M&C MP Series User manual

Analytical Diaphragm Pump Series MP®
MP30
Instruction Manual
Version 1.00.01

2 MP30 | 1.00.01 www.mc-techgroup.com
Dear customer,
we have made up this operating manual in such a way that all necessary information about the
product can be found and understood quickly and easily.
Should you still have any question, please do not hesitate to contact M&C directly or go through your
appointed dealer. Respective contact addresses are to be found in the annexe to this operating
manual.
Please also contact our homepage www.mc-techgroup.com for further information about our
products. There, you can read or download the data sheets and operating manuals of all M&C
products as well as further information in German, English and French.
This Operating Manual does not claim completeness and may
be subject to technical modifications.
© 04/2016 M&C TechGroup Germany GmbH. Reproduction of this
document or its content is not allowed without permission from M&C.
Version: 1.00.01

www.mc-techgroup.com MP30 | 1.00.01 3
Content
1General information.................................................................................................................. 4
2Declaration of conformity......................................................................................................... 4
3Safety instructions.................................................................................................................... 5
4Warranty.................................................................................................................................... 5
5Used terms and signal indications.......................................................................................... 6
6Introduction............................................................................................................................... 7
7Applications .............................................................................................................................. 7
7.1 Ambient conditions .............................................................................................................. 8
7.2 Safety.................................................................................................................................. 8
8Technical data........................................................................................................................... 9
9Dimensions ............................................................................................................................. 10
10 Receipt and storage................................................................................................................ 10
11 Installation information .......................................................................................................... 10
11.1 Mechanical ........................................................................................................................ 11
11.2 Electrical............................................................................................................................ 11
11.3 Pneumatic ......................................................................................................................... 12
12 Commissioning....................................................................................................................... 13
13 Decommissioning................................................................................................................... 14
14 Maintenance............................................................................................................................ 14
14.1 Replacing diaphragms, valve plates and sealing rings....................................................... 15
15 Cleaning................................................................................................................................... 16
16 Troubleshooting...................................................................................................................... 17
17 Spare parts.............................................................................................................................. 18
18 Appendix ................................................................................................................................. 18
List of illustrations
Figure 1 Delivery capacity MP30..................................................................................................7
Figure 2 Dimensions (mm) MP30...............................................................................................10
Figure 3 Section drawing of pump head MP30...........................................................................15

4 MP30 | 1.00.01 www.mc-techgroup.com
Head Office
M&C TechGroup Germany GmbH Rehhecke 79 40885 Ratingen Germany
Telephone: 02102 / 935 - 0
Fax: 02102 / 935 - 111
E - mail: [e-mail]
www.mc-techgroup.com
1 GENERAL INFORMATION
The product described in this operating manual has been examined before delivery and left our works
in perfect condition related to safety regulations. In order to keep this condition and to guarantee a
safe operation, it is important to heed the notes and prescriptions made in this operating manual.
Furthermore, attention must be paid to appropriate transportation, correct storage, as well as
professional installation and maintenance work.
All necessary information a skilled staff will need for appropriate use of this product are given in this
operating manual.
2 DECLARATION OF CONFORMITY
CE - Certification
The product described in this operating manual complies with the following EU directives:
EMV-Instruction
The requirements of the EU directive 2014/30/EU “Electromagnetic compatibility“ are met.
Low Voltage Directive
The requirement of the EU directive 2014/35/EU “Low Voltage Directive“ are met.
The compliance with this EU directive has been examined according to DIN EN 61010.
Declaration of conformity
The EU Declaration of conformity can be downloaded from the M&C homepage or directly requested
from M&C.

www.mc-techgroup.com MP30 | 1.00.01 5
3 SAFETY INSTRUCTIONS
Please take care of the following basic safety procedures when mounting, starting up or
operating this equipment:
Read this operating manual before starting up and use of the equipment. The information and
warnings given in this operating manual must be heeded.
Any work on electrical equipment is only to be carried out by trained specialists as per the regulations
currently in force.
Attention must be paid to the requirements of VDE 0100 (IEC 364) when setting high-power electrical
units with nominal voltages of up to 1000 V, together with the associated standards and stipulations.
Check the details on the type plate to ensure that the equipment is connected to the correct mains
voltage.
Protection against touching dangerously high electrical voltages:
Before opening the equipment, it must be switched off and hold no voltages. This also applies to any
external control circuits that are connected.
The device is only to be used within the permitted range of temperatures and pressures.
Check that the location is weather-protected. It should not be subject to either direct rain or moisture.
The pump must not be used in hazardous areas.
Installation, maintenance, monitoring and any repairs may only be done by authorized personnel with
respect to the relevant stipulations.
4 WARRANTY
If the equipment fails, please contact M&C directly or else go through your M&C authorised dealer.
We offer a one year warranty as of the day of delivery as per our normal terms and conditions of sale,
and assuming technically correct operation of the unit. Consumables are hereby excluded. The terms
of the warranty cover repair at the factory at no cost or the replacement at no cost of the equipment
free ex user location. Reshipments must be send in a sufficient and proper protective packaging.

6 MP30 | 1.00.01 www.mc-techgroup.com
5 USED TERMS AND SIGNAL INDICATIONS
DANGER!
This means that death, severe physical injuries and/or important
material damages will occur in case the respective safety
measures are not fulfilled.
WARNING !
This means that death, severe physical injuries and/or important
material damages may occur in case the respective safety
measures are not fulfilled.
CARE!
This means that minor physical injuries may occur in case the
respective safety measures are not fulfilled.
CARE!
Without the warning triangle means that a material damage may
occur in case the respective safety measures are not met.
ATTENTIO N!
This means that an unintentional situation or an unintentional status
may occur in case the respective note is not respected.
NOTE!
These are important information about the product or parts of the
operating manual which require user’s attention.
SKILLED STAFF
These are persons with necessary qualification who are familiar with
installation, use and maintenance of the product.

www.mc-techgroup.com MP30 | 1.00.01 7
6 INTRODUCTION
The MP30 diaphragm pump is suitable for 100% oil-free transport of corrosive gases. It has been
dimensioned and designed specifically for use in the analytical sector. The pump is gas-tight and
maintenance-free.
7 APPLICATIONS
The transported gas remains analytically pure due to the absolutely lubricant-free operating pump. A
special diaphragm and valve system ensures freedom from maintenance and a long useful life.
The pump is available for 230V or 115V mains voltage as well as with motor in an explosion-proof
design. The MP30 has a delivery capacity of 7.5l/min at atmospheric pressure. The output on the
pressure side is limited to maximum 2.5 bar absolute..
Application examples are:
Transport of gases and vapours with a temperature of +5°C... + 40°C
Maximum allowable working pressure, final vacuum and delivery capacity according to technical
data
Prior to use in unknown pumping media, the compatibility of the materials of the pump head,
diaphragm and valves with the medium must be verified.
Figure 1 Delivery capacity MP30
NOTE!
Diaphragm pumps of the MP30 type series are not suitable for transporting
liquids.
0
50
100
150
200
250
300
350
400
450
500
00,25 0,5 0,75 11,25 1,5 1,75 22,25 2,5
[bar abs.]
[Nl/hr]
[Nl/hr]
[Nl/hr] with constant
sucction pressure -0,2bar

8 MP30 | 1.00.01 www.mc-techgroup.com
7.1 AMBIENT CONDITIONS
The following ambient conditions must be maintained during operation:
Ambient temperature range in operation: +5°C .... + 40°C.
The pumps must be protected from water and dust.
Sufficient ventilation must be provided during operation.
The pump type MP30 must not be used in areas subject to explosion hazards or for transporting a
potentially explosive medium. The pumps have the degree of protection IP54 as standard.
7.2 SAFETY
The following must be observed concerning safety when using MP30 diaphragm pumps:
WARNING !
The pump must only be used for the intended purpose (see 7.).
The pumps must not be used in areas subject to explosion hazards
or for transporting a potentially explosive medium.
When transporting toxic media, system-specific and safety-relevant
regulations must be observed (MAC values).
The transported medium must be safely discharged.
When connecting other components to the pump, the pneumatic
conditions must be observed (see 8.).
When connecting the pump top the electrical system, the relevant
safety requirements must be observed.
The standard internal thermal safety cut-out protects the pump
against overload. The pump automatically restarts after cooling
down. Hazardous situations constituted by this must be prevented
by suitable measures.
The compatibility of the pump materials with the medium to be
transported must be verified prior to use of the pump and the
safety requirements for the media to be used observed.

www.mc-techgroup.com MP30 | 1.00.01 9
8 TECHNICAL DATA
Diaphragm pump
MP30 /230V
MP30 /115V
Part No.
02 P 1500
02 P 1500a
Voltage supply
230V 50Hz
10%
115V 60Hz
10%
Power input
70W
Power consumption
0,45A
0,7A
Degree of protection
IP 54 - DIN 40050
Delivery capacity max.
7.5 l/min*
Operating pressure
0.14 to max. 2.5 bar abs.
Gas temperature
+5°C to +40°C
Ambient temperature
+5°C to +40°C
Storage temperature
-15°C to +60°C
Gas connections
G1/8" i DIN ISO 228/1
Electrical equipment
standard
EN 61010, part 1
Medium contacted parts
Pump head
Diaphragms
Valves
PVDF, SS316Ti
CR, PTFE coated
FFPM
Weight
3,1kg
3,3kg
Material designations according to ISO 1629 and 1043.1
* Litre in standard condition

10 MP30 | 1.00.01 www.mc-techgroup.com
9 DIMENSIONS
The dimensions of the MP30 are shown below:
Figure 2 Dimensions (mm) MP30
10 RECEIPT AND STORAGE
Carefully remove the diaphragm pump and any accessories from the transport packaging
immediately upon receipt and check the delivery against the delivery note.
Check the contents for possible transport damage and immediately notify the transport insurer of
any damage.
NOTE!
The diaphragm pump should be stored in a protected, frost-free room.
11 INSTALLATION INFORMATION
The safety rules and regulations for the prevention of accidents must be observed during installation
and also subsequent operation. The information in Chapter 3‚ “Safety” must be observed.

www.mc-techgroup.com MP30 | 1.00.01 11
NOTE!
The safety requirements applicable to the respective media to be
transported must be observed.
In order to prevent a disturbing accumulation of heat, the pumps
should be installed away from sources of heat and freely
ventilated.
For installation outdoors, the pump must be installed in a
protective housing frost-free in winter and sufficiently ventilated in
summer. Direct exposure to sunlight must be avoided.
NOTE!
Pumps have mechanical moving parts that can induce vibrations.
To prevent damages at the pump or at peripheral components /
facilities as well as minimizing noise development an appropriate
vibration decoupling is necessary. For this M&C can deliver e.g.
anti-vibration pads.
This explicit is also valid for the connection of the sample lines at
the pump head.
11.1 MECHANICAL
The fixing dimensions are shown in Figures 2 and 3.
The pumps must be installed in such a way that the impeller is able to draw in sufficient cooling air.
The pumps should be installed at the highest point in the system and/or with the pump head
pointing downward to prevent an accumulation of condensate –this will extend the useful life of the
pump.
11.2 ELECTRICAL
Electrical installation must take place in compliance with the safety regulations. Before connecting the
pump, safe isolation from the supply must be ensured.
The protective conductor must be connected to the pump motor.
A device for disconnecting the pump from the electrical system must be provided in the electrical
installation (according to EN 60335-1).
The supply circuit should be provided with a fuse with a rating corresponding to the current
consumption (over-current protection, current consumption, see technical data).
WARNI NG!
The supply voltage must be compared with the voltage shown on
the rating plate. A voltage deviation of about 10% is admissible.
The pumps must be mounted so that contact with live parts (e.g.
electrical connection, possibly motor windings) is excluded.

12 MP30 | 1.00.01 www.mc-techgroup.com
11.3 PNEUMATIC
NOTE!
Components to be connected to the pump must conform to the pneumatic
data of the pump.
Remove safety stoppers from threaded gas connections (thread size G1/8”).
Accessories such as threaded hose couplings must be screwed into the threaded connection with
sealing tape (the use of sealing tape is unnecessary when using M&C couplings).
Connect suction and pressure pipe.
NOTE!
Do not interchange hose connections for sample gas inlet and outlet; the
connections are appropriately marked.
After connecting all pipes, they must be checked for tightness.
When connecting the hoses to optional threaded hose couplings, the following should be noted:
NOTE!
The tightness of the connection can only be ensured when the connecting
hose has a straight terminating edge (use of a hose cutter).
Loosen the swivel nut of the clamping ring by turning anticlockwise; it must be ensured that the nut
is carefully removed from the coupling, so that the clamping ring lying loosely in the clamping ring
is not lost.
Slide the swivel nut on to the connecting hose.
Slide the clamping ring with the thicker part pointing towards the nut on to the connecting hose.
Fit the hose on to the supporting nipple in the coupling;
Tighten the swivel nut hand-tight.
The hose is not connected non-slip and pressure-proof.
Optional threaded couplings for DN 4/6 or DN 6/8 can be obtained through M&C
Route the suction and pressure pipe so that no condensate can flow into the pump.

www.mc-techgroup.com MP30 | 1.00.01 13
12 COMMISSIONING
Prior to commissioning, system and process-specific safety measures must be observed.
For the media to be transported, the respective safety requirements and measures must be taken into
account.
Prior to using a medium, the compatibility of the materials of the pump head, diaphragm and valves
with the medium must be verified (for materials, see technical data).
The following steps must be carried out for commissioning:
The pumps must not start against pressure or vacuum. When the pump is switched on, the normal
atmospheric pressure must prevail in the pipes. This applies similarly during operation following a
brief interruption of power.
The maximum allowable working pressure (see technical data) must not be exceeded.
Restriction or regulation of the gas flow should only take place in the suction-sided pipe in order to
avoid exceeding the maximum allowable working pressure.
If restriction or regulation of the gas flow takes place on the pressure side, it must be ensured that
the maximum allowable working pressure of the pump is not exceeded.
With the pump stationary, normal atmospheric pressure must be established in the pipes.
Diaphragms and valve plates are the only wearing parts of the pumps. Wear is usually noticeable
by a considerable reduction in pneumatic power. Replacement must take place as described in
chapter 14ff.
Ambient conditions, see technical data.
For pumps used as vacuum pump and compressor:
Pressure and vacuum cannot be produced simultaneously.
WARNI NG!
The pumps must not be used in areas subject to explosion hazards
or for transporting a potentially explosive medium.
The transported medium must be safely discharged.
When connecting other components to the pump, the pneumatic
conditions must be observed (see 6.).
When connecting the pump to the electrical system, the relevant
safety requirements must be observed.
The standard internal thermal safety cut-out protects the pump
against overload. The pump automatically restarts after cooling
down. Hazardous situations constituted by this must be prevented
by suitable measures.
For the transport of aggressive or toxic media, the system-specific
safety requirements must be observed. Purging with air or inert
gas under atmospheric conditions is recommended prior to
decommissioning.

14 MP30 | 1.00.01 www.mc-techgroup.com
13 DECOMMISSIONING
NOTE!
The site of installation of the diaphragm pump must remain frost-
free also during the time when the unit is switched off.
No further particular measures are required for decommissioning.
WARNI NG!
When transporting aggressive media, purging the pump with inert
gas under atmospheric conditions is recommended prior to
decommissioning. If there is no risk of explosion, air can also be
used for this purpose.
Aggressive media residues possible. For disassembly, repair or
cleaning of the pump, safety goggles and suitable protective
clothing must be worn!
14 MAINTENANCE
Before carrying out maintenance work, the system and process-specific safety measures must be
observed!
WARNING
Dangerous voltage. Before working on the diaphragm pump, the
same must be safely isolated from the supply and disconnection
from the supply verified!
Aggressive or toxic media residues possible. For disassembly,
repair or cleaning of the pump, safety goggles and suitable
protective clothing must be worn. Wearing parts must be disposed
of in a proper manner!
Diaphragms and valve plates are the only wearing parts of the pumps and can be easily replaced.
NOTE!
It is recommended to replace valve plates, diaphragms and sealing
rings simultaneously to maintain the life expectancy of the pump.
For the maintenance or repair of the pump, the following tools are parts are required:
2 valve plates, 2 sealing rings and 1 diaphragm according to spare parts list.
Cross-tip screwdriver No.2.
Cross-tip screwdriver No.1.
Felt-tip pen.

www.mc-techgroup.com MP30 | 1.00.01 15
14.1 REPLACING DIAPHRAGMS, VALVE PLATES AND SEALING RINGS
Figure 4 shows a sectional drawing of the pump head.
1
2
3
4
5
6
7
8
9
10
11
15
Positioning
the cup
spring 11
Figure 3 Section drawing of pump head MP30
Replacing the diaphragm:
Mark position of pressure plate 15, head cover 4, intermediate plate 1and housing 14 by making a
continuous line with a felt-tip pen.
Loosen four head screws 5.
Remove pressure plate 15, head cover 4and intermediate plate 1from pump housing.
Loosen four fixing screws in impeller cover 13 and remove.
Bring diaphragm 8 into top position by turning impeller 12;
Unscrew diaphragm on side edges anticlockwise.
1 Intermediate plate
2 Valve plate
3 Sealing ring
4 Head cover
5 Screw
6 Screw cap
7 Screw
8 Diaphragm
9 Supporting cup
10 Adjusting washers
11 Cup spring
12 Impeller
13 Impeller cover
14 Housing
15 Pressure plate
M Mark
15
14
13
12
1
4
5
6
M

16 MP30 | 1.00.01 www.mc-techgroup.com
Remove support cup 9, adjusting washers 10 and cup spring 11 from thread bolt of diaphragm and
clean if necessary.
Fitting the new diaphragm takes place in reverse order.
NOTE!
The edge of the cup spring must point towards the diaphragm.
Replacing valve plates and sealing rings:
Loosen screws 7and separate head cover 4from intermediate plate 1.
Remove valve plates 2and sealing rings 3from intermediate plate.
Inspect valve seat, intermediate plate or ribbed cover for cleanliness and damage and replace if
necessary.
Fit new valve plates 2(suction and pressure side or top and bottom side are identical); check for
correct position by lightly moving the valve seat.
Fit sealing rings 3in intermediate plate 1.
Join head cover 4and intermediate plate 1together (felt-tip pen mark must be in alignment) and
check centred seat through lateral movement.
Fix head cover 4and intermediate plate 1in place with screws 7.
Fitting pump head:
Place intermediate plate 1and head cover 4according to felt-tip pen mark Mon pump housing.
Also place pressure plate 15 in position (mark) and lightly tighten crosswise with screws 5and cup
springs.
Check pump for smooth operation by turning impeller 12.
Tighten screws 5crosswise until cup springs rest flat against pressure plate.
15 CLEANING
When replacing the valve plates and diaphragms, all parts must be checked for fouling before
assembling the valve head and cleaned if necessary. If available, the parts should carefully be blown
out with compressed air.

www.mc-techgroup.com MP30 | 1.00.01 17
16 TROUBLESHOOTING
Before carrying out any work on the pump, it must be safely isolated from the supply and
disconnection from the supply verified. The following instructions for troubleshooting are hierarchically
structured, i.e. to be used in the specified order.
Problem/Indication
Possible cause
Check/Remedy
Pump does not
transport
No system voltage available.
Check system voltage. Check mains cable for
tightness.
Connections or pipes are
blocked.
Clear blockage.
An external valve is closed
or a filter is clogged.
Open valve or clean fouled/clogged filter.
Liquid (condensate) has
collected in the pump head.
Purge pump with inert gas for several minutes.
If there is no risk of explosion, air can also be
used for this purpose. Install pump at the
highest point in the system.
MP30:
Thermal safety cut-out has
operated due to overheating.
Disconnect pump from the supply, allow to cool
down and remedy cause of overheating.
Delivery capacity,
pressure or vacuum
too low
Diaphragms or valve plates
worn.
Replace worn parts (see 14. ff).
Problem/Indication
Possible cause
Check/Remedy
Initially compare reached
pump capacity with technical
data in chapter 1.2 or data
sheet.
Pump is not designed for this condition.
Liquid (condensate) has
collected in the pump head.
Purge pump with inert gas for several minutes.
If there is no risk of explosion, air can also be
used for this purpose. Install pump at the
highest point in the system.
Excess pressure is present
on the pressure side and on
the suction side
simultaneously a vacuum or
pressure above atmospheric
pressure.
Pump is not designed for this condition.
Pneumatic lines or
connecting parts have an
insufficient cross-section or
are restricted.
To measure capacity values, decouple pump
from the system; a pipe with insufficient cross-
section or, e.g. a valve installed in the system
can alter the measured value considerably.
Leaks at connections, pipes
or pump head.
Diaphragms or valve plates
are faulty or head parts are
fouled.
Steam leaks.
Tighten screwed connections.
Replace faulty parts.
Clean fouled parts or replace.

18 MP30 | 1.00.01 www.mc-techgroup.com
NOTE!
If none of the specified faults can be located, despite the pump not
operating correctly, the pump should be returned to M&C for examination.
When sending diaphragm pumps for repair to M&C Customer Service,
information about the transported medium is required.
Our workshop should be informed in particular about aggressive media.
Where pumps have been used for transporting dangerous or highly
aggressive gases, these should be cleaned prior to being returned.
17 SPARE PARTS
Wear, tear and replacement part requirements depend on specific operating conditions.
The recommended quantities are based on experience and are not binding.
Diaphragm Pump
Type MP30
(C) consumable parts, (S) spare parts
Recommended quantity
MP30 being in operation
(f.d. = for demand)
V/E/T
1
2
3
90P1500
Diaphragm 8
C
1
2
3
90P1510
Set sealing ring 3 (2 pc., Kalrez®)
C
1
2
3
90P1505
Set valve plate 2(2 pc.)
C
2
4
6
PVDF male connectors with G-thread (ISO 1010031)
05V1045
Straight connector
DN 4/6-G1/8” material: PVDF
S
-
-
2
05V1050
Straight connector
DN 6/8-G1/8” material: PVDF
S
-
-
2
05V6600
Ferrule DN 4/6 PVDF
S
2
2
4
05V6602
Ferrule DN 6/8 PVDF
S
2
2
4
05V6605
Union nut DN 4/6 PVDF
S
2
2
4
05V6607
Union nut DN 6/8 PVDF
S
2
2
4
18 APPENDIX
More product documentation is available on our Internet catalogue:
www.mc-techgroup.com
