Output angle when facing the front side of the unit
In RAW mode the MAGICFX®PSYCO2JET is controlled with 1 safety address and 3 operational
addresses.
DMX Address Address range
Safety address 1 - 512
Start address (Angle) 1 - 512
Start address + 1 (Speed) 1 - 512
Start address + 2 (Output) 1 - 512
DMX addresses
The Safety address cannot be the same as one of the operational addresses.

10  MAGICFX®PSYCO2JET —User and Installation Manual
Operating of the addresses in RAW mode results in the following:
DMX Address DMX Value (Decimal) Result
Safety address
0 99 Device disabled
100 155 Device enabled
156 255 Device test mode (CO2output is disabled)
Start address (Angle)
0 126 -90° to -0,7°
127 128 Center position
129 255 +0,7° to +90°
Start address + 1 (Speed) 0 255 Minimal speed -> Full speed
Start address + 2 (Output) 0 199 Valve o
200 255 Valve on
Operation of the DMX addresses
When you link multiple machines with DMX, we advise you to use the same Safety address for all
machines.
CAUTION Always plug in a DMX Terminator into the DMX output of the nal unit in the
control sequence. Using a DMX Terminator improves signal reliability.
1.7 PRESET MODE
In PRESET mode, the operator controls the output of the MAGICFX®PSYCO2JET with the help of one
of the preprogrammed presets. With DMX the operator controls the following variables:
• The selected preset
• The speed of rotation of the output pipe
• The directions of the output pipe
• The ´Go´ mode:
• OFF (No movement)
• Continuous (The preset is repeated continuously)
• Step in preset (Step by step)
PRESET mode is selected from the operator menu. Check Section 1.5 for the menu structure.
