Majestic GATEWAY M5533D User manual

For more information please visit
http://www.majestic-percussion.com Ver.201212
Check Contents
1. Tone Bars (naturals & accidentals) x 2 st
2. Keyboard Frame x 1 pc
3. Z-Stands (legs & crossbar) x 1 st
4. Resonator Set (optional) x 2 pc
5. Upgrade: add-on wheel (optional) x 2 pc
Assembly leg stand
Setup Z-stand by adjusting height on upright legs. Loosen knob, Slide the pin in
position, and then tighten the knob. (match height on both upright sections) If M5533
Resonators are used, must keep 5 pin holes or more open. Connect crossbar to the
middle of each upright leg, secure the crossbar by tightening each knob.
For X5535 Xylophone
For M5533 Marimba
1
2
3
4
GATEWAY SERIES
Assembly Instructions for M5533D X5535D
Attach Keyboard frame & Resonators (optional)
1. Fit the round rubber feet under the frame with the slots on top of each Z leg and
Slide-in to attach.
2. Attach resonator set by hanging each end on the rubber brackets at inner
side of keyboard frame. (the full resonator section is for the naturals and the
staggered resonator section is for the accidentals)
Attach bars to the frame
1. Unroll the tone bars carefully, holding the cord from both ends, place the bars
onto the frame.
2. Align bars between each post, slide cord into the ring of each post. (Attach the
naturals rst, followed by the accidentals)
3. Pull the cord at the low register end to a medium tension. And then connect the
springs. (adjust the knot at each spring to adjust tension)
1
2
4
3
5

For more information please visit
http://www.majestic-percussion.com
Ver.201212
GATEWAY SERIES
Assembly Instructions for
Add-on Wheels (M5533D & X5535D)
Wheel x 2 pc
Flat washer x 2 pc
Spring washer x 2 pc
Screw x 2 pc
Step by Step instruction:
1. Remove the parts from the bag
2. Insert screw with the sequence of spring washer, at washer
and wheel.
3. Attach the wheel assembly to Z-stand. The screw slots are
available only at one end of leg.
4. to nish the installation, fasten the screw and tighten with
drum-key.
M5533D
X5535D
Add-On Wheels (PGC26-252A) (MGW2 USA)
includes following items
