Parts Breakdown 9558PB
Page 1 of 3 2/8/2008

Parts Breakdown 9558PB
Fig # Part ID Part Name Quantity
1 621706-3 FIELD 115V, 9557NB 1
2 418770-1 BAFFLE PLATE, 9557NB 1
3 421868-5 LABYRINTH RUBBER RING,9553NB 1
4 210034-7 BALL BEARING 607LLB, 9553NB 1
5 681636-0 INSULATION WASHER, 4304 1
5 681667-9 RESIN WASHER, MT952 1
6 515611-3 ARMATURE ASS'Y 115V, 9557NB 1
7 240076-7 FAN 56, 9553NB 1
8 317821-6 GEAR HOUSING COVER, 9553NB 1
9 213445-5 O-RING 26,9550H 1
10 210042-8 BALL BEARING 629LLB, 5277NB 1
10 210053-3 BALL BEARING 629LLB,4200NH 1
10 210071-1 BALL BEARING 629LLB, 9553NB 1
11 227464-5 SPIRAL BEVEL GEAR 10,9554NB 1
12 252186-8 HEX. NUT M6, 9553NB 1
13 417771-6 PIN CAP, 9557NB 1
14 233376-2 COMPRESSION SPRING 8, 9557NB 1
15 266361-0 TAPPING SCREW 4X30,9553NB 4
16 213960-9 O RING 5, 9553NB 1
17 256486-8 SHOULDER PIN 4, 9553NB 1
18 317814-3 GEAR HOUSING, 9553NB 1
19 263002-9 RUBBER PIN 4, HR2400 1
20 210033-9 BALL BEARING 696ZZ, 9553NB 1
21 961052-5 RETAINING RING S-12, 9218PBL 1
22 267794-2 WAVE WASHER 12, 9553NB 1
23 227465-3 SPIRAL BEVEL GEAR 37,9554NB 1
23 227505-7 SPIRAL BEVEL GEAR 37, 9557PB 1
24 962151-6 RETAINING RING R-32, 9005B 1
25 211129-9 BALL BEARING 6201DDW, N9501B 1
26 267238-2 FLAT WASHER 12, 9550H 1
27 213622-9 O RING 45, 9553NB 1
28 317819-3 BEARING BOX, 9553NB 1
29 265099-4 P.H. SCREW M4X14, HP1351 4
30 345464-4 LABYRINTH RING, 9553NB 1
31 254011-9 WOODRUFF KEY 4, NHP1310 1
32 324474-4 SPINDLE, 9554NB 1
33 265103-9 P.H. SCREW M5X14, 9550H 1
34 125268-8 WHEEL COVER ASS'Y,9558PB 1
35 224399-1 INNER FLANGE 45, 9554NB 1
36 224568-4 LOCK NUT 5/8-45, 9005B 1
37 266345-8 TAPPING SCREW 4X80, 9557NB 2
38 861318-2 NAME PLATE, 9558PB 1
40 650561-6 SWITCH, 9557NB 1
42 183943-2 REAR COVER SET, 9557PB 1
43 231252-4 COMP. SPRING 6, 9526PB 1
44 418842-2 LOCK-ON BUTTON, 9557PB 1
45 682559-5 CORD GUARD 8, 6824 1
46 664891-9 CORD 1
47 687169-3 STRAIN RELIEF, HP1621F 1
48 266326-2 TAPPING SCREW PT 4X18, MT240 1
49 154605-9 MOTOR HOUSING CPL.,9557PB 1
50 643760-7 BRUSH HOLDER, BO6040 2
51 266007-8 TAPPING SCREW 3X10, 9523NB 4
52 194074-2 CARBON BRUSH CB325,9553NB 1
53 265954-0 TAPPING SCREW BIND PT3X8,9526PB 1
54 345504-8 PLATE, GD0060 1
55 154583-3 SWITCH LEVER A CPL.,9557PB 1
56 266351-3 TAPPING SCREW 4X35, 9557PB 2
56 266363-6 N/A 2
57 183943-2 REAR COVER SET, 9557PB 1
Page 2 of 3 2/8/2008

Parts Breakdown 9558PB
1,001 153489-2 GRIP 36, 9557NB 1
1,002 782422-3 LOCK NUT WRENCH 28,9554NB,9557NB 1
1,002 782424-9 LOCK NUT WRENCH 28, BGA452 1
5,001 810164-0 N/A 1
Page 3 of 3 2/8/2008
