Magnum Industrial MI-11600 User manual

MODEL NO.: MI-11600 / MI-11650
OPERATING MANUAL
SAFELY RULES - CONSIGNES DE SECURITE
WARNUNG
AVERTISSEMENT
!
!
MFG. NO.:
SERIAL NO.:
H.P. :
VOLT :
H.Z. :
PHASE
:
:
DATE :
R.P.M.
TR. / MN.
CSA :
AMP.
:
MODEL NO.:
MADE IN TAIWAN/ FABRIQUÉ EN TAIWAN

1
RULES for SAFE OPERATION
MAGNUM INDUSTRIAL MI-11600 & MI-11650 Air Cleaners
To help ensure safe operation, take a moment to learn the how to operate the machine and understand its
applications and limitations, as well as potential hazards. Make sure you understand all caution labels on
the unit. KMS Tools and Equipment disclaims any real or implied warranty and holds itself harmless for any
injury that may result from the improper use of its equipment.
• Do not operate the machine when tired, distracted or under the eects of drugs, alcohol or any medication that impairs
reexes or alertness.
• Ensure your working area is well lit and free of debris.
• Keep children and visitors at a safe distance when the machine is in operation. Do not permit them to operate the machine.
• Prevent unauthorized or unsupervised use by child proong and tamper proong your shop and all machinery with locks,
master electrical switches and switch keys.
• Stay alert! Give your work your undivided attention. Even a momentary distraction can lead to serious injury.
• Fine particulate dust is a carcinogen that can be hazardous to health. Ensure your shop is well ventilated. Protect your face,
eyes, ears, lungs and body with suitable personal protective equipment.
• Do not use the system near, or to lter, ammable or combustible liquids, gases, gasoline or other fuels, lighter uid,
cleaners, oil-based paints, natural gas, hydrogen, or explosive dusts like coal, magnesium, grain, or gunpowder
• Do not use the system to lter anything that is burning or smoking, such as cigarettes, matches, or ashes. Do not use the
system to lter toxic materials.
• Do not wear loose clothing, gloves, bracelets, necklaces or other jewelry near the ltration system.
• Keep the intake and exhaust vents clear of dust, lint, hair, or anything that may limit air ow. Do not use the system if the
vents are clogged or blocked. Do not put objects in the vents. Do not use the unit if the element is not correctly installed.
• Do not use the ltration system outdoors or near wet surfaces.
• Never leave the machine unattended while it is running or with the power on.
• Never stand on machinery.
• Always disconnect the machine from the power source before changing the lter element; performing any maintenance,
cleaning or servicing; or leaving the machine unattended. Never pull on the cord. Do not touch the plug with wet hands.
• Ensure the switch is in the OFF position before plugging in the power cord.
• Make sure the machine is properly grounded. If equipped with a three-prong plug, use it with a three-pole receptacle. Never
modify the plug. If you're not sure if the machine is properly grounded, contact a qualied electrician.
• When using an extension cord, ensure that it is the correct length and gauge to supply enough current for the unit. Do not
use damaged, worn, or broken extension cords. If you're not sure if your cord is suitable, contact an electrician.
• If power cord, plug, or any other electrical component is visibly damaged, do not use this ltration system. If the system is
missing parts, is visibly damaged, was le outdoors, dropped in water, or is not functioning, contact a qualifed technician.
• Do not use this machine for other than its intended use. If used for other purposes, KMS Tools and Equipment disclaims any
real or implied warranty and holds itself harmless for any injury that may result from that use.

2
CLEANIN FILTER MEDIA
MAGNUM INDUSTRIAL MI-11650 Air Cleaner
Your Magnum MI-11650 air cleaner includes a two stage HEPA and electrostatic ltration system. Under normal shop conditions,
your HEPA lter will require cleaning once a month. To clean your lter elements, follow these steps:
CLEANIN HEPA FILTER
1. Vacuum the intake side of the HEPA lter. Use your brush attachment for best results.
2. Blow o the opposite side of the HEPA lter with compressed air. To protect the element, don’t hold the blow gun too close.
WASHIN ELECTROSTATIC FILTER
1. Rinse the intake side with water at normal garden hose pressure
2. Repeat for opposite side
3. Soak in warm, slightly soapy water
4. Rinse both sides again with garden hose pressure
5. Let drip dry
6. Reinstall the element once it is totally dry
Troubleshooting Chart: MI-11600 & MI-11650
Issue Possible Cause Possible Solution
Motor doesn't run when power
switch is ON
• Switch is burnt out
• Wire is loose or damaged
• Replace the switch
• Tighten or replace the wire
Motor doesn't run at full speed • Voltage is too low
• Motor is damaged
• Check power supply
• Check and repair motor
Motor doesn't reach full speed • Power cord is not suitble
• Motor is damaged
• Use correct power cord
• Check and repair motor
Motor overheats • Power supply voltage is not correct
• Motor is damaged
• Check voltage
• Check and repair motor
Suction power is insucient • Inlet or exhaust ports are blocked
• Filter media is clogged
• Check and clear ports
• Clean lter media
Air lter shakes • Unit is not mounted securely
• Unit is not level
• Secure mounts
• Check and level the unit

3
MANUM INDUSTRIAL 5-YEAR LIMITED WARRANTY
ank you for purchasing Magnum Industrial. Your new Magnum Industrial tool has been designed and manufactured
to deliver high-quality performance and dependability over a long service life. Before leaving the factory, every Magnum
Industrial product is tested and checked for quality.
5YEAR LIMITED WARRANTY
Magnum Industrial woodworking and metalworking machinery is backed by a 5-year limited warranty. is warranty covers
replacement parts against manufacturer's defect.
• is warranty does not cover parts that have been modied or damaged through misuse, lack of maintenance, negligence,
accidents, natural disasters, inadequate dust collection or excessive production demands.
• is warranty does not cover consumable parts or parts that are subject to regular wear and tear during normal operation.
Examples of wear and tear parts include drive belts, bearings and switches.
• is warranty does not cover parts damaged during shipping or transportation.
To make a warranty claim, the original purchaser must contact a Magnum Industrial representative and provide documented
proof of purchase. Once the representative conrms that the damage has occurred due to manufacturer's defect, Magnum
Industrial will ship a replacement part or parts prepaid to the original purchaser. e original purchaser may choose to install the
replacement parts or transport the machinery to an authorized Magnum Industrial service centre for installation. Transportation
costs are not covered by the warranty.
As determined on a case-by-case basis, parts may need to be inspected by an authorized Magnum Industrial representative
before parts are eligible for warranty. In these cases, the original purchaser is responsible for transporting the parts to a
representative or an authorized Magnum Industrial service centre.
LABOUR AND TRANSPORTATION COSTS
e original purchaser may choose to transport the machinery to an authorized Magnum Industrial service centre for warranty
evaluation. Transportation costs and expenses related to moving machinery to and from carrier vehicles are not covered by the
warranty.
Once the machinery has been evaluated by the authorized Magnum Industrial service centre, any parts damaged due to
manufacturer's defect will be replaced and installed at no cost. Labour is covered by warranty only when completed by an
authorized Magnum Industrial service centre. e warranty does not cover third-party repairs.
ORIINAL PURCHASER OF THE PRODUCT
is warranty is non-transferable and applies to the original purchaser only. is warranty requires documented proof of
purchase.
MANUAL
is manual is a guide for assembling and adjusting this product. It is not a woodworking or metalworking training manual.
It is the end user's responsibility to understand how to safely set up, operate, and maintain woodworking and metalworking
machinery. Because product specications can change without notice, some details in this manual may not apply to the product
you purchased.
DISCLAIMER
KMS Tools and Equipment and Magnum Industrial holds itself harmless for any injury or property damage that may result from
the use of this product.

16
15
10
19
17
5
1
20
11
9
18
5
17
12
8
13
21
22
4
2
3
23
11
25
27
26
24
14
7
PARTS LIST FOR MI-11600 / MI-11650

ITEM NO. PARTS NO. DESCRIPTION SPECIFICATION Qty
1MI-11600-01 Main Housing 1
2 MI-11600-02 Fan Housing 1
3 MI-11600-03 Fan 1
4 MI-11600-04 Rubber Washer 3
5 MI-11600-05 Filter Fix Plate 2
7 MI-11600-07 Capacitor cover 1
8 MI-11600-08 Bushing 1
9 MI-11600-09 Switch Plate 1
10 MI-11600-10 Power Cord 1
11 MI-11600-11 Round HD screw M4*8 5
12 MI-11600-12 Round HD screw M5*25 2
13 MI-11600-13 Capacitor 1
14 MI-11600-14 Set Screw M6*8 1
15 MI-11600-15 Inner Filter
MI-11600-16
1
16
MI-11650-15H
Outer Filter
MI-11650-16H
17 MI-11600-17 Rivet 4-2 4
18 MI-11600-18 Button HD screw 1/4"x 1/2" 6
19 MI-11600-19 Hanging Screw 4
20 MI-11600-20 Pulling Switch 1
21 MI-11600-21 Round HD Screw M4 x 12 3
22 MI-11600-22 Motor 1
23 MI-11600-23 Connector 4
24 MI-11600-24 Washer M4 3
25 MI-11600-25 Bushing 1
26 MI-11600-26 Nut M4 1
27 MI-11600-27 Start Washer M4 1
PARTS LIST FOR MI-11600 / MI-11650
1
1
1
Electrostatic Filter
HEPA Filter
1 micron
1 micron
0.3 micron
0.3 micron
