Thank you for choosing Malibu Kayaks, a leading manufacturer of roto-
molded, linear polyethylene sit-on-top kayaks oering many models suited to
everything from beach-front surng to agling, we proudly serve the shing,
diving, surng and recreational communities; known for being dry sit-on-top
kayaks that are comofortable, stable, stylish, versatile and aordable.
Malibu Kayaks continues to look forword to the future with excitement about
the endless possibilities that come to play with new designs that are in the
works. Our kayaks are engineeres for years of enjoyment by both novice and
advanced paddlers, be the anglers or recreational touring enthusiasts... sure
to inspire paddlers of all ages and abilities! You can always look foward to our
latest model oering with our continued focus on new designs and innovation.
We’re sure to excite both kayak anglers and recreational paddlers alike.
Look for these icons for more information or to purchase accessories:
Instructional Video
Installation Manual
Shop: http://www.codpaddlesports.com/
Copy this link for our Installation Videos and Instructional manuals:
http://www.malibukayaks.com/customer-support/
About Us Table of Contents
INSTALLATION MANUALS INSTRUCTIONAL VIDEOS

Bow
Soft Grip Handles
8” Round Hatch
Flush Mount Rod Holder
Adjustable Footrest Pedals
Cup Holder
Scupper Holes
Rectangular Hatch
Nylon Leashing Hook
Bungee Side Carry Handle w/
Paddle Holder
Front Strap Seating Eyelet
Seat Drainage
Back Strap Seating Eyelet
Seating Area
Threaded Eyelet
Back Well Storage w/ Bungee
Shock Cord Cleat
Nylon Bungee Hook
Hull Drainage
Stern
Cockpit
Starboard Port
AnatomyGetting To Know Your Kayak
A kayak has basic features. The front of the kayak is the bow and the rear is the
stern. When looking forward to the bow, the left side of the kayak is port and
the right side of the kayak is startboard. The hull ID number (KPO sticker) can
be found on the port side of the kayak at the stern.
In the middle of the boat, there is a cockpit area with foot wells (toward the
bow) and a seating area (towards the stern). Inside the cockpit, there are holes
that go all of the way through the kayak called scuppers. These scuppers allow
the kayak to drain. On many of the models, there is a bungee in the front of the
cockpit and behind the seat. This allows you to secure gear to the deck of the
kayak. Your particular model may have hatches that allow access to the inside
of the kayak for gear storage. Some models feature a molded-in tank which
can be used for live bait well, dry storage, cooler, or battery compartment.
Threaded eyelets and shock cord cleats are line along the rails of the kayak to
attach numerous accerssories.
12

Loved by resorts and rental eets, the standard package is great for users
who don’t require any hatches or are looking for a blank slate to do their own
customization.
Want just enough, but not too much? Our kayaks that come available in a
recreational package is just right. These come with at least one hatch and are
perfect for users who aren’t big anglers and will be using the kayak for other
purposes.
Rigged, set, and ready to go! Our Fishing and Diving packages come equipped
with all the rod holders and hatches you’ll ever need. Never fear though, there
is still plenty of room left for you to install even more.
Standard
Packages
Specications
Recreational
Fish and Dive
Kayak Packages
Standard Package (overall weight: 43 lbs.)
Molded cup holder, molded footrests, threaded eyelets, drain plug w/ base,
shock cord cleat, nylon hooks, bow & stern handles, side carry handles/
paddleholders, rear bungee storage.
Recreatinal Package (overall weight: 47 lbs.)
Include all standard features plus, center rectangular hatch w/ bag, 2 rear rod
holders.
Fish and Dive Package (overall weight: 51 lbs.)
Includes all Standard and Recreational features plus, front 8” round hatch w/
bucket, 2 front rod holders.
Kayaking with your family is a great way to get together and play! Whether
you’re basking in the Bahamas, splashing around in California, or racing in New
York, you’re going to want a safe, light, and durable option your family can
enjoy for years. If the kids are up for paddling independence, have them try the
Mini-X or 3.4. Both models are light, easily transportable, and sized perfectly
for the younger generation. Also the paddler could perform stand up paddling
on the Mini-X.
The weight stated above is only the base weight. The actual weight of the
kayak may vary by accessories on other packages.
Length: 9’3” Width: 33.5” Depth: 12” Weight: 40 lbs Max Capacity: 325 lbs
Mini-X
Standing Platform Light Weight
34

Mini-X
8” Round Hatch
8” Round Hatch
Access the 8” hatch by lifting both T-handles and twist left to unlock. Pull
T-handle to lift hatch.
The bucket is also removable to allows access inside of the kayak.
56
open

Adjustable Footrest Pedals
Foot pedals can easily be adjusted by sliding them accross track. Press/
hold to lift the lever tab and adjust slide pedal across track for comfortable
leg room.
Flush Mount Rod Holder
Mount your gear into one of the shing rod holders to free your hands
and bait a shing hook. Our Accessory Leash can attach your shing rod
securely to any ush mount rod holder; preventing your expensive gear to
sink into the abyss.
Flush Mount Rod Holder & Adjustable Footrest Pedals
78
Mini-X
Rod Holders
Adjustable
Footrest Pedals
press
adjust

Standing Platform
For recreational stand up paddling and shallow-water shing.
Standing Platform & Side Bungee Carry Handle
910
Mini-X
Side Bungee Carry Handle
Standing Platform
Side Bungee Carry Handle
Can be utilize to strap down your paddle.

The basket is also removable to access kayak hull that can be utilize for
large storge.
Access to the rectangular hatch simply lift T-handle and twist to the left to
unlock. Pull T-Handle to lift hatch.
11 12
Mini-X
Rectangular Hatch
Rectangular Hatch

Front Seat Straps
Place Apex seat in cockpit area. Hook top straps to threated eyelets that
are near the front of seating area.
Back Seat Straps
Hook seat clips to eyelets that are near the back of seating area.
Adjust straps for comfort.
13 14
Mini-X
Front Strap Eyelet for
Seating
Back Strap Eyelet for
Seating
Seating Mount

15 16
Mini-X
Threaded Eyelet w/
Washer (Seat Drainage)
Threaded Eyelet w/
Washer (Hull Drainage)
Hull Drainage
Unscrew threaded eyelet, located near the stern of the kayak, to drain out
any excess water from inside the hull.
Seat Drainage
Unscrew threaded eyelet to drain excess water from the seating area for a
dry and comfortable ride.
Drain System

Designed for ergonomic shing with eortless control in reaching for
those far away items and customize for your own specications. The
adapter brackets are required to install the X-Wing sliding console onto
your Mini-X.
17 18
Mini-X
5 Gal. Place Holder
X-Wing Console X-Wing Sliding Console
5 Gal. Bait Tank
Optional Features
Back well has an ideal placement for a 5 gallon live bait bucket. It can also
be utilize as storage for any gear you wish to bring on board and hold se-
curly with our sturdy bungee cord.

Step 1
Step 2
Step 3
Pull Strap under rack. Throw both ends of strap over
kayak
Pull loose end under rack. Insert loose end into buckle
and tighten gently.
Step 1
Mini-X
12
3
4
Step 2
After strapping down your kayak to your roof rack make sure to strap it down
to the front and back bumber of your vehicle. Tie one end of the strap to front
carry handle and the other end to your tow hook. This will prevent your kayak
from swaying while making turns.
Step 3
Tie one end of the strap to the stern carry handle and the other end to your
vehicle back bumper.
NOTE: Avoid over-thightening any of the straps holding your kayak in place.
Too much tension can distort the hull.
Transportation
19 20
Tie Down Straps and roof rack pads
are available on codpaddlespots.com

Patching Holes
Super linear polyethylene is vey durable and can be repaired if the need arises.
Cracks or deep gouges can be welded with a suitable heat gun and resin
powder. Marine goop is also a very inexpensive way to seal a pin-hole leak or
other small patching areas.
Instructions for Patching Holes:
Be sure NOT to leave soldering iron in one area too long; you can burn a hole
in your kayak. The cooling process takes about 10 minutes. Test area when
nished. In some cases you might need to add a second application depending
on the size of the repair. Items needed: color plastic to match your kayak and a
pencil-grip soldering iron. (approximatley 25 watt)
Repair
3
2
1
3
Use a hot soldering iron to
melt a piece of plastic.
Apply consistently around the
patching area.
Smooth over with solderin iron
and nish surface with shaver.
Patch inside crack or hole and
surrounding area, leaving a
little extra for nishing. If crack
is deep let the patching dry
then apply another layer.
21 22
Maintenance
After every use, it is recommended to thoroughly rinse your kayak with water.
Make sure to rinse foot pegs and all hardware with plenty of fresh water after
paddling in saltwater, barckish or polluted water.
Kayak Wash
Recommended supplies:
- Bucket
- Sponge
- Soft cloth
- Garden hose
- Wash soap solution
In preparation, ll your bucket with water and add a cap or two full of soap
solution. Next, nd a clean and at area to wash your kayak. Utilize kayak
cradles or stands if you have them, if not, a deck or grassy lawn works great.
First, wash down the kayak with your garden hose to remove any surface dirt,
pollen, debris, sea salt, etc. While the kayak is still wet, take your sponge and
soak it in the soap/water solution. Wash down the entire kayak with the soap/
water solution. This will remove any stubborn dirt and debris. Be careful not to
remove decals, striping, etc. while scrubbing your kayak.
After you scrub down the surface with soap/water solution, rinse down the
kayak with your garden hose again to remove any excess suds. Remove
threaded eyelet that is located near the stern (see Hull Drainage on page 16) to
drain out any excess water that might be inside the hull. Let your kayak air dry,
or towel dry the surface if you prefer. Turn your kayak over and make sure the
hull is completly dry.
Kayak UV Protection
As nish touch, to prevent damages from harmful UV radiation we suggest a
quality UV protectant. 303 Areospace Protectant can be applied as a sunscreen
for your kayak.
Repair Kit is available on
codpaddlespots.com
Installation manual is
available

StorageMini-X
Always store your kayak indoors or under cover to protect from harsh weather,
direct sun light and other elements.
Never use a wheel cart as a storage platform for your kayak. A wheel cart
should only be used for transportation. Prolonged exposure for direct sun light
may cause degradation.
Storing your boat upside down on crossbars or hanging from wide strapping
around the cock pit area, are the best ways to keep the kayak stored.
Never hang the kayak by handles or by the scuppers. It will distort the kayak
hull.
On its side over a long period of time it can deform or dent the sides.
Storing your kayak cockpit side up on cross bars can dent the bottom.
You could also store your kayak on its stern standing againts a wall. Make sure
to strap your kayak to prevent it from tipping over.
Storage Do’s Storage Don’ts
23 24

Replacement Parts and Optional Accesories
Replacement Parts
Fishing Gear
Flush Mount Fishing Rod Holder
Handles
Soft Grip Carry Handles
Side Bungee Carry Handles
Hardware Parts
Bungee Cord Kit
Nylon Lashing Hook
Shock Cord Cleat
Square Handle Washer
Threaded Eyelet
Threaded Eyelet with Base
Threaded Eyelet with Washer
Hatches
8” Round Hatch
Small Rectangular Hatch
Misc. Parts
Adjustable Foot Peg System
Optional Accessories
Fishing Gear
5 Gal. Bucket with Pump Kit
Transportion Gear
Tie Down Straps
33” Roof Rack Pads
Multi-Purpose Roof Rack System
Red Flag
X-Wing
X-Wing Sliding Console
The list below referes to a specic catagory for each replacement part and
accesories that you could nd on http://www.codpaddlesports.com/
Safety
Kayak Safety Suggestions
There are basic safety rules that all kayakers should follow. Get paddlesports
instructions from a licensed or certied instructor. Obtain certied rst aid and
rescue training and carry rst aid rescue equipment.
For your rst time on a kayak we recommend beginning in calm water. You can
get the feel of the kayak and distributions of your weight. Practice getting in
and out of the kayak until you’re comfortable.
Never exceed the weight capacity of your kayak; check your equipment for
wear and tear before you paddle. Contanct the technicle support before
making any modication to your kayak.
Alway do the following check up before launching your kayak:
Always
- Wear a Coast Guard approved personal oatation device
- Dress appropriately for weather conditions; cold water and/ or weather can
result in hypothermia; apply sunscreen and other sun protective clothing
- Check your equipment prior to each use for signs of wear of failure.
- Tie a leash to your paddle
- Scout unfamiliar waters
- Be aware of river water levels, tidal changes, wind conditions, obstacles in
and above the water and weather changes
- Always make sure that your hatch is secure
- Always carry the spare paddle provided with the boat
- Make sure draing plugs are properly installed
- Test the rudder kit system (if applicable)
- Test the navigation device (if applicable)
Never
- Never go alone and always le a oat plan
- Never go in ood and/or fast moving water conditions
- Never exceed your ability and be aware of you limitiations
- Never use alcohol or mind-altering drugs prior to or while using this product
- Never open your hatches in unstable water conditions
- Never remove the foam pieces inside the hull. They are installed for structure.
25 26

Warranty
Limited Lifetime Warranty
To register your kayak online please ll out the form, print a copy for yourself,
then hit submit.
Crack of Dawn Paddlesports dba Malibu Kayaks warrants as a limited lifetime
warranty, this kayak purchased is to be free of manufacturing defects in
workmanship and materials from the original date of consumer purchase. This
warranty is eective as long as there is proof of purchase from an authorized
Malibu Kayaks dealer and it only applies to the original owner. Some states do
not allow the exclusion or limitation of incidental or consequential damages,
so the above limitation or exclusion may not apply to you. This warranty gives
you specic legal rights, and you may also have other rights which vary from
state to state. Malibu Kayaks reserves the right to choose the nal warranty
resolution. Option to repair or replace parts of a given kayak is determined
against damages and in the discretion of Malibu Kayaks. Some exclusions may
apply. This warranty is valid only in the U.S.A.
Malibu Kayaks is not liable for any injury or damage to person or property
sustained as a result of the use of kayaks manufactured by Malibu Kayaks. The
user of any such kayak acknowledges and assumes any and all risk associated
with the use of such kayak including death, waives any and all claims against
Malibu Kayaks LLC., its agents and assigns.
Malibu Kayaks reserves the right to change its products without notice while
not incorporating those changes into completed and purchased products in
the possession of dealers or consumers.
This Warranty Does Not Cover The Following:
1. Normal wear and tear or as a result of abuse or failure to maintain kayak.
2. Discoloration due to excessive sun exposure.
3. Damage caused by alterations, modications, storage or mooring to kayak.
4. Transportation of kayaks; signicant or incidental damage to kayak and/or
personal property.
5. Damage due to failure of following procedures and instructions provided.
6. Kayaks purchased from an unauthorized dealer or consumer resale.
7. Factory 2nds (Kayaks purchased as a blem).
27 28
Expedite Claim
Steps to Expedite Claim
In the unlikely event that your kayak has any manufacturing defects, photos,
proof of purchase and description of your claim are required. All warranty
claims are subject to any exclusion and in lieu of provided evidence decided
upon the discretion of Malibu Kayaks.
For all kayak warranty claims:
Please ll out our Warranty Claim Form and submit photos or les to
[email protected]
After receiving above items, Malibu Kayaks may request to have your kayak
returned to the original dealer for inspection. Malibu Kayaks will warrant the
right to either exchange or repair your kayak. Depending upon date of purchase
and damage to the kayak Malibu Kayaks may repair/replace kayak, some fees
may apply. All shipping cost will be paid by customer. If you are unable to get
a replacement kayak from an authorized dealer, Malibu Kayaks will ship the
warranty replacement kayak (shipping fees will apply). Kayak serial # must be
cut and mailed to Malibu Kayaks to nalize all kayak replacement claims. Once
your claim is approved you may be required to provide proof of disposal of
your original kayak. Please do not dispose of your kayak prior to your claim
being approved.
Exclusions
Kayaks that are structurally altered or subjected to stress beyond the physical
limits of the materials used in hull or components, or damaged as a result of
abnormal use are considered as damage done by the user and void of Malibu
Kayaks warranty. Warranty does not cover un-recommended/unauthorized
alterations or unauthorized repair.
Warranty and Replacement Parts
Any part/parts replaced or repaired hereafter shall be warranted as an original
part/parts purchased by the consumer.

www.malibukayaks.com
7110 E Jackson St. Paramount, CA 90723 T: 562.630.6282
