Mami Robot PPORO User manual

www.mamirobot.com
Free Your Life With Innovative Technology
PPORO User’s Guide
Please read this manual before using the product.
Please keep this manual in your sight.
Please visit www.mamirobot.com for more information.

This product specially designed for the US home use.
Please check if the machine works properly several times before you clean the floor.
Please check the status of the machine when you use it for the first time.
Please stop operating the machine if you see any scratches. We are not responsible for the
problems if you did not check the circumstance listed above.
Please check if there is any problem especially when you use the machine on the wooden
floor and Korean heating floor.
※This is user manual. Some images in this manual can be slightly different with the actual product.

1. Mamirobot is designed for efficient cleaning the regular floor and carpet(less than
1cm). Mamirobot can clean powerfully the normal floor and carpet by installing of
vacuum suction guidance.
2. With installed Front Sensor and Side Sensor, Mamirobot follows the wall smoothly.
3. Mamirobot has the auto-recharge function similar method with Ground Controlled
Approach of airplane. It guides Mamirobot to the charging station quickly and ac-
curately.
4. Battery of Mamirobot is high-speed rechargeable and working time is long,
efficient cleaning is possible.
5. With the charging station, Mamirobot and Hand Held Cleaner Zaaloo can be
charged at the same time. You can clean narrow area such as edges, window
frames with Zaaloo.
6. Dust cloth can be attached easily by plate for dust cloth. Plate for dust cloth located
in a body of machine.
Thank you for purchase Mamirobot.
Mamirobot vacuum cleaner which is made by patents of Mamirobot leads you to new world. The
Mamirobot of remarkable cleaning ability is ...

Contents
Before using
Preparing
Cleaning
Guidance
Zaaloo
Product
Information
Important Safety Information
Check List Before Operation
Know-how for Using
Components
Name of Part
Characteristic of Battery
Battery Installation
Station Installation (K5, K7)
Recharging Battery using Station (K5, K7)
Recharging Battery using Adapter (K5,K7)
Empty Dust Bin and Replace Filter
Install Dust Cloth
Side Brush Maintenance
Main Brush Maintenance
Cover and Main Brush Tips
Composition of Display Panel
Remote Controller
Operating Mamirobot
Normal Mode
SSW Mode
Auto Recharging (K5, K7)
Voice Guidance
Station Guide
Troubleshooting Error Code
Hand Cleaner Zaaloo
Important Tips
Part Name
Recharging Battery
Operating
Empty Dust Bin and Maintenance
Replace Filter
Troubleshooting
Check List Before Service Request
Specification
Warranty
6
7
7
8
9
10
10
11
11
11
12
13
13
14
14
15
16
17
18
18
19
20
20
21
22
22
23
24
24
24
25
25
26
26
27
5
Before using Preparing Cleaning Guidance Zaaloo Product Information

Safety Information
Before using Mamirobot, read all safety precautions and keep these in mind to reduce the risk of
accident or damage.
Mamirobot is for indoor use only. Do not use outdoors or on wet surfaces. It may cause failure.
Before using, put away any obstacles which interrupt Mamirobot movement on the floor. Obstacles could
be clothes, papers, power cords, etc.
Product is design for the best vacuuming performance. Make sure if there is any small object on the
bottom panel before use.
Children and pets should be supervised to ensure that they do not sit or stand on Mamirobot.
Do not use Mamirobot to pick up anything that is burning or cigarette.
Do not use Mamirobot to pick up inflammables (combustible liquids, gasoline). It can cause fire.
During operating, close any doors to prevent it from exiting the room.
Make sure that the air circular hole is not clogged.
Do not use on the table, furniture or other electronic product. Mamirobot can be damaged by falling
down.
Do not use on the outdoor surface such as concrete or asphalt. It can cause failure.
Use only the charger and battery supplied by the manufacturer. Do not charge Mamirobot around any
electronic product which generates heat such as a refrigerator. Make sure that Mamirobot is off the
ground except the wheels while charging because it can cause fire.
Do not disassemble or repair Mamirobot except by authorized technicians. Disassembling or repairing by
unauthorized person will void the warranty.
6
Before usingPreparingCleaningGuidanceZaalooProduct Information

Before Use
Prepare for Cleaning
Before using, put away any obstacles which interrupt Mamirobot movement on the floor. Obstacles could be clothes, papers, power
cord, etc..
Make sure if there is any small object on the bottom panel before use.
Anti-Falling Sensor
Sensors of Mamirobot can recognize the depth between current area and next area. That function prevents to fall the machine down.
If the depth is more than 5 cm, the machine does not go further and arrange cleaning scope again.
Cross the Threshold
Mamirobot is designed to be able to cross the threshold when Mamirobot does not attach the dust cloth. Available height is around
1 cm and it depends on the shape of threshold. It does not cross threshold if the height is over 1 cm for safety.
Mopping Mode
For improving the efficient of damp mop cleaning, put away any obstacles which interrupt Mamirobot movement. Furthermore, with
attaching dust cloth, Mamirobot could not cross the threshold and carpet. Damp Mop mode cannot be used for carpet cleaning.
There can be some dust on the wheel cause by product test.
It is not a not a sign of refurbished product or used product..
Know-How for Using
1. If the machine is not used for more than 1~2 months, battery capacity could be down. At this case, it will improve again with
repetition about 2 times of full-recharge and full-discharge. Please separate the battery from the product when you don’t use the
machine for a long period of time.
2. Due to the properties of Ni-MH, frequent recharge may cause using time to reduce. Please use the machine after full recharge
and use until the battery is fully discharged.
3. Life time of battery is 18 ~ 24 months and 500 times recharge-dischargeable. As time goes by, using time may reduce, and if
the using time becomes remarkably short, you should replace it. You can purchase battery and consumable items on line http://
usa.mamirobot.com.
4. The warranty of battery is 6 months.
5. Using without dust filter or using defective dust filter can cause a breakdown due to dust inside the machine. Dust filter should
be replaced after 2~3 times used.
6. Please contact to 1-800-xxx-xxxx for A/S or send item to xxx,xxxx,xxxx,xxx
※Store the packaging box in case you need to send the product for the repair.
7
Before using Preparing Cleaning Guidance Zaaloo Product Information

Main Brush Cover
Hair Mode Cover
(Ni-MH)
Rechargeable Battery
Main Brush
100~240V(50/60Hz) Adapter
* 220v plug need to be changed to 110v plug
Dust Filter
2 AAA Remote
Controller Battery User Manual
Superfine Fibers Mop
※One of these covers is installed in the main body.
※Hair Mode Cover is used for hair cleaning.
Main Components
Components
Unpack the product and check that all of the following contents are included.
Parts/Small components
Remote Controller
Mamirobot cleaner
Hand Vacuum
( for K7 )
Battery Charge Station
(for K5, K7)
8
Before usingPreparingCleaningGuidanceZaalooProduct Information

Front Sensor
Bumper
Rubber Bumper
Remote Control Sensor
Display Window
Status Indicator
Operating Buttons
Dust Bin Cover Button
Dust Bin Cover
Recharging Holder for Hand Cleaner
Remote Controller Holder
Recharge Indicator Recharge Approach Window
Charging Socket
Anti Falling Sensor Recharge Plate
Front Wheels Rear Wheel
Side Brush Intake
Main Brush Cover (for hair mode)
Main Brush Mop Plate
Battery Cover
Name of Part



























9
Before using Preparing Cleaning Guidance Zaaloo Product Information

About Battery
1.Mamirobot’s adapter is free voltage type (100 ~240V), so you can use it in any country without limitation of voltage. With a full-
recharge, the battery lasts maximum 2 hours. (Working time can be various by types of floor and cleaning mode.)
2.Because the first status of battery is not fully charged, you should charge it before using. For the first time use, battery working
time could be shorter than normal. At this case, it will improve again with repetition about 2 times of full-recharge and full-
discharge.
3.Life time of battery is 500 times recharge-dischargeable. As time goes by, using time may reduce, and if the using time becomes
remarkably short, you should replace it. Due to the properties of Ni-MH, frequent recharge may cause using time to reduce. Please
use the machine after full-recharge and use until the battery is fully discharged.
4.For the recharging failure, check the connection between adapter and power cord.
5.Actual battery life and working time varies by usages, setting, and operating conditions.
Battery Installation
1. Place Mamirobot upside down on a flat, padded surface such as on a
towel or blanket. Press and slide the battery cover as shown in picture.
2. Insert the battery plug into the socket as shown in the picture. Please
make sure the battery is installed properly.
3. Place the Rechargeable Battery in the battery repository and close the
battery cover after well arrangement of cords.
4. Dismounting is carried out in reverse order.
5. You do not need to separate the battery once battery is installed prop-
erly. Use the battery charging station and recharge connector when
you recharge the battery.
* When the connection is not good, the error code will be shown in Status Indicator and it wouldn’t be recharged.
* Never touch an electrical socket or appliance with wet hands.
* If you will not use the machine for a long time, remove the battery from machine and keep in a cool & dry place.
Insert plug into socket Correct Installation
O
Incorrect Installation
X
Battery plug
Click!
Battery socket
10
Before usingPreparingCleaningGuidanceZaalooProduct Information

Charging Station Installation (K5, K7)
1.Locate charging station in an even surface and stand it against the wall as shown in Figure. For the auto-recharging, make sure
there is no obstacle within 1.5m radius.
2.After inserting adapt terminal into the charging station, plug the power cord in the power socket.
Recharge Using Charging Station (K5, K7)
1.In the power-on status, auto-recharge function will operate when you press the Auto-Recharge Button located in remote control or
located in main body. When the function operates, Mamirobot starts to search and approach the charging station. After connecting
machine with charging station, it will charge automatically.
2. During the cleaning, Mamirobot checks residual battery power. Before the battery runs out, the machine goes for recharging to the
charging station automatically. During the recharging, charging indication[Chr] is turned on at status display window.
Recharge Using Adapter (K3, K5, K7)
1.Recharge the battery when you see [LO] on display window. Place the
robot fully charged after cleaning.
2.Stop operating before charging.
3.After inserting adapter’s terminal into the charge point of main
body, plug the power cord in the power socket as shown in figure.
Charging starts with turning on indication LED[Charge] and charging
indication[Chr] at the status display window.
CHARGING
11
Before using Preparing Cleaning Guidance Zaaloo Product Information

1.Press dust bin cover release and pull to remove bin. You can
empty and clean dust bin easily.
2.For restraining the propagating of germs, clean dust bin with
a pH-neutral detergent and rinse it with water.
3.After drying dust bin at good ventilation, install it in main
body.
4.Remove dirty dust filter through separating upper filter com-
partment and under filter compartment as shown in picture.
Replace new dust filter as shown in picture.
5.Combine filter compartment with dust bin, and install it in
main body with closing dust bin cover until it “clicks” into
place.
※Do not attempt to run Mamirobot without dust filter.
Using without dust filter or using defective dust filter
causes failure due to dust inside the machine.
※Dust bin and dust filter is factory assembled.
※Dust filter should be replaced after 2 ~ 3 times used.
It depends on the amount of hair and dirt in your
cleaning. We recommend filter replacing after every
cleaning.
Empty Dust Bin and Replace Dust Filter
The longer pin(+) must be facing to
downward.
Place filter in place on the mark(+)
Place the cover in place
12
Before usingPreparingCleaningGuidanceZaalooProduct Information

Mop Installation
1.Place Mamirobot upside down on a flat floor (Use soft cloth to prevent dent or scratch).
2.Pull the attachment plate from its original location to the holder until it “clicks” into place as shown in Figure. If you misplace the
plate, cleaning efficiency and working time can be influenced by friction between machine and floor.
3.Attach the clean and moistened cloth to the plate as shown in Figure. Use only Microfiber Dust cloth offered from Mamirobot,
otherwise, working time can become shorter due to differences of area, thickness, and friction.
4.Before using with dust cloth, pick up objects like clothing, power cords for blinds or curtains, power cords, and any fragile objects.
5. Separate the attach plate to its original position when you use Mamirobot without dust cloth. If you do not return it exactly, foreign
substances may be caught in the gap.
6.If you want to use damp cloth cleaning without vacuum suction, press Damp Mop Cleaning Button on the remote control. After
selecting this mode, the machine works with only wheels and side brush.
7.Robot can cross threshold less than 0.5cm height when the mop is attached.
Maintenance Side Brush
Because the side brushes easily attract hair and other foreign substances, we recommend cleaning them frequently. Cleaning ef-
ficiency may decrease due to excessive foreign substances on the side brushes.
Remove the screw of the side brush turning in anticlockwise direction with (+) driver. Be careful when you remove the side brush.
Using (-) driver may be helpful. Remounting is carried out in reverse order.
13
Before using Preparing Cleaning Guidance Zaaloo Product Information

2. Hair Mode Cleaning (for dust, hair and pet’s hair)
Separate main brush and main brush cover by referring to previous chapter ‘Maintain Main Brush’, and install dust cleaning
cover.
Make sure to separate the main brush cover and main brush when you use Hair Mode. Do not use Hair Mode cover with
main brush is installed. It can cause serious failure.
Rotor Stator
Maintenance Main Brush
For maintaining of cleaning ability, check and clean the main brush regularly.
1.Separate the main brush cover by pressing the cover releaser as shown in Figure.
2.After lifting the stator part (black cube) up, separate the rotor part from the main
body. After Removing foreign substances, Reinstall the main brush and cover in
reverse order.
1. Normal Cleaning
Install main brush and main brush cover by referring to previous chapter ‘Maintain Main Brush’
Two Types of Cover and Brush
You can choose the type of covers for increasing efficiency of cleaning. For the normal cleaning, use main brush cover with main
brush. If there are dust, hair or pet’s hair in the area, you can use dust cleaning cover without mounting of main brush, and press
dust cleaning button on the remote control.
Make sure the cover is installed correct after installation to prevent floor dents and incorrect recharging station access
14
Before usingPreparingCleaningGuidanceZaalooProduct Information

Composition and Name of Display Panel
Status Display
Shows the selected cleaning time, scheduled time, error
codes and various messages.
Quiet Mode Indicator
Turns on when Low Noise Mode is selected by pressing
Low Noise Mode button on the remote control.
Charging Indicator
K5, K7. Press Auto Charge Button on the machine or on the
Remote Controller for Auto Charge. Turns on when Mami-
robot returns to the charging station to recharge and start
charging.
K3 Connect recharge adapter to the main machine then
Indicator lights on. Battery needs to be recharging when
the Indicator’s ‘Lo’ sign is on.
Cleaning Time Indicator
Turns on when the Cleaning Time Control Button on the
remote control or on the main body is pressed. Selected
cleaning time is displayed on Status Display.
Schedule Time Indicator (K5, K7)
Flashes when Scheduled Cleaning button on the remote
control is pressed. Selected scheduled time is displayed on
Status Display and the machine stands by until selected time
is passed. ( ‘after 2 hours’ ~ ‘after 12 hours’)
Auto Recharge Button (K5, K7)
When you press the Auto-Recharge Button located in main
body, Mamirobot stops its work and approaches the charg-
ing station. After connecting machine with charging station,
it will be charged automatically.
Main Power Button
When you press the Main Power Button, Mamirobot is
turned on and becomes standby status. If you press this
button again, the machine will operate. When you press
this button during the operating, it will stop its work. If you
press Main Power Button over 2 seconds during power-on
status, the machine is turned off.
Cleaning Time Control Button
Each time the Cleaning Time Control Button is pressed,
working time is selected as ‘30 min’, ‘60 min’, ‘continu-
ous’.
Light Sensor
Detects the intensity of radiation for preventing that Mami-
robot stops operating under bed, sofa or desk.
 Status Display Quiet Mode Indicator Charging Indicator
Cleaning Time Indicator Schedule Time Indicator Auto-Recharge Button
Main Power Button Cleaning Time Control Button Light Sensor
※K3 Customer also can use Auto Recharge and Schedule
Cleaning Time function just buying Recharge Station.
Please Visit to ‘usa.mamirobot.com’ for more informa-
tion.
LOW NOISE CLEANING
CHARGING SCHEDULE

 
  


15
Before using Preparing Cleaning Guidance Zaaloo Product Information

Remote Controller
1.Lift the battery cover at the back of the remote control, and install the batteries into the
remote control with the right polarity as shown in figure. Close it until it clicks into place.
2.For using remote control, press the main power button on the Mamirobot to stand by.
3.If the remote control does not work, check the batteries for wrong direction or make sure
the main machine’s status is stand-by. Sometimes the battery may be discharged due to its
distribution. In this case, try again with other batteries.
Start/Stop Button
This button is to start operating or stop
operating. This button can be used for
returning to initial state during operat-
ing.
Auto-Recharge Button
When this button is pressed, Mami-
robot stops its work and returns to
the charging station to recharge its
battery. If you press the other buttons
while it is returning to the charging
station, Mamirobot will operate those
selected functions by priority.
Quite Mode Button
When this button is pressed, voice
announcement is stopped and operat-
ing noise becomes smaller. However,
sound of alarm will be operated during
silent mode. When the machine stops
and restarts, the silent mode will be
canceled.
Operation/Pause Button
This button is to start operation and
pause operation. Also can stop direc-
tion command pressing this button.
Directional Button (▲,▼,◀,▶)
By using the directional button, you
can move Mamirobot to clean a prefer
location directly. These buttons func-
tion with Forwards, Left (move forward
after turn left 15°), Right (move for-
ward after turn right 15°)and Back-
wards (move forward after turn right
180°).
Cleaning Time Control Button
Each time the Cleaning Time Control
Button is pressed, working time is
selected as ‘30 min’, ‘60 min’, and
‘continuous’.
Schedule Cleaning Time Button
When this button is pressed, Time de-
lay is increased as ‘2 hours’,‘3 hours’,
‘4 hours’... up to ‘12 hours’. You can
also increase and decrease time de-
lay by pressing Directional Buttons
(▲,▼). Scheduled cleaning function
is only performed when Mamirobot is
docked with the charging station.
SSW Mode Button
SSW(Spider Spinning Web) is for the
perfect cleaning mode. It indicates the
size of the room and operates. Each
time this Button is pressed, cleaning
mode is selected as ‘SSW’, ‘Normal’.
Mop Cleaning Button
Select this function if you want to clean
with damp cloth without suction. Side
Brush works.
Turbo Mode Button
Select this function at particularly dirty
place and intensive.
Hair Mode Button
Use this mode for hair and pet’s hair
cleaning. Please separate main brush
and install proper cover for this mode.
Intensive Cleaning Button
Select this function for intensive clean-
ing around particularly dirty area.
Corner Cleaning Button
Select this function for intensive clean-
ing around the corner and the edge.

 

 



 




16
Before usingPreparingCleaningGuidanceZaalooProduct Information

Operating Mamirobot
1.Press the Main Power Button on the main body. Mamirobot is turned on and becomes standby status.
2.In stand-by status, Mamirobot start cleaning with pressing the Main Power Button or Start/Stop Button on the remote control.
Default cleaning time is 1 hour.
3.For changing the cleaning time, press Cleaning Time Control Button on the main body or on the remote control. Each time the
Cleaning Time Control Button is pressed, working time is selected as ‘Continuous’, ‘60 min’, ‘30 min’ as shown in Figure. After
selecting with preferred cleaning time, start cleaning by following the step 2.
4.When you press Auto-Recharge Button on main body or on the remote control, Mamirobot stops it’s work and returns to the
charging station to recharge its battery. (K5, K7)
5.When the residual battery power runs out, [doc] is shown in status display with beep. The machine goes for recharging to the
charging station automatically. (K5, K7)
6.Mamirobot will be turned off automatically by pressing the Main Power Button 2 seconds.
7.When no key is pressed in 2 minutes in stand-by status, Mamirobot is automatically turned off. (If Mamirobot is docked with
charging station, stand-by status will be held.)
8.If you will not use the machine for a long time, remove the battery from machine.
Reserve 60minutes when turn on
the power.
Long-lasting 30minutes Repeat pressing button
● ●● ●●●
or
CLEANING
17
Before using Preparing Cleaning Guidance Zaaloo Product Information

Regular Cleaning Mode
1.Mamirobot uses the six steps for cleaning the area.
① Random Moving → ② Spiraling → ③ Random Moving → ④ Wall Following → ⑤ Random Moving → ⑥ Grid Moving
→ Cleaning will be operated by repeating those 6 steps (each steps takes about 2 minutes
2.During cleaning, you can select Spiraling step or Wall Following step additionally. In this case, selected step will be operated around
2 min, and Mamirobot will continue working with next step.
(ex) Pressing 2 Spiraling button while operating in mode 4 it will operate about 2 minutes and continue to next mode 3,4,5 and 6
automatically.
①③⑤ Random Moving
Mamirobot goes straight until it
encounters walls or obstacles. It goes
forward again after selecting other
direction.
② Spiraling
Mamirobot moves with a spiral motion
to clean as shown in Figure.
④ Wall Following
Mamirobot approaches the wall as
close as possible, and follows the wall
to clean.
⑥ Grid Moving
Mamirobot moves as shown in Figure.
⑥ Grid Moving ⑤ Random Moving ④ Wall Following
SSW System Mode
With SSW(Spider Spinning Web, derived from the idea of spider’s
ecology who starts building its house after it surveys the dimension
of space and surroundings) system cleaning mode, Mamirobot measures the dimension
of space that needs to be cleaned at first and then cleans up compactly and neatly. This
cleaning mode will be operated by pressing [SSW] button on the remote control.
Step 1
Going round corners, it estimates
the layout, location and course of
space and prepares calculation
of total space
Step 2
It takes 3 min. to run free mode
where it calculates total number
of obstacles and also the size of
a room.
Step3
After determining the size of
circle according to the calculated
room size, it rotates toward
center drawing centric circles.
Step 4
It goes to the edge of calculated
room and gets ready for the last
5th stage, cleaning mode.
Step 5
It determines the size of circle
to fit into the room size and
proceeds cleaning with rotating
and drawing centric circles.
①Random Moving ③ Random Moving
② Spiraling
18
Before usingPreparingCleaningGuidanceZaalooProduct Information

Auto Recharge Function (K5, K7)
1.When you press Auto-Recharge Button on main body or on the remote control, Mamirobot stops it’s work and returns to the
charging station to recharge its battery.
2. During the cleaning, Mamirobot checks residual battery power. Before the residual battery power runs out, the machine goes for
recharging to the charging station automatically.
3.While Mamirobot moves to the charging station, [doc] is shown in status display window. During the recharging, charging
indication[Chr] is turned on at status display window. If you select scheduled cleaning at this situation, the time delay will be
shown in status display window.
4.When charging is complete, [FU] and [LL] will be displayed in the status display window.
5.If you press the other buttons while it is returning to the charging station or recharging, Mamirobot will operate those selected
functions by priority. However, if you have selected scheduled cleaning before, Mamirobot will deny other commends with an-
nouncement of scheduled cleaning. In this case, you can give the other command by cancelling of
scheduled cleaning function.
6.You can cancel the scheduled cleaning by pressing backwards Directional Button(▼) until [- - - ]
is shown in the status display window.
7.If you have selected scheduled time, Mamirobot stands by until selected time is passed at the
charging station.
8.Docking at the charging station can be failed by following reasons : full-discharged battery, trou-
ble with charging station, trapped by an obstacle or trouble with main body. In this case, [End] is
displayed in status display window, and it is turned out in 2 min.
※If you separate the robot while it is recharging, the scheduled time will be canceled and it will stand by for 2 minutes for turning off power.
※When you connect adapter to K5, K7, the scheduled time will be canceled automatically.
※You can place the robot manually for recharging battery. It will start recharge automatically.
Docking failure
Cancellation of the scheduled time
Seeking the charging station The battery is charging The battery is fully charged
CHARGING
19
Before using Preparing Cleaning Guidance Zaaloo Product Information

Voice Guidance
Mamirobot guides you with voice for more convenient using.
Hello, I am Mamirobot When power is turned on.
Start Charging When Mamirobot start recharging at the charging station or it is recharged by adapter.
Half an hour, One hour, Continue When Cleaning Time Control Button is pressed.
Charge the battery please When the battery voltage is low and when you press operation button in a low
battery.
Charging Completed When charging is completed.
Dust cloth cleaning on When Damp Mop Cleaning Button is pressed.
Check the wheels please When the wheel is not working properly with obstacles. When it runs under over
load conditions. When the wheel does not touch the floor or when the sensor is
failure.
Check the battery please When the battery and main body have a wrong connection.
Check the sensors please When the sensors have problem or when the bumper is pressed .
Check the brush please When some object is caught in the main brush.
I am programmed When scheduled cleaning is selected.
Cancelled When scheduled cleaning is cancelled.
Cleaning finished When the cleaning is completed.
Station Description
Remote Controller Holder
· Place the remote controller when it is not in use.
Recharge Holder for Hand Held Cleaner Zaaloo
· Place Zaaloo for recharging the battery.
Power and Recharging Indicator
· When it plugged by power supply, indicator is turned on with blue color.
·Indicator’s color turns to red while Zaaloo is charged.
Red light blinks when it is not connected properly.
· Blue light blinks when Zaaloo battery recharge is completed.
Recharge Controlled Approach Window
· It guides Mamirobot to the charging station by similar method as Ground
Controlled Approach of airplane.
Battery Recharge Connector
· It connects with cleaner for battery recharge.
20
Before usingPreparingCleaningGuidanceZaalooProduct Information
