Makita HP0300 User manual

HP0300
EN Hammer Driver Drill INSTRUCTION MANUAL 4
SL Udarni vrtalni vijačnik NAVODILA ZA UPORABO 9
SQ Trapan me goditje dhe punto MANUALI I PËRDORIMIT 14
BG Ударна бормашина РЪКОВОДСТВО ЗА
ЕКСПЛОАТАЦИЯ 20
HR Udarna bušilica-odvijač PRIRUČNIK S UPUTAMA 26
МК Ударна чекан-дупчалка УПАТСТВО ЗА УПОТРЕБА 31
SR Ударна бушилица-одвртач УПУТСТВО ЗА УПОТРЕБУ 37
RO Maşină de găurit şi înşurubat
cu percuţie MANUAL DE INSTRUCŢIUNI 43
UK Дриль з ударним приводом ІНСТРУКЦІЯ З
ЕКСПЛУАТАЦІЇ 49
RU Ударная Дрель Шуруповёрт РУКОВОДСТВО ПО
ЭКСПЛУАТАЦИИ 55

12
Fig.1
1
AB
Fig.2
1
Fig.3
2
3
1
4
Fig.4
2
3
4
1
5
Fig.5
2
3
1
Fig.6
1
33
2
Fig.7
1
2
Fig.8
2

1
Fig.9
1
Fig.10
1
Fig.11
1
Fig.12
3

4ENGLISH
ENGLISH (Original instructions)
SPECIFICATIONS
Model: HP0300
Drilling capacities Masonry 8 mm
Steel 10 mm
Wood 28 mm
Fastening capacities Wood screw 5.1 mm x 63 mm
Machine screw M6
No load speed (RPM) High (2) 0 - 1,500 min-1
Low (1) 0 - 450 min-1
Blows per minute High (2) 0 - 22,500 min-1
Low (1) 0 - 6,750 min-1
Overall length 235 mm
Net weight 1.3 kg
Safety class /II
• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange
without notice.
• Specicationsmaydifferfromcountrytocountry.
• WeightaccordingtoEPTA-Procedure01/2014
Intended use
Thetoolisintendedforimpactdrillinginbrick,brickwork
andmasonry.Itisalsosuitableforscrewdrivingand
drilling without impact in wood, metal, ceramic and
plastic.
Power supply
Thetoolshouldbeconnectedonlytoapowersupplyof
the same voltage as indicated on the nameplate, and
canonlybeoperatedonsingle-phaseACsupply.They
aredouble-insulatedandcan,therefore,alsobeused
from sockets without earth wire.
Noise
ThetypicalA-weightednoiseleveldeterminedaccord-
ingtoEN62841-2-1:
Sound pressure level (LpA):82dB(A)
Sound power level (LWA):93dB(A)
Uncertainty(K):3dB(A)
NOTE:Thedeclarednoiseemissionvalue(s)has
beenmeasuredinaccordancewithastandardtest
methodandmaybeusedforcomparingonetoolwith
another.
NOTE:Thedeclarednoiseemissionvalue(s)
mayalsobeusedinapreliminaryassessmentof
exposure.
WARNING: Wear ear protection.
WARNING: The noise emission during actual
use of the power tool can differ from the declared
value(s) depending on the ways in which the
tool is used especially what kind of workpiece is
processed.
WARNING: Be sure to identify safety mea-
sures to protect the operator that are based on an
estimation of exposure in the actual conditions of
use (taking account of all parts of the operating
cycle such as the times when the tool is switched
off and when it is running idle in addition to the
trigger time).
Vibration
Thevibrationtotalvalue(tri-axialvectorsum)deter-
minedaccordingtoEN62841-2-1:
Workmode:impactdrillingintoconcrete
Vibrationemission(ah,ID):12.5m/s2
Uncertainty(K):2.0m/s2
Workmode:drillingintometal
Vibrationemission(ah,D):2.5m/s2or less
Uncertainty(K):1.5m/s2
NOTE:Thedeclaredvibrationtotalvalue(s)hasbeen
measured in accordance with a standard test method
andmaybeusedforcomparingonetoolwithanother.
NOTE:Thedeclaredvibrationtotalvalue(s)mayalso
beusedinapreliminaryassessmentofexposure.

5ENGLISH
WARNING: The vibration emission during actual
use of the power tool can differ from the declared val-
ue(s) depending on the ways in which the tool is used
especially what kind of workpiece is processed.
WARNING: Be sure to identify safety measures
to protect the operator that are based on an estima-
tion of exposure in the actual conditions of use (tak-
ing account of all parts of the operating cycle such
as the times when the tool is switched off and when
it is running idle in addition to the trigger time).
EC Declaration of Conformity
For European countries only
TheECdeclarationofconformityisincludedasAnnexA
to this instruction manual.
SAFETY WARNINGS
General power tool safety warnings
WARNING: Read all safety warnings, instruc-
tions, illustrations and specications provided
with this power tool. Failure to follow all instructions
listedbelowmayresultinelectricshock,reand/or
seriousinjury.
Save all warnings and instruc-
tions for future reference.
Theterm"powertool"inthewarningsreferstoyour
mains-operated(corded)powertoolorbattery-operated
(cordless) power tool.
Hammer driver drill safety warnings
1. Wear ear protectors when impact drilling.
Exposuretonoisecancausehearingloss.
2.
Hold the power tool by insulated gripping surfaces,
when performing an operation where the cutting
accessory or fasteners may contact hidden wiring or
its own cord. Cuttingaccessoryorfastenerscontacting
a"live"wiremaymakeexposedmetalpartsofthepower
tool"live"andcouldgivetheoperatoranelectricshock.
3. Always be sure you have a rm footing. Be
sure no one is below when using the tool in
high locations.
4. Hold the tool rmly.
5. Keep hands away from rotating parts.
6. Do not leave the tool running. Operate the tool
only when hand-held.
7. Do not touch the bit or the workpiece immedi-
ately after operation; they may be extremely
hot and could burn your skin.
8.
Some material contains chemicals which may be
toxic. Take caution to prevent dust inhalation and
skin contact. Follow material supplier safety data.
9. If the drill bit cannot be loosened even you
open the jaws, use pliers to pull it out. In such a
case,pullingoutthedrillbitbyhandmayresultin
injurybyitssharpedge.
Safety instructions when using long drill bits
1.
Never operate at higher speed than the maximum
speed rating of the drill bit.Athigherspeeds,the
bitislikelytobendifallowedtorotatefreelywithout
contactingtheworkpiece,resultinginpersonalinjury.
2. Always start drilling at low speed and with the bit
tip in contact with the workpiece.Athigherspeeds,
thebitislikelytobendifallowedtorotatefreelywithout
contactingtheworkpiece,resultinginpersonalinjury.
3. Apply pressure only in direct line with the bit and do
not apply excessive pressure.Bitscanbendcausing
breakageorlossofcontrol,resultinginpersonalinjury.
SAVE THESE INSTRUCTIONS.
WARNING: DO NOT let comfort or familiarity with
product (gained from repeated use) replace strict adher-
ence to safety rules for the subject product. MISUSE or
failure to follow the safety rules stated in this instruc-
tion manual may cause serious personal injury.
FUNCTIONAL DESCRIPTION
CAUTION: Always be sure that the tool is
switched off and unplugged before adjusting or
checking function on the tool.
Switch action
►Fig.1: 1. Switch trigger 2.Lockbutton
CAUTION: Before plugging in the tool, always
check to see that the switch trigger actuates
properly and returns to the "OFF" position when
released.
CAUTION: Switch can be locked in “ON” posi-
tion for ease of operator comfort during extended
use. Apply caution when locking tool in “ON”
position and maintain rm grasp on tool.
Tostartthetool,simplypulltheswitchtrigger.Tool
speedisincreasedbyincreasingpressureontheswitch
trigger. Release the switch trigger to stop.
For continuous operation, pull the switch trigger, push
inthelockbuttonandthenreleasetheswitchtrigger.
Tostopthetoolfromthelockedposition,pulltheswitch
trigger fully, then release it.
Reversing switch action
►Fig.2: 1. Reversing switch lever
CAUTION: Always check the direction of
rotation before operation.
CAUTION: Use the reversing switch only after
the tool comes to a complete stop.Changingthe
directionofrotationbeforethetoolstopsmaydam-
age the tool.
Thistoolhasareversingswitchtochangethedirection
of rotation. Depress the reversing switch lever from the
AsideforclockwiserotationorfromtheBsideforcoun-
terclockwise rotation.

6ENGLISH
Speed change
►Fig.3: 1. Speed change lever
CAUTION: Always set the speed change lever
fully to the correct position. If you operate the
tool with the speed change lever positioned halfway
betweenthe"1"sideand"2"side,thetoolmaybe
damaged.
CAUTION: Do not use the speed change lever
while the tool is running.Thetoolmaybedamaged.
Position of
speed
change lever
Speed Torque Applicable
operation
1Low High Heavy load-
ing operation
2High Low Light loading
operation
Tochangethespeed,switchoffthetoolrst.Select
the"2"sideforhighspeedor"1"forlowspeedbuthigh
torque. Be sure that the speed change lever is set to the
correctpositionbeforeoperation.
If the tool speed is coming down extremely during the
operationwith"2",slidethelevertothe"1"andrestart
the operation.
Selecting the action mode
CAUTION: Always set the ring correctly to
your desired mode mark. If you operate the tool
with the ring positioned halfway between the
mode marks, the tool may be damaged.
CAUTION: When you change the position
from " " to other modes, it may be a little dif-
culty to slide the action mode changing ring. In
this case, switch on and run the tool for a second
at the " " position, then stop the tool and slide
the ring to your desired position.
►Fig.4: 1.Actionmodechangingring2.Adjusting
ring 3. Graduation 4.Arrow
Thistoolhasthreeactionmodes.
• Drilling mode (rotation only)
• Hammer drilling mode (rotation with
hammering)
• Screwdriving mode (rotation with clutch)
Selectonemodesuitableforyourwork.Turnthe
action mode changing ring and align the mark that you
selectedwiththearrowonthetoolbody.
Adjusting the fastening torque
►Fig.5: 1.Actionmodechangingring2.Adjusting
ring 3. Graduation 4. marking 5.Arrow
Thefasteningtorquecanbeadjustedin20levelsbyturningtheadjustingring.Alignthe marking with the arrow
onthetoolbody.Then,alignthegraduationswiththearrowonthetoolbody.Youcangettheminimumfastening
torque at 1 and maximum torque at 20.
Before actual operation, drive a trial screw into your material or a piece of duplicate material to determine which
torquelevelisrequiredforaparticularapplication.Thefollowingshowstheroughguideoftherelationshipbetween
the screw size and graduation.
Graduation 12345678910 11 12 13 14 15 16 17 18 19 20
Machine screw M4 M5 M6
Wood
screw
Soft wood
(e.g. pine)
–ɸ3.5 x 22 ɸ4.1 x 38 –
Hard wood
(e.g. lauan)
–ɸ3.5 x 22 ɸ4.1 x 38 –
ASSEMBLY
CAUTION: Always be sure that the tool is
switched off and unplugged before adjusting or
checking function on the tool.
Installing or removing driver bit/
drill bit
CAUTION:Afterinsertingthedriverbit/drillbit,
makesurethatitisrmlysecured.Ifitcomesout,do
not use it.
►Fig.6: 1.Tighten2. Sleeve 3. Ring
Hold the ring and turn the sleeve counterclockwise to
openthechuckjaws.Placethedriverbit/drillbitinthe
chuckasfarasitwillgo.Holdtheringrmlyandturn
the sleeve clockwise to tighten the chuck.
Toremovethedriverbit/drillbit,holdtheringandturn
the sleeve counterclockwise.

7ENGLISH
Installing hook
Optional accessory
CAUTION: When installing the hook, always
secure it with the screw rmly. If not, the hook
may come off from the tool and result in the personal
injury.
►Fig.7: 1. Groove 2. Hook 3. Screw
Thehookisconvenientfortemporarilyhangingthetool.
Thiscanbeinstalledoneithersideofthetool.Toinstall
the hook, insert it into a groove in the tool housing on
eithersideandthensecureitwithascrew.Toremove,
loosen the screw and then take it out.
Installing driver bit holder
Optional accessory
►Fig.8: 1.Driverbitholder2.Driverbit
Fitthedriverbitholderintotheprotrusionatthetoolfoot
on either right or left side and secure it with a screw.
Whennotusingthedriverbit,keepitinthedriverbit
holders.Driverbits45mm-longcanbekeptthere.
OPERATION
CAUTION: When the speed comes down
extremely, reduce the load or stop the tool to
avoid the tool damage.
►Fig.9: 1. Vent
Holdthetoolrmlywithonehandonthegrip.
Inthecaseofthetwistingaction,holdthegriprmly
withbothhands.
NOTICE: Do not cover vents, or it may cause over-
heating and damage to the tool.
Screwdriving operation
CAUTION: Adjust the adjusting ring to the
proper torque level for your work.
CAUTION: Make sure that the driver bit is
inserted straight in the screw head, or the screw
and/or driver bit may be damaged.
First, turn the action mode changing ring so that the
arrowonthetoolbodypointstothe marking.
Placethepointofthedriverbitinthescrewheadand
apply pressure to the tool. Start the tool slowly and then
increase the speed gradually. Release the switch trigger
as soon as the clutch cuts in.
NOTE: When driving wood screw, pre-drill a pilot hole
2/3 the diameter of the screw. It makes driving easier
and prevents splitting of the workpiece.
Hammer drilling operation
CAUTION: There is a tremendous and sud-
den twisting force exerted on the tool/drill bit
at the time of hole breakthrough, when the hole
becomes clogged with chips and particles, or
when striking reinforcing rods embedded in the
concrete.
First, turn the action mode changing ring so that the arrow
onthetoolbodypointstothe marking.Theadjusting
ringcanbealignedinanytorquelevelsforthisoperation.
Besuretouseatungsten-carbidetippeddrillbit.
Positionthedrillbitatthedesiredlocationforthehole,
then pull the switch trigger. Do not force the tool. Light
pressuregivesbestresults.Keepthetoolinposition
and prevent it from slipping away from the hole.
Donotapplymorepressurewhentheholebecomes
clogged with chips or particles. Instead, run the tool at
anidle,thenremovethedrillbitpartiallyfromthehole.
Byrepeatingthisseveraltimes,theholewillbecleaned
outandnormaldrillingmayberesumed.
Blow-out bulb
Optional accessory
►Fig.10: 1.Blow-outbulb
Afterdrillingthehole,usetheblow-outbulbtocleanthe
dust out of the hole.
Drilling operation
First, turn the action mode changing ring so that the arrow
points to the marking.Thenproceedasfollows.
Drilling in wood
Whendrillinginwood,thebestresultsareobtainedwith
wooddrillsequippedwithaguidescrew.Theguidescrew
makesdrillingeasierbypullingthedrillbitintotheworkpiece.
Drilling in metal
Topreventthedrillbitfromslippingwhenstartinga
hole, make an indentation with a center-punch and
hammeratthepointtobedrilled.Placethepointofthe
drillbitintheindentationandstartdrilling.
Useacuttinglubricantwhendrillingmetals.Theexcep-
tionsareironandbrasswhichshouldbedrilleddry.
CAUTION: Pressing excessively on the tool
will not speed up the drilling. In fact, this excessive
pressure will only serve to damage the tip of your drill
bit,decreasethetoolperformanceandshortenthe
service life of the tool.
CAUTION: Hold the tool rmly and exert care
when the drill bit begins to break through the
workpiece.Thereisatremendousforceexertedon
thetool/drillbitatthetimeofholebreakthrough.
CAUTION: A stuck drill bit can be removed
simply by setting the reversing switch to reverse
rotation in order to back out. However, the tool
may back out abruptly if you do not hold it rmly.
CAUTION: Always secure workpieces in a
vise or similar hold-down device.

8ENGLISH
MAINTENANCE
CAUTION: Always be sure that the tool is
switched off and unplugged before attempting to
perform inspection or maintenance.
NOTICE: Never use gasoline, benzine, thinner,
alcohol or the like. Discoloration, deformation or
cracks may result.
TomaintainproductSAFETYandRELIABILITY,
repairs,anyothermaintenanceoradjustmentshould
beperformedbyMakitaAuthorizedorFactoryService
Centers,alwaysusingMakitareplacementparts.
Replacing carbon brushes
►Fig.11: 1. Limit mark
Checkthecarbonbrushesregularly.
Replace them when they wear down to the limit mark.
Keepthecarbonbrushescleanandfreetoslipinthe
holders.Bothcarbonbrushesshouldbereplacedatthe
sametime.Useonlyidenticalcarbonbrushes.
1. Useascrewdrivertoremovethebrushholder
caps.
2. Takeouttheworncarbonbrushes,insertthenew
onesandsecurethebrushholdercaps.
►Fig.12: 1. Brush holder cap
OPTIONAL
ACCESSORIES
CAUTION: These accessories or attachments
are recommended for use with your Makita tool
specied in this manual.Theuseofanyother
accessories or attachments might present a risk of
injurytopersons.Onlyuseaccessoryorattachment
for its stated purpose.
If you need any assistance for more details regard-
ing these accessories, ask your local Makita Service
Center.
• Drillbits
• Driverbits
• Socketbits
• Tungsten-carbidetippeddrillbit
• Blow-outbulb
• Hook
• Driverbitholder
NOTE:Someitemsinthelistmaybeincludedinthe
toolpackageasstandardaccessories.Theymay
differ from country to country.

9SLOVENŠČINA
SLOVENŠČINA (Originalna navodila)
TEHNIČNI PODATKI
Model: HP0300
Vrtalnezmogljivosti Zidarstvo 8 mm
Jeklo 10 mm
Les 28 mm
Zateznezmogljivosti Lesnivijak 5,1 mm x 63 mm
Strojnivijak M6
Hitrostbrezobremenitve
(vrt/min)
Visoka (2) 0 - 1.500 min-1
Nizka (1) 0 - 450 min-1
Udarci na minuto Visoka (2) 0 - 22.500 min-1
Nizka (1) 0 - 6.750 min-1
Celotnadolžina 235 mm
Netoteža 1,3 kg
Razredzaščite /II
• Kernenehnoopravljamoraziskaveinrazvijamosvojeizdelke,selahkotehničnipodatkivtemdokumentuspremenijobrezobvestila.
• Tehničnipodatkiselahkorazlikujejooddržavedodržave.
• TežavskladuspostopkomEPTA01/2014
Predvidena uporaba
Orodjejenamenjenozavrtanjevopekoterzidoveiz
opekeinkamna.Pravtakojeprimernozavijačenjein
vrtanjebrezudarjanjavles,kovino,keramikoinplastiko.
Priključitev na električno omrežje
Napetostelektričnegaomrežjasemoraujematispodatkinatip-
skiploščici.Strojdelujesamozenofaznoizmeničnonapetostjo.
Strojjepoevropskihsmernicahdvojnozaščitnoizoliran,zatose
galahkopriključitudivvtičnicebrezozemljitvenegavoda.
Hrup
ObičajnaA-ovrednotenaravenhrupavskladuzEN62841-2-1:
Ravenzvočnegatlaka(LpA):82dB(A)
Ravenzvočnemoči(LWA):93dB(A)
Odstopanje(K):3dB(A)
OPOMBA:Navedenevrednostioddajanjahrupaso
bileizmerjenevskladusstandardnimimetodami
testiranjainselahkouporabljajozaprimerjavoorodij.
OPOMBA:
Navedenevrednostioddajanjahrupaselahko
uporabljajotudipripredhodnioceniizpostavljenosti.
OPOZORILO: Uporabljajte zaščito za sluh.
OPOZORILO: Oddajanje hrupa med dejansko
uporabo električnega orodja se lahko razlikuje od
navedenih vrednosti, odvisno od načina uporabe
orodja in predvsem vrste obdelovanca.
OPOZORILO: Upravljavec mora za lastno
zaščito poznati varnostne ukrepe, ki temeljijo na
oceni izpostavljenosti v dejanskih pogojih upo-
rabe (poleg časa proženja je treba upoštevati celo-
ten delovni cikel, vključno s časom, ko je orodje
izklopljeno, in časom, ko deluje v prostem teku).
Vibracije
Skupnevrednostivibracij(vektorskavsotatrehosi)v
skladuzEN62841-2-1:
Delovninačin:udarnovrtanjevbeton
Emisijevibracij(ah, ID):12,5m/s2
Odstopanje(K):2,0m/s2
Delovninačin:vrtanjevkovino
Emisijevibracij(ah,D):2,5m/s2alimanj
Odstopanje(K):1,5m/s2
OPOMBA:Navedeneskupnevrednostioddajanja
vibracijsobileizmerjenevskladusstandardnimi
metodamitestiranjainselahkouporabljajozaprimer-
javoorodij.
OPOMBA:Navedeneskupnevrednostioddajanja
vibracijselahkouporabljajotudipripredhodnioceni
izpostavljenosti.
OPOZORILO: Oddajanje vibracij med
dejansko uporabo električnega orodja se lahko
razlikuje od navedenih vrednosti, odvisno
od načina uporabe orodja in predvsem vrste
obdelovanca.
OPOZORILO: Upravljavec mora za lastno
zaščito poznati varnostne ukrepe, ki temeljijo
na oceni izpostavljenosti v dejanskih pogojih
uporabe (poleg časa proženja je treba upoštevati
celoten delovni cikel, vključno s časom, ko je
orodje izklopljeno, in časom, ko deluje v prostem
teku).
Izjava o skladnosti ES
Samo za evropske države
IzjavaESoskladnostijevključenavdodatkuA,kije
priložentemnavodilomzauporabo.

10 SLOVENŠČINA
VARNOSTNA OPOZORILA
Splošna varnostna opozorila za
električno orodje
OPOZORILO: Preberite vsa varnostna opo-
zorila in navodila s slikami in tehničnimi podatki,
ki so dobavljeni skupaj z električnim orodjem.
Obneupoštevanjuspodajnavedenihnavodilobstaja
nevarnostelektričnegaudara,požarain/alihudih
telesnihpoškodb.
Shranite vsa opozorila in navo-
dila za poznejšo uporabo.
Izraz„električnoorodje“vopozorilihsenanašanavaše
električnoorodje(skablom)alibaterijskoelektrično
orodje(brezkabla).
Varnostna opozorila za udarni
vrtalni vijačnik
1. Pri udarnem vrtanju nosite zaščito za sluh.
Izpostavljenosthrupulahkopovzročiizgubosluha.
2. Če obstaja nevarnost, da bi se pri uporabi
rezalnega pripomočka ali sponk dotaknili
skrite električne napeljave ali lastnega kabla,
držite električno orodje na izoliranih mestih
za držanje. Obstikurezalnegapripomočkaali
sponkzvodnikipodnapetostjodobijonapetostvsi
neizoliranikovinskidelielektričnegaorodja,zaradi
česarlahkouporabnikutrpielektričniudar.
3. Vedno zagotovite, da imate trden oprijem na
podlagi, kjer stojite. Kadar uporabljate orodje
na višini, se prepričajte, da spodaj ni nikogar.
4. Trdno držite orodje.
5. Ne približujte rok vrtečim se delom.
6. Orodja ne pustite delovati brez nadzora.
Dovoljeno ga je uporabljati samo ročno.
7. Takoj po končani obdelavi se ne dotikajte
nastavka ali obdelovanca; lahko sta zelo vroča
in povzročita opekline kože.
8. Nekateri materiali vsebujejo kemikalije, ki so
lahko strupene. Bodite previdni in preprečite
vdihavanje prahu in stik s kožo. Upoštevajte
varnostne podatke dobavitelja materiala.
9.
Če vrtalnega nastavka ni mogoče sprostiti, niti ko
odprete čeljusti, ga izvlecite s kleščami. V takšnih
primerihselahkoprivlečenjuvrtalneganastavkaz
rokopoškodujeteobostremrobunastavka.
Varnostna navodila za uporabo dolgih vijačnih
nastavkov
1. Nikoli ne uporabljajte vrtalnega nastavka pri
hitrosti, ki je višja od največje nazivne hitrosti.
Privišjihhitrostihselahkonastavekukrivi,če
seprostovrtibrezstikazobdelovancem,zaradi
česarlahkopridedotelesnihpoškodb.
2. Vedno začnite vrtati pri nizki hitrosti, pri čemer
mora biti konica nastavka v stiku z obdelo-
vancem.Privišjihhitrostihselahkonastavek
ukrivi,česeprostovrtibrezstikazobdelovancem,
zaradičesarlahkopridedotelesnihpoškodb.
3. Na orodje pritiskajte samo v smeri nastavka
in ne uporabite prekomerne sile. Nastavki se
lahkoukrivijo,zaradičesarlahkopridedozloma
aliizgubenadzoraterposledičnotudidotelesnih
poškodb.
SHRANITE TA NAVODILA.
OPOZORILO: NE dovolite, da bi zaradi udob-
nejšega dela ali znanja o uporabi izdelka (prido-
bljenega z večkratno uporabo) opustili strogo
upoštevanje varnostnih zahtev v okviru pravilne
uporabe orodja. ZLORABA ali neupoštevanje var-
nostnih zahtev v teh navodilih za uporabo lahko
povzroči resne telesne poškodbe.
OPIS DELOVANJA
POZOR: Pred vsako nastavitvijo ali pregle-
dom nastavitev orodja se prepričajte, da je orodje
izklopljeno in izključeno z električnega omrežja.
Delovanje stikala
►Sl.1: 1.Sprožilnostikalo2.Gumbzazaklep
POZOR: Pred priključitvijo orodja na elek-
trično omrežje se vedno prepričajte, da je stikalo
brezhibno in se vrača v položaj za izklop (OFF), ko
ga spustite.
POZOR: Stikalo lahko zaklenete v položaju
za vklop (ON), kar omogoča lažje upravljanje med
daljšo uporabo. Bodite previdni, kadar zaklepate
orodje v položaju za vklop (ON), in pri tem dobro
držite orodje.
Zazagonorodjapovlecitesprožilnostikalo.Hitrost
orodjasepovečazapovečanitlaknasprožilnemsti-
kalu. Za izklop spustite stikalo.
Zaneprekinjenodelovanjepritisnitesprožilnostikalo
ingumbzazaklep,natopaspustitesprožilnostikalo.
Zaizklopneprekinjenegadelovanjapritisnitesprožilno
stikalo do konca in ga spustite.
Stikalo za preklop smeri vrtenja
►Sl.2: 1.Ročicazapreklopsmerivrtenja
POZOR: Pred obratovanjem vedno preverite
smer vrtenja.
POZOR: Stikalo za spreminjanje smeri vrtenja
uporabite šele, ko se stroj popolnoma ustavi.Če
smervrtenjaspremenite,predensestrojustavi,seta
lahkopoškoduje.
Toorodjejeopremljenospreklopnikomzaspremembo
smerivrtenja.Ročicopreklopnikasmerivrtenjapritisnite
vsmeriAzavrtenjevsmeriurnegakazalcainvsmeriB
zavrtenjevobratnismeriurnegakazalca.
