Parts Breakdown 6906
Page 1 of 3 2/8/2008

Parts Breakdown 6906
Fig # Part ID Part Name Quantity
1 421112-0 BUMPER, 6906 1
2 156087-1 HAMMER CASE, 6906 1
3 231920-9 RING SPRING 16, 6906 1
4 257040-1 RING 65, 6906 1
5 253939-8 F. WASHER 25,6906 1
6 324231-0 ANVIL, 6906 1
6 325586-6 ANVIL, 6906 (TYPE 2) 1
7 261023-5 WASHER 27, 6906 1
8 216008-6 STEEL BALL 4.0, 6820V 30
9 325318-1 HAMMER, 6906 1
10 253764-7 F. WASHER 30, 6906 (TYPE 2) 1
11 231135-8 COMP. SPRING 37, 6906 1
12 253765-5 F. WASHER 36, 6906 (TYPE 2) 1
13 216009-4 STEEL BALL 7.1, HR2400 2
14 221243-3 P.S. GEAR 29, 6906 2
15 212011-5 N.BEARING 609,JS1600 2
16 325322-0 SPINDLE, 6906 1
17 256041-6 PIN 6, 6906 2
18 212151-9 N. BEARING 1412, JN1600 1
19 211441-7 BALL BEARING 3009, 6906 1
20 221242-5 INTERNAL GEAR 65, 6906 1
21 256040-8 PIN 5, LS1030 4
22 962352-6 RETAINING RING R-75, 6906 1
23 216103-2 INNER RACE 1016, 6906 1
24 253180-3 F. WASHER 10, 6222DWE 1
25 241609-1 FAN 73, 6906 1
26 512881-5 ARMATURE, 6906 1
27 681613-2 INS. WASHER, JN3200 1
28 211031-6 BALL BEARING 608LLB, HR2400 1
29 413008-9 BAFFLE PLATE, 6906 1
30 265350-2 HEX BOLT M5X70, 6906 2
31 622282-0 FIELD, 6906 1
32 253929-1 CUP WASHER 5, 6906 4
33 262001-8 RING 5, 6906 4
34 922262-9 H.S.H. BOLT M5X40, 6906 4
36 253774-4 F. WASHER 65, 6906 1
37 911173-3 P.H. SCREW M4X45, 6906 1
38 414959-9 HANDLE COVER,6906,T2 1
39 911106-8 P.H. SCREW M4X8, NHP1310 1
40 651564-3 SWITCH, DA6300 1
42 911133-5 P.H. SCREW M4X18, N9501B 2
43 687002-9 STRAIN RELIEF, 9217SPC 1
44 682503-2 CORD GUARD 8-90, 9005B 1
46 643600-9 BRUSH CAP 6-10, 9005B 2
47 191945-4 CARBON BRUSH CB-124, 9045B 1
49 815088-5 NAME PLATE, 6906 1
50 159414-1 MOTOR HOUSING,6906,T2 1
51 262010-7 RING 18, 6906 1
53 284065-2 REAR COVER,6906,T2 1
54 922221-3 HEX BOLT M5X16, 6906 2
55 664064-4 CORD (2X18X8 SJ), HR2400 1
400 273474-0 N/A 1
401 312700-3 GRIP BASE 1
402 345086-0 BELT, 6906 1
403 251920-3 C.S.N. BOLT M6X30, 5007NB 1
406 182604-1 N/A 1
406 182604-1 N/A 1
500 122464-9 GRIP ASSEMBLY, 6906-T2 1
501 132389-9 ANVIL ASS'Y,6906 1
501 134946-9 ANVIL ASS'Y, 6906 1
Page 2 of 3 2/8/2008

Parts Breakdown 6906
902 810146-2 N/A 1
908 819064-1 MAKITA MARK, HM1100C 1
Page 3 of 3 2/8/2008
