MAINE ENERGY SYSTEMS PES 20 User manual

Please read carefully prior
to installing and servicing.
SAVE THESE INSTRUCTIONS
Operating
Manual
Pellet heating with auger
delivery or vacuum suction
system for the end-user
AutoPellet®
PES 20, 32, 56
A_V3.10
AutoPellet TOUCH
USA
PE 568 USA 2.0 ·www.maineenergysystems.com

Title: Operating Manual AutoPellet® PES 20, 32, 56
Article number: PE 568 USA 2.0
Version valid from: 09/2021
Approved: Wohlinger Christian
Author Manufacturer
MAINE ENERGY SYSTEMS LLC
8 Airport Road — P.O. Box 547 Bethel
Maine 04217
E-Mail: [email protected] © MAINE ENERGY SYSTEMS LLC
www.maineenergysystems.com Subject to modifcations

Operating Manual AutoPellet® PES 20, 32, 56
1 Dear Customer ................................................................................................................................................ 5
2 Use only for the purpose intended................................................................................................................ 6
3 Types of safety warning sign......................................................................................................................... 7
4 Warnings and safety instructions.................................................................................................................. 8
4.1 Basic safety instructions............................................................................................................................... 8
4.2 Warning signs............................................................................................................................................... 8
4.3 What to do in an emergency.......................................................................................................................10
5 Prerequisites for installing a pellet boiler .....................................................................................................11
5.1 Guidelines and standards for installing a pellet boiler .................................................................................. 11
5.2 Installation room........................................................................................................................................... 11
5.3 lue gas system........................................................................................................................................... 12
5.4 Safety systems............................................................................................................................................ 15
5.5 Installation with an existing boiler............................................................................................................... 15
6 Fuel ................................................................................................................................................................ 17
6.1 Specification for high quality pellets as per EN ISO 17225–2, class A1 and by P I standards in North
America......................................................................................................................................................... 17
6.2 Distance to flammable materials................................................................................................................. 18
6.3 Storing the pellets....................................................................................................................................... 18
6.4 Measures for the ventilation of storage rooms........................................................................................... 18
7 Product description ......................................................................................................................................19
7.1 The pellet boiler............................................................................................................................................ 19
7.2 Pellet suction system...................................................................................................................................22
7.3 Auger delivery system ................................................................................................................................22
7.4 Storage systems..........................................................................................................................................23
7.4.1 Pellet storage room......................................................................................................................23
7.4.2 lexilo fabric tank........................................................................................................................23
8 Operating the Pellematic............................................................................................................................. 24
8.1 Operating the heating system .................................................................................................................... 24
8.2 Description of the control panel .................................................................................................................25
8.3 Setting language, date and time at Pelletronic Touch................................................................................25
8.4 Operating Device with Touch screen ........................................................................................................ 28
8.5 Opening window........................................................................................................................................ 28
8.6 User controls and their function ................................................................................................................ 29
8.7 Main Menu ................................................................................................................................................... 31
9 Mode ............................................................................................................................................................. 33
10 Measuring Values........................................................................................................................................ 34
11 Weather ....................................................................................................................................................... 35
12 Heating Circuit ............................................................................................................................................ 36
12.1 Measuring values Heating circuit................................................................................................................37
12.2 Time programme Heating circuit.............................................................................................................. 38
12.3 Party.......................................................................................................................................................... 39
12.4 Vacation .................................................................................................................................................... 39
12.5 Heating curve and Heating limits..............................................................................................................40
13 Domestic hot water .................................................................................................................................... 43
13.1 Measuring values Domestic hot water.......................................................................................................44
13.2 Time programme DHW.............................................................................................................................44
14 DHW Return pump ..................................................................................................................................... 45
14.1 Measuring values DHW Return pump .......................................................................................................46
14.2 Time programme DHW return pump .......................................................................................................46
15 Solar............................................................................................................................................................. 47
15.1 Measuring values Solar............................................................................................................................... 47
15.2 Solar circuit................................................................................................................................................ 48
15.3 Yield - Solar Energy...................................................................................................................................49
16 Pellematic....................................................................................................................................................50
16.1 Measuring values........................................................................................................................................50
16.2 ull Power................................................................................................................................................... 51
Contents

Operating Manual AutoPellet® PES 20, 32, 56
16.3 Boiler cleaning............................................................................................................................................52
16.4 Level detection system............................................................................................................................. 53
16.5 Suction turbine.......................................................................................................................................... 54
17 General ........................................................................................................................................................ 55
17.1 Chimney ..................................................................................................................................................... 56
17.2 avorite ..................................................................................................................................................... 56
17.3 Local Settings............................................................................................................................................ 58
17.4 Malfunction................................................................................................................................................ 59
17.4.1 Malfunction report ..................................................................................................................... 59
17.5 Information................................................................................................................................................ 76
17.6 ModBUS .....................................................................................................................................................77
17.7 E-Mail......................................................................................................................................................... 78
17.8 IP Config.................................................................................................................................................... 79
18 Software ...................................................................................................................................................... 84
19 Emptying the ash pan................................................................................................................................. 85
20 Emptying the ash box................................................................................................................................ 86
21 Maintenance and servicing......................................................................................................................... 88
21.1 Maintenance............................................................................................................................................... 88
21.2 Cleaning the boiler every year .................................................................................................................. 89
21.3 Maintenance intervals ...............................................................................................................................94
21.4 Repairs ......................................................................................................................................................94
21.5 Checking the boiler room and storage room............................................................................................ 94
22 Data for 20KW model, including emissions.............................................................................................. 95
23 Data for 32KW model, including emissions .............................................................................................. 96
24 Data for 56KW model, including emissions.............................................................................................. 97
25 General information ................................................................................................................................... 98
Contents

Dear Customer 5
1Dear Customer
Maine Energy Systems specializes in wood pellet heating.
Our company enjoys an exclusive license from Öko EN to manufacture products here in North America.
We represent expertise, innovation and quality.
We are delighted that you have decided to purchase our product.
• This instruction manual is intended to help you operate the product safely, properly and economically.
• Please read this instruction manual completely and take note of the safety warnings.
• Keep all documentation supplied with this unit in a safe place for future reference.
• Installation and first startup must be carried out by a qualified installer certified by Maine Energy Systems.
• The installation must comply with the requirements of the Authority having jurisdiction over the
installation.
• Please contact your authorized dealer if you have any questions.
We place great importance on the development of new products. Our R&D department continues to
question accepted solutions and works continually on new improvements. That is how we maintain our
technological lead. We have already received several awards for our products in Austria and abroad.
Our products fulfil European and USA requirements regarding quality, efficiency and emissions.
Operating Manual AutoPellet® PES 20, 32, 56

2Use only for the purpose intended
The pellet boiler is designed to heat water for central or other indirect heating systems and hot water supply
for buildings. It is not permissible to use the pellet boiler for any other purpose. Reasonable foreseeable
inadvertent uses for the pellet boiler are not known.
The boiler fulfils the requirements of UL 2523-2013 and CSA B366.1–2011.
PE 568 USA 2.0
6Use only for the purpose intended

Types of safety arning sign 7
3Types of safety warning sign
The warning signs use the following symbols and texts.
Types of safety warning sign
1. Risk of injury
2. Consequences of risk
3. Avoiding risk
1. Risk of injury:
Danger - indicates a situation that could lead to death or life-
threatening injury.
Warning - indicates a situation that could lead life-threatening or
serious injury.
Caution - indicates a situation that could lead to injury.
Note - indicates a situation that could lead to property damage.
2. Consequences of risk
Effects and consequences resulting from incorrect operation.
3. Avoiding risk
Observing safety instructions ensures that the heating system is
operated safely
Operating Manual AutoPellet® PES 20, 32, 56

44 Warnings and safety instructions
Observing safety instructions ensures that the heating system is operated safely.
4.1 Basic safety instructions
• Never get yourself into danger; give your own safety top priority.
• Keep children away from the central heating room and storage room.
• Observe all safety warnings on the boiler and in this user manual.
• Observe all instructions relating to maintenance, servicing and cleaning.
• The pellet heating system may only be installed and commissioned by an installer that is trained and re-
mains currently authorized by Maine Energy Systems.
• Never make any changes to the heating system or flue gas system. All maintenance, cleaning and changes
should only be done by trained professionals.
• Never close or remove safety valves.
4.2 Warning signs
RRiisskk ooff ppooiissoonniinngg
Make sure that the pellet boiler is supplied with suffi-
cient combustion air.
The openings in the combustion air inlet must never be
partially or completely closed.
Ventilation systems, central vacuum cleaning systems,
extractor fans, air conditioning systems, flue gas
blowers, dryers, fuel storage ventilation fans or similar
equipment must never be allowed to draw air from the
boiler room and cause a drop in pressure.
The boiler must be connected tight to the chimney
using a flue gas tube.
Clean the chimney and the flue gas tube at regular
intervals.
The boiler room and pellet storage room must be suffi-
ciently supplied with air and ventilated.
Before entering the storage room it must be ventilated
with sufficient air and the heating system switched off.
RRiisskk ooff eelleeccttrriicc sshhoocckk
Always disconnect / de-energize the power supply be-
fore working on the boiler.
RRiisskk ooff eexxpplloossiioonn
DO NOT BURN GARBAGE, GASOLINE, NAPHTHA, EN-
GINE OIL, OR OTHER INAPPROPRIATE MATERIALS.
DO NOT USE CHEMICALS OR LUIDS TO START THE
IRE.
Switch off the heating system before filling the storage
room.
PE 568 USA 2.0
8Warnings and safety instructions

Warning signs 9
RRiisskk ooff ffiirree
Do not store any flammable materials in the boiler room.
Do not hang out any washing in the boiler room.
Do not operate with fuel loading or ash removal doors
open.
RRiisskk ooff bbuurrnnss
Do not touch the flue gas connector or flue gas pipe.
Do not reach into the ash chamber.
Do not clean the boiler until it has been allowed to cool
down.
HHOOTT SSUURR AACCEESS
Keep children away.
Do not touch during operation.
Do not operate if maximum draft as listed on boiler
nameplate is exceeded.
Doing so can allow non-controlled combustion.
RRiisskk ooff ccuutt iinnjjuurriieess dduuee ttoo sshhaarrpp eeddggeess..
Use gloves for performing all work on the boiler.
DDaammaaggee ttoo pprrooppeerrttyy
The pellet boiler is suitable only for pellets which comply
with P I premium or EnPlus -A1 pellets specifications.
The use of any other fuel voids your warranty and can
cause damage to the pellet boiler and chimney.
DDaammaaggee ttoo pprrooppeerrttyy
Do not use the heating system if it, or any of its compo-
nents, come into contact with water.
If water damage occurs, check the heating system and
replace damaged parts.
All cover plates, enclosures, and guards must be main-
tained in place at all times, except during maintenance
and servicing.
Operating Manual AutoPellet® PES 20, 32, 56

4.3 What to do in an emergency
RRiisskk ttoo lliiffee
Never get yourself into danger; give your own safety
top priority.
What to do in the event of a fire
• Switch off the heating system.
• Call your local fire department and / or 911.
• Use approved fire extinguishers (fire protection class ABC).
What to do if you smell smoke
• Switch off the heating system.
• Close the doors leading to living areas.
• Ventilate the boiler room.
PE 568 USA 2.0
10 What to do in an emergency

Prerequisites for installing a pellet boiler 11
55 Prerequisites for installing a pellet boiler
You must fulfill the following conditions before operating a fully automatic pellet boiler.
5.1 Guidelines and standards for installing a pellet boiler
Overview of standards and guidelines applying to the installation of a pellet boiler.
Check whether you need to obtain planning permission or approval from the authorities for installing a new
heating system or changing your existing system. Legislation in your country must be observed.
lue gas system EN 13384–1 Legislation in your country must be observed.
Building and fire pre-
vention regulations
Legislation in your country must be observed.
Type of installation C 42x ireplace with a flue gas fan for connection to an air exhaust sys-
tem. The combustion air line from air shaft and the connecting
piece to the chimney are part of the fireplace.
C 52x ireplace with a flue gas for connection to a chimney. The com-
bustion air line from outside and the connecting piece to the
chimney are part of the fireplace.
Sound insulation DIN 4109 Please note the building-unique demands on sound insulation.
5.2 Installation room
The installation room of the boiler is not necessarily a boiler room. Observe the applicable national and regio-
nal regulations.
1. Safety warnings for the installation room
RRiisskk ooff ffiirree
Do not store flammable materials or liquids in the vici-
nity of the pellet boiler.
Do not permit unauthorized persons to enter the boiler
room - Keep children away.
Do not operate with fuel loading or ash removal doors
open.
2. Ventilation of the installation room
The installation room must have air inlet and outlet openings for ventilation, even if there is a direct con-
nection to the burner for combustion air.
This is to keep the combustion zone at a neutral pressure.
3. Admission of combustion air,
the pellet boiler requires combustion air. The combustion air can be supplied by:
a. Relying upon the boiler room air as supplied by the air inlet and outlet openings for ventilation in the
installation room.
b. Independently of the room air via a separate air intake line with a direct connection to the outdoor
atmosphere.
The air intake line must not follow the sewage pipe. The diameter of the air intake line must be at least
4 inches. If the air line is greater than 12 feet in length, or if it has more than 270 degrees of turns, then
it should be increased in size to 5 inch.
Never operate the pellet boiler if the air intake openings are partially or completely closed.
Contaminated combustion air can cause damage to the pellet boiler. Never store or use cleaning deter-
gents containing chlorine, nitrobenzene or halogen in the room where the heating system is installed, if
combustion air is drawn directly from the room. Be particularly cautious around swimming pools and
Operating Manual AutoPellet® PES 20, 32, 56

chemicals.
Do not hang out washing in the boiler room.
Prevent dust from collecting at the combustion air intake to the pellet boiler.
4. System damage due to frost and humidity
The temperature in the installation room must not drop below 38° and must not exceed +86° . The rela-
tive humidity in the installation room must not exceed 70%.
5. Danger for animals
Prevent pets and other small animals getting into the installation room. Install grilles over all openings.
6. Flooding
In the event of a flooding risk, switch off the pellet boiler and disconnect it from the main power supply
before water enters the boiler room. All components that come into contact with water must be replaced
before the pellet boiler is put into operation again.
5.3 Flue gas system
The flue gas system consists of a chimney and a flue gas tube. The flue gas tube connects the pellet heating
system to the chimney. The chimney leads the flue gas from the pellet heating system out into the open.
1. Design of the chimney
The dimensions and design of the chimney is very important. The chimney must be able to ensure suffi-
cient draft to safely draw away the flue gas regardless of the status of the boiler. Low flue gas tempera-
tures can cause sooting and moisture damage on chimneys that are not insulated. or this reason
moisture-resistant chimneys (stainless steel or ceramic) should be used. An existing chimney that is not
damp-resistant needs to be rennovated before use. ollow guidelines below:
Boiler size AutoPellet
lue gas tube diameter (at boiler) inch/mm 6/160
lue gas temp. / rated power ° 266 – 320
lue gas temp. / partial load ° 194 – 248
Min. draft – full load/part load in/wc – 0.04 / – 0.02
Chimney size Min. Height
6in x 6in 17ft
7in x 7in 16ft
8in x 8in 16ft
6in round 19ft
7in round 17ft
Person(s) operating a hydronic heater is/are responsi-
ble for operation in a manner that does not create a
public or private nuisance condition. The manufacturer's
distance and stack height recommendations and the re-
quirements in any applicable laws or other requirements
may not always be adequate to prevent nuisance condi-
tions due to terrain or other factors.
Recommended and UL-103HT approved chimney materials are:
PE 568 USA 2.0
12 Flue gas system

Flue gas system 13
a. Selkirk sure temp
b. Supervent (JSC)
c. Security chimneys (secure temp ASHT)
Use flue gas pipe from chimney to boiler as required by your local code.
UUnnrreegguullaatteedd ccoommbbuussttiioonn
Please observe that combustion air openings and flue
pipes are not reduced in size or closed. Make end user
aware of these guidelines and their potential danger.
Clean the chimney and the flue gas tube at regular
intervals.
Check if the draft inducer is clean and in a good
condition.
2. Flue gas temperature
The flue gas temperatures are approximately the same for all AutoPellet covered in this manual.
The dewpoint of flue gas with wood pellets (max. 10% water content) is approx. 120° .
It is possible to increase the flue gas temperature to prevent condensation inside the chimney and avoid
damage due to damp. Only authorised installers may increase the flue gas temperature.
Note:
The increase in flue gas temperature results in reduced efficiency and thus increases fuel
consumption.
3. Negative pressure of the chimney
The boiler must be connected to a chimney or a vertical venting system that is capable of handling and
producing a negative breeching pressure of –0.4 “WC. Use a draft gauge to verify the indicated draft va-
lue, adjust barometric damper as required. Drill a small hole in the connection pipe at about 2in/ 50mm
from the boiler flue outlet and use this hole as your measuring point.
Chimney draft
The suction effect of the chimney draft must extend all the way to the boiler flue pipe connection. The
maximum flow rate that can be drawn through the chimney limits the maximum performance of the chim-
ney connection. The boiler performance must be reduced if the chimney does not possess the necessary
cross-section. This may only be performend by authorised personnel.
4. Cleaning
Clean the flue gas tube and chimney regularly. Solid fuel burning appliances need to be cleaned fre-
quently because soot, creosote, and ash may accumulate. The hotter the fire, the less creosote is depos-
ited. Cleaning intervals can vary in warm periods due to this and become more frequent.
Operating Manual AutoPellet® PES 20, 32, 56

RRiisskk ooff cchhiimmnneeyy ffiirree
Creosote-formation and need for removal:Low flue gas
temperature can cause creosote. Creosote can con-
dense in a relatively cool chimney. As a result, creosote
residue accumulates on the flue lining. If ignited, this
creosote will create an extremely hot fire. The chimney
and the chimney connector should be inspected at least
twice monthly during the heating season to determine if
a creosote buildup has occurred. If creosote has accu-
mulated it should be removed to reduce the risk of a
chimney fire.
OOxxiiddaattiioonn ooff cchhiimmnneeyy
Do not use metal brushes to clean chimneys made of
stainless steel.
Your state and local regulations must be observed.
PE 568 USA 2.0
14 Flue gas system

Safety systems 15
5.4 Safety systems
The following safety measures are the prerequisite for safe operation of your system.
Emergency stop switch
Every heating system must be able to be switched off with an Emergency Stop switch.
The Emergency Stop switch location is determined by your local code requirement.
It should remove all electrical power from the boiler.
Safety valve / Over Pressure Relief Valve
This valve opens when the pressure inside the heating system increases to max. 43.5 PSI.
or North America, a 30 PSI Relief Valve is supplied with each boiler. This valve must not be
locked out or plugged and must be within 3 feet of the boiler, with no valves between the
relief valve and boiler.
Low Water Detection
The "Low Water Detection" device is connected to the Emergency Stop of the boiler.
Should a low water condition be detected, the boiler stops firing immediately. This device
must be of the manual reset variety.
Safety temperature sensor
The pellet boiler is equipped with a safety temperature sensor. This is located on the pellet
boiler. If the boiler temperature exceeds 230° , then the heating system switches off.
Expansion tank
All heating systems must be equipped with an expansion tank.
The overall size of the heating system volume will dictate the required expansion tank size.
IInniittiiaall ssttaarrtt--uupp
The initial start-up of each MESys boiler must be per-
formed by an authorized installer.
5.5 Installation with an existing boiler
MESys boilers are not to be connected to a chimney flue serving another appliance. However, when all State
and local codes allow for the sharing of chimney flues, MESys boilers and another appliance burning pellets
or a different fuel can be operated simultaneously while connected to a single existing chimney or flue gas
system providing the following conditions are met:
• All state and local codes permit the specific installation.
• All appliances are installed in accordance with the manufacturer’s installation specifications or if lacking
manufacturers specifications, the appliance in question is installed in a manner commonly recognized as
safe and correct for the application and circumstances.
• The chimney or flue gas system must be able to handle the combustion products of either appliance and
both appliances when operated simultaneously.
AAvvooiidd cclleeaarraannccee iissssuueess tthhaatt ccaann mmaakkee sseerrvviicciinngg
ddiiffffiiccuulltt::
Be sure to follow suggested clearances when installing
this boiler with an existing boiler to be sure that service
and cleaning can be performed adequately.
Operating Manual AutoPellet® PES 20, 32, 56

AAvvooiidd ccooddee vviioollaattiioonnss::
When connecting to or with an existing boiler, contact
the authority having jurisdiction to be sure the type of
installation planned is allowed.
Document the type of boiler that the Pellematic is con-
nected to or with.
Pellet boiler: Make and Model number:
____________________
Existing boiler: Make and Model number:
_____________________
PPoossssiibbllee eessccaappee ooff fflluuee ggaass::
Do not connect this unit to a chimney flue serving an-
other appliance unless multiple appliances into a single
flue is authorized by all authorities having jurisdiction.
PE 568 USA 2.0
16 Installation ith an existing boiler

Fuel 17
66 Fuel
Wood pellets are natural wood (dried sawdust or waste from machining) that has been formed into pellets
under high pressure. They have a very low moisture content and very high calorific value. The manufacture of
wood pellets is regulated by European standard EN ISO 17225–2.
Fuel Property PFI Premium
Normative Information – Mandatory
Bulk Density, lb./cubic foot 40.0 – 46.0
Diameter, inches 0.230 – 0.285
Diametern mm 5.84 – 7.25
Pellet Durability Index ≥96.5
indes, % (at the mill gate) ≤0.50
Inorganic Ash, % ≤1.0
Length, % greater than 1.50 inches ≤1.0
Moisture, % ≤8.0
Chloride, ppm ≤300
Heating Value NA
Informative Only – Not Mandatory
Ash usion NA
NNeevveerr uussee ppeelllleettss tthhaatt ccooppnnttaaiinn ttrreeaatteedd wwoooodd,,
ccoolloorreedd ppaappeerr pprroodduuccttss,, ccaarrddbbooaarrdd,, ssoollvveennttss,, ppllaassttiicc
ttrraasshh oorr ggaarrbbaaggee..
Never burn trash, plastics, gasoline, solvents, naphtha,
houshold garbage, material treated with petroleum
products such as particleboard, railroad ties und
pressure treated wood leaves, paper products,
cardboard.
6.1 Specification for high quality pellets as per EN ISO 17225–2,
class A1 and by PFI standards in North America
Calorific value ≥4,6 kWh/kg or ≥16,5 MJ/kg
Loose density min. 600 kg/m³
Water content max. 10% Specification for high quality pellets as per EN
ISO 17225–2, class A1
Ash content max. 0.7%
Length max. 40 mm
Diameter 6 mm
ine material max. 1%
Contents 100% natural wood
Operating Manual AutoPellet® PES 20, 32, 56

TThhee hheeaattiinngg ssyysstteemm iiss ssuuiittaabbllee oonnllyy ffoorr ppeelllleettss ooff nnaa--
ttuurraall wwoooodd tthhaatt ccoommppllyy wwiitthh ssttaannddaarrdd EENN IISSOO 1177222255––
22 ccllaassss AA11 wwiitthh aa ddiiaammeetteerr ooff 66 mmmm.. UUssiinngg nnoonn--ppeellllee--
ttiisseedd ffuueellss oorr ppeelllleettss tthhaatt aarree nnoott mmaannuuffaaccttuurreedd ffrroomm
nnaattuurraall wwoooodd wwiillll lleeaadd ttoo tthhee wwaarrrraannttyy bbeeccoommiinngg
vvooiidd aanndd wwiillll ccaauussee ddaammaaggee ttoo tthhee ppeelllleett bbooiilleerr aanndd
tthhee cchhiimmnneeyy..
Use only quality pellets that are DINplus or ENplus or
P I premium Certified.
NNeevveerr uussee ppeelllleettss tthhaatt ccoonnttaaiinn ttrreeaatteedd wwoooodd,, ccoolloo--
rreedd ppaappeerr pprroodduuccttss,, ccaarrddbbooaarrdd,, ssoollvveennttss,, ppllaassttiicc,,
ttrraasshh oorr ggaarrbbaaggee
Never burn trash, plastics, gasoline, solvents, naphtha,
household garbage, material treated with petroleum
products such as particleboard, railroad ties and press-
ure treated wood, leaves, paper products, cardboard.
6.2 Distance to flammable materials
Observe the country-specific regulations, Local Regulations or N PA.
6.3 Storing the pellets
1. Pellets are to be stored in a place where they are kept dry all year.
2. Install a back-ventilated partition to prevent pellets from contacting damp walls, or use a fabric tank.
3. Refer to our planning hints for pellet storage rooms and warning signs.
4. Legislation in your country must be observed regarding building specifications for storage rooms.
5. Öko EN also offers leXILO fabric tanks for storing pellets.
6.4 Measures for the ventilation of storage rooms
To avoid any kind of danger through possible degassing of the pellets, make sure you obey the following
guidelines:
• The storage room has to be insulated towards the living area.
• The storage room has to be ventilated to the outdoors.
or further information please consult your expert adviser.
PE 568 USA 2.0
18 Distance to flammable materials

Product description 19
77 Product description
The description of the product is intended to provide an overview of the components that make up an
Öko EN pellet heating system, the parts of the pellet boiler and advice on where you can find more
information.
The Öko EN concept features different sizes of design and type for each component. These are compatible
and designed to match.
The ÖkoFEN pellet heating system consists of 3 components
1Pellematic pellet boiler
2 Conveyor system
3Storage system – storage room or fabric tank
7.1 The pellet boiler
The pellet boiler is equipped with an automatic cleaning system, an ash box with ash compression system
and an integrated return water temperature control. The installed programmable logic controller system en-
ables fully automatic operation and highest efficiency. We offer an optional automatic de-ashing system for
the highest level of cleanliness and comfort.
Pellematic types and power ratings
We offer the Pellet boiler with the following power ratings:
Suction-feed systems: 68,300; 109,500 and 191,000 BTU/hr
All sizes / outputs of the Autopellet boiler are
available with external automatic ash compression
system.
Note:
Refer to the data plate for the power rating of
your Pellematic. The data plate is located on
the rear side of the Pellematic. Here you will
find the type designation, manufacturer's seri-
al number and year of build.
Operating Manual AutoPellet® PES 20, 32, 56

Key components of the Pellematic
1Boiler (heat exchanger)
2Vac Hopper / Day tank
3 Burner
4External automatic ash compression
system
5Boiler controller
PE 568 USA 2.0
20 The pellet boiler
