Majestic CDVR33SC7 Installation instructions

PR O D U C T S P E C I F I C AT I O N S
CDVR33SC7 Direct Vent
G L A S S V I E W I N G A R E A
27-3/16”W x 15-7/16”H (418 Square Inches)
(691 mm x 386 mm)
S TA N D A R D F E AT U R E S
Unitized black louver assembly
Ember bed burner
Ceramic Fiber logs
Grate
Junction box
Nailing tabs for 1/2” (12.7 mm) and 5/8” (15.9 mm)
FIELD INSTALLED ACCESSORIES
Firebrick: Tavern Brown
Curved Trim: Black
Medium Trim Kit: Black
M nu l Blower nd Cord (160cfm): F -12
Thermost t Blower (160cfm): BLOT
Sign ture Comm nd Blower (160cfm): BLOTSC (requires purchase
of SCSACM & TSFSC)
Sign ture Comm nd Remotes &Thermost ts: RMSC,TSMSC,TSTSC,
TSFSC,WT)
Sign ture Comm nd Accessories: A/C Accessory, Module and
Command Center,Wall Mount its
Conversion Kits: Natural Gas (CDV33C NS), LP Gas (CDV33C PS)
Mesh Screen Glass Cover
Wood Cabinet Surrounds
Designer Facings (Current 300DVB trim, fronts and filigree panels will
fit the CDV. Doors and door frames do not.)
A Brand of Monessen Hearth Systems Co.
149 Cleveland Drive, Paris, Kentucky 40361
www.majesticproducts.com
21-1/2” (546 mm)
2-5/16”
(59 mm)
5” (127 mm)
21-15/16”
(557 mm)
32-1/4”
(819 mm)
31-11/16”
(805 mm)
15-3/16”
(386 mm)
27-3/16”
(691 mm)
15/16”
(23.8 mm)
29-7/8”
(759 mm)
33-3/8”
(848 mm)
1-1/4”
(31.8 mm)
33-5/8” (854 mm)
Minimum Rough Opening Width
Minimum Rough
Opening Depth
1/2”
(12.7 mm)
5/8”
(15.9 mm)
5/8”
(15.9 mm)
C
L
51”
(1295 mm)
36”
(914 mm)
11-1/4”
(286 mm)
36”
(914 mm)
25-1/2”
(648 mm)
11-3/4”
(299 mm)
Minimum Rough
Opening Height
1/2” (12.7 mm)
5/8” (15.9 mm)
1/2” (12.7 mm)
5/8” (15.9 mm)

To avoid personal injury or property damage, the product described by this brochure must be installed, operated and maintained in strict compliance with the instructions packaged with the product and all applicable
building or fire codes. Contact local building or fire officials about restrictions and installation inspection requirements. All photographs and drawings on this brochure are for illustrative purposes only and are
not intended for, nor should they be used as a substitute for the instructions packaged with the unit. Appearance and specifications of the product are subject to change without notice. 12/10 ver.1
HPBA
Hearth, Patio & Barbecue Association
MADE IN U.S.A.
A Brand of Monessen Hearth Systems Co.
149 Cleveland Drive, Paris, Kentucky 40361
www.majesticproducts.com
PR O D U C T S P E C I F I C AT I O N S
CDVR33SC7 Direct Vent
T E C H N I C A L S P E C I F I C AT I O N S
BTU Input: 18,000 Max, 13,000 Min. (Nat) / 18,000 Max, 13,000
Min. (LP)
Ignition System: Signature Command System (AC w/ battery back up)
G s Type: Natural Gas or Liquid Propane
G s Line: 18” (473 mm) Flex line w/ shut off 1/2” (12.7 mm) FPT
Flue Type: 4 x 7 Twist Lock, Flex Vent*
Termin tion: Dedicated Rear Vent
Horizont l Vent: Maximum 20” (508 mm) straight off rear of unit
Low Volt ge W ll Switch Wire: 15' (4.5 m) wire with wall switch
and cover
Design Certified: CSA
C L E A R A N C E T O F L U E
Horizont l: 3” (26 mm) Top, 1” (25 mm) Bottom and sides**
Vertic l: 1” (25 mm) on all sides
C L E A R A N C E T O C O M B U S T I B L E S
Firepl ce: 0” Clearance to stand offs all sides
Floor of unit to Ceiling: 72” (1.83 m) to Combustibles
Firebox Opening to W ll: 6” (152 mm) to Combustibles
He rth Requirement: 0” Clearance
E F F I C I E N C Y D A TA
Therm l Efficiency: Up to 80% Nat / 80% LP
AFUE Efficiency: 61.2% Nat / 66.3% LP
P4 C n d Efficiency: 57.6% Nat / 64.3% LP
*Simpson Dura-Vent, Selkirk Metalbestos and Metalfab are also approved for vent ap-
plications (requires adapter).
**When vertical rise is 7-1/2 feet (2.29 m) or higher from base of unit, the horizontal
vent clearance to combustibles is 1" (25 mm) all sides.
12” (305 mm)
8” (203 mm)
6” (152 mm)
2-1/2” (64 mm)
14” (356 mm)
11” (279 mm)
10” (254 mm)
8” (203 mm)
Finish Wall
Header
Stud
Standoff
Top of Heat
Exhaust Vent
FP2285b
Side View
Front View
6”(152 mm)
5”(127 mm)
3”(76 mm)
45°
1”(25 mm)
2-1/2” (64 mm)
1-1/2” (38 mm)
3-1/2” (89 mm)
4-1/2” (114 mm)
Side of Fireplace
Opening
Stud
Wall
FP2286
Combustible
Material Area
M A N T E L C L E A R A N C E S
NOTE: The combustible area above the facing must not protrude
more than 3/4” (19 mm) from the facing. If it does, it is consid-
ered a mantel and must meet the mantel requirements listed
here.
