Manutti Zendo Sense User manual

Coffee tables
instruction manual

Index
Intro 3
Assembly notice 4
Necessary packaging & hardware 5
Packaging Zendo Sense coffee table 96×96 5
Packaging Zendo Sense coffee table 150×80 6
Hardware 7
How to assemble a Zendo Sense coffee table base 25h & 35h 8
Pats 8
Assembly of Zendo Sense coffee table base 25h & 35h 8
How to assemble a Zendo Sense coffee table 25h & 35h 10
with teak tabletop (96x96 & 150x80)
Pats 10
Assembly of Zendo Sense coffee table 25h & 35h : teak top 10
How to assemble a Zendo Sense coffee table 25h & 35h 12
with ceramic tabletop (96x96 & 150x80)
Pats 12
Assembly of Zendo Sense coffee table 25h & 35h : ceramic top 12
Maintenance & Safety 21

instruction manual - Zendo Sense : Coffee tables |3
Zendo Sense.-designed by Stephane De Winter
A sleek frame, sophisticated upholstery fabrics, exceptional seating comfot and endless
combination possibilities are only a few features of Zendo Sense, a new take on a timeless
Manutti icon. Carefully selected materials are crafted into durable, weatherproof pieces
that emanate luxury and show no distinction between interior and exterior design. Offering
modular and freestanding sofas, club sofas, daybeds and coffee tables, the versatility of
Zendo Sense makes it the perfect fit for settings of all shapes and sizes : from intimate urban
balconies to lavish terraces with infinite views.

WARNING:
2 people needed to assemble the Zendo Sense coffee tables
WARNING:
To avoid any damage to the furniture, always put a blanket
underneath before stating the assembly
Assembly notice
For Zendo Sense coffee tables

instruction manual - Zendo Sense : Coffee tables |5
Necessary packaging & hardware
Packaging Zendo Sense coffee table 96×96
To assemble Zendo Sense coffee table 96×96 - 25h or 35h, you will need :
BOX 1  ZENDO SENSE LEGS
BOX 2  ZENDO SENSE PROFILES
BOX 3  ZENDO SENSE TABLE TOP  CERAMIC OR TEAK
=
=
=
+
4x legs
4x profiles
1x ceramic tabletop 96×96 or teak tabletop 96×96
hardware
included

6|instruction manual - Zendo Sense : Coffee tables
Packaging Zendo Sense coffee table 150×80
To assemble Zendo Sense coffee table 150×80 - 25h or 35h, you will need :
BOX 1  ZENDO SENSE LEGS
BOX 2  ZENDO SENSE PROFILES
BOX 3  ZENDO SENSE TABLE TOP  CERAMIC OR TEAK
=+
+
4x legs hardware
included
=
2x long profiles 2x shot profiles
=
1x ceramic tabletop 150×80 or teak tabletop 150×80

instruction manual - Zendo Sense : Coffee tables |7
Hardware
Each box of Zendo Sense legs will include one bag of hardware. Depending on which coffee
table you are building, you may have extra hardware.
Every hardware bag includes :
8x use for
all coffee tables
1x use for
all coffee tables
18x use only for
ceramic table tops
6x use only for
ceramic table tops
18x use only for
teak table tops
5

8|instruction manual - Zendo Sense : Coffee tables
How to assemble a Zendo Sense coffee table base 25h & 35h
Pats
Assembly of Zendo Sense coffee table base 25h & 35h
5
Lay out all the pats of your base on a soft surface like a blanket or a carpet
1
8x bolt M8×15 1x hex key 5 4x legs 4x profiles

instruction manual - Zendo Sense : Coffee tables |9
Attach the legs and the profiles using the bolts and the hex key.
2
8x bolt M8×15 1x hex key 5
Go to page 12 for futher instructions on ceramic table top
Go to page 10 for futher instructions on teak table top
5

10 |instruction manual - Zendo Sense : Coffee tables
How to assemble a Zendo Sense coffee table 25h & 35h
with a teak tabletop (96x96 & 150x80)
Pats
Assembly of Zendo Sense coffee table 25h & 35h : teak top
Before installing put the tabletop upside down on a soft surface like a blanket or
a carpet! Install the screws with a screwdriver.
1
1x teak tabletop
96×96 or 150×80
1x Zendo Sense base
according to page 8
18x screw 4×50
screw 4×50
(for teak table
top 150×80)
screw 4×50
(for teak table
top 96×96)
18x16x

instruction manual - Zendo Sense : Coffee tables |11
Turn around the table with 2 people and place it where you like.
2
Adjust the feetcaps by turning them to ensure the table is level and will not rock.
3
max.
7 mm

12 |instruction manual - Zendo Sense : Coffee tables
How to assemble a Zendo Sense coffee table 25h & 35h
with a ceramic tabletop (96x96 & 150x80)
Pats
Assembly of Zendo Sense coffee table 25h & 35h : ceramic top
First install the adhesive bumpers on the profiles like shown beneath.
1
1x ceramic tabletop
96×96 or 150×80
1x Zendo Sense base 6x clamping
knob M6X50
18x bumpers
bumpers
(for ceramic table
top 150×80)
top view base with bumpers
bumpers
(for ceramic table
top 96×96)
18x16x

instruction manual - Zendo Sense : Coffee tables |13
Before installing put the tabletop upside down on a soft surface like a blanket or a
carpet! Place the base of the coffee table on top of the tabletop so that the outer
edge of the base is about 2mm from the outer edge of the table
2
Install the clamping knobs on the side as shown below.
IMPORTANT Do not over tighten the clamping knobs! There should be some space
between the frame and the table top.
3
clamping knob
M6×50
6x

14 |instruction manual - Zendo Sense : Coffee tables
Turn around the table with 2 people and place it where you like.
Adjust the feetcaps by turning them to ensure the coffe table is level and will not
rock.
4
5
max.
7 mm

instruction manual - Zendo Sense : Coffee tables |15
WARNING:
Do not use a high pressure cleaner to clean your furniture.
This may damage your furniture.
Maintenance
Safety
Each Manutti creation has been manufactured with close attention to the smallest detail. We
carefully select the best raw materials and finishings for your outdoor furniture, enabling it
to withstand the most capricious weather conditions. To maintain and protect your Manutti
pieces, we’ve developed a series of products that will guarantee their extended lifespan and
your carefree enjoyment for many years to come.
Go to Manutti.com/maintenance for more information.
For Zendo Sense coffee tables
WARNING:
Do not step or stand on coffee tables.
WARNING:
Do not sit or lean on coffee tables.
WARNING:
Maximum weight capacity 15kg.
MAX
15
kg

Need more assistance?
Contact the Manutti customer service anytime and
get all your questions answered at suppo[e-mail]
