DynaFlex II Go
Secure Card Reader
PCI PTS POI v6.2 Security Policy
October 2023
Document Number:
D998200596-100
REGISTERED TO ISO 9001:2015

DynaFlex II Go| Secure Card Reader | PCI PTS POI v6.2 Security Policy
Page 2 of 18 (D998200596-100)
Copyright © 2006 - 2023 MagTek, Inc.
Printed in the United States of America
MagTek® is a registered trademark of MagTek, Inc.
MagnePrint® is a registered trademark of MagTek, Inc.
MagneSafe® is a registered trademark of MagTek, Inc.
Magensa™is a trademark of MagTek, Inc.
AAMVA™is a trademark of AAMVA.
American Express® and EXPRESSPAY FROM AMERICAN EXPRESS® are registered trademarks of
American Express Marketing & Development Corp.
Apple Pay® is a registered trademark to Apple Inc.
D-PAYMENT APPLICATION SPECIFICATION® is a registered trademark to Discover Financial
Services CORPORATION
MasterCard® is a registered trademark and PayPass™and Tap & Go™are trademarks of MasterCard
International Incorporated.
Visa® and Visa payWave® are registered trademarks of Visa International Service Association.
ANSI®, the ANSI logo, and numerous other identifiers containing "ANSI" are registered trademarks,
service marks, and accreditation marks of the American National Standards Institute (ANSI).
ISO® is a registered trademark of the International Organization for Standardization.
PCI Security Standards Council® is a registered trademark of the PCI Security Standards Council, LLC.
EMV® is a registered trademark in the U.S. and other countries and an unregistered trademark elsewhere.
The EMV trademark is owned by EMVCo, LLC. The Contactless Indicator mark, consisting of four
graduating arcs, is a trademark owned by and used with permission of EMVCo, LLC.
UL™and the UL logo are trademarks of UL LLC.
All other system names and product names are the property of their respective owners.

DynaFlex II Go| Secure Card Reader | PCI PTS POI v6.2 Security Policy
Page 3 of 18 (D998200596-100)
Table 0-1 - Revisions
Rev Number
Date
Notes
100
October 25, 2023
Initial Release

0 - Table of Contents
DynaFlex II Go| Secure Card Reader | PCI PTS POI v6.2 Security Policy
Page 4 of 18 (D998200596-100)
Table of Contents
Table of Contents .............................................................................................................................................. 4
1Purpose ...................................................................................................................................................... 5
2General Description.................................................................................................................................. 6
2.1 Product Name and Appearance..................................................................................................... 6
2.2 Product Type ..................................................................................................................................... 7
2.3 Identification ..................................................................................................................................... 7
2.3.1 Hardware Identification .......................................................................................................... 7
2.3.2 Firmware Identification.........................................................................................................10
3Installation and User Guidance ............................................................................................................11
3.1 Initial Inspection .............................................................................................................................11
3.2 Installation.......................................................................................................................................11
3.3 Environmental Conditions.............................................................................................................11
3.4 Communications and Security Protocols ...................................................................................12
3.5 Configuration Settings................................................................................................................... 12
4Operation and Maintenance .................................................................................................................13
4.1 Periodic Inspection.........................................................................................................................13
4.2 Self-Test ...........................................................................................................................................14
4.3 Roles and Responsibilities............................................................................................................ 14
4.4 Passwords and Certificates ..........................................................................................................14
4.5 Tamper Response ..........................................................................................................................14
4.6 Patching and Updating ..................................................................................................................15
4.7 Decommissioning........................................................................................................................... 15
5Security..................................................................................................................................................... 16
5.1 Account Data Protection ...............................................................................................................16
5.2 Algorithms Supported.................................................................................................................... 16
5.3 Key Management ........................................................................................................................... 16
5.4 Key Loading..................................................................................................................................... 16
5.5 Key Replacement ...........................................................................................................................16
6Acronyms .................................................................................................................................................17
Appendix A References..............................................................................................................................18

1 - Purpose
DynaFlex II Go| Secure Card Reader | PCI PTS POI v6.2 Security Policy
Page 5 of 18 (D998200596-100)
1Purpose
This document addresses the proper use of the DynaFlex II Go family of secure card readers (SCR) in a
secure manner. This includes information about key-management responsibilities, administrative
responsibilities, device functionality, identification, and environmental requirements.
The use of this secure card reader in any method not described in this security policy will invalidate the
PCI PTS POI v6.2 approval of the device.
Throughout this document:
•DynaFlex II Go products refers to all products in the DynaFlex II Go product family, including
DynaFlex II Go models equipped with a barcode reader (BCR) and Bluetooth LE connectivity.

2 - General Description
DynaFlex II Go| Secure Card Reader | PCI PTS POI v6.2 Security Policy
Page 6 of 18 (D998200596-100)
2General Description
2.1 Product Name and Appearance
The front view of all DynaFlex II Go models (with and without BCR), are shown in Figure 2-1 below.
The back view of all DynaFlex II Go devices are identical, as seen in Figure 2-2.
Figure 2-1 - DynaFlex II Go and DynaFlex II Go with BCR Front View
Figure 2-2 –Back View of all DynaFlex II Go Models

2 - General Description
DynaFlex II Go| Secure Card Reader | PCI PTS POI v6.2 Security Policy
Page 7 of 18 (D998200596-100)
2.2 Product Type
All DynaFlex II Go products include USB communications, magnetic stripe reader (MSR), contact chip
card reader (ICCR), a contactless card reader (CTLS), and may also be purchased with an embedded
barcode reader (BCR) and Bluetooth LE connectivity.
DynaFlex II Go models can be used as desktop or handheld devices. They are approved as a secure card
reader (SCR) under PCI PTS POI v6.2 requirements.
Usage in any other environment will invalidate the approval.
2.3 Identification
2.3.1 Hardware Identification
To find important product identification, look on the printed product label on the back face of the device
as shown in Figure 2-3 below.
Do not remove or alter this label.
Figure 2-3 - DynaFlex II Go Device Label Location

2 - General Description
DynaFlex II Go| Secure Card Reader | PCI PTS POI v6.2 Security Policy
Page 8 of 18 (D998200596-100)
The product label includes the following elements of device identification information, shown by the
numbered callouts in Figure 2-4 and Figure 2-5.
1) Product Name
2) PCI Hardware Identifier (“HW”)
Figure 2-4 -DynaFlex II Go Device Label
Figure 2-5 DynaFlex II Go with Bluetooth LE Device Label
The label also contains other supporting information about the device.
All DynaFlex II Go product family hardware configurations are listed in Table 2-1 below. The device
utilizes two interface types, USB and Bluetooth LE. Use of any interface other than USB or Bluetooth
LE will invalidate PCI approval.
Table 2-1 - PCI Hardware Identifier
PCI ID Tag
Configuration Description
42PCI30U0BB0
DynaFlex II Go, PCI, BLACK
42PCI50U0BB0
DynaFlex II Go, PCI, BCR, BLACK
42PCI30B0BB0
DynaFlex II Go, PCI, BLACK, BLUETOOTH LE
42PCI50B0BB0
DynaFlex II Go, PCI, BCR, BLACK, BLUETOOTH LE
1
2
2
1

2 - General Description
DynaFlex II Go| Secure Card Reader | PCI PTS POI v6.2 Security Policy
Page 9 of 18 (D998200596-100)
Table 2-2 –Hardware Versions with Description of Associated Variables
Hardware Versions with Description of Associated Variables
PCI Hardware ID Number
1
2
3
4
5
6
7
8
9
10
11
12
4
2
P
C
I
3
0
U
0
B
B
0
4
2
P
C
I
5
0
U
0
B
B
0
4
2
P
C
I
3
0
B
0
B
B
0
4
2
P
C
I
5
0
B
0
B
B
0
Fixed Position
Variable “X” Position
Description of Fixed or Variable “X” in the Selection Position
1-2
42 = DynaFlex II Go
3-5
PCI = PCI Hardware
6
Front options
3 = Standard
5 = includes Barcode Reader
7
Option RFU (Reserved for Future Use)
RFU 0 = as Certified
8
Interface Options
U = USB only
B = USB + Bluetooth LE
9
Option RFU (Reserved for Future Use)
RFU 0 = as Certified
10
Cover Color:
B = Black
11
Version
B = as Certified
12
minor fixes not adding functionality or related to security (e.g., change
component value for antenna matching):
0 = as certified

2 - General Description
DynaFlex II Go| Secure Card Reader | PCI PTS POI v6.2 Security Policy
Page 10 of 18 (D998200596-100)
2.3.2 Firmware Identification
The most recent firmware versions for DynaFlex II Go products are 1000009446-AA0-PCI for the
secure bootloader (Boot1 FW), 1000009421-AA0-PCI for the core firmware (Main FW), and
1000009327-AA0-PCI for the Bluetooth LE Firmware Version. The lowercase x in firmware versions
indicates minor non-security related changes. The secure bootloader firmware version also covers the
initial bootloader (Boot0) permanently programmed into the device. Any changes to either Boot0 or
Boot1 will result in a change to the Boot1 FW version that is visible to the user, reported by the device,
and listed on the PCI Approved Devices website.
All device identification information, including firmware versions and PCI Hardware ID, is accessible by
connecting DynaFlex II Go to a host device via USB or Bluetooth LE, using the latest software provided
by MagTek, as seen in Figure 2-6 - Device Information Screen.
The host user can also can retrieve device information at any time using Command 0xD101 Get
Property as described in D998200597 DynaFlex II Go Programmer’s Manual (COMMANDS).
Figure 2-6 - Device Information Screen

3 - Installation and User Guidance
DynaFlex II Go| Secure Card Reader | PCI PTS POI v6.2 Security Policy
Page 11 of 18 (D998200596-100)
3Installation and User Guidance
3.1 Initial Inspection
After receiving the device, the customer should visually inspect the product as follows:
1) Inspect the label found on the bottom of the device (see section 2.3.1 Hardware Identification) and
make sure the label is not missing, obscured, or modified.
2) Check the PCI Hardware Identifier on the device label and make sure it matches the Hardware #
listed for the device on the PCI web site for Approved Devices. Go to the PCI compliance web page
and search for MagTek, and find the product name, DynaFlex II Go. Compare the Hardware ID and
Firmware ID: https://www.pcisecuritystandards.org/assessors_and_solutions/pin_transaction_devices
Note: Firmware ID is accessible by connecting DynaFlex II Go to a host device via USB or Bluetooth
LE, using the latest software provided by MagTek (see section 2.3.2 Firmware Identification).
3) Check the Device serial number (SN) and make sure it matches with labels on shipping materials and
documentation.
4) Visually inspect the device, per D998200593 DynaFlex II Go, Device Inspection Document,
which is included in the package with each device. See section 4.1 Periodic Inspection for more
information regarding visual inspection of the device.
5) Follow the steps in section 2.3.2 to view the PCI firmware versions installed on the device. Make
sure this matches one of the Firmware # values listed on the PCI web site for DynaFlex II Go. Note
that in PCI listings, lowercase “x” is a wildcard meaning ‘any single character.’
3.2 Installation
Connect the device to a USB host for control and power (if battery power is not sufficient). DynaFlex II
Go products are designed to provide flexible mounting options such as:
•External clip
•Embedded lanyard
3.3 Environmental Conditions
The specified environmental conditions to operate and store the device are:
•Operating temperature range: 0°C to 35°C / 5% to 90% RH
•Storage temperature range: -20°C to 45°C / 5% to 90% RH
For safety, battery charging is disabled when the device is connected outside the recommended operating
temperature range.
The security of the reader is not compromised by altering the environmental conditions outside the stated
operating ranges above. Any temperature or operating voltage outside the values in the table below will
trigger environmental security protections, resulting in a tamper condition. The device will need to be
returned to the factory for inspection before this condition can be cleared.
Sensor
Low Threshold Value
High Threshold Value
Internal Voltage
1.60V ± 0.055V
3.775V ± 0.1V
Temperature
-45°C ± 15°C
120°C ± 10°C

3 - Installation and User Guidance
DynaFlex II Go| Secure Card Reader | PCI PTS POI v6.2 Security Policy
Page 12 of 18 (D998200596-100)
3.4 Communications and Security Protocols
DynaFlex II Go products support a USB interface using the USB-HID protocol, and a Bluetooth LE
interface. Transactions, configuration, firmware updates, and key injection can all be performed using
these interface types. Use of any method not listed in this security policy will invalidate the device’s PCI
PTS approval.
3.5 Configuration Settings
DynaFlex II Go products ship from the factory fully secure. The devices have no configuration settings
that require modification by the user to meet PCI security requirements.

4 - Operation and Maintenance
DynaFlex II Go| Secure Card Reader | PCI PTS POI v6.2 Security Policy
Page 13 of 18 (D998200596-100)
4Operation and Maintenance
4.1 Periodic Inspection
The merchant or acquirer should daily check the appearance of secure card reader:
1) Inspect the appearance of secure card reader to make sure it is the right product.
2) Inspect whether the Swipe Path has an additional card reader or other inserted bugs, See Figure
4-1, below.
3) Observe the Chip Card Insertion Slot to determine whether there are any wires or obstructions.
See Figure 4-1, below.
4) Inspect whether the product appearance has been changed.
5) Check if the firmware version is correct.
6) Power on the secure card reader and check that the firmware runs well, as the startup will inspect
the hardware security, authenticity, and integrity of firmware. Only the leftmost LED should be
on and blinking green.
Figure 4-1 - Chip Card Insertion Slot and Swipe Path Examples
MagTek strongly recommends performing security inspections on a regular schedule. Additional
information can be found in D998200593 DynaFlex II Go, Device Inspection Document. If any
problems are detected, stop using the device, set it aside in a secure location, and contact the manufacturer
or your acquirer for further advice.
Chip Card Insertion Slot
The card slot for the Contact Chip Reader is
a smooth, unobstructed path. Other than
the contact points that read the chip, there
are no electronics, mechanics, or wires in
the path.
MSR Swipe Path
The swipe path is smooth. The only moving
part is the spring-mounted read head that
depresses into the device as the card’s
magnetic stripe makes contact with the
read head.

4 - Operation and Maintenance
DynaFlex II Go| Secure Card Reader | PCI PTS POI v6.2 Security Policy
Page 14 of 18 (D998200596-100)
4.2 Self-Test
DynaFlex II Go performs self-tests at power-up and after reset. By default, the device automatically
resets and performs self-tests every 23 hours if it is configured to automatically reset 23 hours after
booting, otherwise the device automatically resets and performs self-tests every 24 hours if it is
configured to automatically reset at a specific time of day. No manual intervention by the operator is
required. Self-tests include:
•Checking the integrity and authenticity of the firmware and cryptographic keys.
•Checking security mechanisms for signs of tampering.
4.3 Roles and Responsibilities
The secure card reader has no functionality that gives access to security-sensitive services based on roles.
Such services are managed through dedicated tools, using cryptographic authentication.
4.4 Passwords and Certificates
DynaFlex II Go products ship from the factory fully secure. The devices have no security related default
values (e.g., passwords/authentication codes/certificates) that require modification by the user to meet
PCI security requirements.
4.5 Tamper Response
If the device senses a physical or environmental attack, it erases all sensitive keys, and will have limited
functionality. While powered on, the SCR indicates it is in a tampered state by flashing green LEDs 1,3,
and 4 as depicted in Figure 4-2 Tamper Response. If this occurs:
1) Remove the device from service immediately.
2) Store it securely for possible forensics investigation.
3) Contact the manufacturer for assistance. The device will likely need to be returned to the
manufacturer for diagnosis and servicing.
Figure 4-2 Tamper Response

4 - Operation and Maintenance
DynaFlex II Go| Secure Card Reader | PCI PTS POI v6.2 Security Policy
Page 15 of 18 (D998200596-100)
4.6 Patching and Updating
DynaFlex II Go products support file-based updates of the device’s core firmware (main firmware) and
authorized commands for updating sensitive configuration. For optimal device security, MagTek
recommends the latest versions of firmware should always be installed.
Firmware updates are provided as files that have been signed by MagTek. The firmware files can be
loaded locally through USB or Bluetooth LE connection by using update tools available from the MagTek
web site. The device verifies each update is newer than the installed version, and cryptographically
authenticates the file. If version checking or authentication fails, the device erases the update file and
reports an error to the host.
For help with updates to EMV configuration, contact Magensa Remote Services.
4.7 Decommissioning
Before DynaFlex II Go products are permanently removed from service, all the keys and sensitive data
must be erased. One way to accomplish this is by temporarily removing the back cover, which forces a
tamper response.
If removal from service is only temporary, no action is required. All sensitive data will continue to be
protected by the device’s physical and logical protection mechanisms.

5 - Security
DynaFlex II Go| Secure Card Reader | PCI PTS POI v6.2 Security Policy
Page 16 of 18 (D998200596-100)
5Security
5.1 Account Data Protection
The device always encrypts account data from all three reader types using 112-bit TDEA, 128-bit AES, or
256-bit AES algorithms with X9.24 DUKPT key management. This device does not support any
mechanisms such as whitelists or SRED disable that would allow the data to be sent out unencrypted.
5.2 Algorithms Supported
The device includes the following cryptographic algorithms:
•AES
•TDEA
•RSA
•ECDSA (P256 and P521 curves)
•SHA-256
5.3 Key Management
The device implements the original AES/TDEA DUKPT as its only key management method. Use of any
other method will invalidate PCI approval. DUKPT derives a new unique key for every transaction. For
more details, see ANS X9.24 Part 3:2017.
Table 5-1 - DynaFlex II Go Product Keys
Key Name
Size
Algorithm
Purpose
Transport Keys
32 bytes
AES X9.143 KBPKs
Key Injection
Account Data Key
16 bytes for TDEA and
AES-128
32 bytes for AES-256
AES and TDEA DUKPT
(ANS X9.24-3)
Encrypt and MAC
Account Data
Firmware Protection Key
64 bytes for
ECDSA Curve P-256
ECDSA and SHA-256
Checks integrity
and authenticity of
firmware
EMV CA Public keys
Varies per issuer
RSA
Authenticate card
data and keys
5.4 Key Loading
The device does not support manual or plaintext cryptographic key entry. Only specialized tools,
compliant with key management requirements and cryptographic methods, specifically ANSI X9.143, can
be used for key loading. Use of any other methods will invalidate PCI approval.
5.5 Key Replacement
Keys should be replaced with new keys whenever the original key is known or suspected to have been
compromised, and whenever the time deemed feasible to determine the key by exhaustive attack has
elapsed, as defined in NIST SP 800-57-1.

6 - Acronyms
DynaFlex II Go| Secure Card Reader | PCI PTS POI v6.2 Security Policy
Page 17 of 18 (D998200596-100)
6Acronyms
Acronym
Definition
AES
Advanced Encryption Standard
BCR
Barcode Reader
CTLS
Contactless
DES
Data Encryption Standard
DUKPT
Derived Unique Key Per Transaction
ECC
Elliptic-Curve Cryptography
ICCR
Integrated Circuit Card Reader
MAC
In cryptography: Message Authentication Code
In networking: Media Access Control [address]
MSR
Magnetic Stripe Reader
NFC
Near Field Communication
POI
Point Of Interaction
S/N
Serial Number
SCRA
Secure Card Reader Authenticator
SHA
Secure Hash Algorithm
SRED
Secure Reading and Exchange of Data
TDEA
Triple Data Encryption Algorithm
USB
Universal Serial Bus
USB HID
USB Human Interface Device

Appendix A - References
DynaFlex II Go| Secure Card Reader | PCI PTS POI v6.2 Security Policy
Page 18 of 18 (D998200596-100)
Appendix A References
The following documents may be used to provide additional details about the device and this security
policy:
•D998200595 DynaFlex II Go Installation and Operation Manual
•D998200597 DynaFlex II Go Programmer’s Manual (COMMANDS)
•D998200593 DynaFlex II Go Device Inspection Document
•D998200594 DynaFlex II Go Package Inspection Document
•NIST SP 800-57-1 Recommendation for Key Management
•ANS X9.24 Part 3:2017, Retail Financial Services Symmetric Key Management, Part 3:
Derived Unique Key Per Transaction Using Symmetric Techniques
•X9 TR-31:2010, Interoperable Secure Key Exchange Key Block Specification for Symmetric
Algorithms
