MaiLink MLD6 Series Operator's manual

Electric Height Adjustable Desk Frame
Professional For Health
MLD6 SERIES
MaiLink
INSTRUCTIONS FOR ASSEMBLY AND USE
Please provide this operation to any users,installer ,or support personnel
operating the product.
Inappropriate use of this product may cause property or bodily injury.
Do not move around,crawl or lie under the desk frame.Do not sit or stand
on the desk frame.
Check that no cables can get jammed.
The desk height is adjustable so that it can be positioned at the most
ergonomically suitable height. The desk are disigned only for the purposes
ncluded in this manual.They should not be used in environments with
high humidity or dampness.
!
WARNING

MLD6 series parameter instruction
Electric Control Part:
Input Voltage: 100-240V can be use
Output Voltage: 24V DC
Duty cycle: 10%MAX 2min on 18 min off
Switch power supply, low energy consumption
Manual device can move and long press
Desk frame part:
Built-in limit switch
Dynamic load: 120KG
The maximum static load: 140KG
Load speed: 30mm/s
Lift range: 620mm---1270mm
The length of the adjusting range: 1100mm~1600mm
Other part:
Packing Size：1080*270*330mm 1Set
Gross weight : 45KG
Safety and warnings
This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in safe way and understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall not be made by children
without supervision.
Correct Disposal of this product
This marking indicates that this product should not be disposed
with other household wastes throughout the EU. To prevent
possible harm to the environment or human health from un-
controlled waste disposal ,recycle it responsibly to promote the
sustainable reuse of material resources. To return your used
device, please use the return and collection systems or contact
the retailer where the product was purchased. They can take
this product for environmental safe recycling.

The overall effect
Desk frame installation instructions
L2egs pcs
Feet 2pcs
Long ube 2pcst
Horizontal tube 2pcs
Motor wires 2pcs
Power pcscable 1
Handset 1pcs
Control box 1pcs
M8*10 12pcs M8*25 8pcs M6*10 4pcs
M6*12 8pcs

2.Install table legs(2pcs) and horizontal tube(2pcs)
Installation Guide
Loose the eight screw and adjust to the target length then screw up.
1 Adjust the frame length according the desktop size..
Level the desk on smooth surface,put the leg up
on the two horizontal frame,fix each leg to the
frame with M8*10 screw(6pcs).

fasten the desk bae with M8*25 screws
(4pcs per leg)
3.Install desk feet(2pcs)
4.Installation controller bracket
Firstly install, the controller bracket with M6*10 screw(4pcs)
then insert the control box from one side.
Installation Guide

5.Motor wires(2pcs) switch wire (1pcs) power supply wire (1pcs)
Ensure can be use after plug in the power supply.
Installation Guide
MaiLink

Handset Usage Instructions
Mode of operation
1.Lightly touch up/down button and hold the key to rise and low the desk height
2.Press HOME button and quickly release to move the base height(withou work surface)
to a normal desk height of 28.3"
3.To set M1 and M2 height memories press and hole key in for 5 seconds.
Once set in memory, quickly press M1 or M2 to achieve programmed in height.
4.After 30 seconds of not touching the keypad, display screen lights will turn off.
5.To start keypad push either up or down to light up.
116
SAVE
M1 M2 HOME
MaiLink
The height automatically go to
720mm(28.3"). Touch the key and release.
Second memory position. Press and hold the key
for 5 seconds for memory 2.
First memory position. Press and hold the key for 5
seconds for memory 1.
Display screen
Show current height Range from 620mm--1270mm(24.4"--50")
Lowering button. Push and hold to lower desk/table
Raising button. Push and hold to raise desk/table
