Magnum TE100 User manual

Taylor Products
Model TE100
Electronic Small Bagging Scale
Operation and Maintenance Manual

Taylor Products
a division of Magnum Systems
2205 Jothi Avenue
Parsons, Kansas 67357-8460
Toll Free: 888-882-9567
Phone: [phone]
Fax: [phone]
Web: www.taylorproducts.com
[e-mail]
Machine Serial Number:
Sales Order Number:

Revision 001 i Model TE100
Electronic Small Bagging Scale
Important Information
Conventions
Safety Alert Symbols
The symbol indicates that important personal safety information follows. Carefully read this text for
the warnings information it contains. The signal word next to each safety alert symbol is defined as:
WARNING Indicates a potentially hazardous situation that, if not avoided, could
result in death or serious injury.
CAUTION Indicates a potentially hazardous situation that, if not avoided, may
result in minor or moderate injury, or damage to the equipment. This
single word may also be used to identify unsafe practices.
±LOCKOUT This symbol will be used anytime that a procedure requires an
electrical lockout.
Static Sensitive Symbols for Equipment Handling Instructions
The and symbols indicate important handling guidelines for proper handling of electronic
equipment modules and sensitive components for the prevention of potential damage that could be
caused by ESD (electrostatic discharge) during routine maintenance, handling and transportation.
ESD
NOTICE To protect against ESD damage to electronic equipment, follow the
Standard ESD Prevention Procedures. Failure to use protective
measures could result in permanent equipment damage, either
immediate or latent, when handling modules.
ESD
NOTICE To protect against ESD damage to electronic equipment containing
components, follow the Standard ESD Prevention Procedures.
Failure to use recommended protective measures could result in
permanent equipment damage, either immediate or latent, when
handling components.

Model TE100
Electronic Small Bagging Scale ii Revision 001
Standard Electro-static Discharge (ESD) Prevention Procedures
The Model TE100 Electronic Small Packer utilizes many electronic components that are susceptible to
damage from Electro Static Discharge. Anytime electronic components are serviced, the following
precautions should be followed:
1. Wear a commercial grounding wrist strap.
2. Remove power from the machine.
3. Leave all static sensitive components in their protective packaging until it is time to install the
component
4. Always hold static sensitive components by their metal mounting tabs, and/or by their edges
Important/Notable Information
While all of the information in this manual is important, there are some pieces of information where
special attention needs to be paid to avoid equipment damage, or specific information needs to be
emphasized. This information will be handled as follows:
Important: Indicates an operating procedure, practice, or condition that, if not strictly followed,
may cause equipment damage.
Note: Indicates additional information or emphasizes a topic related to the subject being
discussed.
Personal Safety Instructions
Only qualified personnel should work on or around this equipment. To ensure the highest degree of
personal safety, all who use this equipment are required to become thoroughly familiar with all safety
instructions contained in this document. Successful and safe operation of this equipment depends upon
proper handling, operation, maintenance, and application of associated equipment. Refer to Appendix A
of this manual for all safety instructions. Safety instructions are also provided where they apply within
the body of this manual.
WARNING No information in this manual supersedes or replaces your employer’s operating rules.
If there is a difference in instructions between this manual and the employer’s
operating rules, follow the most restrictive instruction.
Deliberate misuse or abuse of electronic components may cause personal injury or
death.

Revision 001 iii Model TE100
Electronic Small Bagging Scale
Warranty Information
Seller warrants that the Products will operate substantially in conformance with Seller's published
specifications, when subjected to normal, proper and intended usage by properly trained personnel, for a
period of one (1) year from the date of shipment to Buyer (the "Warranty Period"). Seller agrees during
the Warranty Period, provided it is promptly notified in writing upon the discovery of any defect and
further provided that all costs of returning the defective Products to Seller are pre-paid by Buyer, to
repair or replace, at Seller's option, defective Products so as to cause the same to operate in substantial
conformance with said specifications. Replacement parts may be new or refurbished, at the election of
Seller. All replaced parts shall become the property of Seller. Replacement Parts will be billed at list
price, unless they are approved as warranty replacement item(s) by the service technician and the
technical services manager.
Lamps, fuses, bulbs and other expendable items are expressly excluded from the warranty.
Seller's sole liability with respect to equipment, materials, parts or software furnished to Seller by
third party suppliers shall be limited to the assignment by Seller to Buyer of any such third party
supplier's warranty, to the extent the same is assignable. In no event shall Seller have any
obligation to make repairs, replacements or corrections required, in whole or in part, as the result
of (i) normal wear and tear, (ii) accident, disaster or event of force majeure, (iii) misuse, fault or
negligence of or by Buyer, (iv) use of the Products in a manner for which they were not designed,
(v) causes external to the Products such as, but not limited to, power failure or electrical power
surges, (vi) improper storage of the Products or (vii) use of the Products in combination with
equipment or software not supplied by Seller. If Seller determines that Products for which Buyer
has requested warranty services are not covered by the warranty hereunder, Buyer shall pay or
reimburse Seller for all costs of investigating and responding to such request at Seller's then
prevailing time and materials rates. If Seller provides repair services or replacement parts that
are not covered by the warranty, the Buyer shall pay Seller therefore at Seller's then prevailing
time and materials rates. ANY INSTALLATION, MAINTENANCE, REPAIR, SERVICE,
RELOCATION OR ALTERATION TO OR OF, OR OTHER TAMPERING WITH, THE
PRODUCTS PERFORMED BY ANY PERSON OR ENTITY OTHER THAN SELLER
WITHOUT SELLER'S PRIOR WRITTEN APPROVAL, OR ANY USE OF REPLACEMENT
PARTS NOT SUPPLIED BY SELLER, SHALL IMMEDIATELY VOID AND CANCEL ALL
WARRANTIES WITH RESPECT TO THE AFFECTED PRODUCTS.
Field Service
Taylor Products can provide field service for start-up assistance, training, maintenance, and
replacement/spare parts for new and existing equipment. Contact Taylor Products at [phone] for
more information.

Model TE100
Electronic Small Bagging Scale iv Revision 001
This Page Intentionally Left Blank

Revision 001 v Model TE100
Electronic Small Bagging Scale
TE100 Electronic Small Bagging Scale
Table of Contents
Chapter Page
1 Product Description................................................................................................1-1
1.1 General Description ........................................................................................... 1-1
1.2 Introduction........................................................................................................ 1-1
1.3 Manual Scope .................................................................................................... 1-1
1.4 Electrical Requirements ..................................................................................... 1-1
1.5 Pneumatic Requirements.................................................................................... 1-1
1.6 Major Systems and Components........................................................................ 1-2
1.6.1 Scale Cabinet Assembly.............................................................................. 1-3
1.6.1.1 Scale Cabinet............................................................................................................1-3
1.6.1.2 Shut Off Gate............................................................................................................1-4
1.6.1.3 Shut Off Gate Bearings.............................................................................................1-4
1.6.1.4 Shut Off Gate Cylinder.............................................................................................1-4
1.6.1.5 Dribble Gate.............................................................................................................1-4
1.6.1.6 Dribble Gate Cylinder...............................................................................................1-4
1.6.1.7 Dribble Gate Mounting Rails....................................................................................1-4
1.6.1.8 Load Cell..................................................................................................................1-4
1.6.1.9 MAC Valves.............................................................................................................1-5
1.6.1.10 Filter/Regulator/Lubricator (FRL) Assembly ..........................................................1-6
1.6.1.11 Control Panel..........................................................................................................1-6
1.6.2 Spout assembly ........................................................................................... 1-7
1.6.2.1 Spout........................................................................................................................1-7
1.6.2.2 Bag Clamp Arms......................................................................................................1-8
1.6.2.3 Bag Clamp Cylinders................................................................................................1-9
1.6.2.4 Bag Clamp Pads .......................................................................................................1-9
1.6.2.5 Start Switch............................................................................................................1-10
1.6.2.6 Bag position Switch................................................................................................1-10
2 Receiving Equipment..............................................................................................2-1
2.1 General Description ........................................................................................... 2-1
2.2 Uncrating the Equipment ................................................................................... 2-1
3 Setup/Installation....................................................................................................3-1
3.1 General Description ........................................................................................... 3-1
3.2 Mechanical Setup............................................................................................... 3-2
3.3 Making Electrical Connections .......................................................................... 3-2
3.3.1 Electrical Connections................................................................................. 3-2
3.3.2 Load Cell Connections................................................................................ 3-4
3.4 Making Pneumatic Connections......................................................................... 3-4

Model TE100
Electronic Small Bagging Scale vi Revision 001
3.4.1 Lubrication Requirements........................................................................... 3-4
3.5 Dry Cycle........................................................................................................... 3-5
3.6 Calibration ......................................................................................................... 3-5
3.6.1 Weight Display Setup ................................................................................. 3-9
3.6.2 Zeroing The Weight Display..................................................................... 3-10
3.6.3 Calibration Of Scale To Full-Scale Weight............................................... 3-11
3.6.4 Adjusting Density Correction Setting........................................................ 3-13
3.6.5 Over/Under Reject Adjustments................................................................ 3-15
3.6.6 Dribble Gate Setup.................................................................................... 3-16
3.7 Installing the Optional Small Bag Adapter....................................................... 3-17
4 Operation.................................................................................................................4-1
4.1 General Description ........................................................................................... 4-1
4.2 Operational Controls.......................................................................................... 4-1
4.3 Initial Setup........................................................................................................ 4-2
4.4 Normal Operation (Typical Fill Cycle) .............................................................. 4-5
4.4.1 Maintaining Operational Efficiency ............................................................ 4-6
5 Preventive Maintenance .........................................................................................5-1
5.1 General Description ........................................................................................... 5-1
5.2 Daily Maintenance Procedures........................................................................... 5-1
5.2.1 Cleaning...................................................................................................... 5-1
5.2.2 Check Calibration ....................................................................................... 5-1
5.3 Monthly Maintenance ........................................................................................ 5-1
6 Troubleshooting......................................................................................................6-1
6.1 General Description ........................................................................................... 6-1
6.2 The Troubleshooting Process ............................................................................. 6-1
6.3 Trouble Symptoms............................................................................................. 6-1
6.3.1 Scale is Not Accurate.................................................................................. 6-1
6.3.2 Scale Does Not Return to Zero.................................................................... 6-2
6.3.3 The Machine Is Unable To Auto Correct To The Target Weight................. 6-2
6.3.4 The Weighments Fluctuate Between Too Light and Too Heavy.................. 6-2
6.3.5 Filled Bag Won’t Drop................................................................................ 6-3
6.3.6 Bag Won’t Stop Filling ............................................................................... 6-3
6.3.7 Air Cylinder Failure.................................................................................... 6-3
6.3.8 MAC Valve Failure..................................................................................... 6-3
7 Repair and Adjustment ..........................................................................................7-1
7.1 General Description ........................................................................................... 7-1
7.2 System Adjustments........................................................................................... 7-1
7.2.1 Bag Clamp Adjustment............................................................................... 7-1
7.2.2 Shut Off Gate Adjustment........................................................................... 7-2
7.2.3 MAC Valve Flow Control Adjustment........................................................ 7-3

Revision 001 vii Model TE100
Electronic Small Bagging Scale
7.3 System Repairs .................................................................................................. 7-4
7.3.1 Spout Replacement ..................................................................................... 7-4
7.3.1.1 Spout Removal .........................................................................................................7-4
7.3.1.2 Spout Installation......................................................................................................7-5
7.3.2 Load Cell Replacement............................................................................... 7-6
7.3.2.1 Load Cell Removal...................................................................................................7-6
7.3.2.2 Load Cell Installation................................................................................................7-6
7.3.3 Dribble Gate Cylinder Replacement............................................................ 7-7
7.3.3.1 Dribble Gate Cylinder Removal................................................................................7-7
7.3.3.2 Dribble Gate Cylinder Installation ............................................................................7-7
7.3.4 Dribble Gate Replacement .......................................................................... 7-7
7.3.4.1 Dribble Gate Removal..............................................................................................7-7
7.3.4.2 Dribble Gate Installation...........................................................................................7-7
7.3.5 Shut Off Gate Cylinder Replacement.......................................................... 7-8
7.3.5.1 Shut Off Gate Cylinder Removal ..............................................................................7-8
7.3.5.2 Shut Off Gate Cylinder Installation...........................................................................7-8
7.3.6 Shut off Gate Replacement.......................................................................... 7-8
7.3.6.1 Shut Off Gate Removal.............................................................................................7-8
7.3.6.2 Shut Off Gate Installation .........................................................................................7-9
7.3.7 Shut Off Gate Seal Replacement............................................................... 7-10
7.3.7.1 Shut Off Gate Seal Removal...................................................................................7-10
7.3.7.2 Shut Off Gate Seal Installation................................................................................7-10
7.3.8 Bag Clamp Arm Replacement................................................................... 7-10
7.3.8.1 Bag Clamp Arm Removal.......................................................................................7-10
7.3.8.2 Bag Clamp Arms Installation..................................................................................7-11
7.3.9 Bag Clamp Arm Spring Replacement ....................................................... 7-12
7.3.9.1 Bag Clamp Arm Spring Removal............................................................................7-12
7.3.9.2 Bag Clamp Arm Spring Installation........................................................................7-13
7.3.10 Bag Clamp Cylinder Replacement .......................................................... 7-13
7.3.10.1 Bag Clamp Cylinder Removal...............................................................................7-13
7.3.10.2 Bag Clamp Cylinder Installation...........................................................................7-13
7.3.11 Bag Clamp Pivot Block Replacement...................................................... 7-14
7.3.11.1 Bag Clamp Pivot Block Removal..........................................................................7-14
7.3.11.2 Bag Clamp Pivot Block Installation ......................................................................7-14
7.3.12 Air Supply Line Replacement ................................................................. 7-15
7.3.12.1 Air Supply Line Removal .....................................................................................7-15
7.3.12.2 Air Supply Line Installation..................................................................................7-15
7.3.13 Pneumatic Quick Connect Fitting Replacement ...................................... 7-15
7.3.13.1 Pneumatic Quick Connect Fitting Removal...........................................................7-15
7.3.13.2 Pneumatic Quick Connect Fitting Installation .......................................................7-16
7.3.14 Main Circuit Board Replacement............................................................ 7-16
7.3.14.1 Main Circuit Board Removal................................................................................7-16
7.3.14.2 Main Circuit Board Installation.............................................................................7-16

Model TE100
Electronic Small Bagging Scale viii Revision 001
Glossary...........................................................................................................Glossary-1
Index.....................................................................................................................Index-1
Appendix A Safety Procedures ................................................................................ A-1
Appendix B Spare Parts............................................................................................B-1
Appendix C Mechanical Drawings .......................................................................... C-1
Appendix D Electrical Drawings.............................................................................. D-1

Revision 001 ix Model TE100
Electronic Small Bagging Scale
List of Figures
Figure Page
Figure 1-1. TE100 Front View ...........................................................................................................1-2
Figure 1-2. Scale Cabinet and Shut Off Gate......................................................................................1-3
Figure 1-3. Load Cell.........................................................................................................................1-4
Figure 1-4. MAC Valves....................................................................................................................1-5
Figure 1-5. MAC Valve Flow Adjustment..........................................................................................1-5
Figure 1-6. Filter/Regulator/Lubricator (FRL) Assembly....................................................................1-6
Figure 1-7. Control Panel...................................................................................................................1-6
Figure 1-8. Spout Assembly...............................................................................................................1-7
Figure 1-9. Chain Links and Pivot Block............................................................................................1-8
Figure 1-10. Bag Clamp Arm – Shown With Stainless Steel Deflector...............................................1-8
Figure 1-11. Bag Clamp Cylinder (1 of 2 Shown)...............................................................................1-9
Figure 1-12. Bag Clamp Pads.............................................................................................................1-9
Figure 1-13. Start Switch..................................................................................................................1-10
Figure 1-14. Bag Position Switch.....................................................................................................1-10
Figure 1-15. TE100 With Small Bag Adapter Installed.....................................................................1-11
Figure 2-1. Typical Shipping Box (2 Boxes Shown)...........................................................................2-1
Figure 3-1. Mounting the TE100........................................................................................................3-1
Figure 3-2. Hanging the Cabinet Assembly on the Hopper Flange......................................................3-2
Figure 3-3. Shipping Bracket Location...............................................................................................3-2
Figure 3-4. MAC Valve Connections And Schematic.........................................................................3-3
Figure 3-5. Load Cell Connections.....................................................................................................3-4
Figure 3-6. Lubricator – Oil Flow Control..........................................................................................3-4
Figure 3-7. Control Panel...................................................................................................................3-6
Figure 3-8. Relay Board.....................................................................................................................3-7
Figure 3-9. Relay Board Schematic....................................................................................................3-7
Figure 3-10. Decimal Point Switches..................................................................................................3-9
Figure 3-11. Display Trim Pot..........................................................................................................3-10
Figure 3-12. ZERO Knob And Lock Collar......................................................................................3-10
Figure 3-13. Coarse Zero Adjustment...............................................................................................3-11
Figure 3-14. Hanging A Certified Test Weight On The TE100.........................................................3-11
Figure 3-15. Weight Trim Potentiometer..........................................................................................3-12
Figure 3-16. Coarse Weight Gain Switches ......................................................................................3-12
Figure 3-17. Density Correction Switch............................................................................................3-14
Figure 3-18. Over/Under Reject Controls.........................................................................................3-15
Figure 3-19. Dribble Gate Cylinder Mounting..................................................................................3-16
Figure 4-1. Control Panel...................................................................................................................4-2
Figure 4-2. Over/Under Reject Controls.............................................................................................4-4
Figure 7-1. Pivot Block Setscrew Location (Setscrew Uninstalled Here)............................................7-1
Figure 7-2. Shut Off Gate Adjustment................................................................................................7-2
Figure 7-3. Adjusting Airflow From The MAC Valve........................................................................7-3
Figure 7-4. Spout Mounting Bolts......................................................................................................7-5

Model TE100
Electronic Small Bagging Scale x Revision 001
Figure 7-5. Checking Load Cell Alignment (As Viewed From The Top Of The TE100).................... 7-6
Figure 7-6. Shut Off Gate Mounting .................................................................................................. 7-9
Figure 7-7. Shut Off Gate Mounting Screw Ground Off Smooth........................................................ 7-9
Figure 7-8. Shut Off Gate Seal......................................................................................................... 7-10
Figure 7-9. Stainless Steel Deflector................................................................................................ 7-11
Figure 7-10. Bag Clamp Arm Bolts and Bearings ............................................................................ 7-11
Figure 7-11. Bag Clamp Arm Bolts And Bearings Installed............................................................. 7-12
Figure 7-12. Bag Clamp Pivot Block ............................................................................................... 7-14
Figure 7-13. Air Supply Fitting....................................................................................................... 7-15

Revision 001 xi Model TE100
Electronic Small Bagging Scale
List of Tables
Table Page
Table 3-1. TE100 Operational Controls..............................................................................................3-8
Table 3-2. Coarse Weight Gain Switch Combinations......................................................................3-13
Table 3-3. Over/Under Reject Dial Settings......................................................................................3-15
Table 4-1. Auto Correction Example (Target Weight = 50.0 Lbs).......................................................4-4
Table 4-2. Over/Under Reject Dial Settings (0 to 100 = 0.8 Lbs)........................................................4-5
Table 7-1. Bag Clamp Cylinder Air Supply Lines (1 Side Shown)......................................................7-4
Table B-2. TE100 Spare Parts List ....................................................................................................B-1

Model TE100
Electronic Small Bagging Scale xii Revision 001
This Page Intentionally Left Blank

General Description
Revision 001 1-1 Model TE100
Electronic Small Bagging Scale
Chapter 1
Product Description
1.1 General Description
This chapter will provide a high-level product description of the TE100.
1.2 Introduction
The Taylor Products TE100 is an electronic, self-correcting, small bagging scale. The TE100 is
configured to fill open mouth bags.
With over five years of technical development, the TE100 electronic weighing and control package is
one of the most advanced weighing systems available. Using a single load cell, the TE100 is a very
economical and accurate scale.
The TE100 comes in a standard configuration, but also has several optional features that are available.
The TE100 units come standard equipped to fill a standard open mouth bag. The TE100 can also be
ordered with . Depending on how the TE100 is equipped, the TE100 can handle weighments from 20 to
125 lbs. (4.54 kilograms to 56.70 kilograms).
1.3 Manual Scope
This manual will provide information on installation, operation, preventive maintenance,
troubleshooting, and repair of the Model TE100.
The appendices will include safety information, spare parts list, and mechanical drawings.
1.4 Electrical Requirements
The TE100 is designed to operate on 115 VAC at 50 or 60 Hz.
1.5 Pneumatic Requirements
The TE100 uses approximately 2 CFM (57 liters) @ 75-80 PSI (.52-.55 MPa) of compressed air. Taylor
Products recommends that the air supply line be equipped with a refrigerated air dryer, or at the very
least a water separator.

General Description
Model TE100
Electronic Small Bagging Scale 1-2 Revision 001
1.6 Major Systems and Components
When working with the Model TE100, it is important to understand the major systems and components
of the unit. The major components of the system are:
• Scale cabinet assembly
o Cabinet
o Shut off gate
o Shut off gate bearings
o Shut off gate cylinder
o Dribble gate
o Dribble gate cylinder
o Dribble gate mounting straps
o Load cell
o Control box
o MAC valves
o Filter/Regulator/Lubricator (FRL) assembly
• Spout assembly
o Spout
o Bag clamp arms
o Bag clamp pads
o Start switch
o Bag position switch
Figure 1-1. TE100 Front View

General Description
Revision 001 1-3 Model TE100
Electronic Small Bagging Scale
1.6.1 Scale Cabinet Assembly
The scale cabinet assembly is the upper portion of the TE100. The scale cabinet assembly is made up of
several components.
1.6.1.1 Scale Cabinet
The scale cabinet is the core of the TE100. All other TE100 components are mounted on the scale
cabinet.
Item # Description Item # Description
1 Scale cabinet 6 Lock washer and
j
am nut
2 Shut off
g
ate pivot bolts 7 C
y
linder to shut off
g
ate bolt and washer
3 Shut off gate pivot bearings 8 Quick connect fittings
4 Lock washer and
j
am nut 9 C
y
linder to cabinet bolt and washer
5 Shut off
g
ate 10 Shut off
g
ate c
y
linder
Figure 1-2. Scale Cabinet and Shut Off Gate

General Description
Model TE100
Electronic Small Bagging Scale 1-4 Revision 001
1.6.1.2 Shut Off Gate
The shut off gate is used to stop product flow into the package, after target weight has been achieved.
1.6.1.3 Shut Off Gate Bearings
The shut off gate rides on a pair of sealed bearings. The use of bearings ensures that the shut off gate is
able to smoothly open and close.
1.6.1.4 Shut Off Gate Cylinder
The TE100 uses a pneumatic cylinder to open and close the shut off gate. The gate is mounted on the
left side of the scale cabinet.
1.6.1.5 Dribble Gate
The TE100 is equipped with a sliding steel gate that is used to control the flow of product from the
hopper. By using a dribble gate, the TE100 is capable of delivering product at two different feed rates.
The result is a more efficient fill cycle. When the dribble gate is all the way open, the TE100 is filling at
the bulk rate. When the dribble gate cylinder extends, it partially blocks the flow of product.
1.6.1.6 Dribble Gate Cylinder
The dribble gate is extended and retracted using a pneumatic cylinder that is mounted on the rear of the
TE100. The rod end of the dribble gate cylinder is bolted directly to the dribble gate, while the cylinder
end is bolted to the dribble gate cylinder mounting bracket.
1.6.1.7 Dribble Gate Mounting Rails
The TE100 is equipped with two aluminum rails on rear of the TE100. These rails provide the mounting
point for the dribble gate cylinder mounting bracket.
1.6.1.8 Load Cell
The load cell is used to sense the weight of the material in the package. As material is loaded into the
package, the load is applied to the load cell in a linear fashion. As the load increases, the voltage output
from the load cell increases.
CAUTION A sudden jerk or shock, such as being struck by a tool or hitting the
spout, etc., can cause load cell damage. The load cell is NOT
covered by warranty.
Figure 1-3. Load Cell

General Description
Revision 001 1-5 Model TE100
Electronic Small Bagging Scale
1.6.1.9 MAC Valves
There are several MAC valves that are mounted on the rear of the TE100. These valves are used to
control various pneumatic components on the TE100, such as the dribble gate, shut off gate, and bag
clamp arms.
Figure 1-4. MAC Valves
Each of the MAC valves is equipped with a manual operation button, or test button. The operator can
use a pencil or small screwdriver to press a button to test that valve function. The buttons are assigned
as follows:
• Shutoff gate – Pressing the button marked CYL A will open the gate. Pressing the button
marked CYL B will close the gate.
• Dribble gate – Pressing the button marked CYL A will retract the gate. Pressing the button
marked CYL B will extend the gate.
• Bag clamp – Pressing the button marked CYL A will apply the bag clamp arms. Pressing the
button marked CYL B will release the bag clamp arms.
Each of the MAC valves is also equipped with a flow control screw. These flow control screws control
the actuation speed of the device that the valve is controlling. For example, if the flow control screw on
the MAC valve that controls the shut off gate cylinder is turned counter-clockwise (opened), it will
make the shut off gate open and close faster. If the flow control screw is turned clockwise (closed) it
will make the shut off gate open and close slower.
Figure 1-5. MAC Valve Flow Adjustment

General Description
Model TE100
Electronic Small Bagging Scale 1-6 Revision 001
1.6.1.10 Filter/Regulator/Lubricator (FRL) Assembly
The air pressure regulator used on the TE100 is a combination unit. It is a Filter/Regulator/Lubricator
(FRL) assembly. This unit filters the incoming compressed air, regulates its pressure, and adds a
lubricant to the air that provides lubrication to the internal components of the pneumatic devices that are
downstream.
Figure 1-6. Filter/Regulator/Lubricator (FRL) Assembly
1.6.1.11 Control Panel
The TE100 is equipped with a control panel that is used to set the operating parameters for the unit. The
control panel is where the operator will find the power switch. It is located on the lower right corner of
the control panel. The panel also includes a weight display for monitoring the weight of the package,
control knobs for setting zero, the dribble weight, and the target weight, a display select switch, and a
HOLD BAG switch. The control panel is also equipped with a STOP button that will immediately
interrupt the operation of the machine when it is pressed.
Figure 1-7. Control Panel
FRL
