Parts Breakdown DS4000
Page 1 of 2 2/8/2008

Parts Breakdown DS4000
Fig # Part ID Part Name Quantity
1 193319-5 DRILL CHUCK S-13, 6304LR 1
2 254011-9 WOODRUFF KEY 4, NHP1310 1
3 324317-0 SPINDLE, DS4000 1
4 285821-3 BEARING RETAINER 22-41, DS4000 1
5 211256-2 B. BEARING 6203LLB, GA7001L 1
6 317612-5 GEAR HOUSING, DS4000 1
7 210016-9 BALL BEARING 698ZZ,DS4000 1
7 211023-5 BALL BEARING 607LB, 9031 1
8 226149-0 GEAR CPL. 7-53,DS4000 1
8 226150-5 GEAR COMPLETE 7-53 1
9 253804-1 F. WASHER 6, 6012HDW 1
10 265013-0 PAN HEAD SCREW M5X45, DS4000 4
10 911266-6 P.H. SCREW M4X45, JS3200 4
11 256157-7 PIN 3, 6222DWE 1
12 257253-4 RING 17, DS4000 1
13 226563-0 HELICAL GEAR 43,DS4000 1
14 961057-5 RETAINING RING S-17, 2711 1
15 211034-0 BALL BEARING 608, 2106 1
16 417976-8 GASKET, DS4000 1
17 153425-8 GEAR HOUSING COVER CPL. 1
18 210042-8 BALL BEARING 629LLB, 5277NB 1
18 211056-0 B. BEARING 629LLB, 4101RH 1
19 241850-6 FAN 60, HP2030 1
20 513536-5 ARMATURE ASS'Y 115V, DS4000 1
21 211031-6 BALL BEARING 608LLB, HR2400 1
22 911681-4 P.H. SCREW M5X60, 9218PBL 2
23 417977-6 BAFFLE PLATE, DS4000 1
24 634481-2 FIELD 115V, DS4000 1
25 638194-7 SUPPORT CPL. 1
26 819063-3 MAKITA LABEL, 6992DWDE 1
27 850134-7 NAME PLATE 1
28 183537-3 MOTOR HOUSING,DS4000 1
29 911233-1 P.H. SCREW M5X20, 2030S 2
30 418071-7 HANDLE BASE, DS4000 1
31 911233-1 P.H. SCREW M5X20, 2030S 2
32 911153-9 P.H. SCREW M4X28, JR3000V 4
33 181162-4 HANDLE SET, 6013BR 1
34 181162-4 HANDLE SET, 6013BR 1
35 643750-0 BRUSH HOLDER CAP, HM1100C 2
36 191963-2 CARBON BRUSH CB-303 SET, 9227C 1
37 652014-1 P.H. SCREW M4X8, 2708 1
38 651564-3 SWITCH, DA6300 1
39 687001-1 STRAIN RELIEF, 6013BR 1
40 911133-5 P.H. SCREW M4X18, N9501B 2
41 183583-6 HANDLE SET,DS4000 1
41 181655-1 HANDLE SET, DA4511 1
42 911143-2 P.H. SCREW M4X22, 6211D 3
43 911221-8 P.H. SCREW M5X16, JR3000V 4
44 664723-0 CORD (3X16X8 SJ), 2012 1
45 682573-1 CORD GUARD,JR3070CT 1
46 654531-7 TERMINAL BLOCK 2P, N900 1
47 181655-1 HANDLE SET, DA4511 1
47 183583-6 HANDLE SET,DS4000 1
48 421297-2 DUST COVER, 6013BR 1
1,001 410102-8 KEY HOLDER, 6013BR 1
1,002 763434-5 CHUCK KEY 10, 6302H,6303H 1
1,003 273657-2 GRIP 27, DS4000 1
5,001 810134-9 N/A 1
Page 2 of 2 2/8/2008
