Magnavox MHT890 User manual

Any changes or modifications not expressly
approved by the party responsible for com-
pliance could void the user's authority to
operate the equipment.
RF warning for Mobile device:
This equiment should be installed and
operated with minimum distance 20cm
bwtween the radiator & your body.

5
LOCATION OF CONTR0LS
Top:
1. LED lights On-Off
2. Microphone Echo Knob
3. USB Port (For music playback)
4. SD Card Slot
5. ROCK Mode (Equalizer)
6. POP Mode (Equalizer)
7. FLAT（OFF）Mode (Equalizer)
8. CLASSIC Mode (Equalizer)
9. JAZZ Mode (Equalizer)
10. Microphone (In) Jack

6
11. Guitar (In) Jack
12. BASS Adjustment Knob
13. TREBLE Adjustment Knob
14. Master Volume Knob
15. Repeat Button (For USB/SD Card Mode）
16. ►►I /CH+ (Skip forward/Fast forward/Radio tuning up) Button
17. ►II/SCAN (Play-Pause/Radio Program Preset) Button
18. I◄◄ (Skip backward/Fast rewind/Radio program down) Button
19. LED Display
20. Remote Receiver
21. MODE Button
22. Microphone/Guitar Volume Knob
Rear:
1. POWER ON/OFF Switch
2. DC 21V (In) Jack
3. AUX (In) Jack
4. Line out R
5. Line out L
6. FM Antenna

7
REMOTE CONTROL:
1. STOP Button (For USB/SD Mode)
2. Numeric Buttons
3. I◄◄ (Skip backward/Fast rewind/Radio program down) Button
4. Repeat button (For USB/SD Card Mode）
5. ►II/PP/SCAN (Play-Pause/Radio Program Preset) Button
6. MODE Button
7. 10+ Button
8. VOL + (Volume Up ) Button
9. ►►I /CH+ (Skip forward/Fast forward/Radio tuning up) Button
10. VOL - (Volume Down ) Button
11. MUTE Button
12. EQ Mode Select Button
13. Battery Holder

8
POWER SOURCE:
Connect the small plug from the supplied AC/DC Adaptor to the DC 21V (In) Jack on
the rear of unit then plug the AC/DC Adaptor to a AC wall outlet having AC 100-240V~;
50/60Hz as illustrated below:
NOTES:
If you will not use the unit for an extended period of time, unplug the AC/DC
Adaptor from wall outlet.

9
Remote Control:
First time use:
Remove and discard the insulation film as illustrated below:
Replacing the button cell when it is drained as follows:
Push and slide out the button cell holder as illustrated below.
Replace the button cell with new CR2025 button cell with the polarity
markings on the rear of the Remote Control.
Close the button cell holder.
Battery precautions:
Follow these Battery Precaution when using a battery in this device:
1. Use only the size and type of battery specified.
2. Be sure to follow the correct polarity when installing the battery as indicated in the
battery compartment. A reversed battery may cause damage to the device.
3. Do not mix different types of batteries together (e.g. Alkaline and Carbon-zinc) or
old batteries with fresh ones.
4. If the batteries in the device are consumed or the device is not to be used for a
long period of time, remove the batteries to prevent damage or injury from
possible battery leakage.
5. Do not try to recharge the battery not intended to be recharged; it can overheat
and rupture. (Follow battery manufacturer’s instructions.)
6. Do not dispose of battery in fire. Battery may explode or leak.
7. Clean the battery contacts and also those of the device prior to battery
installation.
8. This product contains a coin/button cell battery. If the coin/button cell
