Magnavox MS3250C User manual

TABLE OF CONTENTS
Getting Started
Warning/Important Notice . . . . . . . . . . . . .1
Basic Cable Television Connection . . . . . . .1
Basic Antenna Television Connection . . . . . . . . . . . .1
Basic VCR/Accessory Device Connection . . . . . . . .1
Basic Television Operation . . . . . . . . . . . . . . . . . . . .2
Basic Remote Control Operation . . . . . . . . . . . . . . .2
Setting your TV for the first time . . . . . . . . . . . . .3-4
Using the On-screen menu . . . . . . . . . . . . . . . . . . . .3
Using the Language Control . . . . . . . . . . . . . . . . . .3
Setting the Tuner Mode Control . . . . . . . . . . . . . . .3
How to Automatically Program Channels . . . . . . . .4
How to Add and Delete Channels . . . . . . . . . . . . . .4
Quick Use and Setup Guide
12 1
2
3
4
5
6
7
8
9
10
11
BASIC TELEVISION CONNECTIONS
Quick Use and Setup Guide
IMPORTANT
NOTE: This owner's manual is used with several
different television models. Not all features (and
drawings) discussed in this manual will necessar-
ily match those found with your television set.
This is normal and does not require you contact-
ing your dealer or requesting service.
WARNING: TO PREVENT FIRE OR SHOCK
HAZARD DO NOT EXPOSE THIS UNIT TO
RAIN OR EXCESSIVE MOISTURE.
3121 233 40921
75 V
IN
OUT
1
2
75V
VIDEO
L/
Mono
AUDIO
R
Monitorout AV1in
S-VIDEO
Your Cable TV input into your home may be a
single (75 ohm) cable, or a
Converter Box installation.
In either case the connec-
tion to the TV is very easy.
Just put the threaded end
of the cable signal to the
TV's antenna plug and
screw it down finger tight.
CABLE TV
CABLE INPUT/CONVERTER
75 V
OR
OUT TO TV
IN FROM ANT.
1
2
75V
VIDEO
L/
Mono
AUDIO
R
Monitorout AV1in
S-VIDEO
The basic Antenna, or Cable TV, to VCR to
TV connection is shown to
the right. For more infor-
mation on other hookups
(possible when Cable
Converter/Descrambler
boxes are included) refer to
your accessory VCR and
Cable Converter Owner's
Manual for details.
TV TO VCR
BASIC CONNECTION
If your Cable TV signal
is a single round cable (75
ohm) then you're ready to con-
nect to the TV.
If you have a Cable
Converter Box:
Connect the Cable TV signal to
the Cable Signal IN(put) plug
on the Converter.
Connect the Cable TV cable to
the ANTENNA/CABLE plug on the TV.
If you have a Cable Converter Box:
Connect the OUT(put) plug from the
Converter to the 75Ωplug on the TV.
Connect your
Antenna or Cable TV signal
to the IN FROM ANT(enna)
plug on the VCR.
Connect the OUT TO
TV plug on the VCR to the
75Ωplug on the TV (connect-
ing cable supplied with the
VCR.)
Back of TV
Round Cable
75ΩOhm
Cable TV Converter
Box Connection
Cable TV Company
Remember:
Set the TV for the
type signal you've
just connected (see
the “Tuner Mode”
section on page 3 of
this Set-Up Guide.)
To select only the
channel numbers on
your Cable system
see “Auto Program"
(page 4). If you use a
Cable Converter box,
set the TV to the
same channel as the
converter's CH 3/4
switch (on the rear of
the converter.)
SMART
HELP
Cable TV Signal Input
Round Cable
75ΩSupplied with VCR
Outdoor
VHF/UHF
Antenna 300 to 75Ω
Ohm Adapter
Cable TV signal Back of TV
Refer to the Owner's
Manual included with your
VCR for other possible con-
nections and TV/VCR operat-
ing details.
OR
NOTE: The connecting cable
for the Converter is supplied
from the Cable TV Company.
VCR
75 V
12
75V
VIDEO
L/
Mono
AUDIO
R
Monitorout AV1in
S-VIDEO
Acombination antenna receives normal broad-
cast channels (VHF 2-13
and UHF 14-69). Your
connection is easy since
there is only one 75Ω
(ohm) antenna plug on the
back of your TV - and
that’s where the antenna
goes.
ANTENNA
COMBINATION UHF/VHF Remember,
be sure to set the TV
for the type signal
you've connected
(see the “Tuner
Mode” section on
page 3 of this Set-
Up Guide.)
To set the TV to
select only the chan-
nel numbers in your
area see how to
“Program" or "Add"
channels in memory
on page 4 (Auto
Program section).
To order any option-
al accessory contact
your dealer or call
the toll-free accesso-
ry ordering number
(1-800-851-8885).
SMART
HELP
If your antenna has a
round cable (75 ohm) on the end,
then you're ready to connect it to
the TV.
If your antenna has flat twin-lead
wire (300 ohm), you first need to
attach the antenna wires to the
screws on a 300 to 75 ohm adapter.
Push the round end of the
adapter (or antenna) onto the
75Ωplug on the rear of the TV.
If the round end of the antenna
wire is threaded, screw it down
finger tight.
300 to 75Ω
Adapter
Combination VHF/UHF
Antenna
(Outdoor or Indoor) Twin Lead
Wire
Round Cable
75ΩBack of TV
OR
Note: For homes with separate UHF and VHF
antennas you will need an optional combiner
to connect to the TV.
75V
VIDEO
L/
Mono
AUDIO
R
Monitorout AV1in
S-VIDEO
U/V
Combiner
75-300 Ohm Adapter
Back of TV
Color
Television
Color
Television
