MaiLink MLD7 Series Operator's manual

Electric Height Adjustable Desk Frame
Professional For Health
MLD7 SERIES
MaiLink
INSTRUCTIONS FOR ASSEMBLY AND USE
Please provide this operation to any users,installer ,or support personnel
operating the product.
Inappropriate use of this product may cause property or bodily injury.
Do not move around,crawl or lie under the desk frame.Do not sit or stand
on the desk frame.
Check that no cables can get jammed.
The desk height is adjustable so that it can be positioned at the most
ergonomically suitable height. The desk are disigned only for the purposes
ncluded in this manual.They should not be used in environments with
high humidity or dampness.
!
WARNING

MLD7 series parameter instruction
Electric Control Part:
Input Voltage:100-240V can be use
Output Voltage:24V DC
Duty cycle:10%MAX 2min on 18 min off
Switch power supply,low energy consumtion
Manual device can move and long press
Desk frame part:
built-in limit switch
Dynamic load:70KG
The maximum static load:180KG
Load speed:30mm/s
Lift range:620mm---1270mm
The length of adjusting range:1100~1600mm
Other part:
Packing Size：1080*270*330mm 1Set
Gross weight:63KG
Safety and warnings
This appliance can be used by children aged from 8 years and
above and persons withreduced physical,sensory or mental c
apabilities or lack of experience and knowledge if they
have been fiven supervision or instruction concerning use of
the appliance in asafe way and understand the hazards involved.
Children shall not play with the appliance.Cleaning and user
maintenance shall not be made by children without supervision.
This marking indicates that this product
should not be disposed with
other household wastes throughout the EU.
To prevent possoble harm to the environment or
human health from uncontrolled waste
disposal ,recycle� it responsibly to promote the
sustainable reuse of material resources.To return
your used device,please use the ruturn and
collection systems or �contact the retailer where
the procuct was purchased.They can take this
Correct Disposal of this product
product for environmental safe recvcling.
660*260*280mm 1Set

Desk Frame installation instruction
the overall effect
legs 3pcs crossbar 2pcs Long side
bracket 2pcs
short side
bracket 1pcs
crossbar end
1pcs
Long feet
2pcs
Short foot
1pcs Leveling Studs
6pcs
machine screws
M8X25 12pcs
machine screws
M8X12 18pcs
machine screws
M10X25 8pcs
machine screws
M6X10 4pcs
power cord 1pcs Switch 1pcs Connecting cables
(short:2pcs,long:1pcs) control box 1pcs
Part Drawing
①②③④⑤⑥
⑦⑧⑨⑩⑪⑫
⑬⑭⑮⑯
Ma iLi nk

Please count pieces before disposing of any carton or packing material.Use
a padded or carpeted area for assembly to avoid damage.For ease and safety ,we
recommend two people for assembly.
③
⑤
⑫
⑯②③
⑩
①
⑨
⑧
⑨
⑦
⑨
First,loose the machine screws(part11#),and stretched the length of the crossbar
to need.lock the screws,and ensure the same length of each crossbar(Part2#).
1.According to the demand, adjust the length of the crossbar
⑪②

First,Place related parts as below.
Second.,insert qty 4 machine screws(part10#)through the Crossbar(part 2#)and
Crossbar end (part5#)going intothe each leg(part1#).Third,insert qty 2 machine
screws(part10#)through the sidebracket(Part3&part4#)into the each leg(part1#).
First,Place related parts as below. Second.,insert qty 4 machine screws(part9)
through the foot(part 6&7)going into each leg(part1).Third,insert qty 2 leveling
studs(part8) going into each foot
⑨
⑧
⑦
⑨
⑧
⑥
2.Install legs(part 1)、 side bracket（part 3,part 4)and crossbar(part2&5)
3.Install feet(part 6&7) and leveling studs(part8)
①⑩
②
③
⑤
④
③

Insert qty 4 Machine Screws(M6X10) through the 4 holes of crossbar(part2) going into the
control box
4.Install feet(part6&7)and leveling studs(part8)
Insert qty 12 Machine Screws(ST6.3X15) through the 12 holes of crossbar(part2) going into
the panel
5.Install panel

Insert the Conneting cables into the control box and motor,and Insert the power
cord and switch �into control box. Can be used after the power supply.
Connecting cables
(short:2pcs,long 1pcs)
Switch 1pcs
Power cord 1pcs
6.Install the wire
Mai Link

Handset Usage Instructions
Mode of operation
1.Lightly touch up/down button and hold the key to rise and low the desk height
2.Press HOME button and quickly release to move the base height(withou work surface)
to a normal desk height of 28.3"
3.To set M1 and M2 height memories press and hole key in for 5 seconds.
Once set in memory, quickly press M1 or M2 to achieve programmed in height.
4.After 30 seconds of not touching the keypad, display screen lights will turn off.
5.To start keypad push either up or down to light up.
116
SAVE
M1 M2 HOME
MaiLink
The height automatically go to
720mm(28.3"). Touch the key and release.
Second memory position. Press and hold the key
for 5 seconds for memory 2.
First memory position. Press and hold the key for 5
seconds for memory 1.
Display screen
Show current height Range from 620mm--1270mm(24.4"--50")
Lowering button. Push and hold to lower desk/table
Raising button. Push and hold to raise desk/table
