Manhattan HD071A User manual

1
© 2009 Imägo Metrics LLC for Manhattan LCD Inc. - All Rights Reserved
HD071A&HD089B
UserManual
Updated6/15/2010fornewfirmware
Contents
Page 1---------- Contents
Page 2---------- Features & Specifications
Page 3---------- HD071A Monitor Schematic
Page 4---------- HD089B Monitor Schematic
Page 5---------- Remote Control
Page 6-7------- Basic Monitor Adjustments
Page 8---------- Advanced Monitor Adjustments
Page 9---------- Sun Hood
Page 10-------- Power Options
Page 11-------- Warranty




2
© 2009 Imägo Metrics LLC for Manhattan LCD Inc. - All Rights Reserved
HD071AKeyFeatures:
7.1LCDisrealHD(576pnative)
NTSC&PALCompatible
2standard1/4x20mountsTop&Bottom
Case:0.125"thickBlackABSPolymer‐MatteFinish
CaseDimensions:7.9"Wide,5.5"High,1.6"Deep
Weight:Approx1.5LBS
HD071ASpecifications:
ScreenSize:7.1”Diagonal
ScreenArchitecture:WXGA(1024X600Pixels)
ContrastRatio:300:1
Brightness:300nits
HDCP:YES
CompatibleFrameRates24,50,60
HDMI:2Inputs,Supports1080p,1080i,720p,576p,576i,480p,480i
VGA:1Input.SupportForFollowingImageResolutions:
640x480/800x600/1024x768/1280x720/1280x768/1280x1024/1366x768/1920x1080
Component:1Input,Supports1080p,1080i,720p,576p,576i,480p,480i
Composite(VideoOnly):1Input480p,480i
Power:12vDC
PowerConsumption:<20Watts

HD089BKeyFeatures:
8.9LCDisrealHD(576pnative)
NTSC&PALCompatible
2standard1/4x20mountsTop&Bottom
Case:0.125"thickBlackABSPolymer‐MatteFinish
CaseDimensions:9.6"Wide,6.4"High,1.6"Deep
Weight:Approx1.8LBS
HD089BSpecifications:
ScreenSize:8.9”Diagonal
ScreenArchitecture:WXGA(1024X600Pixels)
ContrastRatio:500:1
Brightness:300nits
HDCP:YES
CompatibleFrameRates24,50,60
HDMI:1Input,Supports1080p,1080i,720p,576p,576i,480p,480i
VGA:1Input.SupportForFollowingImageResolutions:
640x480/800x600/1024x768/1280x720/1280x768/1280x1024/1366x768/1920x1080
Component:1Input,Supports1080p,1080i,720p,576p,576i,480p,480i
Composite(VideoOnly):1Input480p,480i
Power:12vDC
PowerConsumption:<20Watts

3
© 2009 Imägo Metrics LLC for Manhattan LCD Inc. - All Rights Reserved

4
© 2009 Imägo Metrics LLC for Manhattan LCD Inc. - All Rights Reserved

5
© 2009 Imägo Metrics LLC for Manhattan LCD Inc. - All Rights Reserved

Theremoterequires2AAAbatteries(notincluded)

SectionshighlightedinBlueharenotavailablewithnewcodeasof4/1/2010.
SectionsHighlightedinRedarenewfeaturesadded4/1/2010.










6
© 2009 Imägo Metrics LLC for Manhattan LCD Inc. - All Rights Reserved
Section: Basic Monitor Adjustments
PoweringontheMonitor:
Insert12Vregulatedpowersourceviaconnectorintothe12VDCsocket.AREDLEDwillindicate
powerisreachingthemonitor.IfREDLEDfailstolight,troubleshootthepoweradapterorbattery.
ThescreenwillbeBLACKuntilyoupressthePOWERbuttononthemonitorortheremote.Whenthe
monitorispoweredontheLEDstatusindicatorshouldbegreenandthemonitorwilldisplaythe
ManhattanLCDlogofor1secondandthenswitchtoasolidbluescreen.(Maydisplayablackscreen
oncertainfirmwarerevisions)

SelectinganInput:
UsingtheControlconsolelocatedontheleft
sideofthemonitorpresstheINPUTbutton.
Usethe^vbuttonslocatedjustunderthe
POWERbuttonandscrolltotheappropriate
input.PresstheINPUTbuttontoselectand
activatetheinput.

UsingtheremotecontrolunitwithtwoAAA
batteriesinstalled,pointtheremoteattheMonitorConsole’sIR
port(beneathLEDindicator)andpresstheSourceButtonusethe
Up&Downarrowstoscrolltotheappropriateinputandthe
enterkeytoselecttheinput.

Navigatingthemenusystem:
***NOTE***youmustbeonaninputthatisreceivingavideo
signaltomakeanychangestoanyoptions.

UsingtheControlconsolelocatedontheleftsideofthemonitorpresstheMenubutton.Toscroll
betweenPicture,Img.Adj,&Setuptabsusethe><buttonslocatedabovetheMENUkey.
Usethe^vbuttonslocatedjustunderthePOWERbuttontoscrollwithinamenutab.Toadjusta
specificfieldusethe><buttonslocatedabovetheMENUkeytoapplyyourchangesandgoupalevel
presstheMENUbuttonagaintosaveyourchangesandgoupalevelandMENUbuttononcemoreto
exitthemenu.

UsingtheI/RremotecontrolunitwithtwoAAAbatteriesinstalled,pointtheremoteattheMonitor
Console’sIRport(beneathLEDindicator)andpresstheMENUButtonusetheup&downarrowsto
scrolltotheappropriateinputandtheenterkeytoselecttheinput.ToscrollbetweenPicture,
Img.Adj,&SetuptabsusetheLeft&RightarrowbuttonslocatedundertheMENUkey.UsetheUp&
DownarrowbuttonslocatedjustundertheMenubuttontoscrollwithinamenutab.Toadjusta
specificfieldusetheLeft&RightarrowbuttonslocatedbelowtheMENUkeytomakechangestoa
certainfield.PresstheMENUbuttonagaintosaveyourchangesandgoupalevelUsetheUParrow
togetbacktothemenutabsandMENUbuttononcemoretoexitthemenu.



7
© 2009 Imägo Metrics LLC for Manhattan LCD Inc. - All Rights Reserved
Thesemonitorsareequippedwith5inputsVGA,Component,Composite,and2HDMIports.The
HD089BmodelhasasecondHDMIportwhichisonlyaccessiblefrominsidethemonitorthereisno
externalconnector.Eachinputhasitsownsetofmenuitemsandarestoredseparatelyfromeach
otheradjustinganinputwillhavenoeffectonanother.

PictureTab:
TheadjustmentsyoucanmakeinthePictureTabofthemenusystemare:
Brightness:Adjuststheamountofwhiteinthepicture.
Contrast:Adjuststhecontrastbetweenthecolors.
Phase:ModifiestheClock/Phaseoftheinput.
Frequency:Changesthefrequencyatwhichthepanelisrunning(VGAonly).
Sharpness:Adjuststhesharpnessfilterallowingyoutogoforasharplookorsmoothlook.
Color:AllowsyoutoadjusttheColorSaturationlevel.
Tint:AllowsyoutoadjusttheHueoftheimage.
ColorTemp:AllowsyoutoadjusttheRed,GreenandBluechannelgainsindividually.

ThePictureTaboptionsforeachinputare:
VGA:Brightness,Contrast,Phase,Frequency,Sharpness,&ColorTemp
Composite:Brightness,Contrast,Sharpness,Color,Tint&ColorTemp
HDMI1&2:Brightness,Contrast,Sharpness,Colortemp.
Component:Brightness,Contrast,Phase,Sharpness,Color,Tint&ColorTemp

Img.AdjTab:
TheimageAdjusttabwillallowtheusertoadjusttheimagespositionandaspectratioonthe
monitor.
Imagesize:Adjustsaspectratio.AUTO,1:1,FillAspect,4:3,16:10,15:9,16:9,1.85:1,2.35:1&FillAll
Hposition:Horizontalpositionofthepicture
Vposition:Verticalpositionofthepicture
Auto:Autocentersthepositionthepictureonthescreen.
FreezeFrame:Freezesaspecificimageonthescreen

TheImg.AdjTaboptionsforeachinputare:
VGA:ImageSizeH.Position,V.Position,AUTO
Composite:ImageSize,H.Position,V.Position,Freeze
Frame
HDMI1&2:ImageSize,FreezeFrame
Component:ImageSizeH.Position,V.Position,AUTO,FreezeFrame

SetupTab:
ThesetuptaballowstheusertocustomizeOSDsettingsaswellastheHDMIColorSpace
OSDSettings:

Transparency:SetshowvisiblethebackgroundoftheOSDmenusystem
OSDTimeout:setsthelengthoftimefortheOSDtobedisplayedafterthelastkeystroke.
HDMIVideoColorspace:ChangesthecolorspacefortheHDMIinput(HDMIONLY)

8
© 2009 Imägo Metrics LLC for Manhattan LCD Inc. - All Rights Reserved

Section:AdvancedMonitorAdjustments

Fromthispointyoucanadjustmanythingsincludingcalibrationtablegreyscalecorrection,2D
peakingfilter3Dgammatable,Sensitivitytodifferentfilmmodessuchas2:23:2pulldownNoise
filters,gammatables&horizontaldeblocking.

***NOTE***IfyouareNotSurewhatasettingdoesdonotmesswithityoumayscrewupthe
monitor.

QuickAccessMenu:
NowthatthePWx90menuisvisableyoucanUsetheQuickMenubypressingtheredbuttononthe
bottomrowofbuttonsontheremote.Oncepressedyouwillgetasinglelinemenusysteminthe
lowerrightcornerofthescreen.
Seepicture.Tonavigatethismenu
usetheUp&Downarrowstoscroll
throughthemenuandtheLeft
arrowtoselectafieldorsub‐menu
usetheRECALLbuttonunderthe
number9togoupalevel.
QuickAccessMenuOptions:

RootMenu:Brightness,Contrast,Sharpness&Imagesize.

PictureMenu:ColorSaturation,Tint(Hue),HPositionADC,VPositionADC,7.5IRESetup,Phase,
GammaSelect&HorizontalDe‐blocking.

TweakingMenu:Thissub‐menuwillallowyoutochangeanyofthefollowingoptions.
ShowMotionLevel,ManualXC/XL,VEHCONTROL,SyncMonitor,HFilter,VFilter,Cuec/ICP,FRMEC,
FilmMode3:2,SPNoise,LumaNoise,ChromaNoise,UV5Blue,UV5Green,UV5Fleshtone,UV5Red,
UV5Yellow,DLTIGain,DCTIGain,DLTIFrequency,DCTIFrequency,CoringLevel,PeakingGain,LAI,
GammaSelect,HorizontalDe‐blocking&IndicateFilmMode.

BWEMenu:BWEEnable,BWGain,BWOffset,BWEMidGain,BWeMidOffset,BWETime.

2DPeakingMenu:Peakingfiltersincreasethegainforhigherfrequencies,resultinginsteeper
transitionsandhigherlocalcontrast.2DPeakingfilteroptionsHighPass,LowPass,BandPass,Un‐
sharp,2DPeakingGain,2DPeakLimiting,2DPeakCoring.

3dCtrlMenu:Modifiesadvanced3dcolormappingtechnology.3DCombsettingsHW3D,SW
Adaptive3D,Off,3DSpeedfasttoslow,

3dAdvCtrlMenu:Adjuststhe3DCombnoisefilters.MinNoise3DAdaptive3DLMMin.Noise,
Adaptive3DMMMin.Noise,Adaptive3DHMMin.Noise.

9
© 2009 Imägo Metrics LLC for Manhattan LCD Inc. - All Rights Reserved

Section:Sun‐HoodInstallation

Thereare8treadedholesonthemonitor2oneachsidethesunhoodisa2piecedesign1piecefits
onthetopthesecondonthebottomtheyaremadetofitoneitherside.Thesunhoodmountstothe
monitorwithsuppliedthumbscrewsin2easysteps.

1.Threadinthethumbscrewsabouthalfway
2.ThenslidethegrovesinthesunhoodaroundtheshaftofthethumbscrewsandSnugthe
thumbscrews.(Donotovertightenoryoumaystripthethumbscrews)



\









10
© 2009 Imägo Metrics LLC for Manhattan LCD Inc. - All Rights Reserved


OurHD071A&HD089Bmodelmonitorsmayuseany12Vregulatedpowersource.Allmonitorsship
withasupplied12VregulatedACadapter.Theinputconnectorisastandard2.1x5.5mmbarrel
connectorthecenterpinbeing+positiveoutershellis‐negative.Youmayuseanypowersourceas
longasitisregulated.Ifthepolarityisreverseditwillvoidyourwarranty,ifyouoverpowerthe
monitorwithahighervoltagethan12.5voltsitwill
blowafuseandvoidthewarranty.Wecurrentlyoffer
optionalbatterypackswithVelcrostripsformounting
&batteryplatesforPanasonicCannon&SonyBatteries
thatincludeabuiltinpowerregulatortoensureproper
operation.TheBatteryplatesaremountedtothe
monitoratthefactoryandaremountedinasideways
positiontoallowthemonitortobeflippedupside‐
downoncameraswith35mmlensadapters.Notethe
greenstatusindicatoritwillturnonwhenthebatteryis
chargedandflashwhenthebatteryislow.Thepower
wireconnectstothe12Vdcjackwhenthemonitoris
beingpoweredbytheplate.


11
© 2009 Imägo Metrics LLC for Manhattan LCD Inc. - All Rights Reserved
Section:WarrantyStatement

Warranty:
ManhattanLCDmonitorsareunderwarranteeandareguaranteedtobefreefrommanufacturing
defectsforaperiodof12Monthsfromthedateofpurchasetotheoriginalownerunlessotherwise
specified.

Disclaimers:
ManhattanLCDShallbeindemnifiedandheldharmlessforanyandallinjuryordeathresultingfrom
theimproperuseoftheirproducts.Warrantyisnullandvoidifthereisanyevidenceoftampering,or
abuseorifthecasehasbeenopenedormodifiedinanywayunlessotherwisespecified.

Claims:
ClaimsfordamagesmustbeprecededbyaReturnMerchandiseAuthorization(RMA).RMA’smaybe
requesteddirectlyfromthemanufacturerorauthorizeddistributors.ManhattanLCDreservesthe
righttorefusetorepairorreplaceanymonitorthatitdeemsisinneedofrepairduetocustomer
negligenceordamagewascausedbyuseotherthanthenormalintendedpurposeoftheproduct.

Contact:
ManhattanLCD
HighDefinitionMonitors

ContactInfo:
JohnReed‐Sales/Engineering,[email protected]
Tel:407‐247‐8338

VincentFalcone‐TechSupport/Shipping,[email protected]
Tel:407‐443‐5235

Sales[email protected]
Support[email protected]

Address:
ManhattanLCD
3328SpottedFawnDr
OrlandoFL32817
USA
