Makita TD020D User manual

TD020
12-06
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16 17
18
19
20
21
22
23
24
25
26
31
32
30
34
28
41
27
35
36
37
29
38
39
40
33

Model TD020 Parts List
A = Standard Equipment
〇= Circuit Diagram
Fig. Part No. Description Q'ty Unit
1 231965-7 RING SPRING 10 1 PC.
2 267143-3 FLAT WASHER 11 1 PC.
3 233005-7 COMPRESSION SPRING 13 1 PC.
4 324711-6 BIT SLEEVE 1 PC.
5 961072-9 RETAINING RING S-12 1 PC.
6 210108-4 BALL BEARING 6801LLU 1 PC.
7 313136-9 LOCK RING 1 PC.
8 324717-4 SPINDLE M 1 PC.
9 268160-6 PIN 3.5 2 PC.
10 324713-2 ANVIL 1 PC.
11 324714-0 HAMMER 1 PC.
12 216019-1 STEEL BALL 3 23 PC.
13 267335-4 FLAT WASHER 20 1 PC.
14 233481-5 COMPRESSION SPRING 20 1 PC.
15 267335-4 FLAT WASHER 20 1 PC.
16 216002-8 STEEL BALL 4.8 2 PC.
17 227173-6 SPUR GEAR 27 2 PC.
18 324715-8 SPINDLE 1 PC.
19 268161-4 PIN 5 2 PC.
20 253052-2 FLAT WASHER 12 1 PC.
21 210108-4 BALL BEARING 6801LLU 1 PC.
22 265172-0 +PAN HEAD SCREW M2.6X6 2 PC.
23 419639-2 INTERNAL GEAR CASE 1 PC.
24 629842-9 DC MOTOR 1 PC.
25 265173-8 PAN HEAD SCREW M3X8 1 PC.
26 188205-3 MOTOR HOUSING SET 1 SET
26 D10 INC. 32 0
27 267803-7 LOCK WASHER 1 PC.
28 419637-6 CHANGE LEVER 1 PC.
29 267803-7 LOCK WASHER 1 PC.
30 862714-7 TD020D NAME PLATE 1 PC.
31 265173-8 PAN HEAD SCREW M3X8 1 PC.
32 188205-3 MOTOR HOUSING SET 1 SET
32 D10 INC. 26 0
33 266404-8 TAPPING SCREW BIND 3X14 3 PC.
34 419638-4 LIGHT COVER 1 PC.
35 188199-2 HANDLE SET (WHITE) 1 SET
35 D10 INC. 37 0
36 638470-9 SWITCH UNIT 1 PC.
37 188199-2 HANDLE SET (WHITE) 1 SET
37 D10 INC. 35 0
38 265999-8 TAPPING SCREW 4X25 1 PC.
39 266404-8 TAPPING SCREW BIND 3X14 2 PC.
40 345749-8 SET PLATE 2 PC.
41 216019-1 STEEL BALL 3 2 PC.
42 810288-2 CAUTION LABEL 1 PC.
A01 DC07SA DC07SA BATTERY CHARGER 1

A02 194356-2 BATTERY BL7010 SET 2 PC.
A03 168435-2 HOLSTOR 1 PC.
A04 831272-4 TOOL BAG 1 PC.
A05 194375-8 DRILL SET 1 PC.
A06 419730-6 HOLDER 1 PC.
A07 784010-0A SLOTTED BIT #5F 1 PC.
A08 784214-0A #2 PHILLIPS BIT 1 PC.
A09 784301-A #1 PHILLIPS BIT 1 PC.
